Unique 400 User manual

USER GUIDE

Picture apliances ..................................................... 3
Before rst use ........................................................ 4
Tips for saving electrict energy ................................ 6
Important warnings .................................................. 7
Installation and connection....................................... 8
Connection to the electricity grid ..............................9
Device operation .....................................................11
Maintenance and cleaning ......................................14
Troubleshooting ......................................................17

Picture appliances
Equipment apparatus can be changed depending on the model of
the appliance.
The label with basic information about the appliance is located in
the interior or on the back of the device.
3

Before rst use
Before plugging in electrical voltage, a machine is
idle for approximately 12 hours.
This reduces the possibility of improper action due
to the impact of transport on cooling system.
Thoroughly clean the appliance, especially the interior
(Follow advice from the chapter Cleaning).
• Instructions for use are intended to,
and describe the appliance and its correct and safe
use.
• Remove the brackets and protectors of Styrofoam.
• Remove all packaging materials and adhesive tape.
• Before you remove the old cooling appliance, remove
His neck, as this will prevent the children during the
Game accidentally shut inside.
• The packaging of our products designed for the
environment harmless material, which is without risk
for the environment can be reprocessed (recycled) or
destroyed. In this regard, packaging materials
adequately labeled.
• Our guide was also printed on recycling paper, or on
paper, without Bleached chlorine.
• When the appliance is can not be used more when
you spend a bothered, make sure not to be a burden
environment.
Provide the authorized collectors of waste household
appliances (see Removing the old appliance).
• served appliance immediately remove from service.
Unpacking
Our care for the
environment
!
4

Possible to disable the lock To avoid the danger
posed to children from choking.
• Appliances containing refrigerant and insulation
ingredients that require special degradation,
thus removing appliances connect with
authorized and certied municipal
company, or contact the dealer. because
the risk of environmental pollution, be careful not to
damage the pipe in the bottom of the apparatu.
Connect the appliance to the power grid
• Insert the power cord -dovodnog cable into a
grounded outlet, which must not be placed directly
behind the camera.
• Make sure the unit is energized, and so to open
the bottom cover under the door and make sure the
display - a pointer electronic thermostat.
Set the to the desired location.
Note: The door may be about 2.5 cm
moved forward with respect to neighboring
elements.
The thermostat for selection temperature
The thermostat for temperature selection is factory
regulated.
The temperature will settle down after 24 hours.
Attention!
5

Tips for saving
electric energy
• Do not close the appliance door more frequently than necessary.
This is especially important in hot or humid weather.
• Periodically check that the camera has secured a sufcient cooling
degree (smooth air circulation behind the appliance).
• Damaged or poorly attached to seal-magnetic rubber door causes a
higher power, therefore, timely to make sure a suitable replacement.
• The condenser on the lower front side must always be clean and free
of dust or layers of dust (see Cleaning the machine).
• Failure to comply with the instructions described in sections Position-
ing and Saving energy can cause a higher power.
The symbol on the product or on its packaging indicates
that the this product may not be treated as household
waste. Instead it should be handed over to the appropri-
ate collection centers for recycling electronic and elec-
trical appliances.
The correct bussing of this product will help prevent po-
tential negative effects on the environment and human
health, which could otherwise be caused by inappropri-
ate waste handling of this product. For more detailed in-
formation regarding the process, and re the use of this
product, please contact your local ofce, your house-
hold waste disposal or shop where you purchased the
product.
6

Important warnings
The appliance is manufactured in compliance with all relevant security standards, but
nevertheless do not recommend that adequate control using face impaired physical,
motional, or mental abilities, or persons without the required knowledge or experience.
• In accordance with the concern about preserving the environment, taking care not
to damage the structure apparatus (or condenser tubes, for example, in transport the
old appliance), or parts of the cooling system inside the appliance.
• The appliance contains a refrigerant and oil, so remove the damaged machine
compliance with environmental requirements (see section Our concern for the envi-
ronment).
• If the mains supply cable el. Energy is damaged, to avoid danger must substitute
manufacturer, its service agent, or qualied personnel.
• The camera does not keep ammable, volatile or explosive substances, such as eg.
explosives or sprays containing volatile solvent (such as butane,
propane, pentane and the like). These sprays can be identied by the printed label
content or symbol for ammability.
• Bottles with high alcohol must be sealed and arranged in a vertical position.
• Warning: Open for ventilation apparatus, must constantly be kept clean and unob-
structed.
• Warning: To defrost not use mechanical devices or other methods
other than those recommended by the manufacturer.
• Warning: When installing, cleaning and removal of obsolete appliance, make sure
not to damage the insulation or parts of the cooling system. This will prevent
environmental contamination.
• Warning: The interior of the appliance do not use electrical appliances except those
that the manufacturer of the appliance for cooling and freezing.
The appliance is properly connected to the power grid (refer to section
Connection to the power network).
Always unplug from the mains prior to repairs, before cleaning and be-
fore replacing the light bulb.
When switching off the machine, grasp the plug, and do not pull on the
supply cable.
!
7

