TurfPride Tri-Deck FP-3132 User manual

MODEL FP - 3132
Tri-Deck Finishing Mower
Operator‘s Manual
TurfPride
3/2014
ASSEMBLY • OPERATION • MAINTENANCE

CONGRATULATIONS!
You have invested in the best implement of its type on the market today.
The care you give your implement will greatly determine your satisfaction with its
performance and its service life. We urge a careful study of this manual to provide you with a
thorough understanding of your new implement before operating, as well as suggestions for
operation and maintenance.
Should you require additional information or assistance, please contact us
BECAUSE TURFPRIDE MAINTAINS AN ONGOING
PROGRAM OF PRODUCT IMPROVEMENT, WE
RESERVE THE RIGHT TO MAKE IMPROVEMENTS IN
DESIGN OR CHANGES IN SPECIFICATIONS WITH-
OUT INCURRING ANY OBLIGATION TO INSTALL
THEM ON UNITS PREVIOUSLY SOLD.
BECAUSE OF THE POSSIBILITY THAT SOME
PHOTOGRAPHS IN THIS MANUAL WERE TAKEN OF
PROTOTYPE MODELS, PRODUCTION MODELS MAY
VARY IN SOME DETAIL. IN ADDITION, SOME
PHOTOGRAPHS MAY SHOW SHIELDS REMOVED
FOR PURPOSES OF CLARITY. NEVER OPERATE
THIS IMPLEMENT WITHOUT ALL SHIELDS IN PLACE.

FP-31 3 2 Finishing Mower
TABLE OF CONTENTS
SECTION/PARA PAGE
Warranty ................................................2
Dealer Preparation Check List...............3
Safety Precautions.................................4
Federal Laws and Regulations ..............5
I. INTRODUCTION & DESCRIPTION ......6
1-1 Introduction......................................6
1-2 Description.......................................6
II. PREPARATION FOR USE....................7
2-1 Attaching To Tractor .......................7
III.OPERATING INSTRUCTIONS..............8
3-1 General Safety.................................8
RETAIL CUSTOMER’S RESPONSIBILITY
UNDER WARRANTY
It is the Retail Customer and/or Operator’s responsibility to read the Operator’s Manual, to
operate, lubricate, maintain and store the product in accordance with all instructions and
safety procedures. Failure of the operator to read the Operator’s Manual is a misuse of this
equipment.
It is the Retail Customer and/or Operator’s responsibility to inspect the product and to have
any part(s) repaired or replaced when continued operation would cause damage or exces-
sive wear to other parts or cause a safety hazard.
It is the Retail Customer’s responsibility to deliver the product to the authorized
Dealer, from whom he purchased it, for service or replacement of defective parts which are
covered by warranty. Repairs to be submitted for warranty consideration must be made with-
in forty-five (45) days of failure.
It is the Retail Customer’s responsibility for any cost incurred by the Dealer for traveling to or
hauling of the product for the purpose of performing a warranty obligation or inspection.
1
SECTION/PARA PAGE
3-2 Cutting Height Adjustment...............8
3-3 Operation.........................................9
3-4 Transporting ....................................9
IV.MAINTENANCE..................................10
4-1 Maintenance Check List....................10
4-2 Lubrication.........................................10
4-3 Spindle Belt Adjustment....................11
4-4 Spindle Belt Replacement.............11
4-5 Blade Replacement ......................12
4-6 Troubleshooting.............................12
Safety Decals................................13
Torque Specifications....................15
DANGER: Red Background,
White Text - Indicates an imminently
hazardous situation which, if not avoid-
ed, will result in death or serious injury.
This signal word is to be limited to the
most extremesituations.
WARNING: Orange Background,
Black Text -Indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
CAUTION: Yellow Background,
Black Text -Indicates a potentially
hazardous situation which, if not avoid-
ed, may result in minor or moderate
injury. It may also be used to alert
against unsafe practices.
UNDERSTANDING SIGNAL WORDS

