Truper MOG-65 User manual

Manual
Gasoline
Engine
ModelsCodes
MOG-65
MOG-90
MOG-130
Applies for:
101327
101328
101329
ENGLISH
ESPAÑOL
Power
6.5 Hp / 9 Hp / 13 Hp
CAUTION Read this manual thoroughly
before using the tool.

2
Technical Data
Fuel Specifications
General Safety Warnings for Motor Tools
Safety Warnings for Gasoline Engines
Parts
Assembly
Fuel and Oil
Start Up
Maintenance
Troubleshooting
Notes
Authorized Service Centers
Warranty Policy
3
3
4
5
6
7
8
9
10
12
13
15
16
MOG-65
MOG-130
MOG-90
ENGLISH
Contents
CAUTION
Keep this manual for future references.
The illustrations in this manual are for reference
only. They might be different from the real tool.
To gain the best performance of
the tool, prolong the duty life,
make the Warranty valid if
necessary, and to avoid hazards
of fatal injuries please read and
understand this Manual before
using the tool.

3
101327
270 cm3
101328 101329
6.5 Hp 13 Hp
0.6 L/h 1.0 L/h 1.4 L/h
Gasoline
9 Hp
3 600 RPM
Gasoline Engine
Code
Description
Motor Cylinders
Motor Rated Power
13.5 Nm 26.5 Nm
16.4 Nm
Max. Torque
No Load Speed
4-stroke OHV
Motor Type
Fuel
1.5 gal
Gas Tank Capacity
SAE 10W-30
Oil Type
Technical Data
Fuel Consumption
Noise Level < 94 dB
Weight
MOG-65 MOG-130MOG-90
Fuel Specifications
• The equipment has an air-cooled 4-stroke motor using
pure unleaded gasoline.
• For no reason at all mix oil with the fuel.
• For no reason at all use fuel mixed
with ethyl alcohol (gasohol), ethanol or methane. These
attract humidity causing separation and acid build up
when stored. Acidity can damage the motor fuel system
when stored.
• To avoid having problems with the motor, please drain
the fuel system before storing the equipment 30 days or
longer. Drain the gasoline tank, start the motor and leave
it running until the fuel lines are empty. Next season, use
fresh gasoline.
WARNING
Do not use the equipment in closed areas.
Prevent breathing accumulated carbon
monoxide, an odorless, toxic and potentially fatal gas.
Never smoke near fuel.
Do not smoke near the filling-up
area or while operating the equipment.
DANGER
DANGER
• Never use inside the gasoline tank products to clean motors
or carburetors. Those products can cause permanent
damage to the Motor.
ENGLISH
420 cm3 212 cm3
0.95 gal 1.7 gal
3/4” whit keyseat 1” whit keyseat
Diameter / Type shaft
Low oil level sensor
51.8 lb 65.5 lb32 lb

4
General Safety Warnings
for Motor Tools
ENGLISH
Keep your work area clean, tidy and well lit.
Cluttered and dark areas may cause accidents.
Never use the tool in explosive areas or in the presence
of flammable liquids.
Before starting the motor keep the tool at least
9 meters (30 feet) away from the fill up area.
Keep children and passersby at a safe distance while
operating the tool.
Distractions could cause loosing control and cause
accidents.
Avoid contact with power lines and circuits.
Find and avoid power lines and circuits, especially
hidden wiring as well as any grounded object.
Stay alert, use care and common sense.
Familiarity with the tool operation could lead to
distractions. It could cause accidents.
Refrain from using the tool if tired or under the
influence of drugs, alcohol or medication.
Being momentarily distracted while using the tool could
cause severe personal injury.
Operate the tool with guards and protection devices in
place and in good working condition.
Failure to comply with this warning is a hazard of severe
personal injury.
Do not force the tool.
Working within the tool’s working design assures
a better and safer job.
Keep the tool in a safe place and out of the reach of
children.
Motor powered tools are dangerous to
inexperienced people.
Wear proper clothes.
Loose clothes, jewelry or long hair could get
caught in the mobile parts.
Keep hands away from rotating and/or mobile parts.
Failure to comply with this warning is a hazard
of severe personal injury.
Do not operate the tool in enclosed areas.
Avoid breathing accumulated carbon monoxide, a
potentially deadly odorless toxic gas.
Wear adequate protective safety accessories.
Wear eye protection, dust mask, non-skid safety shoes,
helmet and ear plugs. These safety gears reduce the risk
of injury.
Turn off the tool before adjusting, changing accessories
or storin.
Double check the tool switch is in the off position.
Refrain from operating the tool if the switch is not
working or is not properly assembled.
Failure to complain with this warning is a hazard of
personal injury. Immediately send it to a
Authorized Service Center.
Do not overreach.
Good balance and support lead to better controlling the tool
in unexpected situations.
Avoid the tool to unintentionally start.
Double-check the tool motor is off
before maintenance or putting it away.
Remove brackets before turning on the tool.
Additional tools or vices installed in a rotating part could
cause severe personal injury.
Service the tool and double-check it is in good working
conditions before operating.
Carefully check mobile parts, alignment and assembly.
Do it periodically. Look for any damaged element or part
not working properly. Repair immediately in a
Authorized Service Center.
Accessories.
Use only accessories or spare parts indicated in this
Manual or certified by .
Never leave a running tool unattended.
Turn off and disconnect the tool after using. Set it in a
safe position to avoid severe injury.
Never smoke in the proximity of fuel.
Do not smoke in the proximity of the fuelling
area or when using the tool.
Do not touch parts with high temperatures.
The surface of the engine and the exhaust reach high temperatures during the
operation of the tool..
Service and repair.
Always go to a Authorized Service Center to use identical spare
parts and maintain the security of the tool.
CAUTION CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
DANGER
DANGER
DANGER
DANGER
DANGER
DANGER
DANGER
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING

