USER MANUAL
Electric Ceramic Cooktop
TTGL2212N TTGL2224N TTGL2230N TTGL2230P

Table of Contents
PRECAUTIONS ..........................................................1
IMPORTANT SAFETY INFORMATION ................ 2
TECHNICAL SPECIFICATIONS ............................. 5
OPERATION ...............................................................8
CLEANING AND MAINTAINANCE .....................12
TROUBLESHOOTING ............................................ 13
WARRANTY ............................................................ 14
READ AND SAVE THESE INSTRUCTIONS

1
PRECAUTIONS
For your safety and correct operation of this appliance, please
read this instruction carefully before installing and using.
Please follow the instruction and advice in the manual. Please
preserve this manual carefully, it will be useful in the future
when facing operation issues.
Safety Definitions
WARNING
Hazards or unsafe practices which COULD result in severe
personal injury or death.
CAUTION
Hazards or unsafe practices which COULD result in minor personal
injury.
WARNING: Read and understand all safety precautions. Failure to
follow all instructions described in this user manual may result in
electric shock, fire and/or serious personal injury. The warnings,
cautions and instructions discussed in this user manual cannot
cover all possible conditions and situations that may occur.
State of California Proposition 65 Warnings:
WARNING: This product may contain a chemical known to the
State of California to cause cancer or birth defects or other
reproductive harm.

2
IMPORTANT SAFETY INFORMATION
WARNING: For your safety and correct operation of this appliance,
please read this instruction carefully before installing and using.
Please follow the instruction and advice in the manual. Please
preserve this manual carefully for future reference.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
WARNING: To reduce the risk of fire, electrical shock, injury to
persons, or damage when using the cooktop, follow basic
precautions, including the following.
CAUTION: DO NOT store items in cabinets above the cooktop that
are of interest to children. Children climbing on the cooktop to reach
items could be seriously injured.
1. Be sure your cooktop is properly installed and grounded by a
qualified technician.
2. DO NOT repair or replace any part of the cooktop unless
specifically recommended in the manual. All other servicing
SHOULD be referred to a qualified technician.
3. Wear proper apparel. Loose-fitting or hanging garments
SHOULD NEVER be worn while using the cooktop.
4. Flammable materials SHOULD NOT be stored near surface units.
5. Only certain types of glass, glass/ceramic, ceramic, earthenware,
or other glazed utensils are suitable for cooktop service without
breaking due to the sudden change in temperature.
6. Utensil handles SHOULD be turned inward and not extend over
adjacent surface units. To reduce the risk of burns, ignition of
flammable materials, and spillage due to unintentional contact with
the utensil, the handle of a utensil SHOULD be positioned so that it
is turned inward, and does not extend over adjacent surface units.

3
7. DO NOT use water on grease fires. Smother fire or flame or use
dry chemical or foam-type extinguisher.
8. NEVER leave surface units unattended at high heat settings.
Boilover causes smoking and greasy spillovers that may ignite.
9. DO NOT leave children alone. Children SHOULD NOT be left
alone or unattended in area where cooktop is in use. They
SHOULD NEVER be allowed to sit or stand on any part of the
cooktop.
10. DO NOT touch surface units or areas near units. Surface units
may be hot even though they are dark in color. Areas near surface
units may become hot enough to cause burns. During and after use,
DO NOT touch, or let clothing or other flammable materials contact
surface units or areas near units until they have had sufficient time
to cool. Among those areas are the cooktop and surfaces facing the
cooktop.
11. Use proper pan size. This cooktop is equipped with one or more
surface units of different size. Select utensils having flat bottoms
large enough to cover the surface unit heating element. The use of
undersized utensils will expose a portion of the heating element to
direct contact and may result in ignition of clothing. Proper
relationship of utensil to burner will also improve efficiency.
12. Use only dry potholders. Moist or damp potholders on hot
surfaces may result in burns from steam. DO NOT let potholder
touch hot heating elements. DO NOT use a towel or other bulky
cloth.
13. DO NOT cook on broken cooktop. If cooktop should break,
cleaning solutions and spillovers may penetrate the broken cooktop
and create a risk of electric shock. Contact a qualified technician
immediately.
14. NEVER use your cooktop for warming or heating the room.
15. Clean cooktop with caution. If a wet sponge or cloth is used to
wipe spills on a hot cooking area, be careful to avoid steam burn.
Some cleaners can produce noxious fumes if applied to a hot
surface. Extreme caution SHOULD be exercised when using
cookware or bakeware constructed of anything other than
ovenproof metal or glass. DO NOT place any of the following
materials in the oven: cardboard, plastic, paper, or anything similar.

