OPERATOR’S
MANUAL
MODEL 1305BC
BRUSH CUTTER

COPYRIGHT 2009 by
Turf Teq, LLC
Honey Brook, PA 19344 U.S.A.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmittedinanyformorbyanymeans,electronic,mechanical,photocopying,recording,orotherwise,
without prior written permission of Turf Teq, LLC.
DISCLAIMER: THE INFORMATION IN THIS MANUAL IS PROVIDED TO PROMOTE THE
SAFEUSEOF,ANDASSISTTHEOPERATORINACHIEVING MAXIMUMPERFORMANCE
FROM THE MODEL 1305 BRUSH CUTTER AS DESCRIBED IN THIS MANUAL.

1
TABLE OF CONTENTS
INTRODUCTION 3......................................................................
OWNER ASSISTANCE 4................................................................
WARRANTY AND LIMITATION OF LIABILITY 6...........................................
SAFETY INFORMATION 10..............................................................
PERSONAL SAFETY 10..............................................................
MACHINE SAFETY 10................................................................
INTENDED USE 12.....................................................................
SURVEY THE AREA 12...............................................................
PERSONAL SAFETY DECALS 13........................................................
SAFETY DECAL INFORMATION 14......................................................
SERIAL NUMBER LOCATIONS 15.......................................................
TRACTOR SERIAL/MODEL NUMBER LOCATION 15....................................
ENGINE SERIAL NUMBER LOCATION 15..............................................
BRUSH CUTTER SERIAL NUMBER LOCATION 15......................................
CONTROL LOCATIONS - OVERVIEW 16.................................................
DAILY CHECKS TO PERFORM BEFORE STARTING THE ENGINE 17.......................
CHECK ENGINE OIL LEVEL 17.......................................................
CHECK FUEL LEVEL 17..............................................................
TRANSMISSION OIL LEVEL 17.......................................................
MAIN DRIVE BELT CONDITION 18....................................................
CHECK THAT ALL SHIELDS ARE IN PLACE AND HARDWARE IS TIGHT 18..............
CHECK TIRE PRESSURES 18........................................................
CHECK CLUTCH CABLE ADJUSTMENT 19............................................
CHECK BLADE SHARPNESS 19......................................................
CHECK BLADE NUT TORQUE 20.....................................................
GREASE MACHINE PIVOTS 20.......................................................
GENERAL CONTROLS 21...............................................................
PARK BRAKE (OPTIONAL EQUIPMENT) 21............................................
TRANSMISSION CONTROL LEVER (TOW VALVE) 22...................................
DIFFERENTIAL CONTROL 23.........................................................
BRUSH CUTTER SWING CONTROL 24................................................
PARKING THE MACHINE 27............................................................
ENGINE OPERATION 28................................................................
STARTING A COLD ENGINE 28.......................................................
STARTING A WARM ENGINE 29......................................................
STOPPING THE ENGINE 30..........................................................

2
OPERATING THE DIRECTIONAL SPEED CONTROLS 32..................................
PRELIMINARY STEPS TO MOVING THE MACHINE IN ANY
DIRECTION WITH ENGINE RUNNING 32...............................................
STOPPING MOVEMENT WITH ENGINE RUNNING 33...................................
VARIABLE SPEED CONTROL ADJUSTMENT 34........................................
ADJUSTING THE VARIABLE SPEED CONTROL 34.....................................
FORWARD DIRECTION 35............................................................
REVERSE DIRECTION 35............................................................
OPERATING THE BRUSH CUTTER 36...................................................
STOPPING THE BRUSH CUTTER 36..................................................
SECURING THE BRUSH CUTTER FOR TRANSPORT 37..................................
BRUSH CUTTER SERVICE AND MAINTENANCE SCHEDULE 38...........................
SERVICE 39...........................................................................
ENGINE MAINTENANCE SEE ENGINE MANUFACTURES OWNER’S MANUAL...............
TRANSMISSION OIL LEVEL 39.........................................................
LUBRICATION 40......................................................................
LUBRICATE CONTROL CABLES 42...................................................
LUBRICATE PIVOT POINTS 42........................................................
MAIN DRIVE BELT 43..................................................................
CHECK MAIN DRIVE BELT CONDITION 43............................................
CHECK MAIN DRIVE BELT TENSION 44...............................................
REPLACING THE MAIN DRIVE BELT 45...............................................
INSTALLING THE MAIN DRIVE BELT 48...............................................
CLUTCH CABLE ADJUSTMENT 49...................................................
TRANSMISSION DRIVE BELT 52........................................................
CHECK AND ADJUST TRANSMISSION DRIVE BELT TENSION 52.......................
TRANSMISSION DRIVE BELT REPLACEMENT PROCEDURE 56.........................
REPLACING THE BLADE 63............................................................
BLADE INSTALLATION 65..............................................................
ATTACHING THE BRUSH CUTTER TO THE TRACTOR 66..................................
REMOVING THE BRUSH CUTTER FROM THE TRACTOR 81...............................
END OF SEASON STORAGE SERVICE 84................................................
SPECIFICATIONS 85...................................................................
TROUBLESHOOTING 86................................................................

