Unix CCTV PT 980 User manual

User’s Manual
Speed Dome Camera
Anti-vandal
x10

2 3
Safety Information
x10 Anti-vandal
Speed Dome Camera
User’s Manual
Ver. 3 . 1 / 2009.09
This symbol indicates that dangerous voltage
consisting a risk of electricshock is present within
this unit.
Warning Precaution
This exclamation point symbol is intended to alert the
user to the presence of important operating and
maintenance (servicing)instructions in the literature
accompanying the appliance.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION:
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
To prevent damage which may result in fire or electric shock hazard, do not expose this appliance to rain or moisture.
1. Be sure to use only the standard adapter that is specified in the specification sheet. Using any other adapter could
cause fire, electrical shock, or damage to the product.
2. Incorrectly connecting the power supply or replacing battery may cause explosion, fire, electric shock, or damage
to the product.
3. Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal heat generation
or fire.
4. Securely plug the power cord into the power receptacle. Insecure connection may cause fire.
5. When installing the camera, fasten it securely and firmly. A falling camera may cause personal injury.
6. Do not place conductive objects (e.g. screw drivers, coins, metal things, etc.) or containers filled with water on top
of the camera. Doing so may cause personal injury due to fire, electric shock, or falling objects.
7. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or electric shock.
8. If any unusual smells or smoke come from the unit, stop using the product. In such case, immediately disconnect
the power source and contact the service center. Continued use in such a condition may cause fire or electric shock.
9. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this
product in any way.
10. When cleaning, do not spray water directly onto parts of the product. Doing so may cause fire or electric shock.
WARNING
WARNING

Precautions Contents
4 5
6
7
Product & Accessories
Parts Name & Functions
4 Precation
1. Introduction
8
10
11
12
13
14
16
17
DIP Switch Setup
Installation Using Surface Mount Bracket
Installation Using Flush Mount Ring Bracket(Option)
Installation Using Ceiling Mount Bracket(Option)
Installation Using Wall Mount Bracket(Option)
Installation Using Wall Mount Bracket with Junction Box(Option)
Cabling the 5P Terminal Block
Cabling the 7P Terminal Block
2. Installation
18
19
20
21
22
24
25
26
28
30
31
32
34
36
37
38
40
Check Points before Operation
Main Functions
OSD Information
General Rules of Menu Operation
OSD Menu Contents
OSD -
ROOT MENU & SYSTEM INFORMATION
OSD - DISPLAY SETUP
OSD - MOTION SETUP
OSD - FUNCTION SETUP>PRESET SETUP
OSD - FUNCTION SETUP>SCAN SETUP
OSD - FUNCTION SETUP>PATTERN SETUP
OSD - FUNCTION SETUP>GROUP SETUP
OSD - FUNCTION SETUP>SCHEDULE SETUP
OSD - CAMRA SETUP>WB SETUP
OSD - CAMRA SETUP>AE SETUP
OSD - SYSTEM SETUP
OSD - SYSTEM INITIALIZE
3. OSD Menu
41
42
44
Dimensions
Dimensions of Option Brackets
Specifications
4. Specification
Operating
Before using, make sure power supply and others are properly connected.
While operating, if any abnormal condition or malfunction is observed, stop using the camera immediately and then
contact your Special dealer.
Handling
Do not disassemble or tamper with parts inside the camera.
Do not drop or subject the camera to shock and vibration as this can damage camera.
Care must be taken when you clean the clear dome cover. Especially, scratch and dust will ruin your quality of camera.
Installation and Storage
Do not install the camera in areas of extreme temperature, which exceed the allowable range.
Avoid installing in humid or dusty places.
Avoid installing in places where radiation is present.
Avoid installing in places where there are strong magnetic elds and electric signals.
Avoid installing in places where the camera would be subject to strong vibrations.
Never expose the camera to rain and water.

Product & Accessories Parts Name & Functions
1
6 7
Main Body
Main Body + Surface Mount Bracket
12
1
Terminal Block x2: 5P+7P
4
Rubber Gasket
6
Screw & Plastic Anchor-4pcs
3
Manual
7
User’s Manual
Surface Mount Bracket
2
Camera module, screws, terminal block slot and
DIP switches are included.
- It is used when installing the camera right on to
the ceiling.
- To install the camera with the surface mount
bracket, the bracket needs to be separated from
the main body, then needs to be re-assembled
the bracket and the main body according to the
order.
Terminal Block
4
Power, video, communication and alarm input
cables are connected through the terminal blocks.
Torx Screw Driver
5
It is used to screw/unscrew the fixed screws on
the main body.
Rubber Gasket
6
Manual
7
Please read the manual carefully before installing.
It is installed between the surface mount bracket
and wall/wall mount bracket to prevent the water
leakage.
Screw & Plastic Anchor
3
- Screws are used to fix the surface mount bracket
to the ceiling.
- Plastic anchors are used to tighten the screws to
the hole by inserting them into the holes in
advance.
Please check if all the camera and
accessories are included in the package.
Torx Screw Driver
5
Main Body
Dome Cover
1
Lockup Screw
2
Surface Mount Bracket
Bottom of Main Body
Dome Cover
1
- Protects the camera module from outside
environment.
- Do not detach protection vinyl from the dome
cover before finishing all installation processes
to protect dome cover from scratches or dust.
Lockup Screw
2
Fixes main body to the surface mount bracket.
7P Terminal Block Slot
3
- Power, keyboard controller/DVR video device are
connected to this terminal block.
- Refer page 17 for details.
DIP Switch
4
- Adjusts camera ID and protocols.
- Refer page 8, 9 for details.
5P Terminal Block Slot
5
- Alarm input and relay out cables are connected to
this terminal block.
- Refer page 16 for details.
Mounting Hole
6
This is used to attach the surface mount bracket
to the ceiling.
¾” Pipe Mounting Hole
7
- This is used to pass the cables to the cameras.
- When water protection is needed, connect the
¾” pipe through this hole, then pass the cables
through the pipe.
5P Terminal Block Slot
5
7P Terminal Block Slot
3
DIP Switch
4
Mounting Hole
6
¾” Pipe Mounting Hole
7

