Uni-Vent 731 Series User manual

Operation Manual
731 Series Electrical Mini Ventilator (EMV+)
Uni-Vent®
Impact P/ 906-EMVP-02
Revision 6.0
Impact Instrumentation, Inc. 27 Fairfield Place West Caldwell, ew Jersey 07006

2
0470

3
EMV+ MAI FEATURES: FIGURE 1

4
TABLE OF CO TE TS
LIST OF FIGURES ....................................................................................................................................... 6
CO VE TIO S, TERMI OLOGY A D ABBREVIATIO S ............................................................................. 7
I TE DED USE ......................................................................................................................................... 8
ACCESSORIES LIST .................................................................................................................................... 9
LIMITED COPYRIGHT RELEASE ................................................................................................................ 11
WAR I GS A D CAUTIO S REGARDI G USE ........................................................................................ 12
EMV+ A D PULSE OXIMETER ...................................................................................................................... 12
SYMBOLS A D ICO S............................................................................................................................. 15
U PACKI G, ASSEMBLY A D CO ECTIO S ......................................................................................... 16
SET-UP ................................................................................................................................................... 17
EXTER AL GAS SOURCES ........................................................................................................................... 18
VE TILATOR CIRCUIT CO ECTIO S ............................................................................................................. 20
VE TILATOR CIRCUIT PATIE T CO ECTIO S ................................................................................................. 21
VE TILATOR CIRCUIT RESISTA CE A D COMPLIA CE ........................................................................................ 22
OPERATI G POWER SELECTIO & STOPPI G .................................................................................................. 22
SELF CHECK ............................................................................................................................................ 22
TRA SDUCER CALIBRATIO ........................................................................................................................ 23
OPERATIO OVERVIEW ......................................................................................................................... 24
I TRODUCTIO ....................................................................................................................................... 24
DESCRIPTIO OF CO TROLS A D DISPLAY ............................................................................................ 27
CO TROLS ............................................................................................................................................. 28
VISUAL I DICATORS ................................................................................................................................. 35
LCD ALARM I DICATORS .......................................................................................................................... 37
ALARM TUR OFF & CA CELLATIO ........................................................................................................... 38
POP UP MESSAGES ................................................................................................................................... 39
OPERATIO ............................................................................................................................................ 40
MODES OF OPERATIO ............................................................................................................................. 40
ADJU CTS TO MODES OF OPERATIO ........................................................................................................... 41
SPO TA EOUS/ ASSISTED BREATH TRIGGER ................................................................................................... 42
OPERATIO AL TEST PROCEDURE .................................................................................................................. 42
TO BEGI VE TILATIO ............................................................................................................................. 43
TO CHA GE SETTI GS ............................................................................................................................... 44
BACK UP VE TILATOR ............................................................................................................................... 45
PULSE OXIMETER ..................................................................................................................................... 45
HUMIDIFICATIO ..................................................................................................................................... 45
HAZARDOUS E VIRO ME T FILTERS .................................................................................................... 47
BACTERIAL/ VIRAL FILTER USE ..................................................................................................................... 47
CHEMICAL/ BIOLOGICAL FILTER USE ............................................................................................................. 47
CHECK VALVE O BREATHI G CIRCUIT WHE I HAZARDOUS E VIRO ME T ......................................................... 48
HARSH E VIRO ME T OPERATIO ....................................................................................................... 50

