Foreword
FOREWORD
This handbook contains information on the Triumph Daytona 675, Daytona 675 R, Street Triple
and Street Triple R motorcycles. Always store this owner's handbook with the motorcycle and
refer to it for information whenever necessary.
Warnings, Cautions and
Notes
Throughout this owner's handbook
particularly important information is
presented in the following form:
Note:
• This note symbol indicates points
of particular interest for more
efficient and convenient operation.
cdks_1
Warning
This warning symbol identifies special
instructions or procedures, which if not
correctly followed could result in personal
injury, or loss of life.
Caution
This caution symbol identifies special
instructions or procedures, which, if not
strictly observed, could result in damage to,
or destruction of, equipment.

2
Foreword
Warning Labels
At certain areas of the
motorcycle, the symbol (left)
can be seen. The symbol
means 'CAUTION: REFER TO
THE HANDBOOK' and will
be followed by a pictorial
representation of the subject
concerned.
Never attempt to ride the motorcycle or
make any adjustments without reference to
the relevant instructions contained in this
handbook.
See page 12 for the location of all labels
bearing this symbol. Where necessary, this
symbol will also appear on the pages
containing the relevant information.
Maintenance
To ensure a long, safe and trouble free life for
your motorcycle, maintenance should only be
carried out by an authorized Triumph dealer.
Only an authorized Triumph dealer will have
the necessary knowledge, equipment and
skills to maintain your Triumph motorcycle
correctly.
To locate your nearest Triumph dealer, visit
the Triumph web-site at www.triumph.co.uk
or telephone Triumph Motorcycles America
Limited on [phone].
Noise Control System
Tampering with the Noise Control System is
Prohibited.
Owners are warned that the law may
prohibit:
• The removal or rendering
inoperative by any person other than
for purposes of maintenance, repair
or replacement, of any device or
element of design incorporated into
any new vehicle for the purpose of
noise control prior to its sale or
delivery to the ultimate purchaser or
while it is in use and,
• the use of the vehicle after such
device or element of design has
been removed or rendered
inoperative by any person.
Talk to Triumph
Our relationship with you does not end with
the purchase of your Triumph. Your feedback
on the buying and ownership experience is
very important in helping us develop our
products and services for you. Please help us
by ensuring your dealership has your E-mail
address and registers this with us. You will
then receive an online customer satisfaction
survey invitation to your E-mail address
where you can give us this feedback.
Your Triumph Team.

3
Foreword
Owner's Handbook
Thank you for choosing a Triumph
motorcycle. This motorcycle is the product of
Triumph's use of proven engineering,
exhaustive testing, and continuous striving for
superior reliability, safety and performance.
Please read this owner's handbook before
riding in order to become thoroughly familiar
with the correct operation of your
motorcycle's controls, its features, capabilities
and limitations.
This handbook includes safe riding tips, but
does not contain all the techniques and skills
necessary to ride a motorcycle safely.
Triumph strongly recommends that all riders
undertake a safety course approved by the
Motorcycle Safety Foundation to ensure safe
operation of this motorcycle. Information
about the nearest Motorcycle Safety
Foundation course to you can be obtained by
calling the following nationwide toll free
number: 800-447-4700, or by writing to the
Motorcycle Safety Foundation at:
2, Jenner Street, Irvine, California 92718.
This handbook is also available from your
local dealer in:
•Dutch;
• French;
•German;
• Italian;
• Japanese;
•Spanish;
•Swedish.
Warning
This owner's handbook, and all other
instructions that are supplied with your
motorcycle, should be considered a
permanent part of your motorcycle and
should remain with it even if your
motorcycle is subsequently sold.
All riders must read this owner's handbook
and all other instructions which are
supplied with your motorcycle, before
riding, in order to become thoroughly
familiar with the correct operation of your
motorcycle's controls, its features,
capabilities and limitations. Do not lend
your motorcycle to others as riding when
not familiar with your motorcycle's
controls, features, capabilities and
limitations can lead to an accident.

