Trivum AudioBox User manual

trivum technologies GmbH
Eierstraße 48
70199 Stuttgart
[email protected]
www.trivum.com
www.facebook.com/trivumtechnologies
Further documentation and troubleshooting
To nd helpful log les in support cases:
– Open the TouchPad Setup Tool.
– Click Reports.
Please visit also our website for the latest documentation,
videos and information:
http://www.trivum.com
http://service.trivum.com
If support is needed
Please contact your local trivum dealer or write to:
[email protected]
Download links:
trivum ServerAdmin Tool (Windows):
http://service.trivum.com/win-admintool
How to update your trivum v8 to v9?
http://service.trivum.com/v9-update
v2_201609 - Errors and specications subject to change
without notice.
Quick Installation Guide for
AudioBox
How to controll?
AudioBox
– Use the buttons on the front for direct access to
control your music.
Mobile Devices
– For Android devices we recommend the DIVUS
KiBro app. Just enter the IP address of your trivum
AudioBox in the app settings as the default URL.
Whenever you start the app, the trivum web
visualization opens.
– Without an app you may always control your trivum
AudioBox by a web browser and the IP address.
TouchPad:
1. Wait a few seconds until the TouchPad has booted
2. On the starting screen press Pair TouchPad with
Audio System
3. Press Select... and select your preferred trivum
MusicCenter from the pop-up menu
iNote: If you want to have the full functionality
of your AudioBox please make sure your trivum
multiroom system is running version 9.
How to update: http://service.trivum.com/v9-update
v9
Optimized for:
AudioBox front
1 - Preset button 1 (default: FM tuner)
2 - Preset button 2 (default: Streaming)
3 - Preset button 3 (default: Analog-In)
4 - Preset button 4 (default: Digital-In)
5 - Indicator LED
6 - Volume -
7 - Volume -
8 - mute (short) / o (long)
AudioBox back
1 - DC power supply
2 - Loudspeaker connection (L-+/R-+)
3 - Optical-In (TOSLINK)
4 - Line-In (3.5 mm mini jack)
5 - FM tuner antenna
6 - Cat-5 ethernet
7 - Line-Out (3.5 mm mini jack)
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7

Quick Installation Guide for AudioBox
Required components for installation:
– Cat-5 cable
– network with DHCP capable router
– audio speakers with 4 or 8 Ohm impedance
– music archive (network share, NAS)
Optional components:
– internet connection (required for software updates,
music streaming services and remote support)
– wireless access point (if a mobile device is to be used)
– FM antenna (cable connection recommended)
– trivum TouchPad for high comfort music selection
– 3.5 mm mini jack audio cable to connect analog devices
– TOSLINK optical audio cable to connect digital devices
1. Mounting and connection
1.1 Place the AudioBox in your living space
1.2 Connect to audio speakers (check polarity) / FM
antenna / ethernet network / power supply.
!Warning: Only use the supplied power adapter.
2. Conguration
The trivum AudioBox has to be congured via web browser.
We recommend you to use the trivum ServerAdmin Tool.
The ServerAdmin Tool lists all trivum devices and their IP
addresses in your network.
2.1 Please download and install the ServerAdmin Tool.
http://service.trivum.com/win-admintool
iNote: If you don‘t want to use the ServerAdmin Tool,
you have to identify the IPaddress of the AudioBox, open
your browser and enter: IPaddress/setup
2.2 Start the ServerAdmin Tool.
2.3 Double-click on the device (AudioBox) to open the
MusicCenter WebCong (main cong site).
iNote: If you are not sure about the assignment of the
listed devices, you can compare the serial number in the list
with the serial number on your device.
2.4 Static IP instead of DHCP? click Network.
2.5 Select Use static IPaddress.
2.6 Enter your IP settings and Restart to apply changes.
3. Adding a network share
The trivum AudioBox can play sound les which are stored
on network shares. If you want to use a shared directory,
make sure that it supports the media sharing service Samba
service (smb). To add a network share (e.g. NAS):
3.1 Open the MusicCenter WebCong.
3.2 Click: Music Library -> Setup music library ->
Add network share.
3.3 Set the network path and user/password if required.
3.4 Click Save as new share.
3.5 Click Refresh your music index now.
4. Adding your online streaming service
account
4.1 Open the MusicCenter WebCong.
4.2 Click Add service.
4.3 Select your favorite service and enter your
user account.
4.4 Click Create the streaming service given account.
iNote: trivum supports only paid accounts.
lTip: The AudioBox is AirPlay ready, so it’s easy to stream
every kind of music to the specic zone (with Apple
devices).
Backup your conguration
Once you have completed the setup, we recommend you
to make a backup of your conguration:
– Open the MusicCenter WebCong.
– Click Backup/Restore -> Export/import conguration.
– Follow the instructions.
For easy operation of your AudioBox, we recommend our
trivum TouchPad.
How to use a trivum TouchPad?
– Make sure your TouchPad is running software v2.35 or
above.
– Wait a few seconds until the TouchPad has booted.
– On the starting screen press
Pair TouchPad with Audio System.
– Press Select... and select your preferred trivum
MusicCenter from the pop-up menu.
How to use KNX?
The KNX programming of the AudioBox is done via the
web browser. No need for extra KNX software.
– Open the MusicCenter WebCong.
– Click KNX and enable use KNX.
– Follow the instructions.
You nd further informations for KNX on:
http://service.trivum.com/knx