4
INSTALLATION
It is recommended that all electrical connections be made by a
licensed, qualified electrical installer.
Model
L
W
H
A
B
X
TTGL2212N
12.0"
21.0"
2.4"
11.1"
20.5"
min 2.0"
TTGL2224N
24.0"
21.0"
2.4"
23.0"
19.7"
min 2.0"
TTGL2230N
30.0"
21.0"
2.4"
28.5"
19.7"
min 2.0"
TTGL2230P
30.0"
21.0"
2.4"
28.5"
19.7"
min 2.0"
CONNECTION CABLE
Cable Connection diagram for model TTGL2212N

5
Cable Connection diagram for model TTGL2224N/ TTGL2230N/
TTGL2230P
TECHNICAL SPECIFICATIONS
Top view (TTGL2212N)
1. Max. 1200W (6.5")
2. Max. 1800W (7.9")
3. Ceramic glass surface
4. Control knobs
5. Touch panel
1. Pause
2. Timer selection
3. Child lock

6
1. 0-90min Timer
2. Power regulating control
3. Burner position indicator
Top view (TTGL2224N)
1. Max. 1200W/2200W (6.5"/7.9")
2. Max. 1200W (6.5")
3. Max. 1800W (7.9")
4. Max. 1200W (6.5")
5. Ceramic glass surface
6. Control knobs
7. Touch panel
1. Pause
2. Timer selection
3. Child lock
1. Power regulating control
2. 0-90min Timer
3. Burner position indicator
4. Timer indicator
5. Dual/Single ring heating switch

7
Top view (TTGL2230N)
1. Max. 1200W/2400W (6.5"/9.1")
2. Max. 1200W (6.5")
3. Max. 1800W (7.9")
4. Max. 1200W (6.5")
5. Ceramic glass surface
6. Control knobs
7. Touch panel
1. Pause
2. Timer selection
3. Child lock
1. Power regulating control
2. 0-90min Timer
3. Burner position indicator
4. Timer indicator
5. Dual/Single ring heating switch
Top view (TTGL2230P)
1. Max. 1200W/2400W (6.5"/9.1")
2. Max. 1200W (6.5")
3. Max. 2000W (7.9")
4. Max. 1200W (6.5")
5. Ceramic glass surface
6. Control knobs
7. Touch panel

8
1. Pause
2. Timer selection
3. Child lock
1. Power regulating control
2. 0-90min Timer
3. Burner position indicator
4. Timer indicator
5. Dual/Single ring heating switch
Technical Data
OPERATION
CHILD LOCK
Lock automatically: After plugging in, the appliance, the Child Lock
will be activated automatically. When timer is not set, after one
minute of no activity, the Child Lock will be activated automatically.
Lock/unlock manually: Press and hold the Child Lock button for 2
second to lock or unlock manually.
Model
TTGL2212N
TTGL2224N
TTGL2230N
TTGL2230P
Heating Elements
2
4
4
4
Voltage
220-240V
220-240V
220-240V
220-240V
Frequency
50-60Hz
50-60Hz
50-60Hz
50-60Hz
Rated Power
Total 3000W
Total 6400W
Total 6600W
Total 6800W
Product Size
12" x 21" x
2.4"
24" x 21" x
2.4"
30" x 21" x
2.4"
30" x 21" x
2.4"
Cutout Size
11.1" x 20.5"
23" x 19.7"
28.5" x 19.7"
28.5" x 19.7"
Gross weight
13.54 Lbs
27.71 Lbs
31.61 Lbs
32.01 Lbs
Net weight
10.93 Lbs
21.10 Lbs
24.29 Lbs
24.69 Lbs

9
Note: This function is to prevent unsupervised children from
operating the cooktop. It is not a malfunction.
POWER SETTING
Turn the knob to the desired temperature, from level 1(minimum) to
level 9(maximum).
TIMER
Press the timer button on the left side of the burner to select the
burner that needs to be timed, after selecting, the timer indicator of
the corresponding burner will light up, then operate the timer knob
to select the time.
To set the timer for other working burners, simply press the
corresponding timer selection button again and set the time.
11 time setting levels: 3 →5→7→10 →15 →20 →30 →45 →
60 →75 →90 minutes.
PAUSE
Press the pause button to pause or continue the current heating
state of the burner (the timer function is also suspended
accordingly).
RESIDUAL HEAT INDICATOR
If the temperature of the surface of the panel is above 140℉/60℃,
a "H" for high temperature will appear on the panel. Please do not
touch the hot burner area.
If the temperature of the surface of the panel is below 140℉/60℃,
the “H”will no longer appear on the panel.
OVERHEAT PROTECTION
If the temperature inside the furnace is higher than the set value
due to poor ventilation or failure of the temperature sensing probe
during continuous heating, the power will be automatically cut off for
safety reasons. When the temperature drops to the set value, it can
work normally when it is reconnected.
AUTO SHUTDOWN
For safety reasons, the electric cooktop will automatically shut
down after 2 hours of continuous operation. After the automatic
shutdown, it can be re-powered to work.