5
Safety Warnings
for Gasoline Engines
• Never smoke close to where there is fuel, nor the
filling up zone or when operating the pump.
• To reduce risk of fire or burns, handle fuel with care.
It is extremely flammable.
• Prevent gasoline or oil to be in contact with your skin.
• Protect your eyes to guard off gasoline or oil splashes.
In the event of accidental contact, wash immediately with
clear water. If irritations persist, go see a physician.
• Store fuel in a dedicated container.
• Before re-fueling, shut down the
motor, set the equipment on clear terrain and wait for it
to cool down.
• Wipe clean all the spilled fuel before
operating the equipment.
• Check for fuel leaks to prevent fire, or
burns. If there are leaks, mend them before using the
pump.
• Under no reason at all burn spilled fuel to get rid of it.
• For no reason use any other type of fuel than that
specified in the instructions.
Fuel Handling
WARNING
CAUTION
CAUTION
ENGLISH

Exhaust
Oil Drain Cap
Fuel
Tank Cap
Air
Filter
Spark
Plug
Throttle
Choke
Lever
Fuel Key
Oil Drain Cap
Shaft
Oil
Supply
Cap
Oil Supply
Cap
Starter
jack-line
Start
Knob
6
Parts
ENGLISH
Fuel tank

A
7
Assembly
ENGLISH
• The motor must be attached to a plate (A) welded to the
structure or chassis of the machine where the engine will
be housed. This plate must be larger than the base of the
engine and have four perforations to fix the motor with
four sets of hexagonal bolts.
The motor must be mounted on a level
surface otherwise the motor may be damaged due to
improper lubrication.
Engine mount
1
2
3
F
• The engine shaft can be attached to a steering wheel or
clutch depending on the purpose of the engine.
1. Remove the bolt (B) to remove the cover (C) that holds
the wedge (D) in place.
2. Place the steering wheel (E) or clutch on the motor
shaft not without first placing the key on the shaft to match
the steering wheel slot (F).
3. Secure the steering wheel on the shaft with the bolt (B).
Shaft junction
B
C
D
E
NOTE

Minimum
Maximum
A
B
8
Fuel and Oil
• Set the equipment onto a flat and leveled surface.
• Turn and remove the oil supply cap.
• Use 4-stroke motor oil. Using SAE 10W-30 general oil for all
temperatures is recommended. As indicated in the following
table, other viscosities can be used when the local average
temperature is within the indicated range.
• Set back the cap and remove it to check oil level in the
cap oil measuring rod.
• Once the oil tank is in the right level indicated in the
rod, tighten the cap to prevent leaks.
• Do not exceed the oil maximum level
because it causes a lot of smoke when starting the motor.
• Check the oil level before each use. If
necessary, add oil until the level is between the limits in
the cap rod.
• Replace oil after 20 hours’ operation or
each month. It may be necessary to replace oil more
often during dusty or dirt conditions.
Oil Supply (A)
• Set the Pressure Washer on a flat and leveled surface.
• Clean and dry the area around the fuel cap.
• Remove the fuel cap.
• Using a funnel fill slowly the fuel tank up to the lower
part of the tank neck. Do not overfill to allow fuel
expansion and prevent spillage.
• Clean any fuel spills.
• Cover the tank rotating the cap until hearing a click.
• Clean any spilled fuel before starting up.
Fuel Supply (B)
CAUTION
CAUTION
CAUTION
-30 -20 -10 010 20 30 40 °C
10 W - 30
10 W - 40
• In high altitudes, the air-fuel combination in a standard
carburetor will be rich in fuel. Performance will be low and
fuel consumption will increase.
• Performance while operating in high altitudes may
improve if the carburetor is regulated adjusting the main
knob. The machine is adjusted to operate at altitudes
above 6000 feet over sea level. If noticing the machine is
not operating efficiently go to a
Authorized Service Center to carry out the modification
needed in the carburetor.
• Even though the carburetor is having an adequate
injection, the motor power will diminish approximately
3.5% per each increase of 1000 feet after 6890 feet above
sea level. The power decrease will be higher if no
modifications are carried out in the carburetor.
• If the machine is operated in a height
inadequate to the carburetor adjustment, low performance,
overheating and severe damage in the motor can be
caused due to the excessive air mix in the fuel.
High Altitude Operation
WARNING
ENGLISH

