Ubiquiti UFiber UF-WIFI User manual

UFiber UF-WIFI Screws (Qty. 4) Screw Anchors (Qty. 4)
Power Adapter (24V, 0.5A)
Package Contents
System Requirements
Linux, Mac OS X, or Microsoft Windows 7/8/10
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Web Browser: Google Chrome (Other browsers may have limited functionality)
Before You Begin
Designing your first GPON deployment requires specific knowledge and planning. For
information on GPON network design and installation, including important
considerations and best practices, refer to:
ubnt.link/UFiber-GPON-Getting-Started
ubnt.link/Designing-a-GPON-Network
For details on configuring UFiber devices for the first time to allow ONU LAN ports to
provide connectivity, refer to: ubnt.link/UFiber-Initial-Configuration
Hardware Overview
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

PON Port
LAN (Ports 1 - 4)
Reset Button
SC/APC GPON port supports WAN connections of 2.488 Gbps downstream and
1.244 Gbps upstream.
RJ45 Ethernet LAN ports support 10/100/1000 Mbps connections. Port 1 also
supports 24V Passive PoE to power the device.
The Reset button serves two functions for the UF-WIFI:
Restart Press and release the Reset button quickly. The three signal LEDs will
flash amber.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Power Port
Signal LEDs
Restore to Factory Default Settings Press and hold the Reset button for more than
five seconds.
The Power Adapter connects to this port to provide power.
White Ethernet connection up
Off Bootup
Signal strength: low
≥ -28 dBm
Signal strength: good
≥ -25 dBm
Signal strength: strong
≥ -11 dBm
Signal strength: too low
< -28 dBm
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Ethernet LED
Power LED
Check the quality of the fiber connection, and
calculate the total optical loss of the optical
splitters.
Signal strength: too strong
≥ -8 dBm
Add an optical splitter, or add a 5 or 10 dB
optical attenuator.
No signal
Check the fiber cables and connectors, and
ensure that the OLT functions properly.
No authority
The UF-WIFI has not been authorized or cannot
communicate with the OLT. Check passwords
and OLT settings.
Off Ethernet connection down
White
Ethernet connection up
Flashing indicates activity
Off Power off
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

White Power on
Hardware Installation
Wall Mounting
1.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

2.
3.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

4.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Connecting Fiber
WARNING: Never look directly into the ends of fiber or modules. The emitted
light could cause damage to the eye.
WARNING: Until ready for use, keep modules and fiber patch cables covered
using the included protective caps to ensure the connections stay clean.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

WARNING: Do NOT connect the device directly to a UFiber GPON module (UF-
GP-B+ or UF-GP-C+). Doing so will damage the device optics. Ensure that the
device’s received signal level never exceeds -8 dBm. Use a UFiber PLC Splitter
to add attenuation as needed.
Connecting LAN
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Connecting Power
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

OR
Note: 24V Passive PoE is required to power the device.
WARNING: The PoE switch must comply with the power specifications listed in
the Specifications section of this Quick Start Guide.
Accessing the Configuration Interface
1. Ensure that your computer (or other host system) is connected to the device.
2. Configure the Ethernet adapter on your host system with a static IP address on the
192.168.1.x subnet.
3. Launch your web browser. Type http://192.168.1.1 in the address field. Press enter
(PC) or return (Mac).
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

4. Enter ubnt in the Username and Password fields. Click Login.
Customize settings as needed. For more information, refer to the UFiber resources,
which are available at: http://ubnt.link/UFiber-Support
Specifications
UF-WIFI
Dimensions 126.34 x 126.09 x 31.65 mm
(4.97 x 4.96 x 1.25")
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