3
INTRODUCTION
This manual is provided as a guide to help you safely operate the product and to achieve the maximum
performance from your Brush Cutter.
Before operating the Brush Cutter, thoroughly read the entire manual. It is important that you, the operator,
thoroughly understand how to operate the machine and adhere to all safety and operating procedures. Special
attention should be paid to all Safety Precautions which are detailed in this manual.
Instructions were written from the perspective that the operator is standing behind the machine grasping the
handlebars and facing the forward direction of travel.
Some pictures in this manual may show optional equipment installed or may not depict current production.
Please contact Turf Teq, LLC directly if, after reading the manual, you have questions about the safe operation
of this machine.

4
Thank you and congratulations on your purchase of a new Turf Teq Brush Cutter!
We are confident that your Brush Cutter will be one of the most gratifying pieces of equip-
ment you will ever own. As a result of your investment in the Brush Cutter, you will elimi-
nate the need for manual back-breaking work and you will see an increase in productivity.
Your happiness is our goal, so please let us know of any questions or issues you may
have so that we may answer them or address them as quickly as possible. (Please have
your serial number available when you call us). We would also like to hear from you on
how much you enjoy your new Brush Cutter!
Turf Teq, LLC Toll Free (866) 503–TURF

5
Total Customer Satisfaction is our Goal
The Brush Cutter is designed to provide trouble-free operation. To ensure that you are
satisfied with your Brush Cutter, we offer the following Guarantee of Satisfaction:
•The Brush Cutter is GUARANTEED TO THE ORIGINAL PURCHASER FOR ONE
FULL YEAR against defects in materials and workmanship. If you feel that a part is de-
fective, contact us and we replace the defective part and provide repair instructions as
required.
•The engine is guaranteed by the engine manufacturer:
Honda Engine: Two years in consumer use; two years in commercial use
•If your have questions or are not 100% satisfied with your Brush Cutter within the first
30 days of use, call us toll free at 1–866–503–TURF and we will work to answer your
questions and to resolve your concerns.
Please have the following information from your packing slip and from the Brush Cutter
available when contacting our customer service department:
Name of Purchaser
Tractor
Model
Serial Number
Date Purchased
Sales Order Number
Brush Cutter
Model
Serial Number
Date Purchased
Sales Order Number

6
Turf Teq, LLC
WARRANTY AND LIMITATION OF LIABILITY
(Customer Copy -- Page 1)
COVERAGE PROVIDED
Turf Teq, LLC, hereinafter called “Turf Teq” warrants to the original retail purchaser of each new Turf Teq
Product that Turf Teq will replace any part thereof found to be defective in materials or workmanship within
the time periods identified below.
DEFINITION
“Products” are machines, attachments, and Replacement Parts therefore supplied by Turf Teq.
WARRANTY PERIOD
12 months from the date of first retail purchase.
Replacement Parts are warranted for 60 days or to the end of the Warranty Period, whichever is longer.
LIMITATIONS, INCLUDING DISCLAIMER OF IMPLIED WARRANTIES AND CONSEQUENTIAL DAM-
AGES
This warranty gives you specific legal rights and you may also have other rights that vary depending on
state or provincial laws.
Turf Teq does not authorize any person or Dealer to create for it any other obligation or liability in connection
with these Products. TO THE EXTENT ALLOWED BY LAW, ANY IMPLIED WARRANTY OF MERCHANT-
ABILITY OR FITNESS APPLICABLE TO THIS PRODUCT IS LIMITED TO THE STATED DURATION OF
THIS WRITTEN WARRANTY. TURF TEQ IS NOT LIABLE FOR LOSS OF THE USE OF THE PRODUCT,
LOSS OF TIME, INCONVENIENCE, COMMERCIAL LOSS OR CONSEQUENTIAL DAMAGES.
Some states and provinces do not allow limitations on how long an implied warranty will last or the exclusion
or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to
you.
The remedy of repair or replacement of a defective part during the warranty period herein specified shall be
the purchaser’s exclusive remedy.
RIGHT TO MAKE DESIGN CHANGES
Turf Teq reserves the right to make changes in the design and other changes in its Products at any time and
from time to time without notice and without incurring any obligation with respect to any product previously
ordered from it, sold or shipped by it.