9
Start Up
Before starting the pump some topics need
to be taken care of. Otherwise it can get damaged and the
Warranty cancelled:
• All the hoses shall be disconnected, totally untangled and
with no kinks.
• Water supply shall be connected and fully open.
• Gasoline and oil levels shall be right.
• The system shall be purged as previously indicated.
• Move the throttle lever (G) into the low speed position ( ).
• Turn off the switch (C).
• Move the fuel lever (A) moving the lever into the closed (OFF) position.
• Move the choke lever (D) into the “OFF” position.
• To stop the motor during an emergency, set the motor switch directly intp the “OFF” position.
Shut OFF
• Open the fuel valve (A).
• Move the choke lever into the off
position (B).
• Set the switch (C) in the ON position ( I).
• Move the throttle lever (G) to the
high-speed position ( ).
• Slowly pull the starter lever (D) until filling resistance in the line. Then, pull with force to start
the motor. Carefully return the lever to its place. do not release it, otherwise it
would snap back and get damaged.
• Allow the motor to run 5 seconds, and then move the choke lever into the “ON” position (E).
• Keep on paying CAUTION to the water source level because during the
pumping operation the level could go so low until the suction hose end is out of the water. In
this situation turn off the pump immediately and correct the suction hose depth. Avoid making
the pump function with no water, otherwise it may get damaged.
Start Up
CAUTION
CAUTION
CAUTION
CAUTION
ENGLISH
G
D
B C
A
D
E

Minimum
Maximum
C
Maintenance
10
Before
Each Use
Check Change (3) Change
Change
Clean (1)
Clean
Clean
Clean
Carry Out
Check
Check and replace every 3 years if necessary (2)
Clean / Readjust
Clean / Readjust (2)
Clean (2)
Every 20 h or
each month Every 50 h or 3 months Every 300 h or every year
Every 100 h
or 6 months
Regular
Maintenance
1. When operating the equipment in dusty places carry out maintenance more frequently.
2. Go to a Authorized Service Center for this service.
3. Only applies for the first oil change
General Inspection
Motor Oil
Air Filter
Sediment Container
Spark Plug
Valve Clearance
Fuel Tank and Sieve
Fuel Line
Fuel Filter
Fuel Tank Cap
• Regular and careful maintenance is
essential to maintain the safety levels and the optimal
performance of the equipment.
• Before cleaning, repairing, inspecting or storing the
equipment, shut off the motor and wait until the motor is
completely cooled down.
• Keep nuts, bolts and screws tight to assure the
equipment is in a safe working condition.
• Do not alter the safety devises. Verify regularly if they
work right.
CAUTION • Any worn or damaged part shall be replaced before
using the equipment. Do not try to repair the parts. It can
damage the equipment and become a risk to your safety.
• Any repair or maintenance works different to those
described in this section, for example, adjusting the
carburetor, shall be carried out only in a
Authorized Service Center.
• Check the air filter to ensure is in good conditions.
Remember, a dirty filter can make starting difficult,
loosing performance and shorten the working life of the
motor.
• Remove the wing nut, then remove the filter cover and
the filter element.
• Set apart both the sponge filter from the paper filter
elements.
• Wash the sponge filter with a detergent and hot water
solution. Let the filter dry completely.
• Soak the sponge filter in clean SAE-20 motor oil.
Squeeze out until eliminating excessive oil. The motor
may expel smoke during start up if too much oil is left.
• Install back the filter in its container and set the cover
back in place.
Never use gasoline to clean the air filter.
It could cause and explosion or fire. Never start the
motor with the air filter removed. The motor will wear
out faster.
Air Filter Oil Replacement
• The oil drain cap is under the motor (B).
• Set the dedicated container underneath the motor to
receive the oil. Remove the drain cap and then, the tank
cap (C). When the oil has drained, set back the drain
cap.
• Wipe clean any leak or spill.
• Fill up the tank with SAE-10W/30 oil.
• Check oil level placing the oil tank cap without
screwing it back. Oil level shall be between the
maximum and minimum marks in the oil measuring rod.
Double check the level is not exceeding the maximum
mark. When the level is right, tighten the tank cap.
• Start the motor. Leave it running a few moments.
Stop the motor, wait one minute and check again oil
level. Fill up if necessary.
• For no reason at all, pour oil in the drain. Take used oil
and oil filter to a recycling unit.
CAUTION
ENGLISH
B

