ULTRA PERFORMANCE 39010 User manual
*Actual product may vary slightly
Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product.
Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property
damage and/or personal injury. Please keep instructions for future reference.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
This product contains or, when used, produces a chemical
known to the State of California to cause cancer and birth
defects or other reproductive harm.
(California Health & Safety Code § 25249.5, et seq.)
WARNING
MULTI-FUNCTION MINI JUMP STARTER
LITHIUM-ION BATTERY
39010
Important Safety Instruction
WARNING
Failure to observe these warnings could result in injury
THIS INSTRUCTION MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. SAVE THESE
INSTRUCTIONS. READ THIS INSTRUCTION MANUAL CAREFULLY AND UNDERSTAND ALL
INFORMATION BEFORE OPERATING THIS TOOL.
• It is the responsibility of the owner to make sure all personnel read this manual prior to using this
device. It is also the responsibility of the jump starter owner to keep this manual intact and in a
convenient location for all to see and read. If the operator is not fluent in English, the product and
safety instructions shall be read to and discussed with the operator in the operator's native
language by the purchaser/owner or his designee, making sure that the operator comprehends
its contents.
• RISK OF EXPLOSIVE GASES
• WORKING IN THE VICINITY OF AN AUTOMOTIVE LEAD-ACID BATTERY IS DANGEROUS.
BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL OPERATION.
• IT IS IMPORTANT THAT YOU FOLLOW THESE INSTRUCTIONS EACH TIME YOU USE THE UNIT.
• NEVER ALLOW CLAMPS TO TOUCH TOGETHER OR CONTACT THE SAME PIECE OF METAL.
To reduce the risk of battery explosion, follow these instructions and those published by the battery
manufacturer and the manufacturer of any equipment you intend to use in the vicinity of a battery.
Review cautionary markings on these products and on the engine.
• RISK OF ELECTRIC SHOCK OR FIRE.
• Keep out of reach of children.
• Do not put fingers or hands into any of the unit’s outlets.
• Do not expose the unit to rain or snow.
• To reduce the risk of damage to the electric plug or cord, pull by the plug rather than the cord when
disconnecting the unit.
• Do not operate the unit with damaged cables or clamps.
• Do not operate the unit if it has received a sharp blow, been dropped or otherwise damaged in any
way; take it to a qualified service person.
• Do not disassemble the unit; take it to a qualified service person when service or repair is required.
Incorrect reassembly may result in a risk of fire or electric shock.
• To reduce the risk of a battery explosion, follow these instructions and those published by the battery
manufacturer and the manufacturer of any equipment you intend to use in the vicinity of the battery.
Review the cautionary markings on these products and on the engine.
• Do not set the unit on flammable materials, such as carpeting, upholstery, paper, cardboard, etc.
• Never place the unit directly above battery being jumped.
• Do not use the unit to jump-start a vehicle while charging the internal battery.
• Do not charge the jump starter in sealed vehicle exposed to the sun, high temperature condition
and/or high humidity environment.
• Do not use the jump starter if it is in abnormal condition such as bulged, leakage, smell, etc.
• Do not place the jump starter in microwave oven, pressurized container or vacuum chamber.
• Do not attempt to disassemble or modify the unit. Please contact your local distributor if the product
has any problems.
Personal Precaution
WARNING:
• RISK OF EXPLOSIVE GASES. A SPARK NEAR THE BATTERY MAY CAUSE A BATTERY
EXPLOSION. TO REDUCE THE RISK OF A SPARK NEAR THE BATTERY:
• NEVER smoke or allow a spark or flame in the vicinity of a battery or engine.
• Remove personal metal items such as rings, bracelets, necklaces and watches when working
with a lead-acid battery. A lead-acid battery can produce a short-circuit current high enough to
weld a ring to metal, causing a severe burn.
• Be careful with tools around your battery. It might spark or short-circuit the battery or other
electrical part that may cause an explosion.
• Do not permit the internal battery of the unit to freeze. Never charge a frozen battery.
• To prevent sparking, NEVER allow clamps to touch together or contact the same piece of metal.
• Consider having someone nearby to come to your aid when you work near a lead-acid battery.
• Wear complete eye and body protection, including safety goggles and protective clothing. Avoid
touching your eyes while working near the battery.
