UNEEK SWING OPTIX User manual
SWING OPTIX
INSTALL GUIDE
®
for EYEXO Users
POWER FOR EVERY GOLFER
2
SWING O P TIX INSTALL GUIDE
0.1INCLUDED ITEMS P A G E 3
0.2CAMERA INSTALLATION P A G E 4
0.3SOFTWARE INSTALLP A G E 6
0.4 MVS DRIVER P A G E 7
0.5 LICENSE AND ACTIVATIONP A G E 8
0.6 LIGHTING ENVIRONMENT P A G E 9
TABLE OF
CONTENTS
SWING OPTIX CONFIGURATION
0.7 P A G E 11
USB 3.0 CABLE(2)
The followingitems are included
in the package. Please make sure
they are all present and accounted for.
NOTE:
If any part is missing,
please contact support.
3
SWING O P TIX INSTALL GUIDE
CAMERA (2)
CAMERA LENSE (2) ACCESSORIES (2 sets)
0.1 INCLUDED ITEMS
STEP ONE
Please find the camera, bracket, and the 4
screws that came with the package.
STEP TWO
Screw in the 4 screwsthroughthe bracket onto the
camera.
STEP THREE
Attach the camera with the bracket to the tri pod stand.
The camera will need to be rotated 90 degrees as
shown in the photo. Attach the USB 3.0 power cable to
the camera. It is recommended to tie the USB 3.0 power
cable to one of the legs of the tri pod.
NOTE:
The cameras will heat up to
43 -46 degree Celcius. This
is normal operating temp.
4
SWING OPTIX INSTALL GUIDE
STEP FOUR
Connect the other end of the USB 3.0 power cable
directly to a USB 3.0 port on your PC. Please confirm
you see the light blinking next to the “Power” text
on the cameras.
STEP ONE STEP TWO
STEP THREE STEP FOUR
0.2 CAMERA INSTALLATION
5
Impact
screen
g
o
l
f
e
r
sensor
Swing
Camera 1
Swing
Camera 2
tee
5feet
6feet
0.2 CAMERA INSTALLATION
STEP ONE
The MVS camera driver gets automatically installed when you go through the first
time setup of the View software. The View setup file is in the USB flash drive that
came with the unit.
STEP TWO
In the next window, make sure the “Destination Folder”
is selected to “C:\View” and then click “NEXT>.”
Once all the View files are installed, the “MVS” driver installer
See next page for steps.
6
SWING OPTIX INSTALL GUIDE
Install Link:
https://bit.ly/support-view
STEP ONE
STEP TWO
0.3 SOFTWARE INSTALL
7
STEP ONE
Once the MVS Driver setup window appears, click
the “Start Setup” button to proceed.
STEP TWO
In the options window, confirm
“C\:Program Files (x86)/MVS” is shown in the
“Directory” and the other options are all checked.
Then click the “Next” button.
STEP THREE
The driver installation isinitiated.
Please wait several minutes for this process.
SWING OPTIX INSTALL GUIDE
STEP ONE STEP TWO
STEP THREESTEP FOUR
STEP FOUR
Once the installation process is complete,
uncheck the “Run the Client” box and click “Finish.”
0.4 MVS DRIVER
STEP TWO
You willneed to click the “Browse” button and search for the QED_30000XXXX
license key file (you willreceive the license key file along with tracking number
after purchase).
Once the license file has been found, click open and then click the
“Activation” button to activate your license key.
Please wait for the “Success” message for the activation to be complete.
NOTE:
It is important to have
internet access for the
Activation process.
8
SWING OPTIX INSTALL GUIDE
STEP ONESTEP ONE
STEP TWO
0.5 LICENSE AND ACTIVATION
9
SWING OPTIX INSTALL GUIDE
Besides your normal background room lighting, additional lightingis required to optimize the SwingOptix.It is recommended to add a minimum of 815W or
higher, non flickering LED light bulbs on a track railwith fixtures. This will help with exposure and eliminating blurring of the club.
Ex:11 non flickering LEDswere used in the environment below.
NOTE:
It is important to angle the
light fixtures away from
the projector light path.
0.6 LIGHTING ENVIRONMENT
15
Note: The LED bulbs on this list have been tested with Uneekor Swing Optix cameras under a 15’ x 10’ enclosure using Uneekor QED and EYE XO
hardware. These bulbs demonstrated minimal ickering during operation to not impeed Swing Optix cameras performance. If you’re still experiencing
issues with the selected bulbs on this list, please contact support@uneekor.com for further assistance. Thank you.
# Brand Where to Buy? Model LED Wattage Wattage Rep. Lumens Light Appear. Dimmable
1Philips Amazon 5967531U0 8.5W 65W 750 2700K Y
2Philips Amazon 9290023277 8.5W 60W 800 2700K Y
3Philips Amazon 9290011531A 7W N/A 500 2700K Y
4Philips Amazon 9290013221 10W 75W 850 3000K Y
5Touchstar Amazon PAR30S 12W 75W 840 3000K Y
The follwing compatible projectors have been approved by Uneekor to function properly with Swing Optix cam-
eras. If you experience issues with the selected projector(s) on this list, please contact support@uneekor.com
for further assistance. Thank you.
Projectors
Compatible Models Type Lumens Throw Ratio
Panasonic PT-VZ590U WUXGA 3LCD 5000 1.09 - 1.77:1
NOT Compatible
BenQ MH530FHD
BenQ LK953ST
BenQ LK953ST
Optoma ZU606TST-W
ViewSonic PRO8800WUL
LED Bulb Recommendations
0.6.1 LIGHT ENVIRONMENT
10
SWING OPTIX INSTALL GUIDE
0.7 SWING OPTIX CONFIGURATION
STEP ONE
Open the View software. Proceed onto the main
home screen of the View software.
STEP TWO
Click on the “Swing” tab in the navigation column
on the left side.
STEP THREE
Inside the “Swing” tab, click on the “Settings” button
on the top right of the screen. Next, click on the
“Optix” tab to open the Swing Optix cameras.
SWING OPTIX INSTALL GUIDE
STEP ONE STEP TWO
STEP THREESTEP FOUR
STEP FOUR
You can make adjustments to the camera’s
Exposure, Gamma, Brightness, and Contrast
in this menu. This is dependent on your lighting
environment.
You are now finished.