E
F
G
• Before removing the spark plug (B), wipe clean the area
around the spark plug base to stop dust and debris
entering the motor. Then, using a spark-plug wrench
remove the spark plug.
•Clean the carbon deposits from the spark plug electrodes
using a spark plug cleaner or a wire brush.
• Replace the old spark plug with a new one if damaged,
worn or if in doubt.
• Measure the gap between both electrodes. Use a spark
plug gauge. The distance between the center electrode
and the side electrode shall be between 0.27” and 0.31”
• Check the spark plug washer is in good conditions.
Insert the spark plug manually to prevent maladjustment.
•After setting the spark plug, tighten with a spark plug
wrench to compress the washer.
If installing a new spark plug, tighten
half-a-turn until the spark plug is in place and can press
the washer. If installing a used spark-plug, tighten 1/8 of a
turn after the spark plug is in place and can press the
washer.
Improperly installed or out of range
spark plugs cause overheating and damage the motor.
Maintenance
11
Storing and Transportation
• When moving the equipment, shut down the motor
switch and close the fuel key. Keep the equipment
leveled to prevent fuel spills.
• When storing the equipment long periods of time:
• Drain completely all the fuel as indicated in the previous
paragraph. Then, start the motor until all the fuel inside
the motor is consumed.
• Replace oil as indicated in page 11.
• Remove the spark plug and pour a spoonful of
SAE-10W/30 oil into the cylinder. Pull the jack-line to
distribute the oil through the system. Set the spark plug
back in place.
• Pull softly the jack-line handle until feeling resistance.
This indicated the cylinder is reaching the compression
phase and the escape and absorption valves are closed.
Storing the equipment in these conditions prevents
internal corrosion.
• Wipe clean the equipment with a damp cloth and
cover it to prevent dust accumulation.
• Store the equipment in a clean, dry place, away from
the reach of children.
Fuel Drain
• Set a dedicated container under the tank to receive
gasoline. Use a funnel to prevent fuel spills.
• Close the fuel key. Remove and clean the fuel filter as
indicated above.
• Before setting the filter, open the filter key to drain all
the fuel tank contents. When drained, place the filter
and the sediment container.
• Set a dedicated container under the carburetor to
receive gasoline. Use a funnel to prevent fuel spills.
• Remove the drain bolt (A).
• When fuel has been drained into the container, set the
drain bolt back and the washer. Tighten firmly.
• Wipe clean all the fuel spills.
Spark Plug
CAUTION
WARNING
• The fuel filter stops water or dirt present in the fuel
tank to enter into the carburetor.
If the motor has not been run after a long period of time,
the sediment container need cleansing.
• With the motor off and ambient temperature close the
fuel key (E).
• Remove the sediment container (F). Clean its interior.
• Leave the container drying completely.
• Verify the washer (G) is in good conditions and set the
sediment container back in place.
• The tank fuel filter shall be washed according to the
maintenance program indicated in page 11.
These instructions apply only for models
MOTB-2 and MOTB-3
Fuel Filter
ENGLISH
NOTE
A
B

Troubleshooting
12
• The switch is OFF.
• Not enough fuel.
• Oil level is too low or there is no oil.
• Gasoline is not getting into the carburetor.
• No spark in the spark plug.
• Oil level is too low.
Motor does not start.
The motor starts but
stops unexpectedly.
Problem Cause Solution
• Turn ON the switch.
• Fill up fuel tank.
• Check oil level as indicated in page 8.
• Having the fuel tank full, verify fuel flow in the
carburetor:
1. Set a dedicated container under the
carburetor and use a funnel to prevent fuel
spills.
2. Remove the drain bolt. Fuel shall flow freely.
Otherwise, go to a Authori-
zed Service Center.
• Verify the spark plug spark:
1. Disconnect the spark plug cable, wipe clean
dust around the spark plug and remove it.
2. Connect the cable to the spark plug.
3. Turn on the motor.
4. Make the spark plug electrode contact any
metal part in the motor that is free of fuel.
Is important to carry out tests
in a ventilated area with no fuel spilled, otherwise
an explosion may occur.
5. Pull the jack-line handle to generate a spark
between the spark plug central electrode and the
metal part. If there is no spark, the spark plug
needs replacement.
6. If with a new spark plug still is no spark go to a
Authorized Service Center.
• Check motor level as indicated on page 8. Start
the motor again.
CAUTION
If problems persist despite all the corrective actions contact a
Authorized Service Center.
ENGLISH