DIP Switch Setup DIP Switch Setup
2
8 9
Choose the appropriate baud rate protocol by setting the DIP switch
Choose the termination resistor on/off to notify the last camera.
ON
21 3 4 5678
ON
21 3 4 5678
ON
21 3 4 5678
ON
21 3 4 5678
2400 BPS
1
4800 BPS
2
9600 BPS
3
19200 BPS
4
ON
21 3 4 5678
38400 BPS
5
ON
21 345678
Normal
1
ON
21 345678
Last Camera
2
Camera ID Setup
- ID number of camera is set using binary number. The example is shown below.
Pin 1 2 3 4 5 6 7 8
1 2 4 8 16 32 64 128ID Value
- Select the appropriate baud rate with DIP switch
combination.
- The factory default is 9600BPS.
3. Baud Rate Setup
- If you want to control a certain camera, you must
match the camera ID with ‘CAM ID, setting of DVR
or keyboard controller.
-
ID number of the camera is set using binary number.
- The range of ID is 0~255. Factory default of
camera ID is 1.
- Camera ID will be effective without rebooting
the camera.
5. DIP Switch for Camera ID Setup
- Pin 8 is use for on/off of RS-485 termination.
Normally, it must be off state.
-
Especially, when you have trouble with long daisy
chain style connection, turn on this termination
switch of the last camera.
4. RS-485 Termination Setup
Auto Protocol
1
Communication
Protocol Setup Pin Baud Rate Setup Pin RS-485 Termination Setup Pin
Auto Protocol
1
- If you set the protocol as auto protocol, camera will
automatically recognize the kind of protocol.
Pin On/Off
If the pin is located ‘ON’ side of the printed
label, it means on. In reverse, means off.
Pin On
Pin Off
Before installing the camera, you should
set the DIP switch to configure the camera
ID, communication protocol.
Choose the appropriate communication protocol by setting the DIP switch.
ON
21 345678
ON
21 3 4 5678
PELCO-D
2
ON
21 3 4 5678
PELCO-P
3
ON
21 3 4 5678
SAMSUNG
4
ON
21 3 4 5678
Bottom of Main Body
ON
1
ON
1
If there is other combination of pins from above, it will be recognize as
auto protocol.
ON
21 345678
ON
8J
21 3 4 5 6 7 8
DIP Switch for
Communication DIP Switch for Camera ID Setup
AD(American Dynamics)
7
ON
21 3 4 5678
- It is consist of communication protocol, baud rate
and RS-485 termination setup pins.
- If you change the camera protocol by changing
the DIP switch, the change will be eective after
rebooting the camera.
1. DIP Switch for Communication
- If you want to control using DVR or keyboard
controller, their protocol must be identical to the
camera’s protocol. Otherwise, you cannot control
the camera.
- The factory default is auto protocol.
2. Communication Protocol Setup
2. Communication Protocol Setup
Panasonic
5
ON
21 3 4 5678
GE(Kalatel)
6
ON
21 3 4 5678

Installation Using Surface Mount Bracket Installation Using Flush Mount Ring Bracket (Option)
2
10 11
Drilling the Hole on the Ceiling
1
Fix the Main Body
5
Connect the
Terminal Blocks
4
Connect the Cables
3
Detach the
Protection Vinyl
6
Drilling the Hole on the Ceiling
To pass cables through the ceiling, drill a hole
(30mm diameter) on the ceiling panel.
Pass the cables to the ¾” pipe hole, and screw
the surface mount bracket to the ceiling.
Fix the Main Body
5
Screw the main body to the surface mount bracket
by screwing 4 lock-up screws.
Detach the Protection Vinyl
6
Detach the protection vinyl from the dome cover.
Detach the Protection Vinyl
6
Detach the protection vinyl from the dome cover.
Fix the Surface
Mount Bracket
2
1
Fix the Surface Mount Bracket
Rubber Gasket
2
Rubber Gasket
Connect the Terminal Blocks
4
Connect the terminal blocks to the main body.
Connect the Cables
3
- Connect wire cables to the terminal blocks.
- Refer page 16, 17 for details.
- Before installing the gasket, the hole in the center
is to be cut by knife when only necessary.
- When installing gasket, the protrusion of the
gasket should be matched with the groove joint
of the bottom of the surface mount bracket.
Fix the Main Body
5
Fix the Flush Mount
Ring Bracket to the
Main Body
3
Drilling the Hole on the Ceiling
1
To pass cables through the ceiling, drill a
hole(70mm diameter) on the ceiling.
Separate the Lock-up Screws from the
Main Body
2
Separate the 4 lock-up screws from the main body
in advance.
Fix the Flush Mount Ring Bracket to the
Main Body
3
Fix the flush mount ring bracket to the main body
using torx screws.
Fix the Main Body
5
Screw the main body with the surface mount
bracket to the ceiling using the screws on the
surface mount bracket.
Connect Wire the Cables and Terminal Blocks
4
Connect wire cables to the terminal blocks.
Refer page 16, 17 for details.
Separate the Lock-up
Screws from the Main
Body
2
Wire the Cables and
Terminal Blocks
4
Drilling the Hole
on the Ceiling
1