Foreword
4
Table of Contents
This handbook contains a number of different sections. The table of contents below will help
you find the beginning of each section where, in the case of the major sections, a further table
of contents will help you find the specific subject required.
Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Warning Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Parts Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Serial Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
How to Ride the Motorcycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Accessories, Loading and Passengers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Maintenance and Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 5

5
Foreword - Safety First
FOREWORD - SAFETY FIRST
The Motorcycle Fuel and Exhaust Fumes
Warning
This motorcycle is designed for on-road
use only. It is not suitable for off-road use.
Off-road operation could lead to loss of
control of the motorcycle resulting in an
accident causing injury or loss of life.
Warning
This motorcycle is not designed to tow a
trailer or be fitted with a sidecar. Fitting a
sidecar and/or a trailer may result in loss of
control and an accident.
Warning
This motorcycle is designed for use as a
two-wheeled vehicle capable of carrying a
rider on his/her own, or a rider and one
passenger (subject to a passenger seat
being fitted).
The total weight of the rider, and any
passenger, accessories and luggage must
not exceed the maximum load limit of
429 lbs (195 kg).
Warning
GASOLINE IS HIGHLY FLAMMABLE:
Always turn off the engine when refuelling.
Do not refuel or open the fuel filler cap
while smoking or in the vicinity of any
open (naked) flame.
Take care not to spill any gasoline on the
engine, exhaust pipes or mufflers when
refuelling.
If gasoline is swallowed, inhaled or allowed
to get into the eyes, seek immediate
medical attention.
Spillage on the skin should be immediately
washed off with soap and water and
clothing contaminated with gasoline
should immediately be removed.
Burns and other serious skin conditions
may result from contact with gasoline.
Warning
Never start your engine or let it run for any
length of time in a closed area. The
exhaust fumes are poisonous and may
cause loss of consciousness and death
within a short time. Always operate your
motorcycle in the open-air or in an area
with adequate ventilation.

6
Foreword - Safety First
Helmet and Clothing
When choosing a helmet, always look for a
DOT (Department of Transport) sticker
indicating that the helmet has DOT approval.
Do not buy a helmet without DOT approval.
Warning
When riding the motorcycle, both rider
and passenger must always wear a
motorcycle helmet, boots, eye protection,
gloves, trousers (close fitting around the
knee and ankle) and a brightly colored
jacket. Brightly colored clothing will
considerably increase a rider's (or
passenger's) visibility to other operators of
road vehicles. Although full protection is
not possible, wearing correct protective
clothing can reduce the risk of injury when
riding.
Warning
A helmet is one of the most important
pieces of riding gear as it offers protection
against head injuries. You and your
passenger's helmet should be carefully
chosen and should fit you or your
passenger's head comfortably and
securely. A brightly colored helmet will
increase a rider's (or passenger's) visibility
to other operators of road vehicles.
An open face helmet offers some
protection in an accident though a full face
helmet will offer more.
Always wear a visor or approved goggles
to help vision and to protect your eyes.

7
Foreword - Safety First
Parking Parts and Accessories
Triumph does not accept any liability
whatsoever for defects caused by the fitting
of non-approved parts, accessories or
conversions or the fitting of any approved
parts, accessories or conversions by
non-approved personnel.
Warning
Always turn off the engine and remove the
ignition key before leaving the motorcycle
unattended. By removing the key, the risk
of use of the motorcycle by unauthorized
or untrained persons is reduced.
When parking the motorcycle, always
remember the following:
Engage first gear to help prevent the
motorcycle from rolling off the stand.
The engine and exhaust system will be hot
after riding. DO NOT park where
pedestrians, animals and/or children are
likely to touch the motorcycle.
Do not park on soft ground or on a steeply
inclined surface. Parking under these
conditions may cause the motorcycle to fall
over.
For further details, please refer to the 'How
to Ride the Motorcycle' section of this
owner's handbook.
Warning
Owners should be aware that the only
approved parts, accessories and
conversions for any Triumph motorcycle
are those which carry official Triumph
approval and are fitted to the motorcycle
by an authorized dealer.
In particular, it is extremely hazardous to fit
or replace parts or accessories whose fitting
requires the dismantling of, or addition to,
either the electrical or fuel systems and any
such modification could cause a safety
hazard.
The fitting of any non-approved parts,
accessories or conversions may adversely
affect the handling, stability or other aspect
of the motorcycle operation that may result
in an accident causing injury or death.