Installation and
connection
proper functioning of the apparatus is conditioned by
the performance (Class) of the appliance, which is
indicated on the label with data on the appliance.
Unique Wine Cooler 400 is in CC5 Tropic this. class
Do not place the device near a heating and not
ispostavljajte by direct sunlight rays. At short distances
from the source heat, use the isolating plate.
The appliance must be set right, and steady to
sufciently hard surface. All models are equipped
the legs for easier leveling regulation appliance.
Classes Ambient temperature
N (normal) from +16°C to +32°C
SB (subtropical) from + 16 ° C to + 38 ° C
CC5 Tropic from +16°C to +42°C
Selection space
8

Levelling appliances
• Larger Phillips screwdriver or by hand from the
outside Turn the legs and thereby raise or lower the
machine and straighten it.
• Accurately determine the position of the camera,
which should in vertically gently sloping to the back
or front feet should be more twisted by approximately
1 cm from the last two legs and to showcase stands
stable without swaying.
Setting up appliances
The front left leg
The front right leg
Rear Right holder
Last left holder
1. Lowering screwdriver turn right
2. Lifting screwdriver turn left
9

Connecting to
electricity grid
The appliance plug in the mains connecting the supply
cable. The wall socket must be Grounding (security
socket). prescribed rated voltage and frequency are
indicated on the label with basic data on the appliance.
Connecting to the power supply and grounding appli-
ances must be made according to current standards
and regulations. The device can withstand short du-
ration voltage deviations, but only the most from -6 To
+ 6%.
If the voltage is not within the specied label with basic
data on aparatu.-any defects caused by maladjusted
voltage (not built-in correctors voltage) a malfunction
outside the warranty period, and the same can be re-
moved at the expense of the customer.
10

Device operation
Regulating
Temperature-thermostats
Dixell XR03CX
The temperature electronic display cases for drinks you can
regulated between 2 ° C and 18-20 ° C. Showcase for drinking
place in the room, where the temperature drops below 16 ° C or
exceeds 42 ° C.
11

The screen display shows the actual temperature the
temperature in the glass case on the rst shelf. Actual
temperature may differ from the selected, depending on the
frequency of opening the door of the wine, and ambient
temperature.
After a change of regulation, before the new changes wait 12
to 24 hours to reach Showcase regulated temperature.
Any change of preset temperature areas require intervention
authorized service center or a professional person.
Temperature can be adjusted between + 2 ° C up to + 14 ° C
without temperature ranges for cooling red wine.
+ 2 ° C to + 4 ° C - white wine
+ 4 ° C to 6 ° C sparkling wines
+ 7 ° C to 9 ° C-liqueur wines
+ 10 ° C to + 12 / + 14 ° C - rose wines
In the display cabinet by means of thermal Brass system
controls the amount of moisture, the optimal amount of
humidity for storing wine in the interval from 55% to 80%,
which can be traced from the hydrometer, which is located on
the rst shelf.
Interior lighting provides better illumination of bottles and their
labels, as well as better visibility of your collection of drinks.
Interior lighting refrigerated cabinets is done blue LED, which
has negative and adverse impact on the wine.
Key lighting is on the thermostat Dixell XR03CX left bottom
row - just behind the label dixell.
When you press the button again - the light is switched on,
and when you press one more time, the light turns off.
Brightness
interior and button
brightness
12

All shelves can draw, allowing easy stacking and extraction
bottle. each shelf You can also remove and remove, allowing
stacking larger bottles.
Removing the shelf
1. Remove the rack from the position STOP.
2. Lift the second shelf goods up to shelves wheels come in an
extended part of the guide, then pull out the drawer.
Putting shelves
The side sills wheels retract into the guide and push the shelf
in the interior, until they reach the shelf in its original position.
Before you start to lie bottles, check whether dials
properly lie in the grooves. Several times pull the shelf
outward to STOP position and push back in, while
wheels properly seated.
In each of the above 8 shelves can agree 9 bottles necks
alternating front - rear. On the motionless bnoo showcases
can agree about 33 bottles of wine portrait or landscape with
necks alternating front - rear. The total capacity of the unit is
approximately 105 bottles (0.75) l.
Do not let children climb, stand or hang on the shelves
refrigerated cabinets, because they can be dangerous in
injury, or damage the case. Fascia panels shelves are made
of wood. Wooden parts are protected by foil, which remove. In
use, ngerprints can leave stains on wood.
The structure and color of natural wood can be
change.
Make sure that the ventilation openings on the front of the
chassis are not blocked. For optimum performance appliances
at least once a year, or suck dust from the condenser. For
free access to capacitors open the front cover on the front
refrigeration cabinets, which attaches the upper side magnet.
Slide shelves
Stacking bottle
Tips for keeping
Wooden front panel
shelf
13