Installation Using Ceiling Mount Bracket (Option) Installation Using Wall Mount Bracket (Option)
2
12 13
Fix the Main Body
7
Connect the
Terminal Blocks
Wire Cables
4
Fix the Surface
Mount Bracket
Detach the
Protection Vinyl
Drill the Ceiling and Fix the Anchor Bolts
1
Fix the Ceiling Mount Bracket
2
On the ceiling, drill a hole (6mm diameter/ 50mm
depth), and fix the anchor bolts.
1. Drill a hole (20mm diameter) on the pipe of the
bracket to pass the cables.
2. On the fixed anchor bolts, attach the rubber
gasket and screw the ceiling mount bracket.
Fix the Wall Mount Bracket
1. Drill a hole (20mm diameter) on the pipe of the
bracket to pass the cables.
2. On the fixed anchor bolts, attach the rubber
gasket and fix the wall mount bracket with nuts
and screws.
Fix the Surface Mount Bracket
3
Pass the cables through the hole of the surface
mount bracket, screw the surface mount bracket
to the ceiling mount bracket.
Connect the Terminal Blocks
5
Connect terminal block to the main body.
Refer page 10.
Fix the Main Body
6
Screw the main body to the surface mount bracket.
(Screws are included in the main body.)
Detach the Protection Vinyl
7
Detach the protection vinyl from the dome cover.
Wire Cables
4
Wire the cables to the terminal block.
Refer page 16, 17.
Fix the Surface Mount Bracket
Pass the cables through the hole of the surface
mount bracket, screw the surface mount bracket
to the wall mount bracket.
Connect the Terminal Blocks
Connect terminal block to the main body.
Refer page 10.
Fix the Main Body
Screw the main body to the surface mount bracket.
(Screw are included in the main body.)
Detach the Protection Vinyl
Detach the protection vinyl from the dome cover.
Wire Cables
Wire the cables to the terminal block.
Refer page 16, 17.
Fix the Ceiling
Mount Bracket
Rubber Gasket
Rubber Gasket
Drill the Wall and
Fix the Anchor Bolts
1
2
3
3
6
5
Fix the Main Body
Connect the Terminal Blocks
Wire Cables
4
6
5
Drill the Ceiling and
Fix the Anchor Bolts
1
Fix the Surface Mount Bracket
Detach the Protection Vinyl
7
Fix the Wall Mount Bracket
1. Installing on the Concrete Ceiling 1. Installing on the Concrete Wall
Drill the Ceiling
1
Fix the Ceiling Mount Bracket
2
To pass cables to upside of ceiling, drill a hole
(30mm diameter) on the ceiling.
Pass the cables into the ceiling mount bracket,
and screw the ceiling mount bracket to the
ceiling.
2. Installing on the Wooden Ceiling
Drill the Wall
Fix the Wall Mount Bracket
Drill the Wall and Fix the Anchor Bolts
On the wall, drill a hole (6mm diameter/50mm
depth), and fix the anchor bolts.
1
2
3
5
6
7
4
1
2
To pass cables to the wall, make a hole about
30 mm on the wall.
Pass the cables into the wall mount bracket,
and screw the wall mount bracket to the wall.
2. Installing on the Wooden Wall
2
Rubber Gasket

Installation Using Wall Mount Bracket with Junction Box (Option)
2
14 15
Drill the Wall to Fix the Anchor Bolts
1
Fix the Junction Box
3
On the wall, drill a hole (6mm diameter/50mm
depth) for fix the anchor bolts.
Fix the junction box to anchor bolts on the wall.
Close Junction Box Cover
4
Close cover to the junction box using the torx driver.
Pass Cables through the Wall Mount
Bracket
2
Pass cables before fixing the wall mount
bracket.
Fix the Sun Shield Bracket
5
Fix the sun shield bracket to the wall mount bracket.
Connect the Terminal Blocks
Connect terminal blocks to the main body.
Refer page 10.
Fix the Main Body
Screw the main body to the surface mount bracket.
(Screws are included in the main body.)
Detach the Protection Vinyl
Detach the protection vinyl from the dome cover.
Wire Cables
Wire the cables to the terminal block.
Refer page 16, 17.
7
8
9
6
Drill the Wall to
Fix the Anchor Bolts
1
Pass Cables through
the Wall Mount Bracket
2
Fix the Junction Box
3
Close the Junction Box Cover
4
Fix the Sun Shield Bracket
5
Fix the Main Body
Connect the Terminal Blocks
Wire Cables
6
8
Detach the Protection Vinyl
9
7

Cabling the 5P Terminal Block Cabling the 7P Terminal Block
16 17
2
Power
3
Keyboard Controller/DVR
2
Monitor
1
BNC Video
Relay Out Input Slot Sensor/Alarm Input Slot
Sensor/Alarm Input
2
- It connects to IR sensor, IrDA sensor or door switch. If the
sensor is activated, it can activate to move camera to the
specific angle and to connect the alarm device.
- A cable of the sensor should connect to input 1 or 2, and
the other should be connected to ‘COM’ slot.
- If you want to use alarm input, the types of sensor must be
selected in OSD menu (ROOT MENU>MOTION SETUP>
ALARM INPUT SETUP). The sensor types are normal open
and normal close.
Output voltage is high state when sensor is
activated.
Output voltage is high state when sensor is not
activated.
Normal Open
(N.O)
Normal Close
(N.C)
N.C
Activation
Activation
N.O In 2
COM
In 2
COM
In 2
COM
In 2
COM
In 2
COM
Relay Out
1
Output voltage is high state when sensor is
activated.
Output voltage is high state when sensor is not
activated.
Normal Open
(N.O)
Normal Close
(N.C)
- It connects to the alarm lights, siren or lamps, and it is
activated according to the OSD menu setting.
- If you want to use relay out, the types of sensor must be
selected in OSD menu (ROOT MENU>SYSTEM SETUP>
RELAY TYPE). The sensor types are normal open and
normal close.
Out Out
<Inside of terminal block: Activation type of relay out N.O.> <Inside of terminal block: Activation type of alarm input N.O. / N.C.>
Sensor/Alarm Input
2
Relay Out
1
5P Terminal Block
5p terminal block connects the sensor/alarm input and the
relay out device to the camer’s main body. (Refer ‘Installation
Using Surface Mount Bracket’ of page 10 for the connection
of the terminal block.)
Power
3
Power Power ConsumptionRange
DC 12V 8WDC 11V ~ 15V
- Please check the correct rated power.
- The rated power is marked on the bottom of the camera.
Monitor
1
Connects to video output device such as monitor using the
BNC coaxial cable.
Keyboard Controller/DVR
2
Controls PTZ by connecting with keyboard controller or
DVR using RS-485 communication standards.
7P Terminal Block
7p terminal block connects the power, keyboard controller/
DVR or video device and etc to the camera’s main body.
(Refer ‘Installation Using Surface Mount Bracket’ of page 10
for the connection of the terminal block.)
Video Input Slot
RS-485 Communication Input Slot
Power Input Slot
Keyboard Controller/DVR
Camera 1 Camera 2 Camera n
~
Fan/Heater model consumes 12W.

