Trivisio SXGA61 User manual
User Manual
Active Stereo
For SXGA61
Subject to technical modifications
Copyright: Lux Prototyping S.A.R.L., 23, rue des Bateliers, ,6713 Grevenmacher,
Luxembourg
Active Stereo User Manual
1
Table of Contents
Table of Contents .......................................................2
1
Liability Limitation ..................................................... .3
2
Active Stereo ..................................... .... .... .... .... .......4
2.1
Firmware Update .....................................................4
2.2
3D Video formats support. .......................................4
Active Stereo User Manual
2
1 Liability Limitation
In no event shall the author be liable for damages, including any
general, special, incidental or consequential damages arising out
of the use or inability to use the program, including but not limited
to loss of data or losses sustained by you or third parties or a failure
of the program to operate with any other programs, even if such
holder or other party had previously been advised of the possibility
of such damages. This software is provided "as-is". No warranty of
any kind is expressed or implied.
By installing the software you accept the end user license
agreement and liability limitations.
Active Stereo User Manual
3
2 Active Stereo
2.1 Firmware Update
In order to support active stereo please ensure that you have
correct firmware.
Active stereo support starts from following versions:
SXGA_M2_42_BINO_HDMI#68:: Ver.1.04
Display engine:: Ver.1.03
2.2 3D Video formats support.
At the moment we support 2 formats of 3D Video:
•Custom side by side 2560x1024@60Hz, HMD displays
1280x1024 on each ocular.
This mode is mostly dedicated to developers, no
Additional 3D driver needed. Also no need to switch HMD as
Primary display.
•Standard HDMI 3D frame packed 1280x720@60Hz
3D driver is needed such as from nVidia.
For authorization purpose you need to purchase
NVIDIA NVIDIA 3D Vision 2 Wireless Glasses Kit
http://www.newegg.com/Product/Product.aspx?
Item=N82E16814998061
Just plug USB IR emitter.
Open nVidia Control Panel.
Go to Stereoscopic 3D folder.
Active Stereo User Manual
4
Then check the box Enable steroscopic 3D ,you'll be run
through Setup Wizard.
Active Stereo User Manual
5
Once it's done you can run nVidia sterescopic 3D test.
Active Stereo User Manual
6
Always refer to Display Information Tab of HMD Connection
software
to get info of current running mode.
http://www.trivisio.com/modules/download_gallery/dlc.php?fil
e=35&id=1427873447
Below are pictures of Display Information for 3D modes
described above:
Custom side by side 2560x1024@60Hz
Active Stereo User Manual
7
Active Stereo User Manual
8
