UniData Communication Systems SQ-3500 User manual

User Manual
This manual includes product specifications and instructions for SQ-3500 phone operation. This manual must be read before operating the product.
The SQ-3500 phone access point is required to use this product. Usage of the SQ-3500 access point provided in the full package is recommended.

Safety Precautions
Do not put the SQ-3500 in heating appliances such as heaters and microwave ovens to dry it if the device is wet.
This can cause explosions, deformation, or other problems. If this occurs, free services shall not be provided.
Do not use the SQ-3500 in places that are too hot or too wet (keep it indoors between 0 ℃and + 50 ℃).
If the device gets wet with rain, or through spilled beverages, or is used in extremely hot/wet places such as public saunas, it can cause battery explosions.
Be careful that conductors such as necklaces, keys, and coins not to contact battery terminals (the metal section).
Since short circuits can cause explosions, be careful to prevent this.
Keep the SQ-3500 and chargers out of the reach of children or pets.
Batteries in the mouth, or using broken batteries, can hurt or cause electric shocks.
Be sure to only use the designated batteries and accessories for the SQ-3500 provided by our company.
If you use unauthorized batteries or accessories, it can reduce the life of the SQ-3500, cause explosions, or damage. If this occurs free servicing is avoid .
Correctly install the SQ-3500 in compliance with instructions.
Otherwise, abnormal operation of the SQ-3500, or a reduction in its life span may occur.
Record and keep the information contained in the SQ-3500 separately.
Since important information stored in the SQ-3500 can be removed due to unavoidable circumstances such as user carelessness, maintenance, and product
upgrades, please keep a record of important information. Take note that the manufacturer will not take responsibility for any damage from the loss of
information.
Never push the power button when the SQ-3500 is wet, and do not touch the SQ-3500, charger, or power cords with wet hands. This
can cause fires or electric shocks. The SQ-3500 is not water-resistant. Keep it dry
Do not use chemical detergents such as benzene, thinners, and alcohol to clean the SQ-3500.
This can cause fires.
1

Safety Precautions
Do not hold the SQ-3500 to your ears to turn on the power. This can cause hearing impairments or physical injuries.
Do not look at the infrared window in a direct way when using the remote control. this can cause visual impairment.
Refrain from the use of SQ-3500, and leave the power cord for the charger unplugged when it is thundering and flashed lightning.
Thunderbolts can cause severe physical injuries or fires.
Do not disassemble the SQ-3500 temporarily, or apply shocks to device.
If the device is damaged when you disassemble it, or inflict shocks on the device, it causes electric shocks, electric leakage or fires.
2

Index
Safety Precautions………………………………………………………………………………....................................................................................1
Basic Components...………….…………………………………………………………………………………….….…...………………………….……4
Battery Replacement….…………………………………………………………………………………….......….……………………………….……...5
TimeTaking to Charge / Battery Life………………...………………………………………………………….……………………………………….6
Inserting / Removing a micro SD card…..…………………………………………………………………….…………………………………………8
Power On/Off………………………………………………………………………………………..................................................................................9
Names & Function of Device Parts……………………………………...………………………………………………………………………………10
Display Indicators…………………………………………………………………………………………………………………………………………..11
Calling Method……………………………………………………………………..………………………………………………….……………………12
Phone Book………………………………………………………………………………………………………………………………………………….20
Messaging………………………………………………………………………………………………………...…………….……………………………27
Display………………………………………………………………………………………………………………………………………………………..28
Sound Settings…………………………………………………………………………………………………………………………………...…………29
Tools………………………………………………………………………………………………………………………………………………...………..30
Multimedia…………………………………………………………………………………………………………..………………………………………31
Logs…………………………………………………….…………………………………….……………………………………………..………………..32
Settings……………..……………………….……………………………………………………………………………………………..………………..33
Before going to service Center …………………………….…………………………………………………………..............................................43
3

Basic Components
Phone Cradle Battery Manual Adapter
The Basic Components as shown below may be different from the original.
For safety in use, please purchase authentic products. If you want to purchase additional batteries or chargers, contact your dealer.
4

CAUTION
RISK OF EXPLOSION IF A BATTERY IS REPLACED WITH AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
Battery Replacement
Use only batteries authorized by the company when you replace batteries, following the diagram below.
Battery installation method Battery removal
If the battery is inserted upside down, the SQ-3500 phone will not work. Please turn off the power before removing the battery from the SQ-3500 phone.
(a sudden power off can cause problems)
Battery Replacement
5
①
②
③ ①
②

Charge the battery
Charge the battery after purchasing the product as it is not fully charged.
Charging with the desktop charger
※Lamp on the charger flickers? Separate the battery from the charger, and
then re-fits into the charger. It is still flickering? Then, cleans the charging
terminal and charge the battery. (When the lamp doesn‟t stop flickering, apply
to the dealer.)
Features Charging Charging
Complete
Charging Lamp RED GREEN
TimeTaking to Charge / Battery Life
6