LIMITED WARRANTY
Turf Pride warrants to the original purchaser of any new Turf Pride equipment, purchased from an
authorized Turf Pride dealer, that the equipment be free from defects in material and workmanship for a period
of one (1) year for non-commercial, state and municipalities’ use and ninety (90) days for commercial use from
date of retail sale. Model FP-3132 gearboxes are covered by a five (5) year limited warranty period. The obliga-
tion of TurfPride to the purchaser under this warranty is limited to the repair or replacement of defective parts.
Replacement or repair parts installed in the equipment covered by this limited warranty are warranted
for ninety (90) days from the date of purchase of such part or to the expiration of the applicable new equip-
ment warranty period, whichever occurs later. Warranted parts shall be provided at no cost to the user at an
authorized Turf Pride dealer during regular working hours. Turf Pride reserves the right to inspect any equip-
ment or parts which are claimed to have been defective in material or workmanship.
DISCLAIMER OF IMPLIED WARRANTIES & CONSEQUENTIAL DAMAGES
Turf Pride’s obligation under this limited warranty, to the extent allowed by law, is in lieu of all war-
ranties, implied or expressed, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE and any liability for incidental and consequential damages with respect to
the sale or use of the items warranted. Such incidental and consequential damages shall include but not be
limited to: transportation charges other than normal freight charges; cost of installation other than cost
approved by Turf Pride; duty; taxes; charges for normal service or adjustment; loss of crops or any other loss of
income; rental of substitute equipment, expenses due to loss, damage, detention or delay in the delivery of
equipment or parts resulting from acts beyond the control of Turf Pride.
THIS LIMITED WARRANTY SHALL NOT APPLY:
1. To vendor items which carry their own warranties, such as engines, tires, and tubes.
2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident.
3. If parts not made or supplied by Turf Pride have been used in connection with the unit, if, in the sole judge-
ment of Turf Pride such use affects its performance, stability or reliability.
4. If the unit has been altered or repaired outside of an authorized Turf Pride dealership in a manner
which, in the sole judgement of Turf Pride, affects its performance, stability or reliability.
5. To normal maintenance service and normal replacement items such as gearbox lubricant, hydraulic fluid,
worn blades, or to normal deterioration of such things as belts and exterior finish due to use or
exposure.
6. To expendable or wear items such as teeth, chains, sprockets, belts, springs and any other items that in the
company’s sole judgement is a wear item.
NO EMPLOYEE OR REPRESENTATIVE OF TURFPRIDE IS AUTHORIZED TO CHANGE THIS LIMITED
WARRANTY IN ANY WAY OR GRANT ANY OTHER WARRANTY UNLESS SUCH CHANGE IS MADE IN
WRITING AND SIGNED BY TURF PRIDE’S SERVICE MANAGER.
Record the model number, serial number and date
purchased. This information will be helpful to your
dealer if parts or service are required.
MAKE CERTAIN THE WARRANTY INFORMATION
HAS BEEN FILED ONLINE WITH TURF PRIDE
ANDALUSIA, ALABAMA
MODEL NUMBER
SERIAL NUMBER
DATE OF RETAIL SALE
2

DEALER PREPARATION CHECK LIST
Tri-Deck Finishing Mower
FP-313 2
BEFORE DELIVERING MACHINE — The following check list should be completed.
Use the Operator’s Manual as a guide.
1. Assembled completed.
2. Gearboxes filled with oil.
3. All fittings lubricated.
4. All shields in place and in good condition.
5. All fasteners torqued to specifications given in Torque Chart
6. All decals in place and readable. (See decal page.)
7. Overall condition good (i.e. paint, welds)
8. Operators manual has been delivered to owner and he has been instructed
on the safe and proper use of the cutter.
9. Waranty information has been registered online with Turf Pride.
Dealer’s
Signature
Purchaser’s
Signature
THIS CHECKLIST TO REMAIN IN OWNER’S MANUAL
It is the responsibility of the dealer to complete the procedures listed
above before delivery of this implement to the customer.
3

IMPORTANT SAFETY PRECAUTIONS
This symbol is used to call attention to safe-
ty precautions that should be followed by
the operator to avoid accidents. When you
see this symbol, carefully read the message
that follows and heed its advice. Failure to
comply with safety precautions could result
in serious bodily injury.
In addition to the design and configuration of equipment, hazard control and accident prevention are
dependent upon the awareness, concern, prudence and proper training of personnel in the operation,
transport, maintenance and storage of equipment. Lack of attention to safety can result in accident, person-
al injury, reduction of efficiency and worst of all—loss of life. Watch for safety hazards and correct deficien-
cies promptly. Use the following safety precautions as a general guide to safe operations when using this
machine. Additional safety precautions are used throughout this manual for specific operating and mainte
nance procedures. Read this manual and review the safety precautions often until you know the limitations.
1. Read the Operator’s Manual. Failure to read the Operator’s Manual is considered a misuse of this
equipment.
2. Become familiar with all the machine’s controls and all the caution, warning and danger decals
affixed to the machine before attempting to start or operate.
3. Before starting or operating the machine, make a walk around inspection and check for obvious
defects such as loose mounting bolts and damaged components. Correct any deficiency before
starting.
4. Do not allow children to operate the cutter. Do not allow adults to operate it without proper instruction.
5. Do not carry passengers.
6. Keep the area of operation clear of all persons, particularly small children and pets. The operator
should cease mowing whenever anyone comes within the operating area.
7. Clear the work area of objects which might be picked up and thrown.
8. Use a piece of cardboard or wood rather than hands to search for hydraulic leaks. Escaping
hydraulic oil under pressure can penetrate skin. If fluid is injected into the skin, it must be surgically
removed within a few hours by a doctor familiar with this form of injury or gangrene may result.
9. Do not operate without all guards and shields in place and in good condition.
10. Lower implement to ground, stop tractor engine, apply parking brake, and allow blades to com-
pletely stop before leaving the tractor.
11. Keep hands and feet away from blades.
12. This cutter is not to be operated along highways or in any area where people may be present
unless all sides of the unit are enclosed by permanent bands, safety chains or other factory
approved safety shields that are in good repair.
13. Wear personal protective equipment such as, but not limited to, protection for eyes, ears, feet,
hands and head when operating or repairing the equipment. Do not wear loose clothing or jewelry
that may catch on equipment moving parts.
14. When performing adjustments or maintenance on the cutter, first lower it to the ground or block it
securely at a workable height.
15. Never stand between tractor and cutter while tractor is being backed to the cutter hitch.
16. Reduce speed when transporting cutter to avoid bouncing and momentary loss of steering.
17. Use tractor flashing warning lights, day or night, when transporting cutter on road or highways
unless prohibited by law.
18. It is recommended that tractor be equipped with Rollover Protective System (ROPS) and seat belt
be used in all mowing operations.
4

