Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

Instructions for Use / Manual

Load Amplifier Cassette LVCpro-S

TRsystems Gmb

Freiburgerstraße 3

75179 Pforzheim

Germany

Tel.: 07231 / 3152-0

Fax: 07231 / 3152-99

email: [email protected]

Web: http://www.trsystems.de

This user manual is kept up to date. As the TRsystems Gmb / UNIDOR products are subject

to continual development, technical modifications might lead to temporary deviations between

the device design and the user manual. Please note that TRsystems Gmb is not liable for

damages caused as a result of these deviations.

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

View of LVCpro-S

Advantages

Functionality

Easy installation and wiring

24VDC supply voltage

2 measuring channels

Peak value memory and current

value available at the same time

Switchable filter for suppression of

disturbances

The load amplifier cassette enables a

cost-efficient multichannel

measurement of the press force by

using piezo sensors, at even

quasi-static processing.

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

Content Page

1.

2.

3.

4.

5.

6.

7.

8.

9.

1 .

11.

12.

13.

14.

Safety Guidelines and Regulations

Technical Specification

Block Diagram

Terminal Assignment

Connector Coding

Connection of the Piezo Sensors

Setting of the Code Switches

Amplification Factors

Setting for DIP-Switches or Filters SW1

Commissioning of the LVCpro-S

Ordering Data LVCpro-S

Mechanical Dimensions LVCpro-S

Opening of the Enclosure LVCpro-S

General Information

4 - 7

8

9

1

11

12

13

14

15

16

17

18

19

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

1. Safety Guidelines and Regulations

Information on Guarantee and Liability

Our “general terms and conditions on sale and delivery” generally apply.

These are available to the operator from the completion of the contract at the latest .

Guarantee and liability claims for personal and material damages are excluded if

caused by one or more of the following:

•Improper use of the device.

•Improper installation, commissioning, operation and maintenance of the device.

•Operation of the device or machines thereof with faulty safety equipment or with

improper or inoperable safety and protection equipment.

•Failure to observe the regulations of the user manual.

•Unauthorised structural changes on the device or machines thereof.

•Unauthorised modifications to the settings of the initial operation.

•Insufficient control of parts subject to wear.

•Improper repairs of unqualified workers.

•Disaster situations caused by third parties or force majeure.



Disclaimer / Right of Amendment

This user manual is kept up to date. As the TRsystems Gmb / UNIDOR products

are subject to continual development technical modifications might lead to temporary

deviations between the device design and the user manual. Please note that

TRsystems Gmb is not liable for damages caused as a result of these deviations.



Due Diligence of the Operator

The LVCpro-S was designed and constructed followinga risk analysis and upon

careful selection of the relevant standards to be complied with, as well as other

technical specifications. It is state-of-the-art and ensures the maximum possible

safety during operation.

However, the machine safety can only be implemented if all necessary measures

have been taken. The planning of these measures as well as the control of their

implementation is part of the due diligence of the operator.

The operator must ensure that ...

•the machine is used in accordance with its intended purpose.

•necessary personal protective equipment for the operation, maintenance and

repair is available and used.

•

the machine is only operated, serviced and repaired by qualified personnel.

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

Furthermore the operator is responsible for ensuring that...

•this personnel is regularly trained in all relevant matters of occupational safety

and environmental protection and knows the the contents of the user manual and

especially the safety regulations therein.

•All safety and warning symbols attached to the machine must remain thereon

and be clearly legible.

Only use the device:

•forthe intended purpose in safe conditions.

•interferences which impair the safety of the device, must be removed

immediately.

•in an ambient temperature not exceeding a temperature range of to 45°C.



Intended use

The device is exclusively intended for the control and measuring of the machines and

equipment provided for this purpose. Any additional or further use is deemed as not

being in accordance with the intended purpose. The company TRsystems /

UNIDOR is not liable for damages caused following other usage.

Intended use also means:

•only using the device in immaculate condition.

•removing interferences which impair the safety of the device immediately!

•the risk ofinterference and damages of the device and the consequences caused

by its peripheral devices is generally subject to the user.

•ensuring prior to the start-up of the device that nobody can impair the starting of

the device. In case of malfunctions the device must be stopped and secured

immediately.

•

the monitoring of all control displays.



Obligations of the operator

•According to the electrical regulations, works on the electrical equipment shall

only be implemented by skilled electricians.

•The safety-conscious work of the personnel will be monitored periodically. The

user manual must be kept at all times ready to hand in close proximity of the

machine/device.

