UniTraQ UD-731 User manual

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 1
User’s Manual
USB Dongle Series Model:UD-731
UniTraQ International Corp. All right reserved, © 2009
2F., No.136, Ziqiang S. Rd., Zhubei City, Hsinchu County 30264, Taiwan (R.O.C.)
TEL：[phone] FAX：[phone]
MADE IN TAIWAN

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 2
Contents
1. Introduction....................................................................................................................... 3
2. Package Contents.............................................................................................................3
3. System Requirements....................................................................................................... 3
4. Features............................................................................................................................ 3
5. Specifications.................................................................................................................... 4
5.1 Electronic Characteristics ........................................................................................... 4
5.2 Physical Characteristics.............................................................................................. 5
6. Getting Started.................................................................................................................. 5
6.1 LED Status..................................................................................................................5
7. Software Installation.......................................................................................................... 6
7.1 Overview..................................................................................................................... 6
7.2 Install USB Driver........................................................................................................ 6
7.3 Install GPSView .........................................................................................................11
7.3.1 Install GPSView onto Windows 2000/XP or Vista..........................................11
7.3.2 Install GPSView onto Pocket PC .................................................................. 14
8. Application Software Introduction................................................................................... 16
8.1 GPSView................................................................................................................ 16
8.2 Data log.................................................................................................................. 18
8.2.1 Set up Data Log.......................................................................................... 18
8.2.2 Check the status of configure..................................................................... 19
8.2.3 Retrieve the content of Data Log................................................................ 20
8.2.4 Clear the Data Log ..................................................................................... 24
9. Trouble Shooting............................................................................................................. 24
10. APPROVED NMEA MESSAGE............................................................................. 25
10.1 GGA – GLOBAL POSITIONING SYSTEM FIX DATA ............................................ 25
10.2 GLL - LATITUDE AND LONGITUDE, WITH TIME OF POSITION FIX AND STATUS
........................................................................................................................................ 27
10.3 GSA - GPS DOPAND ACTIVE SATELLITES ........................................................ 28
10.4 GSV - GPS SATELLITE IN VIEW........................................................................... 29
10.5 RMC - RECOMMANDED MINIMUM SPECIFIC GPS/TRANSIT DATA................. 29
10.6 VTG - COURSE OVER GROUND AND GROUND SPEED................................... 31
10.7 ZDA -TIME AND DATA............................................................................................ 32

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 3
1. Introduction
The UD-731 is a GPS USB Dongle and it is optimized for good performance and low cost.
Its 65 parallel channels and Venus 6 search bins provide short start-up time and fast signal
acquisition. Having fast time-to-first-fix and high sensitivity, the UD-731 offers good
navigation performance even in urban canyons.
The UD-731 is capable of keeping up to 1Mega bytes records or positions, including
longitude, latitude, speed, UTC and tag data. The location histories can be exported to
mapping software such as Google Earth.
It is compact and easily used with your laptop or mini notebook.
2. Package Contents
UD-731 ………….. x 1
CD-ROM …………x 1
3. System Requirements
The UD-731requires the minimum to run on a laptop:
Operating System: Windows 2000 / XP/Vista
CPU: 500 MHz, Pentium III
System Memory: 128MB RAM
Hard Disk: 50MB free space
4. Features
65 channel to acquire and track satellites simultaneously
Capable of keeping up to 1 Mega byte Data logger (Longitude, Latitude, Speed,
UTC….)
Industry-leading TTFF speed
Signal detection better than -158 dBm
SBAS (WAAS/EGNOS) capable
Cold start < 45seconds
Hot start < 1second
USB Interface
Accuracy 5m CEP
Easy-plug-in Notebook
RoHS compliance

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 4
5. Specifications
5.1 Electronic Characteristics
Parameter Specification
Receiver Type 65 channels
Re-acquisition sensitivity -155dBm
Tracking sensitivity -158dBm
Cold start sensitivity -137dBm
Receiver frequency 1575.42MHz
Code C/A code
Accuracy
(1) Position
(2) Velocity
5m CEP
0.1m/sec
Startup Time
hot start
warm start
cold start
< 1 sec
< 35 sec
< 45 sec
Signal Reacquisition <1s
Update Rate 1Hz
Operational Limits
(1) Altitude
(2) velocity
< 18,000m
< 500m/s
Dynamics 4G (39.2m/sec2)
Datum WGS-84
Protocol NMEA-0183 V3.01
Serial Interface USB interface
Input Voltage 5V ±5%
Power Consumption 180mW
Connector USB B-type 4P male
Data Logger Log 1 Mega byte flash memory( 8M Bits).
Data: Longitude, Latitude, Speed, UTC.
Format:WGS84

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 5
5.2 Physical Characteristics
Parameter Specification
Physical dimension 78.62mm X 24.83mm X 11.15mm
Weight 22+-10%g
6. Getting Started
There are only a few simple steps that you need to follow before using your UD-731:
Install the USB driver onto your laptop using the included CD-ROM .
Plug the GPS receiver into your laptop’s USB port.
NOTE: From within your mapping or navigation software (including the supplied GPS
Information utility), you will need to manually configure the COM port that was
assigned to the UD-731 GPS receiver so that proper communication between the
GPS receiver and a mapping program can occur. Most software requires that you
manually configure the COM port setting for any GPS device being used.
1. You must change the default baud rate setting of your mapping software‘s Baud
Rate to 4800, if this is not set then the GPS data cannot be received.
2. Set Baud Rate 4800, Data Bit: 8, Parity: None, Stop Bit: 1, Flow Control: None
6.1 LED Status
The LED flash status:
1. 1 second on/ 1 second off : GPS tracked
2. 1 second on/ 2 seconds off : while tracking