IMPORTANT FEDERAL LAWS AND REGULATIONS* CONCERNING
EMPLOYERS, EMPLOYEES AND OPERATIONS.
*(This section is intended to explain in broad terms the concept and effect of the following federal laws and
regulations. It is not intended as a legal interpretation of the laws and should not be considered as such).
U.S. Public Law 91-596 (The Williams-Steiger Occupational and Health Act of 1970) OSHA
This Act Seeks:
“...to assure so far as possible every working man and woman in the nation safe and healthful working
conditions and to preserve our human resources...”
DUTIES
Sec. 5 (a) Each employer—
(1) shall furnish to each of his employees employment and a place of employment
which are free from recognized hazards that are causing or are likely to cause
death or serious physical harm to his employees;
(2) shall comply with occupational safety and health standards promulgated under
this Act.
(b) Each employee shall comply with occupational safety and health standards
and all rules, regulations and orders issued pursuant to this Act which are
applicable to his own actions and conduct.
OSHA Regulations
Current OSHA regulations state in part: “At the time of initial assignment and at least annually thereafter, the
employer shall instruct every employee in the safe operation and servicing of all equipment with which the
employee is, or will be involved.” These will include (but are not limited to) instructions to:
Keep all guards in place when the machine is in operation;
Permit no riders on equipment;
Stop engine, disconnect the power source, and wait for all machine movement to stop before
servicing, adjusting, cleaning or unclogging the equipment, except where the machine must be
running to be properly serviced or maintained, in which case the employer shall instruct employees
as to all steps and procedures which are necessary to safely service or maintain the equipment.
Make sure everyone is clear of machinery before starting the engine, engaging power, or operating
the machine.
Child Labor Under 16 Years Old
Some regulations specify that no one under the age of 16 may operate power machinery. It is your
responsibility to know what these regulations are in your own area or situation. (Refer to U.S. Dept. of
Labor, Employment Standard Administration, Wage & Home Division, Child Labor Bulletin #102.)
EMPLOYEE TRACTOR OPERATING INSTRUCTIONS:
1. Securely fasten your seat belt if the tractor has a
ROPS.
2. Where possible, avoid operating the tractor near
ditches, embankments, and holes.
3. Reduce speed when turning, crossing slopes, and
on rough, slick, or muddy surfaces.
4. Stay off slopes too steep for safe operation.
5. Watch where you are going, especially at row
ends, on roads, and around trees.
6. Do not permit others to ride.
7. Operate the tractor smoothly - no jerky turns,
starts, or stops.
8. Hitch only to the drawbar and hitch points recom-
mended by tractor manufacturers.
9. When tractor is stopped, set brakes securely and
use park lock if available.
5

SECTION I
INTRODUCTION AND DESCRIPTION
1-1 INTRODUCTION
We are pleased to have you as a Turf Pride
customer. Your FP-3132 Finishing Mower is
carefully designed to give maximum service with
minimum down time. This manual is provided to give
you the necessary operating and maintenance
instructions for keeping your mower in top operating
condition. Please read this manual thoroughly.
Understand what each control is for and how to use
it. Observe all safety precautions decaled on the
machine and noted throughout the manual for safe
operation of implement. If any assistance or addi-
tional information is needed, contact your authorized
TurfPride distributor.
NOTE
All references made to right, left, front, rear, top or
bottom are as viewed facing the direction of travel
with implement properly attached to tractor.
6
The caster wheel arrangement along with the flexi-
ble, floating deck attachment and the standard front
mounted rollers, all work together to give an even
cut and minimizescalping.
NOTE: The inside rear wheel on the wing mower
decks and both the front wheels on the rear mower
deck are rigidly mounted and are not designed to
caster.
Power from the tractor is transmitted through a
telescoping driveline to a belt drive and gearbox
arrangement which allows either wing unit to be fold-
ed up to 30° while still operating. Power is passed to
the spindle housings bya B-section, Kevlar reinforced
belt. Drivetrain protection is provided by belt slip-
page.
1-2 DESCRIPTION
The FP-3132, Figure 1-1, is designed for turf main-
tenance applications where a high quality of cut on
turf grasses is required.
Figure 1-1 FP- 3132
Technical Specifications
Specification FP-3132
Cutting Width . . . . . . . . . . . . . . . . . . . . . . . 11’
Transport Width . . . . . . . . . . . . . . . . . . . . . 78”
Cutting Height. . . . . . . . . . . . . . . . . . . 3/4 to 4-1/2”
Blade Tip Speed (FPM) . . . . . . . . . . . 16,100 FPM
Required Tractor Horsepower . . . . . . . 30 HP min.
Wing Flex . . . . . . . . . . . . . . . . . . . . 30° up, 10° down
Belts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . Kevlar
Driveline Size . . . . . . . . . . . . . . . Cat. IV 80° CV (main),
Cat. III (wing)