•Modifications by the client or third parties require the written confirmation of the

manufacturer. If a failure to observe leads to defects or malfunctions, the

supplier and manufacturer will be excluded of the guarantee and liability.

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

•Guarantee and liability will also be void if defects of the device are not

immediately notified to the supplier and appropriate measures for the damage

control were implemented to late or not at all. Spare parts must correspond to

the technical requirements defined by the manufacturer. Unauthorised

modifications to the program and the control system are not allowed. The

location and operation of extinguishers must be announced. The fire fighting

measures and reporting possibilities must be adhered! Extinguishers must be

suitable for the fire fighting of electrical fires.



Safety Instructions for Maintenance and Servicing

•The equipments always must be isolated from the power supply when

implementing maintenance, servicing or repairs.

•After completion of the work the functionality of the safety equipment must be

checked.

•The relevant safety and accident prevention regulations apply for the

corresponding situations.

•For 24VDC power supplies a safe, electric isolation of the low voltage is

important. Only use power supplies designed acc. to IEC 364-4-41 respectively

HD 384. 4.41 (VDE 1 part 41 ).

•Fluctuations or deviations of the mains voltage to the nominal value must not

exceed the tolerance limits defined in the technical specification, as this might

lead to malfunctions and hazardous conditions of the electric components.

•Connection and signal lines shall be installed in a way that inductive and

capacitive interferences (disturbances, e.g. unshielded valves on the machines)

do not impair the automation feature.

•Wiring as well as the opening and closing of electronic connections shall

only be implemented on isolated machines!

•Short-circuits, voltage peaks, etc. can lead to malfunctions and uncontrolled

conditions of the equipment and hence to severe personal and material damages.

•Check all the electric connections prior to the starting of the device!

•Incorrect connections can cause malfunctions of the device, faulty connections

can cause severe personal and material damages.

•Do not replace components under voltage and do not open enclosures

under voltage!

•Mechanical and/or electric modifications on our equipment are not permitted for

security reasons!

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S



General Fault Clearance Measures / Shielding

•The use of electronic sensor active systems in modern equipment requires a

consistent and correctly implemented fault clearance and wiring concept. The

compliance with these requirements is important to ensure the proper function of

a device with electronic measuring systems.

•Access lines must be laid for remote control and must be separated from supply

lines stressed with disturbances (shielded).

•Ensure a continuous wiring of the shield as well as an extensive contact between

the shield and the electric terminals.

•Cable crossings must be avoided. If inevitable exclusively square crossings shall

be used.



In Conclusion

All information is subject to change.

The TRsystems Gmb / Unidor remains the right of modifications, especially

regarding the states values, dimensions and weights as far as they are not

stated elsewhere and lead to product improvements.

All our documentation is protected by copyright.

The distribution to or the use by third parties, of parts or the entire

documentation, requires the written confirmation of TRsystems Gmb /

Unidor.

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2. Technical Specification

Power Supply

Input voltage:

Input current:

1 -32VDC / 24VDC nom.

9 mA

Amplifier

Input resistance:

Output resistance:

1

15

Ω/ Ohm

5 Ω / Ohm

Measuring Window

Input / Cams

Input voltage:

Input current:

Function:

18-32VDC

ca. 1 mA at 24VDC

active high = 1,

Output low = deletes

analogous signal

Output Data

Output voltage:

Output channels:

-1 V to +1 V

2

Dimensions (Wx xD)

Enclosure incl.

connector

35 x 11 x 112mm

3. Block Diagram

Measuring W indow

(Cams)

SW 201

SW 401

Pos.

Input

Sensor

Neg.