5
AIRBOR E PARTICULATES .......................................................................................................................... 50
EXTREME TEMPERATURE E VIRO ME TS...................................................................................................... 50
ALTITUDE .............................................................................................................................................. 50
RAI A D S OW ..................................................................................................................................... 51
ALARM FU CTIO S ............................................................................................................................... 53
ALARM PRIORITIES ................................................................................................................................... 53
VE TILATOR ALARM CATEGORIES ................................................................................................................ 54
PULSE OXIMETER ALARMS ......................................................................................................................... 57
ROUTI E CARE: CALIBRATIO , CLEA I G A D PREVE TATIVE MAI TE A CE .................................... 59
CALIBRATIO CHECKS ............................................................................................................................... 59
GE ERAL CLEA I G ................................................................................................................................. 59
PREVE TATIVE MAI TE A CE .................................................................................................................... 59
REMOVABLE FOAM FILTER REPLACEME T ...................................................................................................... 60
FRESH GAS/ EMERGE CY AIR I TAKE DISK FILTER REPLACEME T ......................................................................... 60
POST CO TAMI ATED E VIRO ME T CLEA I G ............................................................................................ 60
BATTERY CAPACITY, CARE A D RECHARGI G ........................................................................................ 62
BATTERY CAPACITY .................................................................................................................................. 62
BATTERY CARE A D CHARGI G ................................................................................................................... 62
I CASE OF DIFFICULTY .......................................................................................................................... 63
OPERATOR CORRECTABLE PROBLEMS ........................................................................................................... 63
OPERATI G PROBLEMS REQUIRI G SERVICE ................................................................................................... 63
STORAGE I FORMATIO ....................................................................................................................... 63
LIMITED WARRA TY .............................................................................................................................. 67
APPE DIX 1: ALARMS ............................................................................................................................ 68
APPE DIX 2: P EUMATIC DIAGRAM ...................................................................................................... 87
APPE DIX 3: PULSE OXIMETER PRI CIPLES A D SPECIFICATIO ........................................................... 88
APPE DIX 4: I TER AL BATTERY CHA GE/ I SERTIO ......................................................................... 90
APPE DIX 5: I TER AL FILTER CHA GE/ I SERTIO ............................................................................. 91
APPE DIX 6: USE OF LOW FLOW OXYGE ............................................................................................. 93
APPE DIX 7: RECHARGI G GUIDELI ES ................................................................................................. 95
APPE DIX 8: POP UP MESSAGE LIST ...................................................................................................... 96

6
LIST OF FIGURES
EMV+ MAI FEATURES: FIGURE 1 ........................................................................................................... 3
CO ECTOR PA EL: FIGURE 2 .............................................................................................................. 17
EXTER AL GAS SOURCES: FIGURE 3 ...................................................................................................... 18
FRESH GAS/EMERGE CY AIR I TAKE: FIGURE 4 .................................................................................... 19
VE TILATOR CIRCUIT, DEVICE CO ECTIO S: FIGURE 5 ....................................................................... 20
VE TILATOR CIRCUIT, PATIE T CO ECTIO : FIGURE 6....................................................................... 21
CO TROLS A D I DICATORS: FIGURE 7 ................................................................................................ 26
EXAMPLE OUTLI ED / ORMAL TEXT: FIGURE 8 ................................................................................... 27
VISUAL I DICATORS: FIGURE 9 ............................................................................................................. 34
ALARM & PLOT LIST: FIGURE 10 ............................................................................................................ 37
POP UP MESSAGE EXAMPLE: FIGURE 11 ............................................................................................... 40
CHECK VALVE CO ECTIO TO BREATHI G CIRCUIT: FIGURE 12 .......................................................... 48
HAZARDOUS E VIRO ME T FILTERS: FIGURE 13 ................................................................................. 49
ALARM DISPLAY: FIGURE 14 .................................................................................................................. 52
P EUMATIC DIAGRAM : FIGURE 15 ...................................................................................................... 87
PULSE OXIMETER DISCRETE SATURATIO TRA SFORM: FIGURE 16 ..................................................... 89
BATTERY CHA GE I STRUCTIO S: FIGURE 17 (A)-(E) ............................................................................ 90
FILTER CHA GE I STRUCTIO S: FIGURE 18 (A)-(I) ................................................................................ 91
OXYGE RESERVOIR BAG ASSEMBLY (PART #704-0004-00): FIGURE 19 ................................................ 94
EMV+ STORAGE CASE (PART #703-0EMV-03): FIGURE 20 ...................................................................... 95

