UniTraQ UD-731 User manual

UD-731
GPS USB Dongle
Technical Manual
USB Dongle Series Model:UD-731
UniTraQ International Corp. All right reserved, © 2008
9F-2, NO. 158, Sec. 2,Gongdao 5th Rd., Hsinchu City 30070, Taiwan, R.O.C
MADE IN TAIWAN

UniTraQ International Corp. RoHS compliance.
2008,8, Version 1.1
Contents
1. Features……………………………………………..……………………………………………………………...1
2. Technical Specifications……..………………………………………………………..…….…. ……………….2
3. GPS status indicator………………………………………………………………………………………………3
4. Communication specification……………………………………………………………….…………………..3
5. Environment specification…………………………………………………….…….…….…………………..4
6. Pin assignment……………………………..………………………………………………….…………………..4
7. Mechanic dimension………………..…………………………………………………………………………….5
8. Customized package………………….…………………………………………………………………………..5
9. Approved NMEA message……………..……………………………….….……..………….………………….5
9.1 GGA – global positioning system fix data…………….………………………….….. …….…………….5
9.2 GLL – latitude and longitude, with time of position fix and status……………… …………………..7
9.3 GSA - GPS DOP and active satellites…………….….….….….…….…..….….……..…………………..8
9.4 GSV - GPS satellite in view………….….….….….….…..….…….….….….….……….………………….9
9.5 RMC – recommended minimum specific GPS/transit data…………. .….….…...……………………9
9.6 VTG – course over ground and ground speed…………….….….……….……..….………………….11
9.7 ZDA – time and data…..….….….….….…..….….….….….….….….….…...….….….………………….12
9.8 Binary messages.….….….….….….…….….….….….….….….….….….….….….….………………….12
UD-731
GPS USB Dongle

UniTraQ International Corp. RoHS compliance.
2008,8, Version 1.1 1
UD-731
GPS USB Dongle
1. FEATURES
z44 channel to acquire and track satellites
simultaneously
zCapable of keeping up to 100,000
positions(Longitude,Latitude,Speed,
UTC )
zIndustry-leading TTFF speed
zSignal detection better than -158 dBm
zSBAS (WAAS/EGNOS) capable
zCold start < 45seconds
zHot start < 1second
zAccuracy 5m CEP
zUSB Interface
zEasy-plug-in Notebook
zSIZE:78.62mmL X 24.83mmW X 11.15mmH
zRoHS compliance
UD-731
Fast Acquisition Enhanced Sensitivity
44 Channel USB Dongle GPS Receiver
The UD-731 is a compact all-in-one GPS receiver that
continuously tracks all satellites in view and provides
accurate satellite positioning data.
Its 44 parallel channels and 20000+ correlators provide
fast satellite signal acquisition and short start-up time.
Acquisition sensitivity of -155dBm and tracking sensitivity
of -158 dBm offer good performance even under difficult
environments.
The UD-731 is optimized for applications requiring good
performance and low cost; it is suitable for a wide range of
handhelds, asset tracking, Notebook, PDA-centric
personal navigation system, and vehicle navigation
products.
Data Logger(optional): Travel along with your USB
Dongle(UD-731), offers simultaneous use of real-time
GPS data logger.

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
2
UD-731
GPS USB Dongle
2. TECHNICAL SPECIFICATIONS
Parameter Specification
Receiver Type 44 channels
Re-acquisition sensitivity -155dBm
Tracking sensitivity -158dBm
Cold start sensitivity -137dBm
Receiver frequency 1575.42MHz
Code C/Acode
Accuracy
(1) Position
(2) Velocity
5m CEP
0.1m/sec
Startup Time
hot start
warm start
cold start
< 1 sec
< 35 sec
< 45 sec
Signal Reacquisition <1s
Update Rate 1Hz
Operational Limits
(1) Altitude
(2) velocity
< 18,000m
< 500m/s
Dynamics 4G (39.2m/sec2)
Datum WGS-84
Protocol NMEA-0183 V3.01
Serial Interface USB interface
Input Voltage 5V ±5%
Power Consumption 180mW
Connector USB B-type 4P male
Flash(optional) Log 100,000 recorsint flash memory( 8M Bits).
Data: Longitude, Latitude, Speed, UTC.
Format:WGS84
Note: Data log function is optional