Charge amplifier Filter

SW1

I

Mass

Shield

SW202

SW204

50

SN3

SN4

P202

P402

Amplifier

50

SV3

SV4

P102

P302

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

4. Terminal Assignment

upper connectors

Connector

Func

tion

Power

24V

V

NC

24VDC

VDC

not connected

CAM 1+2

C1

C2

V

Cams 1

/

Meas. Channel

1

Cams 2/Meas. Channel 2

VDC

PiezoSensor 2

IN2

GND

CASE

Input Signal

Sensor 2

Analogous-Mass

Shield

PiezoSensor 1

IN1

GND

CASE

Input Signal

Sensor 1

Analogous-Mass

Shield

bottom connectors

Connector

Func

tion

PeakOut 1

OUT1

GND

CASE

Peak Value Output

1

Analogous-Mass

Shield

PeakOut 2

OUT2

GND

CASE

Peak Value Output

2

Analogous-Mass

Shield

AnalogOut1

OUT1

GND

CASE

Output

1 /

-

1

to

+1 V

Analogous-Mass

Shield

AnalogOut

2

OUT2

GND

CASE

Output

2 /

-

1

to

+1 V

Analogous-Mass

Shield

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

5. Connector Coding

1x 1x 2x 4x

Power CAM 1+2 PiezoSensor 1

PiezoSensor 2

PeakOut 1 + 2

AnalogOut1 + 2

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

6. Connection of the Piezo Sensors

Sensor JZT127/S with black connection cable for rack mounting

Terminal assignment for pressure load

Sensors Connector LVCpro-S Core Colour PIN

Press Force Sensor

1

PiezoSensor 1

black

red

Shield

IN1

GND

CASE

Press Force Sensor

2

PiezoSensor 2

black

red

Shield

IN2

GND

CASE

Terminal assignment for tensile load

Sensors Connector LVCpro-S Core Colour PIN

Press Force Sensor

1

Piezosensor 1

red

black

Shield

IN1

GND

CASE

Press Force Sensor

2

Piezosensor 2

red

black

Shield

IN2

GND

CASE



Sensor JZT127/P with white connection cable for rod mounting

Terminal assignment for pressure load

Sensors Connector LVCpro-S Connector PIN

Press Force Sensor

1

Piezosensor 1

black

white

Shield

IN1

GND

CASE

Press Force Sensor

2

Piezosensor 2

black

white

Shield

IN2

GND

CASE

Terminal assignment for tensile load

Sensors Core Colour Connector PIN

Press Force Sensor

1

Piezosensor 1

white

black

Shield

IN1

GND

CASE

Press Force Sensor

2

Piezosensor 1

white

black

Shield

IN2

GND

CASE

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

7. Setting of the Code-Switches

The adjustment of the analogous inputs and outputs will be implemented through

hexadecimal code and DIP-switches.

The adjustments will be implemented separately for each channel.

Channel / Sensor

Code-Switch Function

Channel 1 + 2

SW1 Filter adjustment

Channel 1

SW201 Code-switch for capacitive (rough) amplification

Piezo Sensor 1

SW202 Code-switch for amplification adjustment(fine)

P102 Offset analogous output 1

P202 Offset analogous output peak value 1

Channel 2

SW401 Code-switch for capacitive (rough) amplification

Piezo Sensor 2

SW402 Code-switch for amplification adjustment(fine)

P302 Offset analogous output 2

P402 Offset analogous output peak value 2

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

7. Amplification Factors

Rough Adjustment Fine Adjustment

Capacitive

amplification

Code-switch

SW201, SW401

Capacity

(nF)

Amplification

Adjustment

Code-switch

SW202, SW402

Amplification

factor

(times)

0 71.8 0 11.12

1 65.0 1 11.08

2 61.8 2 11.03

3 55.0 3 10.96

4 49.8 4 10.93

5 43.0 5 10.84

6 39.8 6 10.76

7 33.0 7 10.64

8 38.8 8 10.48

9 32.0 9 10.27

A 28.8 A 10.07

B 22.0 B 9.67

C 16.8 C 9.51

D 10.0 D 8.80

E 6.8 E 7.90

F* 0.0 F 5.27

P3 2

P4 2

P2 2

P1 2

SW4 1

SW4 2

SW2 2

SW2 1

Filter Dippschalter SW1

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

* not permitted code-switch adjustments

Measuring W indow

(Cams)

SW 201

SW 401

Pos.

Input

Sensor

Neg.

Charge Amplifier Filter

SW1

I

Mass

Shield

SW 202

SW 204

50

SN3

SN4

P202

P402

Amplifier

50

SV3

SV4

P102

P302

8. Settings for DIP-Switches or Filters SW1

Channel 1 / Piezo Sensor 1

DIP-Switch Function

ON OFF

(Default)

Factory setting with

filter, F-limit = 1K z

1+2

Turn on either only switch 1 or switch 2 ,

or neither of them!

F-limit = 1KHz (33nF)

(Default 1+2= OFF)

1

F-limit = 1 Hz (22 nF II 33nF)

(1=ON,2=OFF)

2

F-limit = 355Hz (47nF II 33nF)

(2=ON,1=OFF)

Caution: Only switch 3 or switch 4 on ON,

never both at the same time as this might

lead to malfunctions or damages to the

electronics.