1. Before power is applied, please check the cables carefully.
2. The camera ID of the controller must be identical to that of the target camera. The camera ID can be checked by
reading DIP switch of the camera.
3. If your controller supports multi-protocols, the protocol must be changed to match to that of the camera.
4. If you changed camera protocol by changing DIP switch, the change will be eective after you reboot the camera.
5. Since the operation method can be dierent for each controller available, refer to the manual for your controller if
camera cannot be controlled properly.
Check Points before Operation
- If the camera is exposed the high temperature(over 50°)
for a long time, the camera can lose focus. As a result, you
will get a blurry image. In this case, enter‘Preset key + 165’
to enable auto calibration.
-
If auto calibration is enabled, the camera will be re-focused
once every 6 hours. If you want to disable this function,
enter ‘Preset key + 165’.
Auto Calibration
3
- Max. 127 positions can be stored as preset positions.
The preset number can be assigned from 1 to 128, but 95
is reserved for starting OSD menu.
- Refer page 28 - ‘ROOT MENU>FUNCTION SETUP>PRESET
SETUP’ for more detailed information.
Preset
1
- Check how to operate preset and pattern function with
keyboard controller/DVR in advance to operate camera
function fully when using keyboard controller/DVR.
- If keyboard controller/DVR has no pattern key or function,
use shortcut keys with preset numbers. For more
information, refer to ‘Reserved Preset’ below.
Preset and Pattern Function Pre-check
1
Some preset numbers are reserved to special functions.
Preset key + 95: Enters into OSD menu
Preset key + 131~134: Runs pattern function 1 ~ 4
Preset key + 141~148: Runs scan function 1 ~ 8
Preset key + 151~158: Runs group function 1 ~ 8
Preset key + 161: Sets relay output to OFF
Preset key + 161: Sets relay output to ON
Preset key + 165: Sets auto calibration to ON
Preset key + 166: Sets auto calibration to OFF
Preset key + 167: Zoom proportional jog ON
Preset key + 167: Zoom proportional jog OFF
Preset key + 170: Sets camera BLC mode to OFF
Preset key + 171: Sets camera BLC mode to HIGH
Preset key + 174: Sets camera focus mode to AUTO
Preset key + 175: Sets camera focus mode to MANUAL
Preset key + 176: Sets camera focus mode to SEMI-AUTO
Preset key + 177: Sets day & night mode to AUTO1
Preset key + 178: Sets day & night mode to NIGHT
Preset key + 179: Sets day & night mode to DAY
Preset key + 190: Sets OSD display mode to AUTO
(Except privacy mask)
Preset key + 191: Sets OSD display mode to OFF
(Except privacy mask)
Preset key + 192: Sets OSD display mode to ON
(Except privacy mask)
Preset key + 193: Sets all privacy mask display to OFF
Preset key + 194: Sets all privacy mask display to ON
Preset key + 195: Sets fan/heater to ON
(Turning o after 5 min, turn to auto mode)
Preset key + 196: Sets fan/heater to OFF
(After turning o, turn to manual mode)
Preset key + 197:
Fan ON(Turning o after 5 min, turn to auto mode)
Preset key + 198: Fan OFF(After turning o, turn to manual mode)
Preset key + 200: Sets digital zoom to ON
Preset key + 201: Sets digital zoom to OFF
Reserved Preset
2
Method 1) Use keyboard controller:
Refer to keyboard controller manual.
Method 2) Use OSD menu.
Method 1) Use keyboard controller:
Preset key + Number key(1~128)
2. Run Preset
To delete pattern, use OSD menu.
3. Delete Preset
1. Set Preset
- By using scan function, you can make camera to move
between 2 preset positions repeatedly.
- Refer page 30 -‘ROOT MENU>FUNCTION SETUP>SCAN
SETUP’ for more detailed information.
Scan
2
Method 1) If there is scan key on the keyboard controller:
Scan key + Scan number(1~8) + Enter key
Ex) Run scan 2 = Scan key + [2] + Enter key
Method 2) If there is no scan key on the keyboard controller:
Preset key + [Scan number(1~8) + 140]
Ex) Run scan 2 = Preset key + [142]
2. Run Scan
To delete scan, use OSD menu.
To set scan, use OSD menu.
3. Delete Scan
1. Set Scan
- Pattern function is that a camera memorizes the path
(mostly curve path) by joystick of controller for assigned
time and revives the path exactly as it memorized.
- Refer page 31 -‘ROOT MENU>FUNCTION SETUP>PATTERN
SETUP’ for more detailed information.
Pattern
3
To set pattern, use OSD menu.
1. Set Pattern
Method 1) If there is pattern key on the keyboard controller:
Pattern key + Pattern number(1~4) + Enter key
Ex) Run pattern 2 = Pattern key + [2] + Enter key
Method 2) If there is no pattern key on the keyboard controller:
Preset key + [Pattern number(1~4) + 130]
Ex) Run pattern 2 = Preset key + [132]
2. Run Pattern
To delete pattern, use OSD menu.
3. Delete Pattern
- The group function allows running sequence of presets,
pattern and/or scans.
- Refer page 32 -‘ROOT MENU>FUNCTION SETUP>GROUP
SETUP’ for more detailed information.
Group
4
To set group, use OSD menu.
1. Set Group
Method 1) If there is group key on the keyboard controller:
Group key + Group number(1~8) + Enter key
Ex) Run group 2 = Group button + [2] + Enter key
Method 2) If there is no group key on the keyboard controller:
Preset key + [Group number(1~8) + 150]
Ex) Run group 2 = Preset key + [152]
2. Run Group
To delete group, use OSD menu.
3. Delete Group
- The schedule function allows running an appropriate
function like preset, scan, group, pattern, home move at
the designated day and time.
-
Refer Page 34 -‘ROOT MENU>FUNCTION SETUP>SCHEDULE
SETUP’ for more detailed information.
Schedule
5
3Check Points before Operation
18 19
Main Functions