Notes
13
ENGLISH

Notes
14 ENGLISH

15
ENGLISH
Authorized Service Centers
In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com
to get an updated list, or call our toll-free numbers 800 690-6990 or 800-018-7873 to get information about the
nearest Service Center.
AGUASCALIENTES
BAJA
CALIFORNIA
BAJA
CALIFORNIA SUR
CAMPECHE
CHIAPAS
CHIHUAHUA
CIUDAD DE
MÉXICO
COAHUILA
COLIMA
DURANGO
ESTADO DE
MÉXICO
GUANAJUATO
GUERRERO
HIDALGO
JALISCO
MICHOACÁN
MORELOS
NAYARIT
NUEVO LEÓN
OAXACA
PUEBLA
QUERÉTARO
QUINTANA ROO
SAN LUIS
POTOSÍ
SINALOA
SONORA
TABASCO
TAMAULIPAS
TLAXCALA
VERACRUZ
YUCATÁN
DE TODO PARA LA CONSTRUCCIÓN
GRAL. BARRAGÁN #1201, COL. GREMIAL, C.P. 20030,
AGUASCALIENTES, AGS. TEL.: [phone]
SUCURSAL TIJUANA
AV. LA ENCANTADA, LOTE #5, PARQUE INDUSTRIAL EL
FLORIDO II, C.P 22244, TIJUANA, B.C.
TEL.: [phone]
FIX FERRETERÍAS
FELIPE ÁNGELES ESQ. RUIZ CORTÍNEZ S/N, COL. PUEBLO
NUEVO, C.P. 23670, CD. CONSTITUCIÓN, B.C.S.
TEL.: [phone]
TORNILLERÍA Y FERRETERÍA AAA
AV. ÁLVARO OBREGÓN #324, COL. ESPERANZA
C.P. 24080 CAMPECHE, CAMP. TEL.: [phone]
FIX FERRETERÍAS
AV. CENTRAL SUR #27, COL. CENTRO, C.P. 30700,
TAPACHULA, CHIS. TEL.: [phone]
SUCURSAL CHIHUAHUA
AV. SILVESTRE TERRAZAS #128-11, PARQUE INDUSTRIAL
BAFAR, CARRETERA MÉXICO CUAUHTÉMOC, C.P. 31415,
CHIHUAHUA, CHIH. TEL. [phone]
FIX FERRETERÍAS
EL MONSTRUO DE CORREGIDORA, CORREGIDORA # 22,
COL. CENTRO, C.P. 06060, CUAUHTÉMOC, CDMX.
TEL: [phone]
SUCURSAL TORREÓN
CALLE METAL MECÁNICA #280, PARQUE INDUSTRIAL
ORIENTE, C.P. 27278, TORREÓN, COAH.
TEL.: [phone]
BOMBAS Y MOTORES BYMTESA DE MANZANILLO
BLVD. MIGUEL DE LA MADRID #190, COL. 16 DE
SEPTIEMBRE, C.P. 28239, MANZANILLO, COL.
TEL.: [phone]
TORNILLOS ÁGUILA, S.A. DE C.V.
MAZURIO #200, COL. LUIS ECHEVERRÍA, DURANGO,
DGO.TEL.: [phone]
SUCURSAL CENTRO JILOTEPEC
PARQUE INDUSTRIAL # 1, COL. PARQUE INDUSTRIAL
JILOTEPEC, JILOTEPEC, EDO. DE MÉX. C.P. 54257
TEL: [phone] EXT. 5728 Y 5102
CÍA. FERRETERA NUEVO MUNDO S.A. DE C.V.
AV. MÉXICO - JAPÓN #225, CD. INDUSTRIAL, C.P. 38010,
CELAYA, GTO. TEL.: [phone] / 79 / 80 / 88
CENTRO DE SERVICIO ECLIPSE
CALLE PRINCIPAL MZ.1 LT. 1, COL. SANTA FE, C.P. 39010,
CHILPANCINGO, GRO. TEL.: [phone]
FERREPRECIOS S.A. DE C.V.
LIBERTAD ORIENTE #304 LOCAL 30, INTERIOR DE PASAJE
ROBLEDO, COL. CENTRO, C.P. 43600, TULANCINGO,
HGO. TEL.: [phone]
SUCURSAL GUADALAJARA
AV. ADOLFO B. HORN # 6800, COL: SANTA CRUZ DEL
VALLE, C.P.: 45655, TLAJOMULCO DE ZUÑIGA, JAL.
TEL.: [phone] AL 90
FIX FERRETERÍAS
AV. PASEO DE LA REPÚBLICA #3140-A, COL.
EX-HACIENDA DE LA HUERTA, C.P. 58050, MORELIA,
MICH. TEL.: [phone]
FIX FERRETERÍAS
CAPITÁN ANZURES #95, ESQ. JOSÉ PERDIZ, COL.
CENTRO, C.P. 62740, CUAUTLA, MOR.
TEL.: [phone]
HERRAMIENTAS DE TEPIC
MAZATLAN #117, COL. CENTRO, C.P. 63000, TEPIC, NAY.
TEL.: [phone]
SUCURSAL MONTERREY
CARRETERA LAREDO #300, 1B MONTERREY PARKS,
COLONIA PUERTA DE ANÁHUAC, C.P. 66052, ESCOBEDO,
NUEVO LEÓN, TEL.: [phone]
FIX FERRETERÍAS
AV. 20 DE NOVIEMBRE #910, COL. CENTRO, C.P. 68300,
TUXTEPEC, OAX. TEL.: [phone]
SUCURSAL PUEBLA
AV PERIFÉRICO #2-A, SAN LORENZO ALMECATLA,
C.P. 72710, CUAUTLACINGO, PUE.
TEL.: [phone] / 84 / 85 / 86
ARU HERRAMIENTAS S.A DE C.V.
AV. PUERTO DE VERACRUZ #110, COL. RANCHO DE
ENMEDIO, C.P. 76842, SAN JUAN DEL RÍO, QRO.
TEL.: [phone]
FIX FERRETERÍAS
CARRETERA FEDERAL MZ. 46 LT. 3 LOCAL 2, COL EJIDAL,
C.P. 77710 PLAYA DEL CARMEN, Q.R.
TEL.: [phone]
FIX FERRETERÍAS
AV. UNIVERSIDAD #1850, COL. EL PASEO, C.P. 78320,
SAN LUIS POTOSÍ, S.L.P. TEL.: [phone]
SUCURSAL CULIACÁN
AV. JESÚS KUMATE SUR #4301, COL. HACIENDA DE LA
MORA, C.P. 80143, CULIACÁN, SIN.
TEL.: [phone]
FIX FERRETERÍAS
CALLE 5 DE FEBRERO #517, SUR LT. 25 MZ. 10, COL.
CENTRO, C.P. 85000, CD. OBREGÓN, SON.
TEL.: [phone]
SUCURSAL VILLAHERMOSA
CALLE HELIO LOTES 1, 2 Y 3 MZ. #1, COL. INDUSTRIAL,
2A ETAPA, C.P. 86010, VILLAHERMOSA, TAB.
TEL.: [phone]
VM ORINGS Y REFACCIONES
CALLE ROSITA #527 ENTRE 20 DE NOVIEMBRE Y GRAL.
RODRÍGUEZ, FRACC. REYNOSA, C.P. 88780, REYNOSA,
TAMS. TEL.: [phone]
SERVICIOS Y HERRAMIENTAS INDUSTRIALES
PABLO SIDAR #132, COL . BARRIO DE SAN BARTOLOMÉ,
C.P. 90970, SAN PABLO DEL MONTE, TLAX.
TEL.: [phone]
LA CASA DISTRIBUIDORA TRUPER
BLVD. PRIMAVERA. ESQ. HORTENSIA S/N, COL.
PRIMAVERA C.P. 93308, POZA RICA, VER.
TEL.: [phone]
SUCURSAL MÉRIDA
CALLE 33 #600 Y 602, LOCALIDAD ITZINCAB Y MULSAY,
MPIO. UMÁN, C.P. 97390, MÉRIDA, YUC.
TEL.: [phone]

