Trust ProtoStat Instruction Manual

...ProtoStat Thermostat operation

On/O Button
Decrease the
temperature,
or down button
OK button,
Confirms changes
Shows radiator
warming up
Menu button
for programming
Current time
& date
Increase the
temperature,
or up button
Indicates the current
temperature of the room

SETTING DATE AND TIME
Press the menu button and hold for 3 seconds.
The screen will show 3 options.
1. Set time
2. Timer settings
3. Options
Use the up down buttons to select SET TIME from
the menu and then press the ok button.
The screen will show TIME SET and the day will be flashing.
Use the up and down keys to set the date and then press
okay. The screen then will flash time. Use the up and down
keys to set the date and then press the ok button.
NOTE
When setting the four programme times/temperatures, the
radiator will never actually turn o, only move to the next
temperature setting. If you don’t wish the radiator to come
on, set the temperature to 5˚ (frost setting). This is as low as
the radiator can go and is designed to protect the radiator
and the property

PROGRAMMING TEMPERATURE – Automatic Mode
You can set four dierent programs for each day or you
can set the days of the week the same.
Press the menu button and hold for 3 seconds.
The screen will show 3 options.
1. Set time
2. Timer settings
3. Options
Use the up down buttons to select Timer settings and
then press the ok button. The screen will then flash with:
mon, tue, wed, thur, fri, sat, sun.
If you want to set the temperature & start / finish time the
same for all the days of the week- press the ok button. If
you want to set every day to a dierent start and finish time
use the up down button to select each day then press
the ok button.
Program 1 will then be on the screen with the word TIME
underneath.

Use the up down button to select the first time you
would like the radiator to come on. Once you have the
correct time then press ok.
The word TEMP will then be on the screen - use the
up down button to select the desired temperature.
Then press ok.
Once this has been completed it will ask you to then do
the same for program 2, 3 & 4.
OPTIMISATION MODE
This means the device calculates how long it takes the
room to reach the desired temperature setting. For
example, if you are wanting your room to be at 22
degrees from 08:00 the thermostat will calculate that
due to the temperature in the room it may need to come
on earlier or later to achieve 22 degrees for that time.
If you want to use this feature press the menu button
down for 3 seconds and scroll down to options, then
press ok.
PROGRAMMING TEMPERATURE – Automatic Mode
You can set four dierent programs for each day or you
can set the days of the week the same.
Press the menu button and hold for 3 seconds.
The screen will show 3 options.
1. Set time
2. Timer settings
3. Options
Use the up down buttons to select Timer settings and
then press the ok button. The screen will then flash with:
mon, tue, wed, thur, fri, sat, sun.
If you want to set the temperature & start / finish time the
same for all the days of the week- press the ok button. If
you want to set every day to a dierent start and finish time
use the up down button to select each day then press
the ok button.
Program 1 will then be on the screen with the word TIME
underneath.