7
CO VE TIO S, TERMI OLOGY A D ABBREVIATIO S
C O VE TIO S
WAR I G!
A WARNING statement identifies conditions or information that could have an adverse effect upon the
patient or operator which if not avoided could result in death or serious injury.
CAUTIO !
A CAUTION statement provides important information about a potentially hazardous situation which if
not avoided may result in minor or moderate injury to the patient operator or damage to the equipment
or other property.
OTE:
A NOTE provides additional information intended to avoid inconvenience during operation.
A BBREVIATIO S
A/C- Assist/Control LED - Light Emitting Diode
ACLS- Advanced Cardiac Life Support LPM - Liters per Minute
ALS- Advanced Life Support ml - Milliliters
ATLS- Advanced Trauma Life Support mm - Millimeter
ACV- Assist-Control Ventilation PPV – Noninvasive Positive Pressure
Ventilation
ATPD - Atmospheric Temperature and Pressure Dry O
2
- Oxygen
BPM - Breaths per Minute P
aw
- Airway Pressure
B/V - Bacterial/Viral Filter PEEP - Positive End Expiratory Pressure
cm H
2
O - Centimeters of Water PIP - Peak Inspiratory Pressure
CPR - Cardiopulmonary Resuscitation psig - Pounds per Square Inch Gage
DISS
-
Diameter Index Safety System
USP - United States Pharmacopeia
FIO
2
-
Fraction of Inspired Oxygen VAC - Volts AC
HME - Heat and Moisture Exchanger VDC - Volts DC
HME/BV
-
H
eat and Moisture Exchanger/Bacterial
Viral filter combined
V
T
- Tidal Volume
Hz
–
Hertz (as in frequency cycles per second)
WOB – Work of Breathing
ID - Internal Diameter
L - Liters

8
I TE DED USE
The Model 731EMV+ (EMV+) is indicated for use in the management of infant through adult patients
weighing ≥5 kg with acute or chronic respiratory failure or during resuscitation by providing continuous
positive-pressure ventilation. It is appropriate for use in hospitals outside the hospital during transport
and in austere environments where it may be exposed to rain dust rough handling and extremes in
temperature and humidity. With an appropriate third-party filter in place it may be operated in
environments where chemical and/or biological toxins are present (see External Filter Use). It is not
intended to operate in explosive environments. The EMV+ is intended for use by skilled care providers
with knowledge of mechanical ventilation emergency medical services (EMS) personnel with a basic
knowledge of mechanical ventilation and by first responders under the direction of skilled medical care
providers.
The EMV+ ventilator is a small extremely durable full-featured portable mechanical ventilator designed
to operate in hospitals or austere and under-resourced environments. It can be used in prehospital (ALS
ATLS ACLS) field hospital and hospital settings. Easy-to-use durable lightweight and portable the EMV+
is built with the same standard of quality reliability and performance that all Impact
®
products are known
for.
F EATURES
•Portable critical care ventilator that can be used in the hospital aeromedical and ground
transport mass casualty situations and extreme environments
•Multiple modes of ventilation for use with acute or chronic respiratory failure in both intubated
and nonintubated patients.
•Intuitive operator interface minimizes operator training and protects existing settings from
inadvertent contact and manipulation.
•Lightweight (9.7 lbs 4.4 kg) provides for easy transport
•Rechargeable battery provides over 10 hours of operation (at factory default settings with pulse
oximeter operating).
•Operating temperature range from -25° to 49°C (Impact Instrumentation validated testing) and
from 10° to 40°C (SGS listed).
•Altitude compensation from -2000 to 25 000 feet
•Self-contained system that operates with or without external O
2
.
•Gas manifold design allows operation with both high and low-pressure O
2
sources. . All O2 is
delivered to the patient circuit none vented or wasted to operate the device.
•Sealed gas path with chemical/biological filter connected to assure safe breathing gas supply.
•Sealed case and control panel protects components from weather and fluids.

