uAvionix tailBeacon STC User manual

UAV-1002514-001
Rev B
tailBeaconTM STC
Installation Manual

UAV-1002514-001 2
Rev B
© 2019 uAvionix Corporation. All rights reserved.
Except as expressly provided herein, no part of this guide may be
reproduced, transmitted, disseminated, downloaded or stored in any
storage medium, for any purpose without the express written permission of
uAvionix. uAvionix grants permissions to download a single copy of this
guide onto an electronic storage medium to be viewed for personal use,
provided that the complete text of this copyright notice is retained.
Unauthorized commercial distribution of this manual or any revision hereto
is strictly prohibited.
uAvionix®and Ping®are registered trademarks of uAvionix Corporation and
may not be used without express permission of uAvionix.
tailBeacon, skyBeacon, Continuous Calibration, Power Transcoder, Echo
Installer, and Ping Installer are trademarks of uAvionix Corporation and
may not be used without express permission of uAvionix.
Patent uavionix.com/patents

UAV-1002514-001 3
Rev B
1 Revision History
Revision
Date
Comments
A
7/7/2019
Initial release
B
8/28/2019
Update ADS-B version to v1.4.0 and note
installation kit

UAV-1002514-001 4
Rev B
2 Warnings / Disclaimers
uAvionix is not liable for damages arising from the use or misuse of this
product.
This equipment is classified by the United States Department of
Commerce's Bureau of Industry and Security (BIS) as Export Control
Classification Number (ECCN) 7A994.
These items are controlled by the U.S. Government and authorized for
export only to the country of ultimate destination for use by the ultimate
consignee or end-user(s) herein identified. They may not be resold,
transferred, or otherwise disposed of, to any other country or to any person
other than the authorized ultimate consignee or end-user(s), either in their
original form or after being incorporated into other items, without first
obtaining approval from the U.S. government or as otherwise authorized by
U.S. law and regulations.

UAV-1002514-001 5
Rev B
3 Table of Contents
1Revision History...................................................................................3
2Warnings / Disclaimers........................................................................4
3Table of Contents ................................................................................5
4System Information..............................................................................6
4.1 Certification...................................................................................6
4.2 TSO Authorization.........................................................................6
4.3 System Limitations........................................................................7
5System Specifications..........................................................................8
5.1 Physical Specifications .................................................................8
5.2 System Interfaces.........................................................................9
6Installation .........................................................................................10
6.1 Unpacking and Inspecting...........................................................10
6.2 Mounting.....................................................................................10
6.3 Unit Installation Overview............................................................11
6.4 Mounting Dimensions .................................................................12
6.5 Mounting Procedure....................................................................13
6.6 tailBeacon System Configuration................................................17
6.6.1 Verify Software Version.........................................................17
6.6.2 Configure Device...................................................................17
6.7 Flight Checks..............................................................................18
7Support..............................................................................................18

UAV-1002514-001 6
Rev B
4 System Information
4.1 Certification
This installation manual provides mechanical and electrical information
necessary to install tailBeacon. The content of this manual assumes use
by competent and qualified personnel using standard maintenance
procedures in accordance with Title 14 of the Code of Federal Regulation
and other related accepted procedures.
Those installing this article on an aircraft listed on the Approved Models List
shall verify the compatibility of existing STCs with this STC prior to
returning the aircraft to service.
4.2 TSO Authorization
Function
TSO/RTCA/SAE
Class/Type
Airborne Navigation Sensor
Using the Global Position System
(GPS) Augmented by the
Satellite Based Augmentation
System (SBAS)
TSO-C145e
INCOMP
RTCA/DO-229E
Beta 1
Universal Access Transmitter
(UAT) Automatic Dependent
Surveillance-Broadcast (ADS-B)
Equipment Operating on
Frequency of 978MHz
TSO-C154c
RTCA/DO-260B
B1S
Position Light (White)
TSO-C30c
SAE/AS8037
Type III
Automatic Pressure Altitude
Reporting Code-Generating
Equipment
TSO-C88b
SAE/AS8003

UAV-1002514-001 7
Rev B
4.3 System Limitations
Installation
This article meets the minimum performance and quality control standards
required by a technical standard order (TSO) and when installed on aircraft
approved on the AML can be approved for return to service after
installation.
If you are installing this article on or in a specific type or class of aircraft,
not listed on the AML you must obtain separate approval for installation.
TCAS/ACAS System
tailBeacon does not support installation on aircraft with an active Airborne
Collision Avoidance System (ACAS) with Resolution Advisory capability,
such as TCAS II or ACAS X.
SatCom
The tailBeacon GPS has not been demonstrated as compatible with
SatCom equipment and should not be installed on SatCom equipped
aircraft.
Transponder
A companion altitude-reporting transponder is required to be installed for
14 CFR 91.225 and 91.227 compliance, unless installed on an aircraft
excepted from the requirements of 14 CFR 91.215 and 91.225.
The transponder’s altitude source must comply with TSO-C10(), TSO-
C106() or TSO-C88() and meet the requirements of 14 CFR 91.217.
Transponder antenna
tailBeacon must be installed at least 3 feet from any operating transponder
antenna.

UAV-1002514-001 8
Rev B
5 System Specifications
5.1 Physical Specifications
Characteristics
Specifications
Width
1.71 in (44mm)
Height
2.63 in (67 mm)
Depth
3.82 in (97 mm)
Weight
3.0 oz (85 g)
Operating Temperature Range
-45°C to +70°C
Maximum Pressure Altitude [1]
18,000 ft
Input Voltage Range
9 to 33 VDC
14V Current
0.5A Max
28V Current
0.25A Max
[1] UAT usage is restricted to below 18,000 feet MSL (§91.225).

UAV-1002514-001 9
Rev B
5.2 System Interfaces
WARNING: Do not connect the power wire to a Xenon strobe power
pack. This can damage the light and voids the warranty.
Position Light
Breaker
Transponder
Aircraft Power
(14/28V)
RED
Aircraft Ground
BLACK
Wi-Fi
iOS/
Android
Device
!

UAV-1002514-001 10
Rev B
6 Installation
6.1 Unpacking and Inspecting
Carefully unpack the device and make a visual inspection of the unit for
evidence of any damage incurred during shipment. If the unit is damaged,
notify the shipping company to file a claim for the damage. To justify your
claim, save the original shipping container and all packing materials.
6.2 Mounting
tailBeacon is a rear, aft position light. Ensure that when mounted, the
downward facing fin and top of the assembly are free from obstructions.
tailBeacon requires a clear view of the sky for optimal GPS performance. It
may not be suitable for installation on aircraft where aircraft elevators or
other structures would block visibility to the sky.
Note: Installation of the tailBeacon must be in accordance with AC 43-
13.2B, Chapter 1
