TypeS Blizzard Box AC58153 User manual

WP ITM. AC58153
AC58153-1
INSTRUCTION MANUAL
PLEASE READ THIS USER MANUAL CAREFULLY BEFORE CONNECTING AND OPERATING APPLIANCE.
SAVE FOR FUTURE REFERENCE.
PORTABLE FRIDGE / FREEZER
22 Quart / 21 Liter

2
PACKAGE CONTENTS:
Blizzard Box
Instruction
Manual
12/24V
DC Power Cord -
9 1/2’
AC to DC
Power Adapter -
6’ Cord
Output: 24VDC 4.75Amp*
see footnote on page 15.
Input: 100-240 VAC,
2.0Amp Max.

3
TECHNICAL SPECIFICATIONS:
Blizzard
Box Lid
Operating
Panel
Handle
Ventilation
Power consumption “as needed*” foot note, see page 15.
Capacity: 22 Quart (21L)
Dimension: 23.4” x 13.4” x 14.5”
(Including Handles) (584mm x 335mm x 363mm)
USB charging port output: 5 V / 1.5A rating
Climate class: 50ºF ~ 109ºF (10ºC ~ 43ºC)
(SN/N/ST/T)
Compressor: SECOP/Danfoss PBC-2.0
Cooling Performance: 0ºF ~ 50ºF (-18ºC ~10ºC)
Refrigerant: R134a (45g)
Insulation: CFC-free PU foam
Power consumption: Dual Voltage; 55W (4.6A) @ 12VDC
or 55W (2.3A) @24VDC (as needed*)
Input rating: 12VDC, 4.6A / 24VDC, 2.3A

4
OPERATION:
1. Connecting power
BEFORE YOU START
CAUTION!
• To reduce the chances of overheating, keep your Blizzard Box
in an open area, not to obstruct the heat dissipation side
ventilation openings. Ensure these side vents are not blocked
while in use, or shortly after use.
• Use in dry conditions.
• Do not use near heat sources such as gas ovens, heaters, or
direct sunlight.
• Do not immerse in water.
• Do not ll with liquid or ice.
• Do not use in direct sunlight or near ames / re.
• Ensure Blizzard Box, cables, and charging inputs / outputs are
not exposed to direct moisture or heat.
The red slide switch on the Operating Panel should be to the left
during “normal use.”
Insert DC plug into vehicle’s power port. You may also use the
included 110V AC to 12V DC Power Adapter for household power.
DC SOCKET
Normal Use

5
2. Operating panel
After connecting power to your Blizzard Box, the Power Light
Indicator on the Operating Panel will be Orange. The Digital
Display will be blank.
Press and hold the On / Off Button for three seconds. The Digital
Display will then show the current interior temperature. Once the
Power Light turns Green, your Blizzard Box is operating.
Temp. / Setting DownDigital DisplaySetting Button
Temp. / Setting Up
On / Off Button Power / Status Light
Orange: Stand-by
Green: Running
Error Light
Red (Flashing): Low voltage or damage,
contact Customer Care.
OPERATION CONT.:
3. Turning on Blizzard Box
4. Setting the temperature
- Press button once, start setting temperature status.
- Use / to set temperature from 0°F to 50°F or
-18°C to 10°C.
- The cooling temperature will be displayed for a few seconds.
The Digital Display will ash several times before the current
interior temperature is displayed.
- Press button once again, start exchange status for
Fahrenheit degree (°F) and centigrade degree (°C).

6
Digital Display will be as follows:
(LOW), (MED), (HIGH)
The Blizzard Box is equipped with multi-level vehicle battery
protection that guards against excessive discharging when
connected to a 12V / 24V power source.
If the Blizzard Box is operating when the vehicle ignition is switched
off, it will be switched off automatically once the supply voltage falls
below the cut-off level. The Blizzard Box will switch back on once
the vehicle battery has been recharged to the restart voltage level
(See table in Section 9).
NOTICE! Avoid Damaging Vehicle Battery
If the Vehicle Battery Protection Setting becomes activated and
switches off the Blizzard Box, the vehicle battery will NOT be fully
charged. Avoid restarting the vehicle repeatedly, or operating the radio
before the vehicle battery has fully recharged via running engine.
Ensure that the battery is recharged.
-Press the button three times.
-Use the / buttons to select the Vehicle Battery
Protection Setting.
5. Vehicle Battery Protection Setting
NOTE
If the ambient outdoor temperature is above +90°F (+32°C), the
minimum setting temperature cannot be attained.
When Blizzard Box interior temperature reaches the desired
temperature setting, the compressor will stop. The Power Light
will turn to Orange.
- Use / to switch between Fahrenheit and Centigrade.
The cooling temperature appears on the display for a few
seconds. The display ashes several times and then the current
interior temperature is displayed again.
OPERATION CONT.:

7
In working status, press and hold button for three seconds
to turn off the Blizzard Box. Pull out power plug.
Emergency Override Mode is for temporary use only.
When Emergency Override is activated this will override the
“Vehicle Battery Protection” setting and the “Preset Temperature”.
The pump will cool full time and the Blizzard Box will try to
achieve lowest temperature possible below freezing.
Emergency Override Mode will restart the Blizzard Box to run at
a voltage below the preset of the battery protection. During the
voltage override, the Blizzard Box will run with the Orange
Stand-by Light. Digital Display will not be available.
Emergency Override Mode can also be used to keep the Blizzard
Box running if the Operation Panel malfunctions.
To conrm if the Blizzard Box is running, feel for the air ow, or
listen for sound from ventilation openings on either side of the
appliance. (See image on page 3 )
NOTE
When using Emergency Override Mode, the vehicle battery
can drain rapidly.
6. Turning off the Blizzard Box
7. Emergency Override Mode
Emergency Switch
Normal Use Emergency Mode 1.5A USB Port
OPERATION CONT.:
The selected mode then appears on the display for a few seconds.
The display ashes several times before it returns to the current
temperature. (Reference Section 9 for more information)

8
8. USB port for power supply
1.5A USB Port allows you to charge most mobile devices.
OPERATION CONT.:
When the vehicle battery’s voltage drops to the below setting, the
Blizzard Box compressor will turn off. This will protect the vehicle
battery from over discharge. The Error Light will ash Red to alert
you to charge the battery by running the engine. The Orange
Stand-by Light will remain on.
When the Blizzard Box is powered by a vehicle starter battery,
High Mode Setting is recommended to warrant the vehicle’s
battery power is high enough to ensure starting.
If you use an additional battery (RV, campers) as a power supply,
Low Mode Setting is recommended.
If you use an AC 110V Power Converter (included), set the Battery
Protection Setting to Low Mode.
After any total power loss the Blizzard Box will retain last setting
and will restart when power is restored.
Voltage Range: Vehicle Battery Protection:
(Reference Section 5 Vehicle Battery Protection Setting)
Power
Supply
Status Battery
Protector
Low
Mode
Medium
Mode
High
Mode
DC 12V Cut-off Voltage 10.1±0.3V 11.4±0.3V 11.8±0.3V
Restart Voltage 11.1±0.3V 12.2±0.3V 12.6±0.3V
DC 24V Cut-off Voltage 21.5±0.3V 24.1±0.3V 24.6±0.3V
Restart Voltage 23.0±0.3V 25.3±0.3V 26.2±0.3V
9. Setting Vehicle Battery Protection / Low Voltage Battery Protection

9
10. Blizzard Box Lid
OPERATION CONT.:
Suggested Beverage & Food Storage Temperatures Temperature
Beer (Light), Sparkling Wines, Champagne 41°F / 5°C
Beer (Craft), White Wine 46°F / 8°C
Beer (Rich avor), Red Wine 53°F / 12°C
Soda / Pop 40°F / 4°C
Fruit & Veggies (Cool Season) 32-35°F / 0-1.6°C
Fruit & Veggies (Warm Season) 45-55°F / 7-12°C
Meat & Fish 41°F / 5°C
Dairy 35°F / 1.6°C
Eggs 45°F / 5°C
11. Temperature Tips
• Blizzard Box is designed to maintain chilled temperatures of food
and beverages.
• Pre-cool Blizzard Box before storing food or beverages.
• Pre-cool food or beverages before storing in Blizzard Box.
• Baskets are important to protect inner walls and to even-out the
cooling temperature.

10
OPERATION CONT.:
Replacing a defective fuse:
WARNING: Always disconnect Blizzard Box from power before
cleaning or servicing.
• Occasionally clean the device interior and exterior with a damp cloth.
• Clean heat dissipation window frequently to ensure good heat
dissipation.
• Do not turn Blizzard Box on its side or upside down. Keep upright.
Defrosting: Humidity can form frost in the interior of the cooling
device or on the evaporator. This reduces the cooling capacity.
WARNING: Do not use abrasive cleaning agents or hard objects
during cleaning as these can damage the Blizzard Box.
Cleaning and Maintenance
Defrosting steps are as below:
• Remove the contents from the Blizzard Box and store them in
another cooler if necessary.
• Disconnect the power of the Blizzard Box. Open the lid, and
keep it open until the ice and frost melt away.
• Use clean cloth to wipe up the defrosted water.
• Never use hard or pointed tools to remove ice or to loosen
objects which have frozen in place.
• Unplug the DC power plug;
• Turn the cap counter-clockwise to open it, and
remove the defective fuse from the plug;
• Insert a new fuse that has the same rating
(15A 250V);
• Close and tighten the cap.