• If battery acid contacts your skin or clothing, immediately wash the area with soap and water. If
acid enters your eye, immediately flood the eye with cold running water for at least 10 minutes
and get medical attention right away.
• If battery acid is accidentally swallowed, drink milk or water. DO NOT induce vomiting. Seek medical
attention immediately.
• Neutralize any acid spills thoroughly with baking soda.
Parts and Features
Three blue LED indicator lights:
respectively means 30%, 60%
and 100% of the electricity
Red LED light (Error indicator)
Preheating indicator
Micro USB input port, 5V/2.1A
USB output port, 5V/2.1A
Flashlight
Jump starter portPower switch
Jumper cables
8 Pin connector for iPhone
Mini USB port
Micro USB port
USB port
1. Suggestion and Application:
(1) This product is a kind of portable electric equipment that can provide additional battery capacity for the
car battery when you start the car.
2. Features:
(1) Appearance:
Size: length 6.33in, width 3.45in, thickness 0.98in
Material: ABS+PC
Color: black
(2) Battery:
Type: Lithium-ion battery
Capacity:23.04Wh (7200mAh) Constant current discharge 200A, peak 400A
Size: length 3.7in, width 3in, thickness 0.59in
Quantity of battery: 4pcs
One pc of battery capacity:1800mAh±5%~77°F
Standard voltage: 12.8V
Full battery voltage: ＞13.2V
(3) Cable:
Contact type: pluggable
With EC5 port
Gauge: 10AWG
Temperature resistance: 200 silicone wire
Material: pure cooper
Cable length: from EC5 port to clamp top
Positive pole: 11.8in
Negative pole: 11.8in
(4) Clamp:
Compose: plastic, metal terminal, metal spring
Size: length 3.74in, width 2.9in, thickness 0.87in
Material: PC coating; cooper plating terminal; iron spring
(5) Charging input:
Micro USB input: input voltage 5V; input current 2A
(6) Output:
5V/2.1A USB:
a. Quantity: 2 ports
b. Voltage output: no-load voltage 5.0-5.2V; 2.1A load voltage 4.5-5.0V
c. Long-time working current: 2.1A
If the working current is less than 30mA, it will enter into sleep mode automatically after 2 minutes.
(7) Auto preheating mode:
Please plug the cable, the product will enter into auto preheating mode automatically if its temperature
is lower than 50°F, yellow LED indicator will lit until the preheating is over based on the temperature is
over than 50°F
(8) Start the car:
Please plug the cable and connect the clamps with the battery terminal, the product will enter the engine
start mode automatically, if the green LED indicator lit, you could start the car.
(9) Safety protection:
Reverse polarity protection:
When you plug into start cable, if the cable short circuit or the clamps reverse, red LED indicator will
twinkle and buzzer warning will sound “bee bee”.
Over charge protection:
When the charging voltage is over than 15V, the product itself will cut down the charging automatically,
and it stops.
Low voltage protection:
a. If the battery voltage is less than 12V, the first LED light of the power indicator on the left will twinkle,
please charge it as soon as possible.
b. If the battery voltage is less than 10V, the product will power off automatically, you have to charge it
then use it.
Over discharge protection:
If the product is in heavy load discharge mode continuously when you start the car, it will provide following
protection:
a. when the voltage is 5-10V and the discharge time is more than 5S
b. when the voltage is 3-5V/1s
c. when the voltage is lower than 3V, please try other ways to start
Over heat protection:
If the internal temperature of product is over than 140°F, the product will protect itself. It will show jump cable,
USB port and LED light are no output current, fault indicator will twinkle and with “bee bee” buzzer warning.
The product begin to work normally if the internal temperature is lower than 122°F.
Over load protection:
The product will stop automatically if the USB port is overload and the current is over than 2.3A, USB
port will stop and will sound “bee bee”. the product will shut off automatically.
(10)Touch switch
Press the switch and the product starts. After starts, the switch can be adjustable for the flashlight modes:
lasting light, flashing and stop. The product will shut down without any operations for 120S. Press the touch
switch for 2s, the prouduct will shut off.
(11) LED light
LED type: highlight LED
LED quantity: 1 pc
Power: 0.5W
(12) Status display way: LED indicator
LED quantity: 5 pcs
Three blue LED indicators show battery capacity for 30%, 60% and 100% One red indicator shows fault
indicator, One double color ( yellow and green) LED indicator: yellow shows product is in preheating mode,
green shows product is in start waiting mode.