2-1 ATTACHING TO TRACTOR
IMPORTANT
(540 RPM only)
The minimum required PTO horsepower is 30
HP for the TD-3132.
A. Adjust tractor drawbar length to dimension
shown in Figure 2-1. Incorrect drawbar length will
change angle of driveline causing possible damage
to constant velocity joint. See tractor operator’s
manual for drawbar adjustment procedure.
WARNING
NEVER STAND BETWEEN TRACTOR
AND MOWER WHILE TRACTOR IS
BEING BACKED TO HITCH.
Figure 2-1 Tractor Drawbar Adjustment
7
E. Connect hydraulic hose to tractor remote
quick couplers.(See tractor dealer if furnished cou-
plers are not correct for your particular tractor) Make
sure hydraulic line is not twisted or kinked.
Figure 2-2 Tongue/Clevis Adjustment
WARNING
USE A PIECE OF CARDBOARD OR WOOD
RATHER THAN HANDS AND WEAR EYE PRO-
TECTION WHEN SEARCHING FOR HYDRAULIC
LEAKS. ESCAPING HYDRAULIC OIL UNDER
PRESSURE CAN PENETRATE SKIN. IF OIL IS
INJECTED INTO SKIN, IT MUST BE SURGICALLY
REMOVED WITHIN A FEW HOURS OR
GANGRENE MAY RESULT.
B. Attach jackstand to frame of cutter. Extend
jackstand to support weight of frame.
C. Connect clevis hitch to tractor drawbar using a
1 inch (25mm) diameter approved pin with lynch pin
retainer or equivalent.
D. Adjust tongue and clevis angle as necessary
to keep mower frame level with ground when
attached to drawbar. (Figure 2-2)
Drawbar
Height
8” - 12-1/2”
12-1/2” - 17”
Above 17”
Clevis
TongueAdjustment (Note Bolt Locations
Pointed Out By Arrows)
SECTION II
PREPARATION FOR USE
NOTE:
FP-3132 units using standard single acting hydraulic cylinders require tractors which are equipped
with a “float” position in their hydraulic systems to allow the wing decks to follow the contour of the
ground. If your particular model tractor does not have a “float” position in its hydraulic system, a
double acting hydraulic cylinder conversion kit should be installed. See your Turf Pride dealer.
Before operation, service all locations outlined in Section 4-2 “Lubrication” and remove transport
lock pins from mower decks as shown in Figure 3-4. Unpin inside wing tires and reposition into a
trailing position and repin in place. Run-in the mower in a static condition at half throttle for 30 min-
utes. Inspect all belts for proper tension; check gearboxes for proper oil level; and check to make
sure blade spindles are not overheating.
NOTE:
Offset drawbar
must be turned
down as shown.
If after turning the offset draw bar downward, there is
less than 7” ground clearance, it should be replaced with
astraight draw bar or theunit cannot be properly leveled.
It is important that the FP be operated in a level posi-
tion. Leveling can be accomplished by adjusting the
implement hitch to the tractor draw bar height and lev-
eling the mowerframe by use of the adjustable jack-
stand.
If after properly leveling the mower deck the draw bar
height is less than 8”, a standard pull pin may be too
long. To prevent turf damage in uneven terrain, the
standard pin should be replaced with a 1 x 5” Grade 5
bolt with locknut securely tightened.