9
SHIPPI G CO TE TS
OTE:
Shipping contents may be different for military and government customers based on
contract spec
ifications. Please refer to the packing slip enclosed with your unit.
ACCESSORIES LIST
The Accessories List contains common items required from time to time some of which are not provided
with each EMV+ at the time of delivery. Each item is preceded by its part number. Accessories may be
ordered direct from Impact or through your local distributor. When ordering please include the part
number description and quantity required.
Send purchase orders to:
Impact Instrumentation Inc.
P.O. Box 508 Telephone orders: 973/882-1212
West Caldwell New Jersey 07007-0508 Fax orders: 973/882-4993
Email:
Government Non-Government
[e-mail] [e-mail]
PART UMBER
PART DESCRIPTIO
024-0012-00 AC/DC Power Supply 110-240 VAC 100Watts 24 Volts 4.2A IEC320 Plug
708-0042-00 AC Power line cord 6’ (United States Version)
402-0032-00 Padded carry case tan material
465-0024-00 Filter Bacterial/Viral (B/V)
465-0025-00 Filter HME/ B/V Heat and Moisture Exchanger
465-0027-00 Filter Disk B/V Emergency Air Intake
465-0028-00 Removable foam compressor inlet filter
820-0108-00 Heat and Moisture Exchange (HME) Adult
820-0109-00 Heat and Moisture Exchange (HME) Pediatric
820-0110-00 Heat and Moisture Exchange (HME) Infant
704-0004-00 Assembly Kit O2 Reservoir 3 Liter
704-0EMV-05 Assembly Cable DC External Power 28 V
704-0EMV-06 Assembly Cable DC External Power 12 V
708-0036-00 Pulse Oximeter Probe Sensor Adult Reusable
708-0043-00 Pulse Oximeter Pediatric Reusable
708-0037-00 Pulse Oximeter Patient Cable Reusable
708-0039-00 Pulse Oximeter Adult - Ear Reusable
708-0047-00 Pulse Oximeter Infant Single Patient Use
820-0106-00 Circuit Vent Single Limb Pediatric/Adult (disposable)
820-0106-15 Circuit Vent Single Limb Pediatric/Adult (disposable) (case of 15)
820-0107-00 Circuit Vent Single Limb Infant/Pediatric (disposable)
820-0107-20 Circuit Vent Single Limb Infant/Pediatric (disposable) (case of 20)
825-0002-00 High pressure Oxygen Hose DISS x DISS oxygen 6’
907-EMVP-01 Quick Reference Guide laminated
906-EMVP-02 Operation Manual (Commercial)
909-EMVP-02 CD format Operation Manual (Commercial)
703-0731-03 Carry-all Case with Foam Inserts Rechargeable
703-0731-11 Assembly Case Transit Carry
703-0731-12 Assembly Case Transit Carry w/ AC Bulkhead Connector
703-0731-13 Assembly Case Transit Carry w/ AC Bulkhead & USB Connectors
703-0731-14 Assembly Case Transit Carry w/ Wheels & Pull-Out Handle

10
PART UMBER
PART DESCRIPTIO
703-0731-15 Assembly Case Transit Carry w/ Wheels & Pull-Out Handle AC Bulkhead
Connector
703-0731-16 Assembly Case Transit Carry w/ Wheels & Pull-Out Handle AC Bulkhead & USB
Connectors
703-0731-01 Assembly Battery Pack Lithium-Ion 6.6 Ah
704-0EMV-XX Extension Cord 8’ US Hospital Grade Female Plug to ***
708-0041-XX Cordset 6’ IEC 60320-C5 Plug to ***
704-0700-01 Check Valve Kit
812-0011-00 Mask CPAP #6 Large Adult
812-0010-00 Mask CPAP #5 Adult
812-0009-00 Mask CPAP #4 Child
812-0008-00 Mask CPAP #3 Small Child
812-0007-00 Mask CPAP #2 Infant
812-0006-00 Mask CPAP #1 Small Infant
334-0125-00 Harness Mask Universal
*** Country Specific (Contact factory for complete part # for each country)