3

with filter

(Default 3=ON , 4=OFF)

4

without filter

(4=ON , 3=OFF)

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

Channel 2 / Piezo Sensor 2

DIP-Switch Function

ON OFF

(Default)

Factory setting with

filter, F-limit = 1K z

Caution: Only switch 5 or switch 6 on ON,

never both at the same time, as this might

cause malfunctions or damages to the

electronics.

5

with filter

(Default 5=ON , 6=OFF)

6

without filter

(6=ON , 5=OFF)

7+8

Turn on either only switch 7 or switch 8,

or neither of them!

F-limit = 1KHz (33nF)

(Default 7+8= OFF)

7

F-limit = 1 Hz (22 nF II 33nF)

(7=ON,8=OFF)

8

F-limit = 355Hz (47nF II 33nF)

(8=ON,7=OFF)

9. Commissioning of the LVCpro-S

Wiring of the piezo sensors. Wire the measuring window and the outputs according to

the PIN-assignment. Apply supply voltage (it is important to use the correct polarity!)

Alignment (calibration) of the amplifiers with the piezo sensors used acc. to the table

in chapter 6.

For the code-switches SW2 1 (channel 1) or SW4 1 (channel 2) it is possible to

adjust different sensitivities of the sensors against the basic adjustments, when

working in a multichannel version of the measurement.

Adjustment of the amplification factor acc. to chapter 9 with the relevant code-

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

switches

SW2 2

(

channel

1) or

SW4 2

(

channel

2)

on the basic position

3

.

Adjust the maximum output of the measurement object (e.g. the maximum press

force). Continuously up-shift the code-switch SW2 1 (channel 1) respectively SW4 1

(channel 2) until reaching the desired output voltage on the analogous output (max.

1 V). We recommend a final adjustment of 7V output voltage for maximum load to

still enable an assessment in case of an overload.

If replacing the load amplifier cassette LVCpro-S it is important to maintain the same

adjustment of the code-switches, otherwise there is the risk of overload (falsification

of the measuring results)!

10. Ordering Data LVCpro-S

Article description

Type

Order-No.:

Load Amplification Cassette, 2-channel

LVCpro-S 02

10 40 4302 0000

Load Amplification Cassette, 2-channel

(low amplification / sensitivity)

LVCpro-S 02-G

10 40 4402 0000

Press Force Sensor black sheath (column

mounting) with 6m* connection cable

JZT 127 / S

50 01 01 01 0000

Press Force Sensor white sheath (con-rod

mounting) with 6m*connection cable

JZT 127 / P

50 01 01 06 0000

Coaxial Cable , open ends on both sides(by the

meter)

MIL-C-17F-RG

058 CU

64200120

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

•additional cable length available on request

11.

Mechanical Dimensions of the LVCpro-S

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

12. Opening the LVCpro-S Enclosure

1. Use a screwdriver to push the

splint in the opening tab down,

located underneath the connector

plugs of Power, PiezzoSensor2

and underneath PeakOut2 and

AnalogOut2.

2. Using the screwdriver, push the

splint down from the locked

closure tab

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

3. …and push it backwards at the

same time. Now repeat these

steps for all 4 tabs to remove the

entire enclosure lid.

4. You can now open the LVCpro-S

and the code-switches for the

adjustment and/or calibration of

the press force are accessible.

14. General Information

E

C

-

Declaration of Conformity

Manufacturer: TRsystems GmbH , System Division Unidor

Factory: Unidor , Freiburger Straße 3, 75179 Pforzheim

certifies for the

Product: Load Amplifier

Device Type: LVCpro-S

Model-Name: LVCpro-S 2 , LVCpro-S 2-G

the confirmation of the EC Directive 89/392/EWG and the following standards:

 EN 6 2 4.1, electrical equipment for industrial machines

 Electromagnetic Compatibility 89/336/EWG IEC 8 1 parts 1,2,4

 EN 55 11 Conducted Emissions

Product Specification / User Manual

Load Amplifier Cassette LVCpro-S

2

 EN 55 22 Radio Radiation

 VDE 1 , VDE 113, EN 6 2 4

Issued by: TRsystems GmbH , System Division Unidor

Date: 26 May 2 1

Place: Pforzheim, Germany

unidor TRsystems LVCpro-S Manual

Popular Amplifier manuals by other brands