F. Route control chain to convenient location and
fasten to tractor. Be sure excess slack is removed
from the chain to avoid entanglement with tractor
tires or other moving parts. Make sure latch locking
pins are in the stored positions so that latches can
be released by pulling the chain.(Refer to Figures
3-3 and 3-4)
G. Attach driveline to tractor . Pull on each drive-
line section to be sure that yoke locks into place.
H. Securely attach safety tow chain to tractor.
Figure 2-3 Control Chain
SECTION III
OPERATING INSTRUCTIONS
3-1 GENERAL SAFETY
Only qualified people familiar with this operator’s
manual and tractor operator’s manual should oper-
ate this machine. Operator should wear hard hat,
safety glasses and safety shoes. The operator
should read, understand and practice all safety mes-
sages shown on the caution, warning and danger
decals affixed to the mower to avoid serious injury or
death. It is recommended that tractor be equipped
with Rollover Protective System (ROPS) and a seat
belt be used. Before beginning operation, clear work
area of any objects that may be picked up and
thrown. Check for ditches, stumps, holes or other
obstacles that could upset tractor or damage mower.
Always lower mower to ground and allow blades to
come to a complete stop, set parking brake and turn
off tractor engine before leaving tractor operator’s
seat.
NOTE: Before initial operation the FP should be connect-
ed to the tractor for a 30 minute “run in” cycle. During
the “run in” phase, the tractor should be operated at
only half throttle. The “runin” phase will allow belt warm-
up and stretching for proper mowing performance. After
the 30 minute “run in”cycle is complete, ALLbelts
should be inspected for proper tension and if adjust-
ments are necessary, refer to Maintenance Section.
3-2 CUTTING HEIGHT ADJUSTMENT
The mower should be operated at the highest posi-
tion that will give desired cutting results. This will
help prevent blades from striking the ground, reduc-
ing blade wear and undue strain on the machine.
Cutting too much material may leave excess clip-
pings on the surface. The more frequently the grass
is mowed, the better the effect will be.
A. Raise mower off ground enough to remove
caster.
B. Remove pin securing caster stem to caster arm.
Remove caster stem from caster arm.
C. Place amount of spacers on caster stem to
give desired cutting height. With no spacers on the
bottom, a 3/4” cutting height is given. (Figure 3-1)
D. Reinstall caster stem into caster arm. Place
remaining spacers on caster stem above caster arm
and install pin to retain.
E. Repeat operation for all caster wheels. Make
certain all wheels are adjusted to the same height.
THE MOWER CAN FALL FROM HYDRAULIC
SYSTEM FAILURE. TO AVOID SERIOUS
INJURY OR DEATH, SECURELY SUPPORT
MOWER BEFORE WORKING UNDERNEATH.
WARNING
Figure 3-1
Caster Wheel
Spacers
8

3-3 OPERATION
A. Perform BEFORE EACH USE maintenance list
in paragraph 4-1.
B. Standard Models With Single Acting Cylinders -
Start tractor. Lower cutter decks until it is supported by
caster wheels and place hydraulic valve in “float” position.
Models Equipped With Double Acting Hydraulic
Cylinder Conversion Kit - Start tractor. Lower cutter
decks until it is supported by caster wheels and hydraulic
cylinders are fully extended to allow mechanical float to
operate.(Figure 3-2)
C. With tractor at idle speed, engage PTO drive.
Advance throttle to 540 PTO rpm.
D. Place tractor in low gear and begin cutting.
Tractor forward speed should be controlled by gear
selection, not engine speed. For maximum cutting
efficiency, forward speed should allow mower to
maintain a constant maximum blade speed.
If tractor engine or cutter stalls, do not slip tractor
clutch to allow engine to retain speed as this will
exert undue strain on the implement drivetrain.
When stalling occurs, disengage PTO drive, move to
a cut area, set tractor throttle to idle, then re-engage
PTO drive.
DANGER
STAY CLEAR OF ROTATING DRIVELINE. DO
NOT OPERATE WITHOUT DRIVELINE SHIELDS
IN PLACE AND IN GOOD CONDITION. FAILURE
TO HEED THESE WARNINGS MAY RESULT IN
PERSONAL INJURY OR DEATH.
DANGER
STAND CLEAR OF ROTATING CUTTER
BLADES UNTIL ALL MOTION HAS
STOPPED. TO AVOID ACCIDENTAL FALL
AND POSSIBLE INJURY FROM CUTTER,
IT IS RECOMMENDED THAT TRACTOR
BE EQUIPPED WITH ROLLOVER PRO-
TECTIVE SYSTEM AND THAT A SEAT
BELT BE USED FOR ALL OPERATIONS
LUG SPACING
Figure 3-2 Make Sure Cylinders Are Fully Extended
To Allow Decks To Float
Wing CylinderLug Spacing
Rear Cylinder Lug Space
When mowing across slopes, yawing or skewing
may occur as the mower slips sideways which may
cause streaking. In this case, mowing up and down
slopes should be done to eliminate skewing.
3-4 TRANSPORTING
IMPORTANT- Before folding for transport, disen-
gage the PTO and wait for blades to stop. Pull
the latch chain to allow complete folding, then
release the chain to lock decks in the raised
position. These locks also serve the purpose of
limiting the upward flex of the cutter decks dur-
ing operation.
Install pins into the transport lock positions. (Figures
3-3, 3-4, & 3-5) When implement is transported on
road or highway, day or night, use tractor flashing
warning lights unless prohibited by law. The slow
moving vehicle (SMV) sign must be visible from the
rear by approaching vehicles.
Figure 3-3 Center Unit Transport Latch
Pin In “Working” Position Transport Lock Hole
Figure 3-4 Wing Unit Transport Latch
Pins In Transport Positions
Holes For Storing Pins
During Work
9
NOTE: The mower deck transport locking pins provid-
ed on the wing sections (Figure 3-4) MUST be
removed BEFORE operation. Failure to remove these
locking pins will result in front caster wheel damage,
turf damage, and unacceptable mowing performance