PATTERN1PRESET LABEL
23/MAR/2009
24 00 00
CAM 1
O 1
Action Title
Preset Label
Date / Time
Camera ID
5
1
2
4
Image Flip
3
Compass Direction
Zoom Magnification
Tilt Angle in Degree
Pan Angle in Degree
Alarm Input Information
Temperature
6
Relay Out Information
F
1
Preset Label
- The label stored for specific preset.
- Refer page 29 for setting preset label.
(ROOT MENU>FUNCTION SETUP>PRESET SETUP>LABEL)
Relay Out Information
This information shows the current state of relay out. If the
output is on state it will show the number of output. If an
output is off state, ' - ' will be displayed.
8
Compass Direction
- Shows the current compass direction of the camera.
- The direction is shown as N(North), S(South), E(East),
W(West), NE(Northeast), NW(Northwest), SE(Southeast),
SW(Southwest).
- Refer page 39 for setting compass direction.
(ROOT MENU>SYSTEM SETUP>SET NORTH DIRECTION)
Zoom Magnification
Shows the current zoom magnification.
Tilt Angle in Degree
Shows the current tilt(0-180) angle.
12
Pan Angle in Degree
Shows the current fan(0-359) angle.
2
Date / Time
- Shows the current date/time.
- Refer page 38 for setting date/time.
(ROOT MENU>SYSTEM SETUP>DATE/TIME SETUP)
3
Image Flip
- Shows that images are currently reversed by auto flip
function.
- Refer page 36 for setting image flip.
(ROOM MENU>CAMERA SETUP>IMAGE FLIP)
4
Camera ID
- The current camera ID.
- The camera ID is identical with the address of
‘ROOT MENU>SYSTEM INFORMATION’.
5
Action Title
Shows the current action titles of the camera.
6
Temperature
- Current temperature: Boxed ‘C’ and ‘F’ means celsius and
fahrenheit respectively.
- Refer page 25 for setting temperature unit.
(ROOM MENU>DISPLAY SETUP>TEMPERATURE)
Action Title
SET PRESET 123
PRESET 123
PATTERN 9
SCN 1/PRESET 123
UNDEFINED
Means to store preset 123.
Means it reached preset 123.
Means tthe camera is running pattern 9.
Means the camera is running scan 1.
Means the action received is not defined.
O -
Relay Out On Relay Out Off
1
b
Move the Cursor
Up/Down to
Choose Menu
This page explains how to operate the OSD
menu using keyboard controller.
Read the manual of the keyboard controller.
If there are no keys or functions described
below, refer the manual of the keyboard
controller.
3
ROOT MENU
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<SYSTEM INFORMATION>
<DISPLAY SETUP>
<MOTION SETUP>
<FUNCTION SETUP>
<CAMERA SETUP>
<SYSTEM SETUP>
<SYSTEM INITIALIZE>
EXIT
ROOT MENU
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<SYSTEM INFORMATION>
<DISPLAY SETUP>
<MOTION SETUP>
<FUNCTION SETUP>
<CAMERA SETUP>
<SYSTEM SETUP>
<SYSTEM INITIALIZE>
EXIT
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
CAMERA ID
PTZ INFORMATION
ACTION TITLE
PRESET LABEL
ALARM I/O
DATE/TIME
<PRIVACY ZONE>
BACK
EXIT
ON
ON
ON
ON
ON
ON
Joystick
Down
Joystick
Down
Joystick
Up
Joystick
Up
>
>
Press
Near/Enter
Key
Press Far Key
>
>
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
CAMERA ID
PTZ INFORMATION
ACTION TITLE
PRESET LABEL
ALARM I/O
DATE/TIME
<PRIVACY ZONE>
BACK
EXIT
ON
ON
ON
ON
ON
ON
Press
Near/Enter
Key
Press Far Key
>
>
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
CAMERA ID
PTZ INFORMATION
ACTION TITLE
PRESET LABEL
ALARM I/O
DATE/TIME
<PRIVACY ZONE>
BACK
EXIT
OFF
ON
ON
ON
ON
ON
>
>
a
c
d
2
Shift to the Sub
Menu of the
Chosen Menu
3
Choose the
Value
4
Change the
Value
5
Move to
the
Previous
Screen
>
1Move the Cursor Up/Down to Choose Menu
To move from items to item in the menu, move the
joystick Up/Down.
2
Shift to the Sub Menu of the Chosen Menu
For all menu level, to go into sub menu, press
near/enter key.
3
Choose the Value
To change the value, press near/enter key to move
the cursor to the value.
4
Change the Value
Move the joystick Up/Down to change the value.
5
Move to the Previous Screen
Press near key to save values and press far key to
cancel values, then go to the previous screen.
25 C
I- 2 O 1
359/180/x100/SE
8
9
10
11
12
7
Alarm Input Information
This information shows current state of alarm Input. If an
input is on state it will show the number of input. If an input
is off state, ' - ' will be displayed.
I- 2
Alarm 2 Slot of the
Terminal Block
Alarm 1 Slot of the
Terminal Block
7
9
10
11
d d
a
The menu items surrounded with < > always have its sub menu.
To move to the sub menu, press near/enter key.
b
This screen is the main menu of the (DISPLAY SETUP).
c
c
This screen is the sub menu of ‘DISPLAY SETUP’ on the screen .
is the value of the each content.
b
OSD Information
20 21
General Rules of Menu Operation