7
Turf Teq, LLC
WARRANTY AND LIMITATION OF LIABILITY
(Customer Copy -- Page 2)
The warranty period will begin on the date of first retail sale.
The obligation of Turf Teq to purchase under this warranty is limited to the repair or replacement of
defective parts free of charge using genuine Turf Teq Replacement Parts. Repair or replacement in
accordance with this warranty shall constitute fulfillment of all liabilities of Turf Teq in respect to such
Products.
Your dealer shall review these warranty provisions with the purchaser prior to retail sale, secure his
acknowledgement of delivery of this warranty and record the date of first retail sale.
WHAT IS NOT COVERED BY THE WARRANTY?
This warranty shall NOT apply under the following conditions:
1. With respect to vendor warranty items such as engines, which shall be warranted by their manufac-
turer, or local representative
a. Honda Engines have a 2 YEAR WARRANTY that is covered by American Honda Motor
Corporation.
2. If the Product has been subject to misapplication, abuse, misuse, improper maintenance or other
negligence, fire or other accident.
3. If parts or attachments other than those made or marketed by Turf Teq have been used in connec-
tion with the Product, and in the sole judgment of Turf Teq such use affects its performance, stability
or reliability.
4. If the Product has been altered or repaired in a manner which, in the sole judgment of Turf Teq, af-
fects its performance, stability or reliability.
5. Turf Teq shall have no liability for used equipment sold beyond the specified coverage period.
6. No warranty shall apply to damage resulting from accident or damage caused by environment (such
as exposure to corrosive material). Turf Teq shall not be responsible for any costs relating to rental
equipment used to replace the Product being repaired.
7. The warranty shall NOT apply to normal maintenance services, to normal replacement of service
items, or to normal deterioration due to use or exposure. Turf Teq shall not be responsible for nor-
mal replacement parts such as belts, chains, clutches, filters, oil, brushes, or other parts that are
worn out, unless they are determined by Turf Teq to be defective in material or workmanship.
Customer Signature _______________________
Date of Purchase _______________________
Date of Signature _______________________
Tractor Model Number _______________________
Tractor Serial Number _______________________
Brush Cutter Model Number _______________________
Brush Cutter Serial Number _______________________

8
Turf Teq, LLC
WARRANTY AND LIMITATION OF LIABILITY
(Turf Teq Warranty Registration Copy -- Page 1)
Important: This copy must be completed, signed and returned to Turf
Teq to register the product and activate the warranty.
COVERAGE PROVIDED
Turf Teq, LLC, hereinafter called “Turf Teq” warrants to the original retail purchaser of each new Turf Teq
Product that Turf Teq will replace any part thereof found to be defective in materials or workmanship within
the time periods identified below.
DEFINITION
“Products” are machines, attachments, and Replacement Parts therefore supplied by Turf Teq.
WARRANTY PERIOD
12 months from the date of first retail purchase.
Replacement Parts are warranted for 60 days or to the end of the Warranty Period, whichever is longer.
LIMITATIONS, INCLUDING DISCLAIMER OF IMPLIED WARRANTIES AND CONSEQUENTIAL DAM-
AGES
This warranty gives you specific legal rights and you may also have other rights that vary depending on
state or provincial laws.
Turf Teq does not authorize any person or Dealer to create for it any other obligation or liability in connection
with these Products. TO THE EXTENT ALLOWED BY LAW, ANY IMPLIED WARRANTY OF MERCHANT-
ABILITY OR FITNESS APPLICABLE TO THIS PRODUCT IS LIMITED TO THE STATED DURATION OF
THIS WRITTEN WARRANTY. TURF TEQ IS NOT LIABLE FOR LOSS OF THE USE OF THE PRODUCT,
LOSS OF TIME, INCONVENIENCE, COMMERCIAL LOSS OR CONSEQUENTIAL DAMAGES.
Some states and provinces do not allow limitations on how long an implied warranty will last or the exclusion
or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to
you.
The remedy of repair or replacement of a defective part during the warranty period herein specified shall be
the purchaser’s exclusive remedy.
RIGHT TO MAKE DESIGN CHANGES
Turf Teq reserves the right to make changes in the design and other changes in its Products at any time and
from time to time without notice and without incurring any obligation with respect to any product previously
ordered from it, sold or shipped by it.