11
LIMITED COPYRIGHT RELEASE
Permission is hereby granted to any military/governmental agency to reproduce all materials furnished
herein for use in a military/governmental service training program and/or other technical training
program.
MASIMO PULSE OXIMETER
This device uses Masimo SET® technology to provide continuous pulse oximeter and heart rate monitoring
and is covered under one or more of the following U.S.A. patents: 5 758 644 5 823 950 6 011 986
6 157 850 6 263 222 6 501 975 and other applicable patents listed at www.masimo.com/patents.htm.
QNET BV
Hommerterweg 286
6436 AM Amstenrade
The Netherlands
Manufactured y:
IMPACT Instrumentation Inc.
27 Fairfield Place, West Caldwell, NJ 07006, U.S.A
P.O Box 508, West Caldwell, NJ 07007-0508, U.S.A

12
WAR I GS A D CAUTIO S REGARDI G USE
EMV+ A D P ULSE O XIMETER
WAR I G!
Electric
shock
hazard: Do not remove equipment covers except to replace batteries! An
operator may only perform maintenance procedures specifically described in this manual. Refer servicing
to Impact or an authorized Impact Service Center in the re
pair of this equipment.
WAR I G! The device is intended for use by qualified personnel only! The operator should read this
manual all precautionary information and specifications before using the device!
WAR I G! Possible explosion hazard if used in the presence of flammable anesthetics or other
flammable substances in combination with air oxygen
-
enriched environments or nitrous oxide!
WAR I G!
During operation the EMV+ unit should not be stacked on top of or under other medical
equipment due to the possibility of electromagnetic interference between the EMV+ and other
equipment. (The EMV+ was subjected to EMC testing in accordance with Military Mil-STD-461F and
Commercial IEC 60601
-
1
-
2 and FDA Reviewers Guidance specifications.)
WAR I G!
Grounding:
•Connect the EMV+ only to a three-wire grounded hospital-grade receptacle! The three-conductor
plug must be inserted into a properly wired three-wire receptacle; if a three-wire receptacle is not
available a qualified electrician must install one in accordance with the governing electrical code.
•Do not under any circumstances remove the grounding conductor from the power plug!
•Do not use extension cords or adapters of any type! The power cord and plug must be intact and
undamaged.
•If there is any doubt about the integrity of the protective earth conductor arrangement operate the
oximeter on internal battery power until the AC power supply protective conductor is fully functional!
WAR I G!
To ensure patient
electrical isolat
ion connect only to other equipment with electronically
isolated circuits!
WAR I G! Do not use antistatic or conductive hoses or tubing with this device!
WAR I G!
Do not connect to an
electrical outlet controlled by a wall switch or dimmer!
WAR I G!
As with all medical equipment carefully route the ventilator circuit hose and tubing patient
cabling and external power cables to reduce the possibility of patient entanglement or strangulation!
WAR I G!
Do not place the EMV+ or external power supply in any position that might cause it to
fall on
the patient! Do not lift the EMV+ by the power supply cord ventilator circuit or pulse oximeter patient
cable!
WAR I G!
Do not use the EMV+ its pulse oximeter or pulse oximetry sensors during
magnetic
resonance imaging (MRI) scanning! Induced current could potentially cause burns. The EMV+ and/or its
pulse oximeter may affect the MRI image and the MRI unit may affect EMV+ operation or the accuracy of
the oximetry measurements.
WAR I G!
The
EMV+ must be connected to a
grounded AC power supply when connected to AC power.
The EMV+ and its integrated pulse oximeter are referred to as an IEC 601/F device in the summary
situation table contained in IEC
-
601
-
1
-
1.
WAR I G!
USB Interconnection: Do
not operate the device on a patient when the USB is connected to
any other device.
OTE:
The USB interconnection does not support automatic record keeping.
WAR I G!
The Impact supplie
d ventilator circuit’s labeling
provides the resistance and compliance
values for the circuits under normal operating conditions. If added accessories are used (e.g.
humidification filters etc.) the operator should assure they do not degrade the performance of the
device. If non-Impact circuits are used the operator should assure these circuits do not affect the
performance of the device.
CAUTIO !
Federal law restricts this device to sale by or on the
order of a physician.
CAUTIO !
Service is to be performed by qualified biomedical equipment
technicians only.
CAUTIO !
Internal components are
susceptible to
damage from static discharge. Do not remove device
covers.