8
Foreword - Safety First
Maintenance/Equipment
Warning
Consult your authorized Triumph dealer
whenever there is doubt as to the correct
or safe operation of this Triumph
motorcycle.
Remember that continued operation of an
incorrectly performing motorcycle may
aggravate a fault and may also
compromise safety.
Warning
Use of a motorcycle with bank angle
indicators worn beyond the maximum
limit (when 0.20 in (5 mm) of the bank
indicator remains) will allow the motorcycle
to be banked to an unsafe angle.
Banking to an unsafe angle may cause
instability, loss of motorcycle control and
an accident.
1. Bank angle indicator
1
Warning
Ensure all equipment that is required by
law is installed and functioning correctly.
The removal or alteration of the
motorcycle's lights, mufflers, emission or
noise control systems can violate the law.
Incorrect or improper modification may
adversely affect the handling, stability or
other aspect of the motorcycle operation,
which may result in an accident causing
injury or death.
Warning
If the motorcycle is involved in an accident,
collision or fall, it must be taken to an
authorized Triumph dealer for inspection
and repair. Any accident can cause
damage to the motorcycle that, if not
correctly repaired, may cause a second
accident that may result in injury or death.

9
Foreword - Safety First
Riding
Warning
Never ride the motorcycle when fatigued
or under the influence of alcohol or other
drugs.
Riding when under the influence of alcohol
or other drugs is illegal.
Riding when fatigued or under the
influence of alcohol or other drugs reduces
the rider's ability to maintain control of
motorcycle and may lead to loss of control
and an accident.
Warning
All riders must be licensed to operate the
motorcycle. Operation of the motorcycle
without a license is illegal and could lead to
prosecution.
Operation of the motorcycle without
formal training in the correct riding
techniques that are necessary to become
licensed is dangerous and may lead to loss
of motorcycle control and an accident.
Warning
Always ride defensively and wear the
protective equipment mentioned
elsewhere in this foreword. Remember, in
an accident, a motorcycle does not give the
same impact protection as a car.
Warning
This Triumph motorcycle should be
operated within the legal speed limits for
the particular road travelled. Operating a
motorcycle at high speeds can be
potentially dangerous since the time
available to react to given traffic situations
is greatly reduced as road speed increases.
Always reduce speed in potentially
hazardous driving conditions such as bad
weather or heavy traffic.
Warning
Continually observe and react to changes
in road surface, traffic and wind conditions.
All two-wheeled vehicles are subject to
external forces which may cause an
accident. These forces include but are not
limited to:
• Wind draft from passing vehicles;
• Potholes, uneven or damaged
road surfaces;
• Bad weather;
• Rider error.
Always operate the motorcycle at
moderate speed and away from heavy
traffic until you have become thoroughly
familiar with its handling and operating
characteristics. Never exceed the legal
speed limit.

10
Foreword - Safety First
Note:
Wobble/Weave
A weave is a relatively slow oscillation of the
rear of the motorcycle, while a wobble is a
rapid, possibly strong shaking of the
handlebar. These are related but distinct
stability problems usually caused by excessive
weight in the wrong place, or by a
mechanical problem such as worn or loose
bearings or under-inflated or unevenly worn
tires.
Your solution to both situations is the same.
Keep a firm hold on the handlebars without
locking arms or fighting the steering.
Smoothly ease off the throttle to slow
gradually. Do not apply the brakes, and do
not accelerate to try to stop the wobble or
weave. In some cases, it helps to shift your
body weight forward by leaning over the
tank.
Warning
Ensure that you know and respect the rules
of the road. Read and observe publications
such as 'MOTORCYCLE SAFETY', 'YOU
AND YOUR MOTORCYCLE, RIDING
TIPS' and also read and become familiar
with the contents of the MOTORCYCLE
HANDBOOK for your state.
Caution
This Triumph motorcycle is not fitted with
spark arresters. Operation in forests, brush
or grass areas may violate state and local
laws and regulations.

11
Foreword - Safety First
Handlebars and Footrests
Warning
The rider must maintain control of the
vehicle by keeping hands on the
handlebars at all times.
The handling and stability of a motorcycle
will be adversely affected if the rider
removes his hands from the handlebars,
resulting in loss of motorcycle control and
an accident.
Warning
The rider and passenger must always use
the footrests provided, during operation of
the vehicle.
By using the footrests, both rider and
passenger will reduce the risk of
inadvertent contact with any motorcycle
components and will also reduce the risk of
injury from entrapment of clothing.