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
3
UD-731
GPS USB Dongle
3. GPS STATUS INDICATOR
The UD-731 provides GPS status indicator. LED On board shows fix or non-fix. In fix mode, the LED will
light for 1second and turn off for 1second. In another mode, the pin will light for 2 seconds and turn-off for 2
seconds.
4. COMMUNICATION SEPECIFICATIONS
Item Description
Interface Full duplex serial interface
Bit rate 4800bps
Start bit 1bit
Stop bit 1bit
Data bit 8bit
Parity none
Transmission data SACII NMEA0183 Ver:3.01
Update rate 1Hz
Output sentence GGA/GSA/GSV/RMC

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
4
UD-731
GPS USB Dongle
5. ENVIRONMENT SPECIFICATION
Parameter Specification
Operating -20℃~+60℃
Temperature Storage -40℃~+80℃
Humidity 5%~95%
6. PIN ASSIGNMENT
PIN Signal name Description Notes
1 VCC USB port power 5V
2 D- USB port data-
3 D+ USB port data+
4 GND USB ground

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
5
UD-731
GPS USB Dongle
7. MECHANIC DIMENSION
Parameter Specification
Physical dimension 78.62mm X 24.83mm X 11.15mm
Weight 22+-10%g
8. CUSTOMIZED PACKAGE
zColor box
zCD (including user manual, USB driver and GPS test program)
9. APPROVED NMEA MESSAGE
The serial interface protocol is based on the National Marine Electronics Association’s NMEA 0183 ASCII
interface specification. This standard is fully define in “NMEA 0183, Version 3.01” The standard may be
obtained from NMEA, www.nmea.org
9.1 GGA – GLOBAL POSITIONING SYSTEM FIX DATA
Time, position and fix related data for a GPS receiver.
Structure:
$GPGGA,hhmmss.sss,ddmm.mmmm,a,dddmm.mmmm,a,x,xx,x.x,x.x,M,x.x,M,x.x,xxxx*hh<CR><LF>
1 2 3 4 56 7 8 9 10 11 12 13
Example:
$GPGGA,060932.448,2447.0959,N,12100.5204,E,1,08,1.1,108.7,M,,,,0000*0E<CR><LF>

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
6
UD-731
GPS USB Dongle
Field Name Example Description
1 UTC Time 060932.448 UTC of position in hhmmss.sss format, (000000.00 ~
235959.99)
2 Latitude 2447.0959 Latitude in ddmm.mmmm format
Leading zeros transmitted
3 N/S Indicator N Latitude hemisphere indicator, ‘N’ = North, ‘S’ = South
4 Longitude 12100.5204 Longitude in dddmm.mmmm format
Leading zeros transmitted
5 E/W Indicator E Longitude hemisphere indicator, 'E' = East, 'W' = West
6 GPS quality
indicator
1 GPS quality indicator
0: position fix unavailable
1: valid position fix, SPS mode
2: valid position fix, differential GPS mode
3: GPS PPS Mode, fix valid
4: Real Time Kinematic. System used in RTK mode with
fixed integers
5: Float RTK. Satellite system used in RTK mode. Floating
integers
6: Estimated (dead reckoning) Mode
7: Manual Input Mode
8: Simulator Mode
7 Satellites Used 08 Number of satellites in use, (00 ~ 12)
8 HDOP 1.1 Horizontal dilution of precision, (00.0 ~ 99.9)
9 Altitude 108.7 mean sea level (geoid), (-9999.9 ~ 17999.9)
10 Geoid Separation Geoid separation in meters according to WGS-84 ellipsoid
(-999.9 ~ 9999.9)
11 DGPS Age Age of DGPS data since last valid RTCM transmission in
xxx format (seconds)
NULL when DGPS not used
12 DGPS Station ID 0000 Differential reference station ID, 0000 ~ 1023
NULL when DGPS not used
13 Checksum 0E
Note: The checksum field starts with a ‘*’ and consists of 2 characters representing a hex number. The
checksum is the exclusive OR of all characters between ‘$’ and ‘*’.