13
OTE:
This Operation Manual is not meant to supersede any controlling standard operating procedure
regarding the safe use of assisted ventilation.
OTE:
Follow all governing regulations regarding the disposal of any part of this medical device.
OTE:
Follow all governing regulations regarding the handling of materials contaminated by body fluids.
OTE:
Follow all governing regulations regarding ship
ment of the Li batteries.
P ULSE O XIMETER S PECIFIC W AR I GS A D C AUTIO S
WAR I G!
A pulse oximeter should not be used as an
apnea monitor.
WAR I G!
A pulse oximeter
should be considered an early warning device. As a trend towards patient
deoxygenation is indicated blood samples should be analyzed by a laboratory co-oximeter to completely
understand the patient’s condition.
WAR I G! MEASUREMENTS
If the accuracy of any measurement does not seem reasonable first check the patient’s vital signs by
alternate means and then check the pulse oximeter for proper functioning.
Inaccurate measurements may be caused by:
•Incorrect sensor application or use
•Significant levels of dysfunctional hemoglobin (e.g. carboxyhemoglobin or methemoglobin)
•Intravascular dyes such as indocyanine green or methylene blue
•Exposure to excessive illumination such as surgical lamps (especially ones with a xenon light source)
bilirubin lamps fluorescent lights infrared heating lamps or direct sunlight (exposure to excessive
illumination can be corrected by covering the sensor with a dark or opaque material)
•Excessive patient movement
•Venous pulsations
•Placement of a sensor on an extremity with a blood pressure cuff arterial catheter or intravascular
line
•The pulse oximeter can be used during defibrillation but the readings may be inaccurate for a short
time.
WAR I G!
Interfering Substances:
Carboxyhemoglobin may erroneously increase readings. The level of
increase is approximately equal to the amount of carboxyhemoglobin present. Dyes or any substance
containing dyes that change usual arterial pigmentation may cause erroneous readings.
WAR I G!
ALARMS Check alarm limits each time the pulse oximeter is used to ensure that they are
appropriate for the patient being mon
itored.
WAR I G! Loss of pulse signal can occur in any of the following situations:
•The sensor is too tight
•There is excessive illumination from light sources such as a surgical lamp a bilirubin lamp or sunlight
•A blood pressure cuff is inflated on the same extremity as the one with a SpO
2
sensor attached
•The patient has hypotension severe vasoconstriction severe anemia or hypothermia
•There is arterial occlusion proximal to the sensor
•The patient is in cardiac arrest or is in shock
WAR I G! Sensors:
•Before use carefully read the LNCS
®
sensor directions for use.
•Use only Masimo oximetry sensors for SpO
2
measurements. Other oxygen transducers (sensors)
may cause improper performance.
•Tissue damage can be caused by incorrect application or use of an LNCS
®
sensor for example by
wrapping the sensor too tightly. Inspect the sensor site as directed in the sensor Directions for Use
to ensure skin integrity and correct positioning and adhesion of the sensor.
•Do not damage LNCS
®
sensors. Do not use an LNCS
®
sensor with exposed optical components. Do
not immerse the sensor in water solvents or cleaning solutions (the sensors and connectors are not
waterproof). Do not sterilize by irradiation steam or ethylene oxide. See the cleaning instructions
in the directions for reusable Masimo LNCS
®
sensors.
•Do not use damaged patient cables. Do not immerse the patient cables in water solvents or
cleaning solutions (the patient cables are not waterproof). Do not sterilize by irradiation steam or
ethylene oxide. See the cleaning instructions in the directions for reusable Masimo patient cables.