Stamp of the business. Delivery date:
Warranty. Duration: 1 year. Coverage: parts, components and workmanship against manufacturing or operating
defects, except if used under conditions other than normal; when it was not operated in accordance with the
instructive; was altered or repaired by personnel not authorized by Truper®. To make the warranty valid, present
the product, stamped policy or invoice or receipt or voucher, in the establishment where you bought it or in
Corregidora 22, Centro, Cuauhtémoc, CDMX, 06060, where you can also purchase parts, components,
consumables and accessories. It includes the costs of transportation of the product that derive from its fulfillment
of its service network. . Phone number 800-018-7873. Made in China. Imported by Truper, S.A. de C.V. Parque
Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
16 ENGLISH www.truper.com
08-2022
1
YEAR
Warranty
policy
Codes Models Brand
MOG-65
MOG-90
MOG-130
101327
101328
101329

16 ESPAÑOL
1
AÑO
Póliza de
Garantía
Códigos Modelos Marca
www.truper.com
08-2022
MOG-65
MOG-90
MOG-130
101327
101328
101329
Sello del establecimiento comercial. Fecha de entrega:
Garantía. Duración: 1 año. Cobertura: piezas, componentes y mano de obra contra defectos de fabricación o
funcionamiento, excepto si se usó en condiciones distintas a las normales; cuando no fue operado conforme
instructivo; fue alterado o reparado por personal no autorizado por Truper®. Para hacer efectiva la garantía
presente el producto, póliza sellada o factura o recibo o comprobante, en el establecimiento donde lo compró
o en Corregidora 22, Centro, Cuauhtémoc, CDMX, 06060, donde también podrá adquirir partes, componentes,
consumibles y accesorios. Incluye los gastos de transportación del producto que deriven de su cumplimiento de
su red de servicio. Tel. [phone]. Made in/Hecho en China. Importador Truper, S.A. de C.V. Parque
Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Tel. [phone].