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
7
UD-731
GPS USB Dongle
9.2 GLL - LATITUDE AND LONGITUDE, WITH TIME OF POSITION FIX AND STATUS
Latitude and longitude of current position, time, and status.
Structure:
$GPGLL,ddmm.mmmm,a,dddmm.mmmm,a,hhmmss.sss,A,a*hh<CR><LF>
1 2 3 4 5 6 7 8
Example:
$GPGLL,4250.5589,S,14718.5084,E,092204.999,A,A*2D<CR><LF>
Field Name Example Description
1 Latitude 4250.5589 Latitude in ddmm.mmmm format
Leading zeros transmitted
2 N/S Indicator S Latitude hemisphere indicator
‘N’ = North
‘S’ = South
3 Longitude 14718.5084 Longitude in dddmm.mmmm format
Leading zeros transmitted
4 E/W Indicator E Longitude hemisphere indicator
'E' = East
'W' = West
5 UTC Time 092204.999 UTC time in hhmmss.sss format (000000.00 ~ 235959.99)
6 Status A Status, ‘A’ = Data valid, ‘V’ = Data not valid
7 Mode Indicator A Mode indicator
‘N’ = Data not valid
‘A’ =Autonomous mode
‘D’ = Differential mode
‘E’ = Estimated (dead reckoning) mode
‘M’ = Manual input mode
‘S’ = Simulator mode
8 Checksum 2D

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
8
UD-731
GPS USB Dongle
9.3 GSA - GPS DOP AND ACTIVE SATELLITES
GPS receiver operating mode, satellites used in the navigation solution reported by the GGAor GNS
sentence and DOP values.
Structure:
$GPGSA,A,x,xx,xx,xx,xx,xx,xx,xx,xx,xx,xx,xx,xx,x.x,x.x,x.x*hh<CR><LF>
1 2 3 3 3 3 3 3 3 3 3 3 3 3 4 5 6 7
Example:
$GPGSA,A,3,01,20,19,13,,,,,,,,,40.4,24.4,32.2*0A<CR><LF>
Field Name Example Description
1 Mode A Mode
‘M’ = Manual, forced to operate in 2D or 3D mode
‘A’ =Automatic, allowed to automatically switch 2D/3D
2 Mode 3 Fix type
1 = Fix not available
2 = 2D
3 = 3D
3 Satellite used 1~12 01,20,19,13,,,,,
,,,,
Satellite ID number, 01 to 32, of satellite used in solution,
up to 12 transmitted
4 PDOP 40.4 Position dilution of precision (00.0 to 99.9)
5 HDOP 24.4 Horizontal dilution of precision (00.0 to 99.9)
6 VDOP 32.2 Vertical dilution of precision (00.0 to 99.9)
7 Checksum 0A

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
9
UD-731
GPS USB Dongle
9.4 GSV - GPS SATELLITE IN VIEW
Number of satellites in view, PRN number, elevation angle, azimuth angle, and C/No. Four satellites details
are transmitted per message.Additional satellite in view information is send in subsequent GSV messages.
Structure:
$GPGSV,x,x,xx,xx,xx,xxx,xx,…,xx,xx,xxx,xx *hh<CR><LF>
1 2 3 4 5 6 7 4 5 6 7 8
Example:
$GPGSV,3,1,09,28,81,225,41,24,66,323,44,20,48,066,43,17,45,336,41*78<CR><LF>
$GPGSV,3,2,09,07,36,321,45,04,36,257,39,11,20,050,41,08,18,208,43*77<CR><LF>
Field Name Example Description
1 Number of message 3 Total number of GSV messages to be transmitted (1-3)
2 Sequence number 1 Sequence number of current GSV message
3 Satellites in view 09 Total number of satellites in view (00 ~ 12)
4 Satellite ID 28 Satellite ID number, GPS: 01 ~ 32, SBAS: 33 ~ 64 (33 =
PRN120)
5 Elevation 81 Satellite elevation in degrees, (00 ~ 90)
6 Azimuth 225 Satellite azimuth angle in degrees, (000 ~ 359 )
7 SNR 41 C/No in dB (00 ~ 99)
Null when not tracking
8 Checksum 78
9.5 RMC - RECOMMANDED MINIMUM SPECIFIC GPS/TRANSIT DATA
Time, date, position, course and speed data provided by a GNSS navigation receiver.
Structure:
$GPRMC,hhmmss.sss,A,dddmm.mmmm,a,dddmm.mmmm,a,x.x,x.x,ddmmyy,x.x,a,a*hh<CR><LF>
1 2 3 4 5 6 7 8 9 10 111213
Example:
$GPRMC,092204.999,A,4250.5589,S,14718.5084,E,0.00,89.68,211200,,A*25<CR><LF>