14
CAUTIO !
Possession
or purchase of this device does not convey any expressed or implied license to use
the device with unauthorized sensors or cables which would alone or in combination with this device fall
within the scope of one or more of the patents relating to this device. Impact cannot assure the proper
functioning of this device if it is used with unauthorized sensors or cables.

15
SYMBOLS A D ICO S
(Used with the EMV+ and this manual)

16
U PACKI G, ASSEMBLY A D CO ECTIO S
U PACKI G
Compare shipping case contents against Shipping Contents list. Examine the device and accessories for
any obvious signs of shipping damage. If there is no apparent sign of mechanical damage read
instructions contained within this manual before attempting operation.
A SSEMBLY
The EMV+ only requires that the operator attach the breathing circuit to begin ventilation using either
internal or external power. Both the ventilator and breathing circuit are supplied clean and are ready for
use on a patient.
The EMV+ batteries may not be installed within the unit (depending upon the contractual requirements or
the storage environment as described in the Battery Care and Recharging section). Battery installation
may be required prior to operation. (See Appendix 4 for Battery Installation.)
C O ECTIO S
OXYGE I PUT – connects the unit to the output of an appropriate O
2
regulator attached to a medical-
grade (USP) O
2
cylinder. The OXYGEN IN fitting has a male oxygen Diameter Index Safety System (D.I.S.S.)
thread. It is located on the Connector Panel at the top of the unit (see Figure 2). A green (white for some
installations) 6 foot long high-pressure oxygen hose with compatible fittings that provides for connection
between the unit and the O
2
source is required. (Also see Harsh Environment Operation section).
OTE:
If external O
2
is connected the gas pressure must be at least 41
-
psig (± 2 psig) when SELF
-
CHECK is
performed.
GAS OUTPUT - connects to the ventilator circuit 22 mm ID corrugated hose. The connector is a 22 mm
male conical connection. It is located on the Connector Panel at the top of the unit (see Figure 2).
FRESH GAS/EMERGE CY AIR I TAKE – allows ambient air into the EMV+’s internal compressor. The port
also functions as the internal anti-asphyxia valve which allows the patient to breathe ambient air in the
event of a ventilator failure. The intake contains a particulate filter and permits the operator to connect
either a bacterial/viral or a chemical/biological filter depending on ambient conditions (see Figure 2).
TRA SDUCER (Patient Airway Pressure) – connects to the ventilator circuit 3/16" ID transducer tubing.
The barb-type connector is colored a green/blue to distinguish it from the other connectors (see Figure 2).
OTE:
The 3/16" ID ventilator circuit transducer tubing is a
green/blue
(darker) color. It is located on the
Connecto
r Panel at the top of the unit.
EXHALATIO VALVE – connects to the ventilator circuit 1/4" ID exhalation valve tubing. The barb-type
connector is clear anodized aluminum to distinguish it from the other connectors (see Figure 2).
OTE:
The 1/4" ID ventilator circuit exhalation valve tubing is clear. It is located on the Connector Panel
at the top of the unit.
EXTER AL POWER I PUT – The External Power Input connector is located on the top of the unit. It
accepts DC voltages between 11 and 32 volts (negative ground). The input mates with the output
connector plug of the AC/DC Power Supply 12 and 28 VDC Power Cables (both are available as
accessories) or the external battery (see Figure 2).