Maintenance and cleaning
Fridge not have to dissolve, because the ice to block
the evaporator dissolves automatically. The ice that
formed on the evaporator block the action of the
compressor in the period compressor standstill melt,
and in the form of droplets collects in the evaporator
below the aluminum body, and then through the
opening in the vessel below the water to the evaporator
copper pan at the bottom of the cabinet through which
the pusher tube hot water controlled compressor which
evaporates and increases the humidity in the cabinet.
The humidity inside the cabinet is controlled by a
hydrometer which is located on the top of the rst shelf.
The excess water, which can occur due to unforeseen
disturbances user forgets to close the door / is still
water in the pan on the compressor, which is volatile
in atmosferu.Temperaturna areas and humidity is set
default settings.
The exterior of appliances
Painted surfaces should be cleaned with a cloth and a
cleaning provided for wooden painted surfaces. For
plastic and lacquered parts is not recommended to use
abrasive or aggressive special funds, as for example.
cleaning stainless pan.
After cleaning, connect the appliance to the power
network, switch it up and re-ll it drink.
Before cleaning the appliances always
disconnect electric energy in the
machine!
Do not use rough and aggressive
cleaning agents that can be damaged
surfaces to be cleaned.
Automatic defrost
Cleaning
appliances
14

The interior of the appliances
The interior of the appliances with lukewarm water and
soap or baking soda and water. Never abrasive agents,
solvents, polish or undiluted detergent. Once a year it
is necessary to switch off the contours of moisture, dry
and soft cloth smeared environmental oil for wooden
surfaces.
Glass
Glass doors clean with glass cleaner or mild detergent
and water and a soft cloth. not use abrasive cleaning
powder.
Gasket doors
Plastic seal the door with a mild detergent and water
or solvent as baking soda or mild powder for cleaning.
Rinse well after cleaning grease seal gate thin lm
initials wax or petroleum jelly on the side of the hinge.
this prevents adhesion or damage to seals.
Replacing the LED strip is a service procedure and
working by an authorized service center. Before starting
the replacement of the ice strip for lighting cut the
power supply to the machine by pulling the plug from
the outlet.
Changing LED
strip lighting
15

In case of failure or power outage, the less open the
door, to keep the temperature in interior. The gradual
increase in temperature will not have negative impact
on the beverage. If the weather is extremely hot, you
can drink move to a cooler location while waiting to turn
on the electric energy.
Nestanak struje
In the vicinity of appliances does
not store or use gasoline or other
ammable substances.
16

Malfunction
The machine does
not work when
connected to the
electricity grid
cooling system
long time working
constantly
Water ows out of the
appliance
Helpful hints
Make sure the plug is live and whether it is
on (thermostat knob in the position of action).
• Too often open the door, or too long
open door.
• Door not closed properly (maybe foreign
body between the door povješena door, Review
seals, ...)
• Complex larger quantity of hot drinks at once.
• Due to insufcient cooling compressor and
capacitors: check the air circulation behind
appliances and clean the condenser,
behind the front bottom cover.
Water ows out of the appliance if the clogged
outlet hole water, or if the melt water dripping next
to the drain collecting water.
• A clogged vent, clean, for example with plastic
straw.
The temperature is not low enough:
• Is the temperature control is correct (see
the “management”)?
• Is the thermometer correctly works?
• Is the ventilation system working properly?
• Is the appliance set up too close to a heat
source?
Check
Troubleshooting
During the use of the appliance may appear less failures. Here are some
of them, which often causes improper use, and you can remove yourself.
17

Malfunction
Noise and murmurs Cooling in the fridge-freezers allows the cooling
system with compressor and fan, and this causes
a certain height noise.
The severity of noise depends on the situation and
the proper the use of appliances.
• During operation of the compressor can
be heard noise liquids, in the dormant heard
streaming coolant. This is normal and does not
affect the the life of appliances.
• After turning on appliances and action
compressor and streaming coolant may be
somewhat louder. This is not a sign of failure and
has no bearing on the life of the appliance.
Over time, during the operation of appliances
strength of these noise is signicantly reduced.
Sometimes, during the operation of appliances
occurrence unusual or loud murmurs, for coffee
unusual. Such murmurs most commonly the result
irregular position of appliances:
• The appliance must be placed gently sloping
towards the back and steady without swaying on
hard courts.
• Do not touch the walls or adjacent
elements.
Check
18

UNIQUE WINE COOLER
BRASS KOMERC d.o.o.
Banja Luka
Address:
Aleja svetog Save 48
78000 Banja Luka
Bosna i Hercegovina
Telephone/fax:
051 257 139
E-mail:
[email protected]