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
10
UD-731
GPS USB Dongle
Field Name Example Description
1 UTC time 092204.999 UTC time in hhmmss.sss format (000000.00 ~
235959.999)
2 Status A Status
‘V’ = Navigation receiver warning
‘A’ = Data Valid
3 Latitude 4250.5589 Latitude in dddmm.mmmm format
Leading zeros transmitted
4 N/S indicator S Latitude hemisphere indicator
‘N’ = North
‘S’ = South
5 Longitude 14718.5084 Longitude in dddmm.mmmm format
Leading zeros transmitted
6 E/W Indicator E Longitude hemisphere indicator
'E' = East
'W' = West
7 Speed over ground 000.0 Speed over ground in knots (000.0 ~ 999.9)
8 Course over ground 000.0 Course over ground in degrees (000.0 ~ 359.9)
9 UTC Date 211200 UTC date of position fix, ddmmyy format
10 Magnetic variation Magnetic variation in degrees (000.0 ~ 180.0)
11 Magnetic Variation Magnetic variation direction
‘E’ = East
‘W’ = West
12 Mode indicator A Mode indicator
‘N’ = Data not valid
‘A’ =Autonomous mode
‘D’ = Differential mode
‘E’ = Estimated (dead reckoning) mode
‘M’ = Manual input mode
‘S’ = Simulator mode
13 checksum 25

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
11
UD-731
GPS USB Dongle
9.6 VTG - COURSE OVER GROUND AND GROUND SPEED
The Actual course and speed relative to the ground.
Structure:
GPVTG,x.x,T,x.x,M,x.x,N,x.x,K,a*hh<CR><LF>
1 2 3 4 5 6
Example:
$GPVTG,89.68,T,,M,0.00,N,0.0,K,A*5F<CR><LF>
Field Name Example Description
1 Course 89.68 True course over ground in degrees (000.0 ~ 359.9)
2 Course Magnetic course over ground in degrees (000.0 ~ 359.9)
3 Speed 0.00 Speed over ground in knots (000.0 ~ 999.9)
4 Speed 0.00 Speed over ground in kilometers per hour (0000.0 ~
1800.0)
5 Mode A
Mode indicator
‘N’ = not valid
‘A’ =Autonomous mode
‘D’ = Differential mode
‘E’ = Estimated (dead reckoning) mode
‘M’ = Manual input mode
‘S’ = Simulator mode
6 Checksum 5F

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
12
UD-731
GPS USB Dongle
9.7 ZDA -TIME AND DATE
Structure:
$GPRMC,hhmmss.sss,dd,mm.yyyy, , ,xxx<CR><LF>
1 2 3 4 5 6 7
Example:
$GPZDA,104548.04,25,03,2004,,*6C<CR><LF>
Field Name Example Description
1 UTC time 104548.04 UTC time in hhmmss.ss format, 000000.00 ~ 235959.99
2 UTC time: day 25 UTC time: day (01 ... 31)
3 UTC time: month 03 UTC time: month (01 ... 12)
4 UTC time: year 2004 UTC time: year (4 digit year)
5 Local zone hour
Not being output by the receiver (NULL)
6 Local zone minutes
Not being output by the receiver (NULL)
7 6C 6C Checksum
9.8 BINARY MESSAGES
See Binary Message Protocol User’s Guide for detailed descriptions.

UniTraQ International Corp. RoHS compliance
2008, 8, Version 1.1
13
UD-731
GPS USB Dongle
UniTraQ International Corp
9F-2, No.158,Gongdao 5th Rd.,Sec. 2 Hsinchu City 300, Taiwan, R.O.C.
TEL：[phone] FAX：[phone]
Email [email protected]
Website www.unitraq.com
© 2008 UniTraQ International Corp. All rights reserved.
Not to be reproduced in whole or part for any purpose without written permission of UniTraQ International Corp (“UniTraQ”)
Information provided by UniTraQ is believed to be accurate and reliable. These materials are provided by UniTraQ as a
service to its customers and may be used for informational purposes only. UniTraQ assumes no responsibility for errors or
omissions in these materials, nor for its use. UniTraQ reserves the right to change specification at any time without notice.
These materials are provides “as is” without warranty of any kind, either expressed or implied, relating to sale and/or use
of UniTraQ products including liability or warranties relating to fitness for a particular purpose, consequential or incidental
damages, merchantability, or infringement of any patent, copyright or other intellectual property right. UniTraQ further
does not warrant the accuracy or completeness of the information, text, graphics or other items contained within these
materials. UniTraQ shall not be liable for any special, indirect, incidental, or consequential damages, including without
limitation, lost revenues or lost profits, which may result from the use of these materials.
UniTraQ products are not intended for use in medical, life-support devices, or applications involving potential risk of death,
personal injury, or severe property damage in case of failure of the product.
All of products designed and produced in Taiwan, and RoHS compliance