FIRMWARE VER
COLOR SYSTEM
PROTOCOL
BAUD RATE
ADDRESS
1.0
NTSC
PELCO-D
2400
1
ON / OFF
ON / OFF / AUTO
ON / OFF / AUTO
ON / OFF / AUTO
ON / OFF / AUTO
ON / OFF
1(UNDEFINED) ~ 4(UNDEFINED)
ON / OFF
CANCEL / OK
CELSIUS / FAHRENHEIT / OFF
ON / OFF
ON / OFF
ON / OFF
2/SEC ~ 360/SEC (Default: 140/SEC)
INVERSE / NORMAL
ON / OFF
ON / OFF
00:00:05 ~ 04:00:00
HOME / PRESET / SCAN / PATTERN / GROUP
N.O(Normal Open) / N.C(Normal Close)
AUTO / MANUAL / SEMIAUTO
ON / OFF
ON / OFF
AUTO / MANUAL
10 ~ 60
10 ~ 60
OFF / LOW / MIDDLE / HIGH
AUTO1 / AUTO2 / DAY / NIGHT
0~100 (Default: 25)
AUTO / MANUAL (0~100)
ESC / A.FLICKER / MANUAL(×128~1/120000 sec)
OFF / NORMAL / HIGH
OFF / LOW / MIDDLE / HIGH
AUTO(2~128) / OFF
<SYSTEM INFORMATION>
<DISPLAY SETUP>
<MOTION SETUP>
<FUNCTION SETUP> <PRESET SETUP>
<SCAN SETUP>
<PATTERN SETUP>
<GROUP SETUP>
<SCHEDULE SETUP>
<CAMERA SETUP>
ROOT MENU The 1st screen The 2nd screen The 3rd screen The 4th screen Value ROOT MENU The 1st screen The 2nd screen Value
CAMERA ID
PTZ INFORMATION
ACTION TITLE
PRESET LABEL
ALARM I/O
DATE/TIME
<PRIVACY ZONE>
TEMPERATURE
PRESET LOCK
PWR UP ACTION
AUTO FLIP
JOG MAX SPEED
JOG DIRECTION
FRZ IN PRESET
<PARKING ACTION SETUP>
<ALARM INPUT SETUP>
PRESET NO.
<EDIT SCENE>
<LABEL>
CLR PRESET
CAM ADJUST
ALARM OUT
SCAN NO.
1ST POSITION
2ND POSITION
SCAN SPEED
CLEAR SCAN
PATTERN NO.
CLR PATTERN
<EDIT PATTERN>
GROUP NO.
CLEAR GROUP
<EDIT GROUP>
MASTER ENABLE
Schedule No.
FOCUS MODE
DIGITAL ZOOM
IMAGE FLIP
<WHITE BALANCE SETUP>
<EXPOSURE SETUP>
MASK NO.
DISPLAY
CLEAR MASK
<EDIT MASK>
Select the Camera location
Select the camera action, operation time and option
Select the Camera location
Select the Camera location
Input Label
Select the Mask Size & Color
PARK ENABLE
WAIT TIME
PARK ACTION
ALARM TYPE
ALARM ACTION
WB MODE
RED ADJUST
BLUE ADJUST
BACK LIGHT
DAY/NIGHT
BRIGHTNESS
IRIS
SHUTTER
AGC
SSNR
SENS-UP
DATE
TIME
RELAY 1
Input Password
Select the Camera location
Select the Camera location
FAN RUN TIME
HEATER RUN TIME
dd / mm / yyyy
hh : mm : ss
N.O(Normal Open) / N.C(Normal Close)
ENGLISH / ESPAÑOL / FRANÇAIS / DEUTSCH / ITALIANO / РУССКИЙ / PORTUGUÊS
30°C ~ 80°C (86°F ~ 176°F) (Default: 40°C)
-10°C ~ 20°C (14°F ~ 68°F) (Default: 5°C)
<SYSTEM SETUP> <DATE/TIME SETUP>
<RELAY TYPE>
<PASSWORD>
<SET HOME POSITION>
<SET NORTH DIRECTION>
LANGUAGE
<FAN/HEATER SETUP>
NO / YES
NO / YES
NO / YES
NO / YES
NO / YES
NO / YES
NO / YES
<SYSTEM INITIALIZE> CLEAR ALL DATA
CLR DISPLAY SET
CLR CAMERA SET
CLR MOTION SET
CLR FUNCTION SET
REBOOT CAMERA
REBOOT SYSTEM
1(UNDEFINED) ~ 128(UNDEFINED)
CANCEL / OK
GENERAL / SPECIAL
- / 1
1(UNDEFINED) ~ 8(UNDEFINED)
PRESET 1 ~ 128
PRESET 1 ~ 128
2/SEC ~ 360/SEC (Default: 30/SEC)
CANCEL / OK
1(UNDEFINED) ~ 4(UNDEFINED)
CANCEL / OK
1(UNDEFINED) ~ 8(UNDEFINED)
CANCEL / OK
1(NONE) ~ 20(NONE)
ON / OFF
1(UNDEFINED) ~ 7(UNDEFINED)
NOT USED / HOME / PRESET 1~128
/ SCAN 1~8 / PATTERN 1~4 / GROUP 1~4
The bold characters of the value are the default value of the system. (Refer page 40 – ‘SYSTEM INITIALIZE’)
The menu of ‘ROOT MENU>SYSTEM SETUP>FAN/HEATER SETUP’ is applicable only for fan/heater model.
OSD Menu Contents
22 23
OSD Menu Contents
3