SECTION IV
MAINTENANCE
4-1 MAINTENANCE CHECK LIST
Perform scheduled maintenance as outlined below.
Lower implement to ground, turn off tractor, and set
parking brake before doing maintenance inspections
or work. All bolts should be torqued as indicated in
torque chart unless otherwise indicated.
BEFORE EACH USE.
1. Check tractor tire air pressure. Refer to tractor oper-
ator’s manual. Mower transport tire pressure should
be 22 psi; deck tire pressure shouldalso be 22 psi.
2. Check blades and spindles to be sure that no
foreign objects such as wire or steel strapping bands
are wrapped around them.
3. Check blade bolts for tightness. Tighten blade
bolts to 76 ft./lbs.
4. Inspect blades for wear. Replace if necessary
per paragraph 4-5. Use only genuine Turf Pride
replacement parts. If it is necessary to sharpen the
blades, remove the blades from the spindles before
sharpening. DO NOT sharpen blades while still
attached to mower.
5. Make certain all shields are in place and in
good condition. Repair or replace any missing or
damaged shields.
6. Inspect wheel(s) for wear, damage or foreign
objects. Repair or replace if necessary.
7. Perform BEFORE EACH USE lubrication per
paragraph 4-2.
8. During operation, listen for abnormal sounds
which might indicate loose parts, damaged bearings,
or other damage. Correct any deficiency before con-
tinuing operation.
AFTER EACH USE
1. Clean all debris from machine especially under-
side of deck, underneath belt shield and off safety
decals. Replace any missing or illegible decals.
2. Inspect cutter for worn or damaged compo-
nents. Repair or replace before next use. Any
replacement components installed during repair shall
include the components’ current safety decals speci-
fied by the manufacturer to be affixed to the compo-
nent.
3. Store cutter in a dry place.
40 HOURS
1. Check belt for proper tension. Refer to para-
graph 4-3.
WARNING
THE MOWER CAN FALL FROM HYDRAULIC
SYSTEM FAILURE. TO AVOID SERIOUS
INJURY OR DEATH, SECURELY SUPPORT
MOWER BEFORE WORKING UNDERNEATH.
4-2 LUBRICATION(Figures 4-1A, B & C)
NOTE
The multi-purpose grease referenced in this section
is an NLGI Grade 2 type grease. Figure 4-2 shows
the necessary position for servicing wing drivelines.
BEFORE EACH USE
1. Driveline Universal Joints - Apply multi-purpose
grease with grease gun.
2. Driveline Guard - Apply 2-3 shots of multi-pur-
pose grease with grease gun to plastic fitting.
3. Wheels - Apply multi-purpose grease with
grease gun.
4. Caster Pivot - Apply multi-purpose grease with
grease gun.
5. Constant Velocity (CV) Joint - Position CV joint
as straight as possible to be sure grease will pene-
trate to ball joint. Lubricate the central body with a
minimum of 30 shots of grease every 8 hours.
Lubricate telescoping members with 10 shots every
8 hours and every 40 hours pull the two sections
apart, apply thin coat of multi-purpose grease to
outside of inner (male) section and reassemble.
6. Gearboxes (5) - Add EP80W-90 gear oil, if nec-
essary, to bring oil level to check plug or dip stick
mark.
20 HOURS
7. Deck Drivelines - Disconnect PTO driveline,
pull the two sections apart, apply thin coat of multi-
purpose grease to outside of inner (male) section.
Reassemble sections and install. Pull each section
to be sure driveline and shields are securely con-
nected. Make certain PTO shielding is in good con-
dition.
40 HOURS
8. Wing Pivots - Apply 5 shots of multi-purpose
grease with grease gun.
9. Cylinder Rod Lugs - Apply 5 shots of multi-pur-
pose grease with grease gun.
10. Deck Pivots - Apply 5 shots of multi-purpose
grease with grease gun.
11. Spindle Assembly - Apply 3-5 shots of multi-
purpose grease with grease gun.
END OF SEASON
12.Transport Wheel Bearings - Pack transport
wheel bearings with grease at end of each mowing
season.
10