(13) Accessory：
Multi-functional USB cable ( for IPad, Sumsung and mini USB port)
Length: 8.26in
Black flannelette bag
3.Temperature range:
Operating temperature range: -4°F-140°F
Storage temperature range: 32°F-113°F
Functions
1. Switch: Products will enter the sleep mode automatically after 2 minutes without any operation. Press “on/off ”
button to activate. Press “on/off “ button again, “LED light” will change the mode. There are three modes of LED
light: on, strong flash and off. Press “on/off “ button for more than 2 seconds, products will shut off .
2. Micro USB charging port: apply the USB line, charging side is connected with Micro USB charging port, the
other side is plugged in 5V 2.1A electricity supply. Three indicator lights will be on one by one during the
charging process. Until three lights are all on, the product is fully charged.
3. USB discharging port: plug the USB cable in the port; the other three ports on the other side can be connected
with different devices for charging purpose.
4. Turn on the switch, plug the auto starting line in startup port (if products’ working temperature is below 50 °F,
products will enter preheating procedure automatically, while at the same time, the preheating and startup
indicator light will turn yellow. The yellow light will be off until the working temperature reaches 50°F and clip
on car battery. The red clip should be clipped to positive pole of the battery, while the black clip should be
clipped to negative pole. Please make sure both connections are tight and in a good condition. At the same
time, the startup light should turn to green. Afterwards, start the car engine.
5. After start procedure, disconnect from car battery, disconnect between products and clips.
NOTICE
1. The product will automatically shut down after 120 seconds without any operation. Long-press
“on/off” button for 2 seconds can also turn it off.
2. If connections to either negative pole or positive pole of the battery are not well-connected, it
will be highly chance to get a spark, resulting in not possible to deliver large electricity to the
battery. Just reconnect well to negative pole and positive pole to solve the problem.
3. When product's working temperature is above 140 °F, products will be under overheating
condition. All functions will be shut down (common protection procedure). Please lower its
working temperature below 122 °F, in order to recover all functions.
4. When product's working temperature is below -4 °F, certain functions of the product will be
limited (too cold working temperature phenomenon). Please try to make working temperature
back to -4 °F or above, it will turn product into preheating procedure. Afterwards, product
functions will work properly.
5. When voltage of car battery is between 5V-10V, if start procedure takes more than 5 seconds,
products will shut down (common protection procedure).
6. When voltage of car battery is between 3V-5V, if start procedure takes more than 1 second,
products will shut down (common protection procedure).
7. When voltage of car battery is below 3V, products are prohibited to enter start mode (common
protection procedure).
8. When USB’s current output is above 2.3A, USB’s output function will be shut down (common
protection procedure).
9. After 3 or 4 times of failed car engine start process, please wait 10 minutes before next actions
are taken.
10. After 3 or 4 times of failed car engine start process, please check if the car itself has any
other problems contributed to the failures.
11. This product is aimed at auxiliary car engine start and is applicable to gasoline car, which its
automobile emission is below 2800 cc. According to different starting currents and car battery
conditions of every car engine, 100% of success cannot be guaranteed. Under start mode,
it advisable to let product charge the car battery for 2 to 3 minutes, in order to increase the
is voltage of car batteries before starting engines.
12. Please charge product’s battery once in 6 to 8 months. With long-time no usage, products
may not be able to turn on, please charge products until it is activated again.
Limited Manufacturer Warranty
FOT makes every effort to ensure that this product meets high quality and durability
standards. FOT warrants to the original retail consumer a 1-year limited warranty
from the date the product was purchased at retail and each product is free from
defects in materials. Warranty does not apply to defects due directly or indirectly
to misuse, abuse, negligence or accidents, repairs or alterations, or a lack of
maintenance. FOT shall in no event be liable for death, injuries to persons or
property, or for incidental, special or consequential damages arising from the
use of our products. To receive service under warranty, the original manufacturer
part must be returned for examination by an authorized service center. Shipping
and handling charges may apply. If a defect is found, FOT will either repair or
replace the product at its discretion.
DO NOT RETURN TO STORE
For Customer Service:
Email: [email protected] or Call 1-800-348-5004
Table of contents