SYSTEM INFORMATION
- - - - - - - - - - - - - - - - - - - - - - - - - - -
FIRMWARE VER
COLOR SYSTEM
PROTOCOL
BAUD RATE
ADDESS
BACK
EXIT
1.0
NTSC
PELCO-D
2400
1
ROOT MENU
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<SYSTEM INFORMATION>
<DISPLAY SETUP>
<MOTION SETUP>
<FUNCTION SETUP>
<CAMERA SETUP>
<SYSTEM SETUP>
<SYSTEM INITIALIZE>
EXIT
PRIVACY ZONE
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASK NO.
DISPLAY
CLEAR MASK
<EDIT MASK>
BACK
EXIT
1
UNDEFINED
OFF
CANCEL
EDIT MASK 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO TARGET POSITION
[NEAR:SELECT/FAR:CANCEL]
0/0/x1/E
DISPLAY SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
CAMERA ID
PTZ INFORMATION
ACTION TITLE
PRESET LABEL
ALARM I/O
DATE/TIME
<PRIVACY ZONE>
TEMPERATURE OFF
BACK
EXIT
> > >>
Select <EDIT MASK>,
Press Near/Enter Key
Move Camera to Area to Mask,
Press Near/Enter Key
5
1
2
1
1
4
3
ON
ON
ON
ON
ON
ON
EDIT MASK 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ZOOM : COLOR CHANGE]
[ ADJUST MASK WIDTH]
[ ADJUST MASK HEIGTH]
[NEAR:SELECT/FAR:CANCEL]
PRIVACY ZONE
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASK NO.
DISPLAY
CLEAR MASK
<EDIT MASK>
BACK
EXIT
1
ON
CANCEL
DISPLAY SETUP
1
This menu defines to enable/disable of OSD display on main screen.
CAMERA ID
PTZ INFORMATION
ACTION TITLE
PRESET LABEL
ALARM I/O
DATE/TIME
<PRIVACY ZONE>
TEMPERATURE
ON / OFF
ON / OFF / AUTO
ON / OFF / AUTO
ON / OFF / AUTO
ON / OFF / AUTO
ON / OFF
CELSIUS / FAHRENHEIT / OFF
If an item is set to be ‘AUTO’, the item is displayed only when the value of
it is changed.
Moves to the privacy zone setup.
ROOT MENU
1
To enter this screen, enter ‘Preset key + 95’.
<SYSTEM INFORAMTION>
Shows information and current configuration.
<DISPLAY SETUP>
Enable/Disable of OSD display on main screen.
<MOTION SETUP>
Setup for motion related settings.
<FUNCTION SETUP>
Setup for various functions such as preset, scan, pattern, group and schedule.
<CAMERA SETUP>
Configure camera related functions and data.
<SYSTEM SETUP>
Configure for basic system setup.
<SYSTEM INITIALIZE>
Initializes system configuration and sets all data to factory default
configuration.
EXIT
To escape from the OSD setting, go to exit.
SYSTEM INFORMATION
1
Shows basic information and current configuration of the system.
FIRMWARE VER
Shows the current firmware version.
COLOR SYSTEM
Shows the current analog video system.
PROTOCOL
Shows the current PTZ control protocol.
BAUD RATE
Shows the current baud rate of the PTZ control.
ADDRESS
Shows the current camera ID of the PTZ control.
EDIT MASK - Select Mask Location
3
1. Move camera to area to mask.
2. Adjust the mask size. Use the zoom key to adjust the image size.
3. Press near key to complete the location.
EDIT MASK - Select Mask Color and Size
4
1. Choose the mask color using zoom key.
(The current color is 50% transparent. When the mask setting
is completed, the mask area is masked by 100% opaque color.)
2. Move joystick Left/Right to adjust the width.
3. Move joystick Up/Down to adjust the height.
4. Press near key to complete the setting.
5. If press far key, it returns to the previous setting without
storing the setting.
MASK SETTING - Completion Screen
5
- Run the mask no. marked on the screen.
- The value of ‘DISPLAY’ is set to ‘ON’ automatically.
- Can set mask 2 ~ 4 continuously.
The objects behind the mask can be shown when the camera is moving
in a short period.
It is recommended that the size of the mask must be 20% bigger than the
original target size so as to mask the objects during high speed pan/tilt.
PRIVACY ZONE
2
- Selects area in image to mask.
-
It selects the area to mask, and setup various function of the mask.
MASK NO.
DISPLAY
Select mask number. If the selected mask has data already, camera moves
as it was set. Otherwise, ‘UNDEFINED’ will be displayed under ‘MASK NO.’.
1 ~ 4
Sets if the camera makes mask shows or not on images.
CLEAR MASK
Deletes data in the selected mask no.
<EDIT MASK>
Moves to setup the mask no.
ON / OFF
CANCEL / OK
Press
Near/Enter
Key
Press Near Key to Save
OSD - ROOT MENU & SYSTEM INFORMATION
25
OSD - DISPLAY SETUP
3
24

ALARM INPUT SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ALARM 1 N.O
ALARM 2 N.O
BACK
EXIT
MOTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET LOCK
PWR UP ACTION
AUTO FLIP
JOG MAX SPEED
JOG DIRECTION
FRZ IN PRESET
<PARKING ACTION SETUP>
<ALARM INPUT SETUP>
BACK
EXIT
>
1
2
OFF
ON
ON
140/SEC
NORMAL
OFF
NOT USED
NOT USED
> >
3
4
5
NOT USED
NOT USED
ALARM INPUT SETUP
2
If an external sensor is activated, camera will move to
corresponding action.
ALARM INPUT SETUP - Type Setup
3
1. Move joystick Up/Down to set alarm type.
2. Move joystick Left/Right to set alarm action.
ALARM INPUT SETUP - Alarm Action Setup
4 5
1. Move joystick Up/Down to set the action(HOME, PRESET, SCAN,
PATTERN, GROUP) and no.
2. On screen 5, move joystick Left/Right to move the focus to set
alarm type, function name and function no.
3. By pressing near key, save the current setting.
Alarm Type:
Alarm Action
- Sets sensor input type.
- Refer page 14 for more detailed information.
N.O(Normal Open) / N.C(Normal Close)
Assign counter-action to each alarm input. Among 149 actions, choose
the action as explained below.
NOT USED / HOME / PRESET 1~128 /
SCAN 1~8 / PATTERN 1~4 / GROUP 1~8
ALARM INPUT SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ALARM 1 N.O
ALARM 2 N.O
BACK
EXIT
ALARM INPUT SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ALARM 1 N.O
ALARM 2 N.O
BACK
EXIT
NOT USED
NOT USED
>
ALARM INPUT SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
ALARM 1 N.O
ALARM 2 N.O
BACK
EXIT
PRESET 1
NOT USED
MOTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET LOCK
PWR UP ACTION
AUTO FLIP
JOG MAX SPEED
JOG DIRECTION
FRZ IN PRESET
<PARKING ACTION SETUP>
<ALARM INPUT SETUP>
BACK
EXIT
OFF
ON
ON
140/SEC
NORMAL
OFF
MOTION SETUP
Setup the general functions of pan/tilt motions.
PRESET LOCK
PWR UP ACTION
If motion lock is set to on, it is impossible to set up and delete preset,
scan, pattern and group. It is possible only to run those functions.
To set up and delete those functions, enter into OSD menu.
ON / OFF
This function enables to resume the last action executed before power
down. Most of actions such as preset, pattern, scan and group are
available for this function but jog actions are not available to resume.
AUTO FLIP
In case that tilt angle arrives at the top of tilt orbit (90°), zoom module
camera keep moving to opposite tilt direction (180°) to keep tracing
targets. As soon as zoom module camera passes through the top of tilt
direction(90°), images should be reversed automatically and ‘ F’ appears
in screen. If this function is set to ‘OFF’, tilt movement range is 0° ~ 90°
ON / OFF
ON / OFF
JOG MAX SPEED
Sets maximum jog speed. Jog speed is inversely proportional to zoom
magnification. As zoom magnification goes up, pan/tilt speed goes down.
JOG DIRECTION
If you set this to ‘INVERSE’, the view in the screen is moving same direction
with jog tilting. If ‘NORMAL’ is selected, the view in the screen is moving
reversely.
FRZ IN PRESET
At start point of preset movement, camera starts freezing the image of
start point. Camera keeps displaying the image of start point during
preset movement and does not display the images which camera gets
during preset movement. As soon as camera stops at preset end point,
camera starts displaying live images which it gets at preset end point.
This function availability should be different by models.
<PARKING ACTION SETUP>
Moves to ‘PARKING ACTION SETUP’ screen.
<ALARM INPUT SETUP>
Moves to ‘ALARM INPUT ACTION’ screen.
2/SEC ~ 360/SEC
INVERSE / NORMAL
ON / OFF
11
PARKING ACTOIN SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PARK ENABLE
WAIT TIME
PARK ACTION
BACK
EXIT
>
2
PARKING ACTION SETUP
2
If ‘PARK ENABLE’ is set to ‘ON’, camera runs assigned function
automatically if there is no PTZ command during assigned
‘WAIT TIME’.
PARK ENABLE
WAIT TIME
Enables/Disables ‘PARKING ACTION’.
ON / OFF
The time is displayed with "hh:mm:ss" format and you can change this
by 1 sec unit.
1. To place the cursor on the time marked as below, press near key.
2. Move joystick Left/Right to adjust hours, minutes and seconds.
3. Move joystick Up/Down to select the digit.
4. By pressing near key, save current setting.
PARKING ACTION
Select the action of parking. Move joystick Up/Down to choose the
appropriate action.
00:00:05 ~ 04:00:00
HOME / PRESET 1~128 / SCAN 1~8 /
PATTERN 1~4 / GROUP 1~8
OFF
00:10:00
HOME
00:10:00
Press
Near/Enter
Key
Press
Near/Enter
Key
Press
Near/Enter
Key
Joystick
Right
Joystick
Down
OSD - MOTION SETUP
27
OSD - MOTION SETUP
3
26