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 6
7. Software Installation
7.1 Overview
USB Driver is necessary software which allows you to operate UD-731 on your computer
properly once the device is connected with the computer. USB Driver is different
depending on your operating system you connect to. Therefore, when you connect
UD-731 with your computer, you need to install an appropriate driver for the UD-731
beforehand. Once you installed the driver properly, you do not need to install again from
the next time.
GPSView is multipurpose GPS utility. Please note that GPSView uses specific NMEA
sentences to display data graphically. For more information on NMEA, please see the
appendix 1. GPSView is a general purpose utility for monitoring the output of a GPS
receiver. Using the NMEA data from the GPS receiver, GPSView will display various
statuses for evaluating GPS which including latitude, longitude, altitude, speed, azimuth,
fix mode and TTFF time. And also can be used to upgrade UniTraQ flash version GPS
receiver.
7.2 Install USB Driver
You need to prepare a PC to install USB driver. The USB driver category depending on
your operating system and then please follow the procedure illustrated below to install
USB driver. Please note this procedure is only for windows XP.
A. Insert the CD into your CD-ROM disk. The installation program should automatically run. If,
the installation program does not initiate, double-click on GPS-Installation.EXE in the root
folder on the CD-ROM. When the main menu appears on the screen, just click on
USB-Driver for XP. If your operating system is vista, please click on USB-Driver for vista.
The installation will begin, and then the install wizard will navigate you to finish installation.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 7
B. Click on Next on the installation welcome dialogue to continue.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 8
C. eview the license agreement information, and select I accept to accept the licensing terms,
and then click on Next to continue. You may click on Back to go to the previous step, or
Cancel to quit.
D. At this point the Installation allows you to change destination folder of CP210X VCP Drive
for XP, if you have a specific reason for doing so. Click on Next to continue. If you want to
install to a different folder, click on Browse. You may click on Back to go to the previous
step, and click on Cancel to quit.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 9
E. On the next dialogue, click on Install to start installation CP210X VCP drive. You may click
on Back to go to the previous step, and click on Cancel to quit.
F. Wait for a few seconds while installation is copying files to your computer.
Select Launch the CP210X VCP Driver installer and then click on Finish to
complete the laboratories CP210X VCP driver installation.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 10
G. On the next dialogue, click on Install to start installation CP210X USB to UART bridge
driver. If you want to install to a different folder, click on Change install location, and click
on Cancel to quit.
H. Wait for a few seconds while installation is copying files to your computer. Click on OK to
complete the laboratories USB to UART bridge driver installation.
I. Click on Next on the installation welcome dialogue to continue.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 11
J. Wait for a few seconds while installation is copying files to your computer. Click on Finish
to complete the PL2303 USB-to-serial driver installation.
7.3 Install GPSView
You need to prepare a PC to install GPSView. The GPSView category depending on your
operating system and then please follow the procedure illustrated below to install
GPSView.
7.3.1 Install GPSView onto Windows 2000/XP or Vista
A. Insert the CD into your CD-ROM disk. The installation program should automatically run. If,
the installation program does not initiate, double-click on GPS-Installation.EXE in the root
folder on the CD-ROM. When the main menu appears on the screen, just click on GPS
View (XP/Vista). The installation will begin, and then the install wizard will navigate you to
finish installation.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 12
B. Click on GPS View(XP/VISTA) on the installation welcome dialogue to continue.
C. Click on Install to continue. You may click on Cancel to quit.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 13
D. Click on OK to complete the installation.
E. You can find a Server icon from StartProgramsUNIGPSAPPgps-view2008.2, or from
C:\Program Files\UNIGPS APP\GPSView\gps-view2008.2.exe. Click on the icon to run
GPSView in your computer.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 14
7.3.2 Install GPSView onto Pocket PC
A. Link to the following Microsoft web-site for downloading Microsoft ActiveSync.
http://www.microsoft.com/windowsmobile/en-us/help/synchronize/activesync45.mspx
B. Install Microsoft ActiveSync onto PC.
C. Connect cradle to PC, and then the ActiveSync should create access between the PC and
pocket PC.
D. Double click on ActiveSync icon, main menu appears on the screen as blow. And then
Click Explore on the pop-up menu.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 15
E. Select My Windows Mobile-Based Device on the dialog.
F. Determine the desired destination folder you want. In this example, the GPSViwe will be
put on Storage Card.
G. Copy GPSViwe-P.exe form CD-ROM to your pocket PC. The GPSViwe-P.exe path is on
the CD-ROMGPS-InstallationPDA. And please note that CD shall be inserted to
CD-ROM disk.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 16
8. Application Software Introduction
8.1 GPSView
Double Click on the gpsview.exe. and
Click on the GT-7 Series. Enter the Window below.

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 17
1. Off the GPS connection
2. Series Selection
3. Open Position Coordinate Window
4. Execute Cold Start
5. Execute Warm Start
6. Execute Hot Start
7. Save NMEA Data (Automatically save in the same Program file)
8. Upgrade Firmware (If upgrading Firmware, save it in the same Program file)

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 18
8.2 Data log
8.2.1 Set up Data Log
1. Execute Data log.exe.
2. Select “DataLog Log Configure”

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 19
3. Configure your favorite log time “min_time” (by seconds) and
“Enable” the Data log.
8.2.2 Check the status of configure
1. Select “DataLog Log Status”

USB Dongle Series Model:UD-731
UniTraQ International Corp. RoHS compliance.
2010,07, Version 1.3 20
2. The window of “Response” will display the above configured status.
8.2.3 Retrieve the content of Data Log
1. Select “DataLog Log Read”