Figure 4-1 B (5) 30 Shots Before Each Use
(1) 3 Shots Before Each Use
(5) 10 Shots Before Each Use -
(Access through holes in shields of
telescoping driveline)
(9) 40 Hrs
6) Before Each Use
(3) Before
Each Use
(4) Before Each Use (10) 40 Hrs
(12) End Of Season (8) 40 Hrs
Figure 4-1 C
4-3 SPINDLE BELT ADJUSTMENT
Belt tensions should be checked every 40 hours to
get maximum life from drive belts and best perfor-
mance from the cutter. Belt tension is adjusted by
increasing or decreasing the length of the spring on
the moveable idlers. For proper belt tension on
the mower, the spring lengths should be set at 2-
7/8”. (Figure 4-2) To adjust the spring length, loosen or
tighten the 1/2” hex nuts on the spring adjustment rod
until the correct spring length is reached.
4-4 SPINDLE BELT REPLACEMENT
Use only genuine Turf Pride replacement parts.
A. Flip up black latches and remove right and left
side shields. To remove the outside shields on the
wing cutter decks, the wings must be in the folded
position.
B. Relieve spring tension by loosening the two 1/2”
hex nuts on each spring adjustment rod. (Figure 4-2)
C. Remove old belt.
D. Install new belt as shown below. (Also refer to
the decal on underside of belt shield)
1. Disconnect the adjustment rod from the idler
assembly. (Figure 4-2)
2. Place belt into the groove on the driving
sheave.
3. Work the belt over the other sheaves.
4. Connect the adjustment rod and the idler
assembly.
5. Tighten the compression springs on the
drive to 2-7/8” long. Tighten the jam nut on the
adjustment rod.
6. Replace all shields before operating machine.
Figure 4-2 Spindle Belt Diagram
Adjustment Rod
& Spring Idler Assembly
Driving Sheave
At Gearbox
2-7/8”
11
(10) 40 Hrs
Figure 4-1A
(2) Before Each Use
(1) Before Each Use
To Remove Shield: Turn slotted head 90° with screwdriver,
remove turn screw and slide coverback.
(11) 40 Hrs

4-5 BLADE REPLACEMENT
A. Raise cutter using tractor hydraulic system
and use transport locks before changing blades.
B. Turn off tractor, set parking brake and
remove key.
WEAR HEAVY WORK GLOVES TO PRO-
TECT HANDS FROM SHARP EDGES.
WHEN TURNING BLADES, BE AWARE
OF OPPOSITE BLADE APPROACHING.
CAUTION
4-6 TROUBLESHOOTING
Troubleshooting procedures are listed in Table 4-1 below. If the problem cannot be solved or replacement parts
are necessary, contact your authorized Turf Pride dealer. Please have ready your machine name, model num-
ber, serial number, purchase date and exact cause or description of problem.
Table 4-1 Troubleshooting
PROBLEM PROBABLE CAUSE REMEDY
Uneven Cut Cutter not level side to side See SECTION III.
or front to rear.
Belt slipping. Adjust belt per paragraph 4-3.
Worn or bent blade(s). Replace blade(s).
Streaking or Windrowing Possible build-up of Clean cutter.
material under cutter.
Cutter not level. See SECTION III.
Worn blades. Replace blades.
Belt slipping. Adjust belt per paragraph 4-3.
Mowing across slopes Mow up and down slopes
Noisy Cutter Loose components. Check all bolts for tightness.
Low oil in gearbox. Check oil per paragraph 4-2.
Rapid Blade Wear Blade contacting Adjust cutting height to
(cutting edge) ground. eliminate ground contact.
Rapid Blade Cutter not being Set tractor throttle for
Wear operated at rated PTO speed. proper PTO speed.
Use lower gear.
Cutter Vibrating Cutter not being operated Set tractor throttle for
at rated PTO speed. proper PTO speed.
Blade(s) bent. Replace blades.
Foreign object wrapped Remove object.
around spindle or blade.
C. Remove bolt and Belleville washer securing
bottom blade to spindle. Remove blade. Shaft wash-
er will come off with the blade.
D. Install the blade washer over the spindle
shaft. Install the blade and torque the 1/2” - 20UNF
Gr. 8 bolt to 76 ft./lbs. Note: The concave side of
the belleville washer must be toward the blades.
Do not substitute with a flat washer.
12

IMPLEMENT CAN FALL FROM HYDRAULIC
SYSTEM RELEASE. TO AVOID SERIOUS
INJURY OR DEATH:
•
SHUT OFF TRACTOR ENGINE, REMOVE KEY, SECURE
TRACTOR PARKING BRAKE AND BLOCK UP OR SECURELY
SUPPORT IMPLEMENT BEFORE WORKING UNDERNEATH.
•
STAND CLEAR IF LOWERING OR RAISING IMPLEMENT.
50042284
SAFETY DECALS
To promote safe operation, Turf Pride supplies safety decals on all products manufactured. Because damage
can occur to safety decals either through shipment, use or reconditioning, Turf Pride will, upon request, provide
safety decals for any of our products in the field at no charge. Contact your authorized Turf Pride dealer for
more information.
13
50012616
DANGER
KEEP AWAY!
SHIELD MISSING FROM THIS AREA
TO AVOID SERIOUS INJURY OR DEATH,
DO NOT OPERATE WITHOUT THIS AND
ALL OTHER SHIELDS IN PLACE AND IN
GOOD CONDITION. 50012616
IMPLEMENT CAN FALL FROM HYDRAULIC
SYSTEM RELEASE. TO AVOID SERIOUS
INJURY OR DEATH:
•
SHUT OFF TRACTOR ENGINE, REMOVE KEY, SECURE
TR ACTOR PARKING BRAKE AND BLOCK UP OR SECURELY
SU PPORT IMPLEMENT BEFORE WORKING UNDERNEATH.
•
STAND CLEAR IF LOWERING OR RAISING IMPLEMENT.
50042284
50042284
50042281
50042289
50042282
50042283
50012615