TimeTaking to Charge / Battery Life
※Battery life varies with the environment temperature,
battery age and movement of the user.
-Battery life is not permanent
Model Standard Model
Charging time 3 hours 30 minutes
Battery life
(continuous
calling)
Voice 6 hours
Video 3 hours
TimeTaking to Charge / Battery Life
The successive use time and standby time of batteries are the
estimates of the company‟s laboratory, which can vary from
the figures in the manual depending on the patterns used
7

Inserting the micro SD card
Inserting / Removing the Micro SD card
Use Only compatible micro SD cards approved by UniData for use with this device. UniData uses approved industry standards for memory
cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card, the device and corrupt data
stored on the card.
The phone supports micro SD cards up to 8GB.
1. Open the side cover of the micro SD slot.
2. Insert the card into the micro SD card slot with the contact surface facing down, and press it until it locks into place.
3. Close the side cover.
Remove the micro SD card
1. Make sure that no application is currently accessing the micro SD memory card.
2. Open the side cover of the micro SD slot.
3. Press the micro SD card slightly in to release lock, and pull the card out.
Important: Do not remove the memory card in the middle of an operation when the card is being accessed.
Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the
card may be corrupted.
You can remove or replace the micro SD card during phone operation without switching the device off.
8

If you want to turn on the power,
keep pressing for 3 seconds or more.
If you want to turn off the power, keep pressing for 3
seconds or more.
If anything abnormal takes place, or if the power button does not work while using a Wi-Fi phone, start the phone after removing and
inserting the battery.Turn on the power after waiting for 5 seconds or more when you restart the phone
Power On / Off
9

Names & Function of Device Parts
10
21 19
14
6 Left Selection Key
7Right Selection Key
8 Mute Shortcut
9AP Search Key
10 Alarm Shortcut
11 Using Message function
12 Calendar
13 Using user-defined function
14 Volume Control
15 MIC
16 Micro SD Insert hole
17 Earphone
18 Earpiece
19 Speaker
20 Camera
21 Back Camera
1 Send Key
Used for receiving and making call
2 End Key
Used to end a call and to switch the
power ON/OFF
3 Clear Key
Removing characters or moving to
previous screen.
4 Vibration shortcut
Press and hold to vibrate
5 Key Lock
Lock and unlock the keypad.

Signal strength
Out of call coverage area
Call trial or connection
Call not available
You have selected the sound setting
Mute button, displayed when the volume is set to “0”
Vibration Mode
Silent Mode
AnAlarm is set
You have one or more unread messages in the Inbox folder
Setting to call forwarding service
Remaining battery life
Full Low Empty
Connecting to network
Display Indicators
11

Voice Calls
Call
Connect
In standby, enter the numeric keys and then press the key
※Call quality may be reduced at increased distance away from the access point.
Calling Method
12

Call
connect
In standby, enter the numeric keys and then press .
※Call quality may be reduced at increased distance away from the access point.
Calling Method
Video Calls
13

Redialing recently used numbers
You can make voice or video calls by dialing
recently used numbers (incoming, outgoing,
missed, received/sent text messages). During
stand-by, press the SEND key and then select
the phone number you want to call.
- Select VIDEO in the menu if you want to
make a video call.
Speed dialing
You can speed dial saved numbers to make
calls quickly and easily.
During stand-by, enter the speed dial number
but press the last number longer to make a
call.
If you enter the speed dial number and press
SEND key, it does not work as the speed dial.
And the speed dial doesn‟t work by using
video call, only voice call.
Calling Method
Call logs
14

Number
Key
Auto-search
Press a part of the number you want to call to auto-search
the phonebook and display the results. Select a phone number
and press the OK key.
-Press the VIDEO key to make a video call.
※Under Development
Calling Method
15

Making a voice call
•Refer to page 12.
Taking a voice call
Press the SEND key to take an incoming call.
Press the END key to reject an incoming call.
Using the menu during a voice call
Mute:This function stops your caller from hearing your
voice temporarily.The caller's voice can still be heard.
16
Using the Menu During aVoice Call

Making a video call
•Refer to page 13.
Taking a video call
Press the SEND key when the message “Incoming
video call” is displayed.
Press the END key to reject the incoming call.
Using the menu during a video call
Change Camera: To converts the current video preview to back or
front camera sight.
Preview Off: Off the preview.
Mute: This function stops your caller from hearing your voice
temporarily.The caller's voice can still be heard.
View my picture: Turns off your picture and displays your caller's
picture only. (Changes to 'Hide my picture' when your picture is in
display.)
Using the Menu During a Video Call
17

If you have a missed call, press , and the last one of those calls will be answered.
To see calls that have arrived in your absence from the call list, press or use the
Left selection key Menu) > Logs > Call history
Missed call
18
