Turn Key BC1C User manual

BC1C Battery-Powered
Camera
Hassle-free home protection
supported by extended battery life.
The BC1C is a 100% wire-free rechargeable camera that delivers
well-rounded home protection for up to 210 days on one single
charge. It can be simply installed anywhere for enhanced security,
inheriting EZVIZ's core technologies of color night vision,
two-way talk, active defense and more with magnetic mount.
Color Night Vision
Active Defense
Accurate Human
Motion Detection
Two-Way Talk
1080p Video
7,800 mAh
Rechargeable
Lithium Battery
IP66 Dust and
Water Protection
H.265 Video
Compression
Works with
EZVIZ Solar Panel
for battery charging
Customizable
Voice Alerts
Supports
2.4 GHz Wi-Fi
Built-in 32 GB
eMMC storage

Equipped with a 7,800 mAh rechargeable battery, the BC1C can last for
up to 210 days* on one full battery charge, ensuring stable performance
all day and night. It can also be connected to EZVIZ Solar Panel
to get powered directly.
Long-lasting battery life
for extended peace-of-mind.
Thanks to two built-in spotlights, the BC1C
can render vivid color imaging even in
pitch-black darkness. This allows you to see
crucial details that would otherwise be lost.
Vivid night vision.
*Data comes from strict tests in the EZVIZ lab, under standard conditions.
*Please note that the solar panel is sold separately.
Color Night Vision Black and White Night Vision

Integrating a PIR sensor and the person-shape detection
algorithm, the BC1C camera is intelligent enough to distinguish
persons from other moving objects, keeping you safe while
also reducing unwanted notifications.
Motion alerts are more accurate
than ever.
Users can set specific time frames for detection. Once the
camera detects a person-shape, the BC1C will automatically
set off a siren and flash two spotlights* to let them know
they have been detected.
A vigilant guard over your property.
*The spotlights will not flash when color night vision mode is enabled.
03-09-2021 09:41:30

A thoughtful product by design, the BC1C allows you to
create unique voice messages* for greeting or deterrence.
Customizable voice messages.
Hello! Welcome!
*Supports recording three 10-second audio messages.
See and hear what’s going on and chat with your
visitors—all with a tap on the EZVIZ App!
Talk as if you were there.

The BC1C camera features an IP66 enclosure, offering high
levels of protection against dust and water and delivering
long-lasting protection in even the toughest weather conditions.
Built to last.
Featuring a large battery, Wi-Fi connectivity, and a
magnetic base, the BC1C camera requires exactly
zero professional help in installation. Simply attach
the camera to any metallic surface and it is good to go!
Fast and easy wire-free setup.
*Screw Base is also included as an additional installation option for you
to screw the camera firmly onto the wall.

The BC1C camera features the advanced H.265 video
compression technology, achieving better video quality with
only half the bandwidth and half the storage space required
by the previous H.264 video compression standard.
BC1C helps you save money on
storage and bandwidth. Storage
H.265
H.264
H.265
H.264
Bandwidth
The BC1C is embedded with 32 GB eMMC storage capacity, which means you
no long need to go through any hassle or spend extra money on expansive storage
cards. You can also choose to save your data onto the EZVIZ CloudPlay upon
service subscriptions, for additional protection in case of device damage or loss.
An affordable product with free,
built-in storage capacity.
Built-in 32 GB
eMMC Storage
Supports
EZVIZ CloudPlay Storage*
*Cloud storage service is only available in certain markets. Please verify the availability before making any purchase.�

Specifications Model CS-BC1C
Camera Parameters
Image sensor 1/2.8” 2-Megapixel Progressive Scan CMOS Sensor
Minimum Illumination 0.2 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed Self-adaptive shutter
Lens 2.8 mm @ F1.6;125° (Diagonal), 107° (Horizontal)
Lens Mount M12
Day & Night IR-cut filter with auto switch
DNR 3D DNR
Night Vision 10 m
Storage
Local Storage Build-in 32GB eMMC Storage
Cloud Storage EZVIZ cloud storage
Function
Smart Alarm AI Human Detection
Customized Alert Area Supports
Two-way Talk Supports
General Function Anti-Flicker, Heart Beat, Password Protection,
Watermark
Video & Audio
Max Resolution 1920 × 1080
Frame Rate 50Hz @ 25fps, 60Hz @ 30fps. Self-Adaptive during
network transmission
Video Compression H.265 / H.264
Video Bit Rate Ultra-HD; HD; Standard. Adaptive bit rate.
Audio Bit Rate Self-Adaptive
Max. Bitrate 2Mbps
Network
Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20MHz
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11Mbps,11g:54Mbps,11n:72Mbps
Wi-Fi Pairing AP pairing
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol
Minimum Network Requirement 2Mbps

General
Operating Conditions -20°C to 50°C (-4°F to 122 °F ), Humidity 95% or less
(non-condensing)
IP Grade IP 66
Power Supply DC 5V/2A
BatteryCapacity 7800 mAh
Power Consumption Max. 5W
Product Dimensions 104.76 × 62.80 × 62.80 mm (4.12 × 2.47 × 2.47 inch)
Packaging Dimensions 186.0 × 103.0 × 103.0 mm (7.3 × 4.0 × 4.0 inch)
Weight Product: 365 g (12.8 oz)
With Package: 835 g (28.4 oz)
Specifications Model CS-BC1C

In the box:
- BC1C Camera
- Magnetic Base
- Screw Base
- Power Adapter
- USB Cable
- Mounting plate
- Drill template
- Screw Kit
- Regulatory Information
- Quick Start Guide
CE/FCC/WEEE/ROHS/REACH/UL
Certifications:
https//www.turnkey.net/BC1C.pdf