9
Turf Teq, LLC
WARRANTY AND LIMITATION OF LIABILITY
(Turf Teq Warranty Registration Copy -- Page 2)
The warranty period will begin on the date of first retail sale.
The obligation of Turf Teq to purchase under this warranty is limited to the repair or replacement of
defective parts free of charge using genuine Turf Teq Replacement Parts. Repair or replacement in
accordance with this warranty shall constitute fulfillment of all liabilities of Turf Teq in respect to such
Products.
Your dealer shall review these warranty provisions with the purchaser prior to retail sale, secure his
acknowledgement of delivery of this warranty and record the date of first retail sale.
WHAT IS NOT COVERED BY THE WARRANTY?
This warranty shall NOT apply under the following conditions:
1. With respect to vendor warranty items such as engines, which shall be warranted by their manufac-
turer, or local representative
a. Honda Engines have a 2 YEAR WARRANTY that is covered by American Honda Motor
Corporation.
2. If the Product has been subject to misapplication, abuse, misuse, improper maintenance or other
negligence, fire or other accident.
3. If parts or attachments other than those made or marketed by Turf Teq have been used in connec-
tion with the Product, and in the sole judgment of Turf Teq such use affects its performance, stability
or reliability.
4. If the Product has been altered or repaired in a manner which, in the sole judgment of Turf Teq, af-
fects its performance, stability or reliability.
5. Turf Teq shall have no liability for used equipment sold beyond the specified coverage period.
6. No warranty shall apply to damage resulting from accident or damage caused by environment (such
as exposure to corrosive material). Turf Teq shall not be responsible for any costs relating to rental
equipment used to replace the Product being repaired.
7. The warranty shall NOT apply to normal maintenance services, to normal replacement of service
items, or to normal deterioration due to use or exposure. Turf Teq shall not be responsible for nor-
mal replacement parts such as belts, chains, clutches, filters, oil, brushes, or other parts that are
worn out, unless they are determined by Turf Teq to be defective in material or workmanship.
Customer Signature ______________________________________________
Date of Purchase __________________________________________________
Date of Signature __________________________________________________
Tractor Model Number _______________ Brush Cutter Model Number____________________
Tractor Serial Number ________________ Brush Cutter Serial Number____________________
Important: This copy must be completed, signed and returned to Turf Teq within
30 days of purchase to register the product and activate the warranty.
RETURN TO: Turf Teq, LLC
699 Todd Road
Honey Brook, PA 19344

10
SAFETY INFORMATION
PERSONAL SAFETY
SAFETY PRECAUTIONS
A careful operator is the best operator. Most accidents can be avoided by observing certain precautions. To
help prevent accidents, read and take the following precautions before operating the machine. Equipment
should be operated only by those who are properly trained.
GENERAL INFORMATION
1. Read the Operator’s Manual carefully before using the machine.
2. Only allow properly trained and qualified persons to operate the machine.
3. Keep safety decals clean.
4. Install shields before starting or operating the machine.
5. Make sure all shields are in place at all times.
6. Do not operate the Brush Cutter over cables, wires, pipes or other objects.
7. Keep people at least 75 feet away from the Brush Cutter when it is in operation.
PERSONAL PREPARATION AND ATTIRE
1. Wear safely glasses while operating the machine to protect your eyes.
2. Wear safety shoes with non-slip treads. Do not go barefoot or wearing open-toed shoes while operating
the machine.
3. Wear long pants
4. Use ear muffs or ear plugs to protect your hearing.
5. Wear gloves.
MACHINE SAFETY
MACHINE PREPARATION
1. Read the Operator’s manual for the machine and engine before operating the machine.
2. Become familiar with the controls BEFORE starting to operate the machine.
3. Inspect the area you will be working in for hidden objects such as large rocks, wires and other obstruc-
tions. Operating the machine over obstacles could damage the machine, cause property damage or
cause personal injury.
4. Wait for the engine to cool before refueling.
5. Fill the gasoline tank with the engine turned off and the machine outdoors.
6. Do not smoke while handling gasoline.
7. Keep any type of open flame away from the machine.
8. Make sure all shields are installed and secured.
9. Remove the spark plug wire from the spark plug before doing any work on the Brush Cutter.
10. Allow the engine and muffler to cool before working around the engine.