17
CO ECTOR PA EL: FIGURE 2
SET-UP
The EMV+ can be configured to suit most applications. Additional hoses fittings and adapters may be
required for particular uses.
1. For use with external O
2
: connect a green (white for some installations) high-pressure O
2
hose to
the OXYGEN IN fitting and a 55 psig external source.
OTE: Use only with medical-grade (USP) oxygen. When using with an oxygen cylinder the cylinder must
be secured.
2. Connect the disposable ventilator circuit to the GAS OUTPUT TRANSDUCER and EXHALATION
VALVE connectors on EMV+ Connector Panel. Follow the directions included with the disposable
ventilator circuit.
3. In a high-dust or biological environment a bacterial/viral filter should be attached to the Fresh
Gas/Emergency Air Intake to prevent entrainment of particulate or biological matter. (See
section on Hazardous Environment Filters.)
4. In toxic biological or chemical environments the user can attach a chemical/biological filter to the
Fresh Gas/Emergency Air Intake. The threaded interface accommodates chemical/biological
filters with an Rd 40 x 1/7 interface (see BS EN 148-1 1999 Respiratory protective devices –
threads for face pieces). (See section on Hazardous Environment Filters.)
5. For use with AC power: connect the AC/DC Power Supply (supplied) to the External Power Input
(see Figure 2).
OTE: The EMV+ can operate from internal battery or from external AC or DC power sources. See
section entitled Operating Power Selection & Stopping for details.
WAR I G! Always assure that there is an alternate means of providing ventilation. A bag-valve
resuscitator and an appropriate mask for the patient being ventilated should be immediately available.
WAR I G! This unit’s USB connection (unlabelled) does not provide any signal output or input to the
Operator. It is for the use of Impact Instrumentation trained personnel only. The Operator should not
connect anything to the USB connection.
HIGH PRESSURE
OXYGEN INPUT
GAS
OUTPUT EXTERNAL POWER
INPUT
USB
CONNECTOR
TRANSDUCER
(PATIENT
AIRWAY
PRESSURE) PULSE
OXIMETER
CONNECTOR
EXHALATION
VALVE
FRESH
GAS/EMERGENCY
AIR INTAKE

18
E XTER AL G AS S OURCES
The EMV+ can operate using high-pressure O
2
from either bottled O
2
or piped O
2
sources as illustrated in
Figure 3.
EXTER AL GAS SOURCES: FIGURE 3

19
The duration of any given gas cylinder depends on the size & pressure of the cylinder and the rate at
which gas is being used to support the patient. The formula to calculate the operating duration of any
cylinder (based on the Ideal Gas Law) is given below. An example is worked out for a typical large
cylinder. It is recommended that the gas cylinder pressure not be allowed to fall below 300 psi.
V
start
= 9540 liter at 1 atm/ 70
o
F (21
o
C) : from label on cylinder
P
start
= 2640 psig : from label on cylinder
P
present in cylinder
= 300 psig : from pressure gauge on cylinder
V
present in cylinder
= volume remaining in cylinder = (P
present
/ P
start
) V
start
= 1084 liter at 1 atm/ 70
o
F (21
o
C)
V
delivered
= 9540 – 1084 = 8456 liter at 1 atm/ 70
o
F (21
o
C)
For a typical ventilator setting (20 BPM Vt = 500 ml FIO
2
=100% I time = 1 sec I:E = 1:2.0) the gas
consumption is 10 liter/min.
OTE:
Whenever external high
-
pressure O
2
is used the EMV+ automatically determines the O
2
usage and
displays it in the FIO
2
parameter window. (See O
2
Use under FIO
2
in Description of Controls and Display.
Total duration of the gas cylinder in above example = V
delivered
/ (10 liter/min) = 8456/10 min = ~14
hours
FRESH GAS/EMERGE CY AIR I TAKE: FIGURE 4
WAR I G! Never block the FRESH GAS/EMERGENCY AIR INTAKE. A free flow of air is required during
compressor operation or in the event of a device failure to allow spontaneous breathing. The FRESH
GAS/EMERGENCY AIR INTAKE also acts as an anti-asphyxia port in the event of a ventilator failure.

20
V E TILATOR C IRCUIT C O ECTIO S
The EMV+ is designed to operate using a standard disposable ventilator circuit. The circuit is attached to
the ventilator as shown in Figure 5.
VE TILATOR CIRCUIT, DEVICE CO ECTIO S: FIGURE 5
CAUTIO ! Always dispose of the circuit after single patient use following the institutional guidelines for
biologically contaminated material. Reusing the circuit can result in cross contamination between
patients.