10
HINTS AND TIPS
Cookware made of enamelled steel and with aluminum or copper
bottoms can cause a color change on the glass-ceramic surface.
The bottom of the cookware must be as thick and flat as possible.
Ensure pan bases are clean and dry before placing on the hob
surface
EXAMPLES OF COOKING APPLICATIONS
The data in the table is for guidance only.
COCKWARE
NOTE: Do not leave empty cookware on a hot surface cooking area,
element or surface burner.
Heat setting
Use to:
Time
Hints
(min)
1
Keep cooked food warm.
as nec-
Put a lid on the cookware.
essary
1 - 2
Hollandaise sauce, melt: butter,
5 - 25
Mix from time to time.
chocolate, gelatine.
1 - 2
Solidify: fluffy omelettes, baked
10 -
Cook with a lid on.
eggs.
40
2 - 3
Simmer rice and milkbased
25 -
Add at least twice as much liquid
dishes, heat up ready-cooked
50
as rice, mix milk dishes halfway
meals.
through the procedure.
3 - 4
Steam vegetables, fish, meat.
20 -
Add a couple of tablespoons of
45
liquid.
4 - 5
Steam potatoes.
20 -
Use max. ¼ l of water for 750 g
60
of potatoes.
4 - 5
Cook larger quantities of food,
60 -
Up to 3 l of liquid plus ingredi-
stews and soups.
150
ents.
6 - 7
Gentle fry: escalope, veal cordon
as nec-
Turn halfway through.
bleu, cutlets, rissoles, sausages,
essary
liver, roux, eggs, pancakes,
doughnuts.
7 - 8
Heavy fry, hash browns, loin
5 - 15
Turn halfway through.
steaks, steaks.
9
Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.

11
We recommend that you use only a flat-bottomed wok. The bottom
of the wok should have the same diameter as the surface element
to ensure proper contact.
Do not use woks that have support rings. This type of wok will not
heat on glass surface elements.
Rough finishes may scratch the cooktop. Aluminum and copper
may be used as a core or base in cookware. However, when used
as a base they can leave permanent marks on the cooktop or
grates.
Place only dry pans on the surface elements. Do not place lids on
the surface elements, particularly wet lids. Wet pans and lids may
stick to the surface when cool.
Cookware material is a factor in how quickly and evenly heat is
transferred, which affects cooking results.
NOTE: Please follow manufacturer’s recommendations when using
any type of cookware on the cooktop.
Recommended
Stainless Steel
Aluminum: Heavy weight recommended. Aluminum residues
sometimes appear as scratches on the cooktop but can be
removed if cleaned immediately. Because of its low meltingpoint,
thin weight aluminum should not be used.
Copper Bottom: Copper may leave residues which can appear as
scratches. The residues can be removed, as long as the cooktop is
cleaned immediately. However, do not let these pots boil dry.
Overheated metal can bond to glass cooktops. An overheated
copper bottom pot will leave a residue that will permanently stain
the cooktop if not removed immediately.
Enamel (painted) on Cast Iron: Recommended if bottom of pan is
coated.
Avoid/ Not Recommended
Enamel (painted) on Steel: Heating empty pans can cause
permanent damage to cooktop glass. The enamel can melt and
bond to the ceramic cooktop.
Glass-ceramic: Poor performance. Will scratch the surface.
Stoneware: Poor performance. May scratch the surface.

