TYG SBWPI05BC User manual

Compact Installation Loudspeaker
USER'S MANUAL
SBWPI05BC/WC

Catalogue
Important Precautions 2
Product maintain 2
Product introduction 2
Application range 2
Use explainer 3
Specification 4
Dimension 4
Product curve picture 5
……………………………………………………………
…………………………………………………………………
………………………………………………………………
…………………………………………………………………
………………………………………………………………………
………………………………………………………………………
…………………………………………………………………………
……………………………………………………………
1

Product introduction:
Full frequency loudspeaker.
With a 5in full frequency unit.
Cover angle 0 x120
Computer optimization simulation design to gain good frequency response
and phase characteristics
High-quality music playback
aterproof, moisture-proof, easy lifting
00
1
2
312
4
5
6 Non-w
）
）
）
）
）
）
Application range:
Apply to full range audio sound reinforcement, meeting rooms, shopping
malls, bars and other public places fixed installation.
tdoor use.
1
2In
）
）
Thank you very much for buying SBWPI05 loudspeaker. To make you know more
how to use our products, please study this user manual before using and keep it for
reference in the future.
Important precautions
To prevent damage of the equipment, please use the accessories we
provide and install it according to direction in this user manual.
Don't use any incomplete, corroded, deformed accessories to install the
equipment. Installation or suspension can only use the accessories/stand
of our company, please contact the local dealer to buy.
When you need to long term suspension of the equipment, please make
sure there is adequate capacity suspension point to support the equipment.
The suspension point must can load at least 10 times the weight of the
equipment.
To make sure there is enough margin, please make sure the power of the
amplifier pushing the loudspeaker is 1.5 times of the loudspeaker.
Product maintain
1 Regularly check all locking pins and fixation to ensure that they are not
rusty or damaged. Damaged parts must be replaced. Please contact your
local dealer to replace the parts.
The speaker unit can be replaced by removing the net. Please note that
when remove the nets, do not make the net distorted or deformed.
The speaker components can use half wet towel to wipe clean.
Forbid using alcohol, gas oil or corrosive chemical composition liquid to
clean the cabinet. Avoid the box near the heat source.
When use the loudspeaker outdoor, please make sure that there is
adequate protection to prevent water droplets splashing into the cabinets.
To prevent equipment damage and possible danger which may caused by
the suspension, we strongly suggest you to employ the qualified technique
person to hang it.
）
1
2
3
4
2
3
4
5
）
）
）
）
）
）
）
）
2

Use explainer
3
Loudspeaker hanging bracket installation steps
1.
2.
3.
4.
5.
6.
7.
：
Install the rear panel of the stand in the wall.
Take out two mounting screws at the bottom of the loudspeaker out.
Install the front arm and fix with screws.
Insert the fixed front arm of the loudspeaker stand into the rear panel fixed
in the wall.
Tighten the screws on the front arm to complete the installation.
Loose the adjustment screw of the front arm to adjust the vertical and
horizontal of the loudspeaker to achieve the required angle degree,
and then tighten the screw.
Ceiling suspension can also use the same steps from 1-6.
12 3
456

Specification
Items Technic specification
Peak power
Speaker components LF:1 5in woofer, 25mm(1in) voice coil dia
HF:N/C
Rated power(RMS) 10-40W
80W
Sensitivity(1W/m)
MAX.SPL
Rated impedance
Frequency range
Crossover frequency
Dispersion angle
Cabinet
Grille
92dB
108dB
4 ohms
150Hz-17KHz
N/C
H=120 V=120
00
Polystyrene
Power coated perforated aluminum,
with acoustically
Input method Clip terminal 1
5Kg/prs
3.5Kg/prs
Shipping weight
Net weight
Product Dimensions(H W D) 154x230x140mm
Packing Dimensions(H W D) 300x250x470mm
4
We reserve the right to make changes in above specifications without
prior notice.
Dimension
Top
Front
Left Right After
Bottom
230 mm
154mm 140mm

Product curve picture
Frequency response curve picture
Impedance curve picture
5
