ULTRA-LINK UL-DVD600HD User manual

QUICK USER GUIDE
UL-DVD600HD

THE FRONT PANEL
THE REAR PANEL
OPEN/CLOSE PLAY/PAUSE STOP

REMOTE CONTROL
1.
2.
3.
4.
5.
6.
7/25/24/28.
8.
9.
10/12.
11/31.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24/28.
26.
27.
29.
30.
32.
33.
34.
35.
36.
37.
38.
39.
OPEN/CLOSE Open and close disc tray
Select the menu language
Turn ON/OFF subtles as
supported by your file or disc
POWER
MENU Enter MENU sengs screen
Pressing this buon allows to input
the specific me so that the player
jumps to the point of play.
MUTE
DVD/USB
Turn sound ON/OFF
[NUMBER KEYS] Select files and chapters of
videos
SETUP
L/R
Enter menu sengs
Press this buon to select L,R or
stereo channel.
RETURN
RESET
Go to the DISC menu screen
VOLUME Turn UP/DOWN volume
DIRECTION KEY Used to move cursor around
screen
ENTER Use to select on opon or
feature
VOLUME Increase or decrease volume
SLOW Reduce the speed of video
playback
PLAY/PAUSE
VIDEO
Press to pause and again to play
Select segment of video or music
for reply
STEP
OSD
View playback one frame at a
me
CLEAR Clear previously selected data
and search informaon
STOP Stop playback of files
ZOOM
N/P
Zoom IN/OUT from an image
FAST FORWARD Fast-forward video or music
PREVIOUS/NEXT Skip forwards/backwards
REWIND Rewind video or music
For PAL or NTSC selecon
Reset the primary interface
PBC
LANGUAGE
SUBTITLE
TIME
REPEAT Repeat the current track
ANGLE
Switch between USB and disc
playback
PROG Program the Title and Chapter
order of playback
Select video output mode
TITLE Return to tle screen
Turn player ON or OFF
Turn ON/OFF subtles as
supported by your file or disc
A-B

SUGGESTED CONNECTIONS
CONNECTING THE HDMI CABLE TO A HOME THEATRE SYSTEM
1. Plug the first HDMI cable into the
HDMI OUTPUT on the player and into
the HDMI input on the
Home
Theatre System.
2. Plug the second HDMI cable into
the HDMI OUTPUT on the Home
Theatre System and into the HDMI
inputon the
t elevision.
OTHER CONNECTION EXAMPLES
HDMI
(EASIEST)
COMPOSITE
Red,White,YellowRCA
(EASY)
COMPONENT
(EASY)

CONNECTING THE PLAYER
HDMI can transmit both audio and video signals over a single cable. If you
have an HDMI capable receiver that can support HDMI audio, you can
simply run an HDMI cable from the player to your receiver and enable
HDMI audio on the receiver (see your receiver’s owners’ manual for more
informaon). The receiver usually has an HDMI output that you can
connect to your TV to pass the video signal.
HDMI is a wonderful thing. A single cable can transport both audio AND
video from your player to your display. Be aware, however, that HDMI is
an evolving standard, and there could be compability issues. A receiver
that supports audio input over HDMI is required.
Some receivers offer HDMI ports solely for video switching. If your receiver
does not have audio input capability, please read the following secons
regarding other connecon methods.
In order to play mul-channel audio for all formats, the receiver must
support HDMI v1.1 or later. A receiver that supports HDMI v1.3 with
decoding capability for Dolby TrueHD and DTS-HD Master Audio is
preferred. Please check the specificaons of your receiver to ensure that it
meets the requirements.
Due to bandwidth limitaons, high resoluon audio formats such as Dolby
Digital Plus, Dolby TrueHD, DTS-HD High Resoluon and DTS-HD Master
Audio cannot be sent through the coaxial digital audio output. A reduced
resoluon version of the same audio track will be output instead. To listen
to high resoluon audio formats in their best quality, please use the HDMI
connecon if you have a receiver that handles HDMI audio.

SYSTEM SETTINGS (LAYOUT)
Press the SETUP buon to enter the SETUP menu. Scroll down and leusing the
ARROW buons and the OK buon to confirm your selecons.
When you have finished, repeatedly press the LEFT arrowunl the cursor returns to
the top MENU tab,otherwise press SETUP again to exit.
(Some of the menu screens have been displayed below for your reference.)

FILE PLAYBACK FROM DISC OR USB
The files supported for playback are: Video – AVI (Xvid),VOB,Music – MP3,Image –
JPG. Insert your disc or connect your USB thumb drive and press the USB buon. The
following screen/s will be displayed which will allowyou to select a file for playback or
for viewing,then press the confirm buon to begin.
MP3 PLAYBACK SCREEN
PLAYBACK SCREEN
VIDEO
PLAYBACK SCREEN

FAQS
No Video displayed on TV
• Make sure TV is turned on.
• Check the cable connecons.
• Check the input selecon on the TV is correct. Eg. HDMI1,HDMI2,AV1 or AV2 etc
Player doesnot respond to remote
• Clear any obstacle between the remote and the player.
• Try moving closer or reduce the angle to the player
• Check the condion of the baeries and replace if necessary.
• Clean the sensor panel on the player.
No audio during DVD/file
• Check the audio output of the player is set correctly.
• If using external amplifier/speakers,ensure connecons are correct and amp is turned on.
• Check input on TV/Monitor.
• Check files audio track is supported by this player.
Disc playback is jerky
• Check the condion of the disc. If surface is damaged or scratched repair or replace if necessary.
Video fileplayback is jerky and stops
• Check the file is compable with player.
• Check resoluon of file. High Definion files may cause intermient playback issues. Reduce
resoluon and bit rate of file to improve playback.
Abnormal Player operaons
• Turn the player offand unplug the player from wall. Wait for 1 or 2 minutes and plug back in.
Player should nowfuncon normally.
Disc is locked in player
• If the player will not eject disc. Turn the power OFF and then ON again. Immediately
press the OPEN/CLOSE buon (32) to open the tray.
Some files donot play back. What files are supported?
The supported files are; Video-AVI (Xvid),VOB; Audio-MP3 and Image-JPG

SPECIFICATIONS
VideoGuide
Line
AudioGuide
line
Audio
Frequency
Response
Power Supply
Supported Files
Weight
Dimension
Operang Condion
Temperature Condion
Power Consumpon
Video OutputVp-p(v)
Level Definion(TV-line)
AudioOutput(Vrms)
S/N Rao(db)
Audio Dynamic Range
DVD Audio
CD Audio
AC Input(v)
Frequency(Hz)
1.0±0.2(75Ω)
≧450
1.8±0.2(10KΩ)
≧80dB
≧80dB
Fs 48KHz PCM 4Hz-22KHz
Fs 496KHz PCM 4Hz-22KHz
Fs 44.1KHz PCM 4Hz-22KHz
~110-240V
50Hz/60Hz
6W
Level Surface
225X190X45MM
700G
Video: AVI(Xvid),VOB
Audio: Mp3
Image: JPG
10℃~40℃