11
OPERATING THE MACHINE SAFELY
1. Shut off the engine, place the transmission control lever in the transmission engaged position when the
machine is not in use. Engage the optional park brake if equipped.
2. Do not operate the machine engine in an enclosed building without adequate ventilation.
3. Make sure all shields are in place before starting the machine.
4. Do not leave the attachment in the raised position when the machine is parked.
5. Only allow properly trained personnel to operate the machine
6. Keep bystanders at least 75 feet away from the machine. The Brush Cutter can throw objects at great
speed and strike a bystander. Do not operate the machine when children or pets are in the area.
7. Disengage the main drive and stop the engine when a person or pet approaches the machine closer
then 75 feet.
8. Be sure the main drive and the hydrostatic control are disengaged before starting the engine.
9. NEVER operate the machine without all the shields installed.
10. NEVER reach under the shields when the engine is running.
11. ALWAYS shut off the engine and disconnect the spark plug wire before making any adjustments to the
machine.
12. ALWAYS shut off the engine and disconnect the spark plug wire before cleaning the machine.
13. Operate the machine during daylight hours.
14. Lower the attachment to the ground when the machine is turned off.
15. Keep the machine clean and do not allow combustible materials to accumulate on the machine.
16. Operate slowly on slopes and uneven terrain
17. DO NOT weld, cut, bend or otherwise modify your Turf Teq machine including any shielding. Altering or
modifying your machine will void the warranty and may make the machine unsafe.
18. Make sure you operate at a speed where you have 100% control of the machine at all times.
19. Do not backup unless there is adequate clear space to safely maneuver.
20. Engage the attachment drive before lowering the attachment to the ground and starting forward motion.
21. Keep feet and hands away from rotating components.
SERVICING THE MACHINE SAFELY
1. Stop the engine before performing any service on the machine.
2. Remove the spark plug wire when working on the machine.
3. Wait for the engine and muffler to cool before working around the engine area.
4. Wear thick gloves when checking, changing, sharpening or tightening the blade.

12
INTENDED USE
The Brush Cutter is a machine designed for cutting down large weeds, brush tall grass, saplings up to 1-1/2 inch
thick and other types of growth down to a height of 3-3/4 inches. Growth of 6 inches or less can be cut to 2-3/4
inches.
This machine is not a lawn mower and will not provide the quality of cut achieved with a lawn mower.
The Brush Cutter should not be used in tight confined spaces. It should be operated in rural settings or large
acreages.
WARNING: To prevent personal injury, make certain all tractor and Brush Cutter safety shields are in
place and secure before operating.
SURVEY THE AREA
Take a few minutes to walk around the job site. These few minutes are time well-spent because you can:
1. Look for obstructions. Walk around the job site to spot items that can damage your machine. Remove or
avoid rocks, roots, steel strapping, rope, wire, plastic wrapping, or anything that may hinder or damage your
machine. Remove these items before you start operating.