Centros de Servicio Autorizados
En caso de tener algún problema para contactar un Centro de Servicio Autorizado Truper
®
consulte nuestra página
www.truper.com donde obtendrá un listado actualizado, o llame al: 800 690 6990 u800-018-7873 donde le
informarán cuál es el Centro de Servicio más cercano.
AGUASCALIENTES
BAJA
CALIFORNIA
BAJA
CALIFORNIA SUR
CAMPECHE
CHIAPAS
CHIHUAHUA
CIUDAD DE
MÉXICO
COAHUILA
COLIMA
DURANGO
ESTADO DE
MÉXICO
GUANAJUATO
GUERRERO
HIDALGO
JALISCO
MICHOACÁN
MORELOS
NAYARIT
NUEVO LEÓN
OAXACA
PUEBLA
QUERÉTARO
QUINTANA ROO
SAN LUIS
POTOSÍ
SINALOA
SONORA
TABASCO
TAMAULIPAS
TLAXCALA
VERACRUZ
YUCATÁN
DE TODO PARA LA CONSTRUCCIÓN
GRAL. BARRAGÁN #1201, COL. GREMIAL, C.P. 20030,
AGUASCALIENTES, AGS. TEL.: [phone]
SUCURSAL TIJUANA
AV. LA ENCANTADA, LOTE #5, PARQUE INDUSTRIAL EL
FLORIDO II, C.P 22244, TIJUANA, B.C.
TEL.: [phone]
FIX FERRETERÍAS
FELIPE ÁNGELES ESQ. RUIZ CORTÍNEZ S/N, COL. PUEBLO
NUEVO, C.P. 23670, CD. CONSTITUCIÓN, B.C.S.
TEL.: [phone]
TORNILLERÍA Y FERRETERÍA AAA
AV. ÁLVARO OBREGÓN #324, COL. ESPERANZA
C.P. 24080 CAMPECHE, CAMP. TEL.: [phone]
FIX FERRETERÍAS
AV. CENTRAL SUR #27, COL. CENTRO, C.P. 30700,
TAPACHULA, CHIS. TEL.: [phone]
SUCURSAL CHIHUAHUA
AV. SILVESTRE TERRAZAS #128-11, PARQUE INDUSTRIAL
BAFAR, CARRETERA MÉXICO CUAUHTÉMOC, C.P. 31415,
CHIHUAHUA, CHIH. TEL. [phone]
FIX FERRETERÍAS
EL MONSTRUO DE CORREGIDORA, CORREGIDORA # 22,
COL. CENTRO, C.P. 06060, CUAUHTÉMOC, CDMX.
TEL: [phone]
SUCURSAL TORREÓN
CALLE METAL MECÁNICA #280, PARQUE INDUSTRIAL
ORIENTE, C.P. 27278, TORREÓN, COAH.
TEL.: [phone]
BOMBAS Y MOTORES BYMTESA DE MANZANILLO
BLVD. MIGUEL DE LA MADRID #190, COL. 16 DE
SEPTIEMBRE, C.P. 28239, MANZANILLO, COL.
TEL.: [phone]
TORNILLOS ÁGUILA, S.A. DE C.V.
MAZURIO #200, COL. LUIS ECHEVERRÍA, DURANGO,
DGO.TEL.: [phone]
SUCURSAL CENTRO JILOTEPEC
PARQUE INDUSTRIAL # 1, COL. PARQUE INDUSTRIAL
JILOTEPEC, JILOTEPEC, EDO. DE MÉX. C.P. 54257
TEL: [phone] EXT. 5728 Y 5102
CÍA. FERRETERA NUEVO MUNDO S.A. DE C.V.
AV. MÉXICO - JAPÓN #225, CD. INDUSTRIAL, C.P. 38010,
CELAYA, GTO. TEL.: [phone] / 79 / 80 / 88
CENTRO DE SERVICIO ECLIPSE
CALLE PRINCIPAL MZ.1 LT. 1, COL. SANTA FE, C.P. 39010,
CHILPANCINGO, GRO. TEL.: [phone]
FERREPRECIOS S.A. DE C.V.