DECALS CONTINUED
14
83343
78786
78608
50042286
50042285
50042286

BOLT DIAMETER
WRENCH (IN.) “B” AND SAE SAE SAE
SIZE (IN.) “A” THREAD SIZE GRADE 2 GRADE 5 GRADE 8
7/16 1/4 - 2O UNC 6 (7) 8 (11) 12 (16)
7/16 1/4 - 28 UNF 6 (8) 10 (13) 14 (18)
1/2 5/16 - 18 UNC 11 (15) 17 (23) 25 (33)
1/2 5/16 - 24 UNF 13 (17) 19 (26) 27 (37)
9/16 3/8 - 16 UNC 20 (27) 31 (42) 44 (60)
9/16 3/8 - 24 UNF 23 (31) 35 (47) 49 (66)
5/8 7/16 - 14 UNC 32 (43) 49 (66) 70 (95)
5/8 7/16 - 20 UNF 36 (49) 55 (75) 78 (106)
3/4 1/2 - 13 UNC 49 (66) 76 (103) 106 (144)
3/4 1/2 - 20 UNF 55 (75) 85 (115) 120 (163)
7/8 9/16 - 12 UNC 70 (95) 109 (148) 153 (207)
7/8 9/16 - 18 UNF 79 (107) 122 (165) 172 (233)
15/16 5/8 - 11 UNC 97 (131) 150 (203) 212 (287)
15/16 5/8 - 18 UNF 110 (149) 170 (230) 240 (325)
1-1/8 3/4 - 10 UNC 144 (195) 266 (360) 376 (509)
1-1/8 3/4 - 16 UNF 192 (260) 297 (402) 420 (569)
1-5/16 7/8 - 9 UNC 166 (225) 430 (583) 606 (821)
1-5/16 7/8 - 14 UNF 184 (249) 474 (642) 668 (905)
1-1/2 1 - 8 UNC 250 (339) 644 (873) 909 (1232)
1-1/2 1 - 12 UNF 274 (371) 705 (955) 995 (1348)
1-1/2 1 - 14 UNF 280 (379) 721 (977) 1019 (1381)
1-11/16 1-1/8 - 7 UNC 354 (480) 795 (1077) 1288(1745)
1-11/16 1-1/8 - 12 UNF 397 (538) 890 (1206) 1444 (1957)
1-7/8 1-1/4 - 7 UNC 500 (678) 1120 (1518) 1817 (2462)
1-7/8 1-1/4 - 12 UNF 553 (749) 1241 (1682) 2013 (2728)
2-1/16 1-3/8 - 6 UNC 655 (887) 1470 (1992) 2382 (3228)
2-1/16 1-3/8 - 12 UNF 746 (1011) 1672 (2266) 2712 (3675)
2-1/4 1-1/2 - 6 UNC 870 (1179) 1950 (2642) 3161 (4283)
2-1/4 1-1/2 - 12 UNF 979 (1327) 2194 (2973) 3557 (4820)
TORQUE SPECIFICATIONS
Proper toque for American fasteners used on equipment.
Recommended Torque in Foot Pounds (Newton Meters).*
Proper torque for metric fasteners used on equipment.
Recommended torque in foot pounds (newton Meters).*
WRENCH BOLT
SIZE DIA. ASTM ASTM ASTM ASTM
(mm) “A” (mm) “B” 4.6 8.8 9.8 10.9
851.8 (2.4) 5.1 (6.9) 6.5 (8.8)
10 6 3 (4) 8.7 (12) 11.1 (15)
13 8 7.3 (10) 21.1 (29) 27 (37)
16 10 14.5 (20) 42 (57) 53 (72)
18 12 25 (34) 74 (100) 73 (99) 93 (126)
21 14 40 (54) 118 (160) 116 (157) 148 (201)
24 16 62 (84) 167 (226) 181 (245) 230 (312)
30 20 122 (165) 325 (440) 449 (608)
33 22 443 (600) 611 (828)
36 24 211 (286) 563 (763) 778 (1054)
41 27 821 (1112) 1138 (1542)
46 30 418 (566) 1119 (1516) 1547 (2096)
*Use 75% of the specified torque value for plated
fasteners. Use 85% of the specified torque values
for lubricated fasteners.
Numbers appearing on bolt heads
indicate ASTM class.
METRIC
AMERICAN
Bolt Head Markings
Wrench
Size “A”
Bolt
Diameter “B”
SAE Grade 8
(6 Dashes)
SAE Grade 2
(No Dashes)
SAE Grade 5
(3 Dashes)
Wrench
Size “A” 8.8
Bolt
Diameter “B”
15

Turf Pride LLC.