13
PERSONAL SAFETY DECALS
Thismanualshowsmachinedecalswithsafetymessageson,“WARNING,”and “DANGER.” Thesesafe-
ty messages are intended for your personal safety and those working with you. Please read the safety
messages and the specific information they contain.
WARNING: THE WORD “WARNING” IS USED WHERE THERE IS A POTENTIAL OR HIDDEN HAZARD
WHICH HAS THE POSSIBILITY FOR SERIOUS INJURY OR DEATH IF YOU DO NOT FOLLOW THE OPER-
ATING INSTRUCTIONS FOR YOUR MACHINE. IT IS USED TO WARN OPERATORS AND OTHERS TO EX-
ERCISE EVERY APPROPRIATE MEANS TO AVOID A SURPRISE INVOLVEMENT WITH MACHINERY.
DANGER:THEWORD“DANGER”ISUSEDWHEREYOUAREATRISKOFBEINGKILLEDORSERIOUSLY
INJURED IF YOU DO NOT FOLLOW THE OPERATING INSTRUCTIONS IN CONNECTION WITH A SE-
RIOUS HAZARD.
FAILURE TO FOLLOW THE “WARNING” AND “DANGER INSTRUCTIONS MAY RESULT IN SERIOUS
BODILY INJURY OR DEATH.

14
SAFETY DECAL INFORMATION
The following safety decals were installed on the machine in the areas indicated. They are on the machine for
your safety.
Keep the decals clean and legible at all times.
Located on the control console. Located on the cutting deck.
Located on the cutting deck.

15
SERIAL NUMBER LOCATIONS
TRACTOR SERIAL/MODEL NUMBER
LOCATION
The serial and model numbers are located below the
control panel as shown.
The serial and model numbers will be required when
ordering parts.
For easy reference, enter Model and serial number
on the lines:
Model
Serial Number 1
ENGINE SERIAL NUMBER LOCATION
The Honda engine serial number is located on the
backside of the engine as shown.
The serial number will be required when ordering
parts.
For easy reference, enter the engine manufacturer
and the serial number on these line:
Manufacturer
Serial Number 2
BRUSH CUTTER SERIAL NUMBER
LOCATION
The serial number is located on the left side of the
attachment as shown.
The serial number will be required when ordering
parts.
For easy reference, enter Model and serial number
on the lines:
Manufacturer
Serial Number 3

16
CONTROL LOCATIONS -- OVERVIEW
B
H
C
E
D
A
G
F
A. Hydrostatic transmission control lever
B. Adjustable speed control
C. Throttle control
D. Attachment drive engage/disengage with
brake control lever
E. Swing control lever
F. Transmission engage/disengage (tow
valve) control lever
G. Park brake lever (Optional)
H. Differential lock control lever

17
DAILY CHECKS TO PERFORM BEFORE STARTING THE
ENGINE
NOTE:Perform all checks with the machineon a flat,
level and hard surface
CHECK ENGINE OIL LEVEL
1. Remove the oil dipstick, A.
2. Check the oil level as indicated in the engine
owner’s manual and fill with the recommended
motor oil.
NOTE: OVERFILLING THE ENGINE OIL WILL
CAUSE LOSS OF POWER.
A
4
CHECK FUEL LEVEL
1. Remove the fuel tank cap, A.
2. Fill tank to the bottom of the fuel tank neck.
3. Use minimum of 86 octane gasoline.
4. Wipe any spilled fuel before staring the engine.
DO NOT OVERFILL THE FUEL TANK. OBSERVE
ALL SAFETY STATEMENTS LISTED IN THE
SAFETY INFORMATION SECTION
A
5
TRANSMISSION OIL LEVEL
1. Check that the oil level is to the full line, A, on the
reservoir bottle.
2. Add 10W30 API motor oil as described in the
“Service”sectiontotheleveloftheblacktiestrap.
DO NOT OVERFILL.
A
6

18
MAIN DRIVE BELT CONDITION
1. Remove the belt cover.
2. Inspect the belt for cuts, excessive wear or
damage.
3. Replace belt as required.
4. Replace the belt cover.
7
CHECK THAT ALL SHIELDS ARE IN PLACE
AND HARDWARE IS TIGHT
1. Check the hydrostatic drive belt shield, A.
2. Check the main drive belt shield, B.
3. Front deflector, C.
NOTE: DO NOT OPERATE THE MACHINE WITH
LOOSE OR MISSING SHIELDS. REPLACE MISS-
ING SHIELDS IMMEDIATELY. A
C
B
8
CHECK TIRE PRESSURES
Check tire pressures in the two rear tires and inflate
to 14 psi. The tires may have liquid in them so when
checking the tire pressure, the valve stem, A, should
be located at the top as shown or liquid will escape.
A
9