UF-WIFI
Weight 190 g (6.70 oz)
Networking Interfaces (1) SC/APC, GPON WAN
(4) Gigabit RJ45, Ethernet LAN
(1) Wi-Fi, 802.11n
Networking Interface Speeds
GPON WAN, ITU G.984 2.4 Gbps Down, 1.2 Gbps Up
LAN 10/100/1000 Mbps
Wi-Fi 300 Mbps
Management Interface In-Band Ethernet
PON
Normal Optical Power Range TX (Class B+): 1.5 to 5 dBm
RX: -28 to -8 dBm
Power Method DC Jack, 24VDC
24V Passive PoE (Pins 4, 5+; 7, 8-)
Power Supply 100-240VAC / 50-60 Hz Universal AC/DC
24V / 0.5A
Max. Power Consumption 7W
Supported Voltage Range 20 to 28V
Processor Specs MIPS, 900 MHz
Memory Information 256 MB DDR
Button (1) Reset
Operating Temperature -10 to 45° C (14 to 113° F)
Operating Humidity 10 to 90% Noncondensing
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

UF-WIFI
Certifications CE, FCC, IC
Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the manufacturer.
WARNING: To reduce the risk of fire or electric shock, do not expose this product to rain or
moisture.
WARNING: Do not use this product in location that can be submerged by water.
WARNING: Avoid using this product during an electrical storm. There may be a remote
risk of electric shock from lightning.
WARNING: CLASS 1 LASER PRODUCT - Do not look into the ends of the fiber optic
cable or SFP modules while converters are powered.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and current requirements indicated
on the manufacturer’s label. Connection to a different power source than those specified may
result in improper operation, damage to the equipment or pose a fire hazard if the limitations are
not followed.
2. There are no operator serviceable parts inside this equipment. Service should be provided only
by a qualified service technician.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Limited Warranty
ui.com/support/warranty
The limited warranty requires the use of arbitration to resolve disputes on an individual basis, and,
where applicable, specify arbitration instead of jury trials or class actions.
Compliance
FCC
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions.
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operations of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
This radio transmitter has been approved by FCC.
ISED Canada
CAN ICES-3(A)/NMB-3(A)
This device complies with ISED Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions:
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired
operation of the device.
This radio transmitter has been approved by ISED Canada.
The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential
for harmful interference to co-channel mobile satellite systems.
CAN ICES-3(A)/NMB-3(A)
Le présent appareil est conforme aux CNR d’ISDE Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
1. l’appareil ne doit pas produire de brouillage;
2. l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
Le présent émetteur radio a été approuvé par ISDE Canada.
Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une
utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux.
IMPORTANT NOTE
Radiation Exposure Statement
This equipment complies with radiation exposure limits set forth for an uncontrolled
environment.
This equipment should be installed and operated with minimum distance 20 cm between the
radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
AVIS IMPORTANT
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Déclaration sur l’exposition aux rayonnements
Cet équipement est conforme aux limites prévues pour l’exposition aux rayonnements dans un
environnement non contrôlé.
Lors de l’installation et de la mise en fonctionnement de l’équipement, assurez-vous qu’il y ait
une distance minimale de 20 cm entre l’élément rayonnant et vous.
Cet émetteur ne doit être installé à proximité d’aucune autre antenne ni d’aucun autre émetteur,
et ne doit être utilisé conjointement à aucun autre de ces appareils.
Australia and New Zealand
Warning: This equipment is compliant with Class A of CISPR 32. In a residential
environment this equipment may cause radio interference.
Brazil
Nota: Este equipamento não tem direito à proteção contra interferência prejudicial e não
pode causar interferência em sistemas devidamente autorizados.
CE Marking
CE marking on this product represents the product is in compliance with all directives that are
applicable to it.
Country List
AT BE BG CY CZ DE DK EE EL ES FI FR HR HU
IE IT LV LT LU MT NL PL PT RO SE SI SK UK
BFWA (Broadband Fixed Wireless Access) members noted in blue
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Note: This device meets Max. TX power limit per ETSI regulations.
The following apply to products that operate in the 5 GHz frequency range:
Note: This device is restricted to indoor use only when operating in the 5150 - 5350 MHz
frequency range within all member states.
Note: All countries listed may operate at 30 dBm. BFWA member states may operate at 36
dBm.
Note: Operation in the 5.8 GHz frequency band is prohibited in BFWA member states.
Other countries listed may use the 5.8 GHz frequency band.
WEEE Compliance Statement
Declaration of Conformity
Online Resources
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

© 2020 Ubiquiti Inc. All rights reserved.