12
Cast Iron: Not recommended—unless designed specifically for
glass cooktops. Poor conductivity and slow to absorb heat. Will
scratch the cooktop surface.
CLEANING AND MAINTAINANCE
To avoid damage to the cooktop, DO NOT use steel wool, abrasive
powder cleansers, chlorine bleach, rust remover or ammonia.
Always wipe with a clean, wet cloth or sponge and dry thoroughly to
avoid streaking and staining.
Light to Moderate Soil
Paper towels or clean damp sponge.
Sugary Spills (Jellies, Candy, Syrup)
Cooktop Scraper: Clean while the cooktop is still warm. You may
want to wear oven mitts while doing so.
Cooktop Polishing Creme and clean damp paper towel: Clean as
soon as cooktop has cooled down. Rub creme into surface with a
damp paper towel or soft cloth. Continue rubbing until white film
disappears.
Heavy Soil, Dark Streaks, Specks and Discoloration
Cooktop Polishing Creme or nonabrasive cleanser: Rub product
into soil with a damp paper towel or soft cloth. Continue rubbing
until white film disappears.
Burned-On Soil
Cooktop Polishing Creme and Cooktop Scraper: Rub creme into
soil with damp paper towel. Hold scraper as flat as possible on
surface and scrape. Repeat for stubborn spots. Polish entire
cooktop with creme and paper towel.
Metal Marks from Aluminum and Copper
Cooktop Polishing Creme: Clean as soon as cooktop has cooled
down. Rub creme into surface with a damp paper towel or soft cloth.
Continue rubbing until white film disappears. The marks will not
totally disappear but after many cleanings become less noticeable.
Tiny Scratches and Abrasions

13
Cooktop Polishing Creme: Rub creme into surface with a damp
paper towel or soft cloth. Continue rubbing until white film
disappears. Scratches and abrasions do not affect cooking
performance and after many cleanings become less noticeable.
TROUBLESHOOTING
Problem
Cause/ Solution
Entire appliance does not
operate.
Appliance not connected. Make sure
power cord is plugged properly into outlet.
Check your fuse box or breaker box to
make sure the circuit is active.
Electrical power outage. Check house
lights to be sure. Call your local electric
company for service outage information.
The controls are unresponsive.
The controls are locked. Press and hold
the Child Lock button for 2 second to
unlock.
Surface element does not heat
or does not heat evenly.
Be sure the correct surface control knob is
turned on for the element needed.
Cookware is light weight or warped. Use
only flat, evenly balanced, medium or
heavy weight cookware. Flat pans heat
better than warped pans. Cookware
materials and weight of the material affect
heating. Heavy and medium-weight pans
heat evenly. Because lightweight pans
heat unevenly, foods may burn easily.
Excessive heat around
cookware on cooktop.
Unproper cookware size. Use cookware
about the same size as the cooking area.
Cookware SHOULD NOT extend more
than 1/2" (1.3 cm) outside the cooking
area.

14
WARRANTY
TTHOB warrants that the Product is free from defects in materials
and workmanship for a period of three hundred sixty-five (365) days
from the date of purchase. The foregoing timeline begins to run
upon the date of purchase, and shall not be stalled, tolled, extended,
or suspended, for any reason whatsoever. The warranties stated
herein apply only to the first purchaser of the Product and are not
transferable.
This warranty does not cover the following:
1. Damages due to improper delivery, installation or maintenance.
2. Failure of the product if it is abused, misused, modified or used
for other than the intended purpose or used commercially.
3. Replacement of house fuses or resetting of circuit breakers.
4. Damages to the finish of appliance or home incurred during
installation, including but not limited to floors, cabinets, walls, etc.
5. Expenses for making the appliance accessible for servicing, such
as removal of trim, cupboards, shelves, etc., which are not a part of
the appliance when it is shipped from the factory.
6. Incidental or consequential damage caused by possible defects
with this appliance.
7. Cosmetic damage to the glass cooktop such as, but not limited to,
chips, scratches, or baked on residue not reported within 90 days of
installation.
8. Damage to the glass cooktop that are not cleaned according to
the directions in the Owner’s Manual.
9. Damage to the glass cooktop due to impact or misuse.
10. Repairs performed by unauthorized service agents.
11. Damage to the product caused by accident, fire, floods or acts
of God.
EXCLUSION OF IMPLIED WARRANTIES
Your sole and exclusive remedy under this limited warranty shall be
product repair or replacement as provided herein. Any implied
warranties, including the implied warranties of merchantability or

15
fitness for a particular purpose, are limited to one year or the
shortest period allowed by law. TTHOB shall not be liable for
consequential or incidental damages such as property damage and
incidental expenses resulting from any breach of this written limited
warranty or any implied warranty. Some states prohibit the
exclusion or limitation of incidental or consequential damages, or
limitations on implied warranties. This warranty gives you specific
legal rights, and you may also have other rights which vary from
state to state.
IF YOU NEED SERVICE:
1. Before contacting us, please determine whether your product
requires repair. Some questions can be addressed without service.
Please take a few minutes to review the Troubleshooting of this
manual.
2. For Service or Assistance please contact the seller or email us to
[email protected] to request warranty service.

[e-mail]
