Hot Dog Grill User Manual
HOT DOG GRILL
User Manual
1
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM

Hot Dog Grill User Manual
Please read this manual carefully before using the machine.
Thanks for purchasing and using our Hot Dog Grill. In order to make full use of the function of this
product and minimize unnecessary loss and damage, please read the manual carefully and keep it
well for future reference.
Warning:
Any refitting and wrong installation, adjustment and maintenance can lead to property loss and
casualty. Please ask qualified people to install or service it.
Do not put any flammable liquid, gas or other objects around the product for your safety sake.
1. Brief Introduction
1.1 The hot dog grill has 5 rollers, 7 rollers, 9 rollers, and 11 rollers. Each one is controlled by 2
proportional controllers. One proportional controller controls front part of rollers, and the other one
controls rear part of rollers. There is one grid in drip tray. The ready hot dog can be put onto the
grid to keep warm. It also can be equipped with a cover to keep hot dogs sanitary. When you
purchase this equipment, you can purchase the cover too, or you can select not to purchase it.
1.2 Structure
1.3 Technical parameter
2. Transportation and storage
During transportation, the machine should be careful handled and prevent from shaking. The
packaged machine should not be stored in open air long. It should be put in a ventilated warehouse
without causticity gas. And it should not be put up side down. If it needs to be stored in open air
temperately, measurement against raining is needed.
3. Precautions:
a) The voltage for using this product must be coordinated with the supplied voltage.
b) The proper power outlet and fuse should be installed near the product and ground connection
should be installed according to safety regulation.
Model
Dimension (mm)
Voltage (V)
Power (W)
Hot dog QTY (pcs)
TT-R4
580x225x222
220-240V,50/60Hz
400
12
TT-R5
580x305x222
220-240V,50/60Hz
560
18
TT-R6
580x385x222
220-240V,50/60Hz
720
24
TT-R7
580x465x222
220-240V,50/60Hz
880
30
2
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM

Hot Dog Grill User Manual
c) The installation of electrical connection and maintenance should be done by professionals or
qualified electrician.
d) The temperature for working environment is at the range from 0 to 35 degree centigrade.
4. Instructions
a) Fix and level the product and add little eating oil at two sides of roller for lubricate and steady
rolling.
b) Switch on power and turn on the “ROTATION” switch and roller rotates.
c) Broil the sausages: Put certain amount of sausages on the rollers in the light of specific
customer needs. Turn the front temperature switch in clockwise direction will switch on the first (3
rollers HD-05S/ 4 rollers HD-07S / 5 rollers HD-09S / 6 rollers HD-11S), other rollers are controlled
by the rear temperature switch.
d) Temperature switch: when the temperature of rollers reaches the set temperature, the
Temperature switch will automatically cut off; it also will automatically switch on as the temperature
lower than the set temperature. In this way, the Hot Dog Grill maintains certain temperature so as
the food be broiled in stable quality. (Suggestion: set the temperature as 1.5 ~2 when broils
sausage)
e) It is not necessary to reheat the broiled sausages and just put them on the rollers (the
temperature switch must be off)
f) Put the broiled sausages on the grid under the rollers that can keep the sausages warm.
g) Cut off the power when finished the work.
5. Cleaning and Maintenance
a) Cut off the power when cleaning or maintaining the equipment in case of electric accidents.
b) To maintain hygiene presentation, please use fabric material to clean the rollers on completion
of work. Water washing is forbidden in case of short circuit and other electric accidents.
6. Circuit diagram
3
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM

Hot Dog Grill User Manual
TT-R4:
TT-R7:
4
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM

Hot Dog Grill User Manual
7. Exploded View
25 22
21
19
18
10
13 15
14
20
11 12
06
07
08
26
24
04
03
05
01
02 27
28
29
30
31
17
16
23
09
Bill of Materials TT-R7
S/N
Description
Spec.
QTY
S/N
Description
Spec.
QTY
1
Screw
M4*8
17
18
Screw
M4*16
4
2
Bottom plate
475*408
1
19
Screw
M5*12
1
3
Foot
Rubber￠
30*30
4
20
Motor sprocket
wheel
1
4
Frame
580*465*225
1
21
Exterior anti-vibrat
ion pad
￠16*10
4
5
Side plate
443*183
2
22
Interior anti-vibrati
on pad
￠16*5
4
6
Insulation plate
395*75
2
23
Motor
1
7
Left
442*67*12
1
24
Light
Yellow
2
8
Left upper cover
plate
442*25*12
1
25
Dial
￠58
2
9
Power cord jacket
plastic
1
26
Knob
￠41
2
10
Power cord
1
27
Proportional
controller
2
11
Pipe sleeve
￠38*6.2
22
28
Screw
M4*6
4
12
Plastic sleeve
￠38*4.4
22
29
Switch
1
13
Stainless steel
pipe with
sprocket wheel
￠29*505
11
30
Oil tray
474*439*
20
1
14
Heater
11
31
Grid
465*424
1
15
Fixing plate for
heater
448*73*20
1
16
Chain
1
5
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM

Hot Dog Grill User Manual
17
Flat washer
￠16*￠5
4
8. Trouble shooting
Troubles
Checks
Roller out of rotation
Whether the power is connected
Whether the power is on
Roller out of heat
Whether the power is connected
Whether the power is on
Whether the temperature is set too low