Warning Labels
12
WARNING LABELS
The labels detailed on this and the following pages draw your attention to important safety
information in this handbook. Before riding, ensure that all riders have understood and
complied with all the information to which these labels relate.
Warning Label Locations - Daytona 675/675 R
cdkt1
6
5
4
3
2
N
1
R.P.M.
Windshield
(page 92)
Breaking-In
(page 51 )
Coolant
(page 77)
Gear
Position
(page 56)Drive Chain
(page 84)
Tires
(page 10 5 )

Warning Labels
13
Warning Label Locations - Daytona 675/675 R (continued)
Caution
All warning labels and decals, with the exception of the Breaking-in label, are fitted to the
motorcycle using a strong adhesive. In some cases, labels are installed prior to an application
of paint lacquer. Therefore, any attempt to remove the warning labels will cause damage to
the paintwork or bodywork.
ccov_2
Daily Safety Checks
(page 52)
Helmet
(page 6)
Unleaded Fuel
(page 45)
Engine Oil
(page 74)

Warning Labels
14
Warning Label Locations - Street Triple and Street Triple R
Caution
All warning labels and decals, with the exception of the Breaking-in label, are fitted to the
motorcycle using a strong adhesive. In some cases, labels are installed prior to an application
of paint lacquer. Therefore, any attempt to remove the warning labels will cause damage to
the paintwork or bodywork.
R.P.M.
6
5
4
3
2
N
1
cgnj
Gear
Position
(page 56)
Breaking-In
(page 51 )
Coolant
(page 77)
Drive Chain
(page 84)
Tires
(page 10 5 )

Warning Labels
15
Warning Labels Location - Street Triple and Street Triple R
(continued)
ntSupport de réservoir de carbura
Fuel Tank Support
Tankstütze
Supporto serbatoio carburante
Stöd för bränsletank
Soporte del depósito de combustible
䑒㠨ኜዐኌኒኺዙእ
Steun brandstoftank
Daily Safety Checks
(page 52)
Unleaded Fuel
(page 45)
Helmet
(page 6)
Engine Oil
(page 74)
Fuel Tank Support
(page 112 )

16
Parts Identification
PARTS IDENTIFICATION
Daytona 675 and 675R
1. Front turn signal
2. Headlight
3. Brake/Tail light
4. Radiator/Coolant pressure cap
5. Oil cooler/Heat exchanger
6. Drive chain
7. S i d e s t a n d
8. Gearshift pedal
9. Front brake disc
10.Front brake caliper
11. F u e l t a n k
12.Fuel filler cap
13 . S e a t l o c k
14.Coolant expansion tank
cdku_1
4 12 11 1314 3
157 8 69 10
2

17
Parts Identification
PARTS IDENTIFICATION
Daytona 675 and 675R (continued)
15.Battery
16.Tool kit
17. Rear brake disc
18.Rear brake caliper
19.Rear brake fluid reservoir
20.Rear suspension unit
21. Oil filler cap
22.Clutch cable
23.Front fork
24.Rear brake pedal
25.Dipstick
26.Muffler
cdku_2
16 15
25
19 23
24 20
21
2217 18
26

18
Parts Identification
Street Triple and Street Triple R
1. Front turn signal
2. Headlight
3. Brake/Tail light
4. Radiator/Coolant pressure cap
5. Oil cooler/Heat exchanger
6. Drive chain
7. S i d e s t a n d
8. Gearshift pedal
9. Front brake disc
10.Front brake caliper
11. F u e l t a n k
12.Fuel filler cap
13 . S e a t l o c k
14.Coolant expansion tank
cgnf
412 11 13 14 3
15 7 8 69 10
2

19
Parts Identification
Street Triple and Street Triple R (continued)
15.Battery
16.Tool kit
17. Rear brake disc
18.Rear brake caliper
19.Rear brake fluid reservoir
20.Rear suspension unit
21. Oil filler cap
22.Clutch cable
23.Front fork
24.Rear brake pedal
25.Dipstick
26.Muffler
cgng
16 19 23
20 24 25 2226 17 18
15
21

20
Parts Identification
All Models (Daytona 675 shown)
1. C l u t c h l e v e r
2. Passing button
3. Headlight dimmer switch
4. Horn button
5. Turn signal switch
6. Ignition switch
7. Front brake fluid reservoir
8. Front brake lever
9. Engine stop switch
10.Starter button
11. Speedometer
12.Tachometer
13.Trip computer display
H
AMPM
SET-UP ODO TRIP 12
km/L/100km/h
mpgmph miles
mph
km/h
13
32 11 12 7 9 8
6 104 5
1