LIBERTAD ORIENTE #304 LOCAL 30, INTERIOR DE PASAJE
ROBLEDO, COL. CENTRO, C.P. 43600, TULANCINGO,
HGO. TEL.: [phone]
SUCURSAL GUADALAJARA
AV. ADOLFO B. HORN # 6800, COL: SANTA CRUZ DEL
VALLE, C.P.: 45655, TLAJOMULCO DE ZUÑIGA, JAL.
TEL.: [phone] AL 90
FIX FERRETERÍAS
AV. PASEO DE LA REPÚBLICA #3140-A, COL.
EX-HACIENDA DE LA HUERTA, C.P. 58050, MORELIA,
MICH. TEL.: [phone]
FIX FERRETERÍAS
CAPITÁN ANZURES #95, ESQ. JOSÉ PERDIZ, COL.
CENTRO, C.P. 62740, CUAUTLA, MOR.
TEL.: [phone]
HERRAMIENTAS DE TEPIC
MAZATLAN #117, COL. CENTRO, C.P. 63000, TEPIC, NAY.
TEL.: [phone]
SUCURSAL MONTERREY
CARRETERA LAREDO #300, 1B MONTERREY PARKS,
COLONIA PUERTA DE ANÁHUAC, C.P. 66052, ESCOBEDO,
NUEVO LEÓN, TEL.: [phone]
FIX FERRETERÍAS
AV. 20 DE NOVIEMBRE #910, COL. CENTRO, C.P. 68300,
TUXTEPEC, OAX. TEL.: [phone]
SUCURSAL PUEBLA
AV PERIFÉRICO #2-A, SAN LORENZO ALMECATLA,
C.P. 72710, CUAUTLACINGO, PUE.
TEL.: [phone] / 84 / 85 / 86
ARU HERRAMIENTAS S.A DE C.V.
AV. PUERTO DE VERACRUZ #110, COL. RANCHO DE
ENMEDIO, C.P. 76842, SAN JUAN DEL RÍO, QRO.
TEL.: [phone]
FIX FERRETERÍAS
CARRETERA FEDERAL MZ. 46 LT. 3 LOCAL 2, COL EJIDAL,
C.P. 77710 PLAYA DEL CARMEN, Q.R.
TEL.: [phone]
FIX FERRETERÍAS
AV. UNIVERSIDAD #1850, COL. EL PASEO, C.P. 78320,
SAN LUIS POTOSÍ, S.L.P. TEL.: [phone]
SUCURSAL CULIACÁN
AV. JESÚS KUMATE SUR #4301, COL. HACIENDA DE LA
MORA, C.P. 80143, CULIACÁN, SIN.
TEL.: [phone]
FIX FERRETERÍAS
CALLE 5 DE FEBRERO #517, SUR LT. 25 MZ. 10, COL.
CENTRO, C.P. 85000, CD. OBREGÓN, SON.
TEL.: [phone]
SUCURSAL VILLAHERMOSA
CALLE HELIO LOTES 1, 2 Y 3 MZ. #1, COL. INDUSTRIAL,
2A ETAPA, C.P. 86010, VILLAHERMOSA, TAB.
TEL.: [phone]
VM ORINGS Y REFACCIONES
CALLE ROSITA #527 ENTRE 20 DE NOVIEMBRE Y GRAL.
RODRÍGUEZ, FRACC. REYNOSA, C.P. 88780, REYNOSA,
TAMS. TEL.: [phone]
SERVICIOS Y HERRAMIENTAS INDUSTRIALES
PABLO SIDAR #132, COL . BARRIO DE SAN BARTOLOMÉ,
C.P. 90970, SAN PABLO DEL MONTE, TLAX.
TEL.: [phone]
LA CASA DISTRIBUIDORA TRUPER
BLVD. PRIMAVERA. ESQ. HORTENSIA S/N, COL.
PRIMAVERA C.P. 93308, POZA RICA, VER.
TEL.: [phone]
SUCURSAL MÉRIDA
CALLE 33 #600 Y 602, LOCALIDAD ITZINCAB Y MULSAY,
MPIO. UMÁN, C.P. 97390, MÉRIDA, YUC.
TEL.: [phone]
15
ESPAÑOL

Notas
14 ESPAÑOL

Notas
13
ESPAÑOL