1
LABEL
2
- Edits label to show on monitor when preset runs.
- Max. 10 alphabets are allowed(Including space).
LABEL – Alphabet Input
3
- If you complete the label editing, move cursor to ‘OK’ and press
near key to save completed label. To abort current change, move
cursor to ‘CANCEL’ and press near key.
PRESET SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET NO.
<EDIT SCENE>
<LABEL>
CLR PRESET
CAM ADJUST
ALARM OUT
BACK
EXIT
1
CANCEL
GENERAL
-
PRESET SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET NO.
<EDIT SCENE>
<LABEL>
CLR PRESET
CAM ADJUST
ALARM OUT
BACK
EXIT
1
CANCEL
<SPECIAL>
-
CAM ADJUST -PRESET1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<WHITE BALANCE SETUP>
<AUTO EXPOSURE SETUP>
BACK
EXIT
>
2
1
2
Moves to ‘WHITE BALANCE SETUP’ screen. Refer page 36.
Moves to ‘AUTO EXPOSURE SETUP’ screen. Refer page 37.
CAM ADJUST
2
Sets WB/AE for the preset when ‘CAM ADJUST’ value is ‘SPECIAL’.
<AUTO EXPOSURE SETUP>
<WHITE BALANCE SETUP>
LABEL PRESET1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ ]
OK
CANCEL
- - - - - - - - - -
12 3 4 5 6 7 8 9 0
A B C D E F G H I J
K LMN O P Q R ST
U V WX Y Z a b c d
e f g h i j k l m n
o p q r s t u v w x
y z < > - / :.
>
3
LABEL PRESET1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ ]
OK
CANCEL
SKY
- - - - - - - - - -
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J
K LMN O P Q R ST
U V WX Y Z a b c d
e f g h i j k l m n
o p q r s t u v w x
y z < > - / :.
LABEL PRESET1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ ]
OK
CANCEL
- - - - - - - - - -
12 3 4 5 6 7 8 9 0
A B C D E F G H I J
K LMN O P Q R ST
U V WX Y Z a b c d
e f g h i j k l m n
o p q r s t u v w x
y z < > - / :.
a
b
c
de
d
a
Preset NO. for Label
b
Input Cursor: The character which cursor is located will be input or
edited.
c
Cursor Selecting Alphabet: Using Left/Right/Up/Down of joystick,
move to an appropriate character from the character set.
Space: If you want to use blank, choose space character (" ").
e
Back-Space: If you want to delete a character before, use back space
character (’ ‘).
FUNCTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<PRESET SETUP>
<SCAN SETUP>
<PATTERN SETUP>
<GROUP SETUP>
<SCHEDULE SETUP>
BACK
EXIT
FUNCTION SETUP
1
Configure 5 special functions with this menu.
<PRESET SETUP>
Moves to ‘PRESET SETUP’ screen.
<SCAN SETUP>
Moves to ‘SCAN SETUP’ screen. Refer page 30.
<PATTERN SETUP>
Moves to ‘PATTERN SETUP’ screen. Refer page 31.
<GROUP SETUP>
Moves to ‘GROUP SETUP’ screen. Refer page 32.
<SCHEDULE SETUP>
Moves to ‘SCHEDULE SETUP’ screen. Refer page 34.
PRESET SETUP - Undefined Screen
2
127 presets from the number 1 to 128 can be assigned excluding
preset 95 reserved for menu.
PRESET SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET NO.
<EDIT SCENE>
BACK
EXIT
1
UNDEFINED
PRESET SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PRESET NO.
<EDIT SCENE>
<LABEL>
CLR PRESET
CAM ADJUST
ALARM OUT
BACK
EXIT
1
CANCEL
GENERAL
-
> > >
4
PRESET NO.
If a selected preset is already defined, camera moves to pre-defined
position and preset characteristics such as label and relay outputs show
on monitor. (Refer screen 4) If a selected preset is not defined,
“UNDEFINED” shows on monitor.
1 ~ 128 (Excluding 95)
1 ~ 128 (Excluding 95)
CANCEL / OK
<EDIT SCENE>
Moves to ‘EDIT SCENE’ setup screen.
Edits Label to show on monitor when preset runs. If the preset is not
defined, this is not shown. Refer following page to setup label.
Deletes current preset data. If the preset is not defined, this is not shown.
Relay output can be linked with preset run. ‘ - ‘means off, ‘1’ means on.
-
CAM ADJUST_GENERAL: The general mode means that WB or AE defined
‘ROOT MENU>CAMERA SETUP’ will be applied to this preset.
- CAM ADJUST_SPECIAL: The Special mode means that WB or AE can be
set up independently or separately for each preset in each preset setup
menu.
- Special WB/AE value should activate only when the camera arrives at
each preset location. During jog operation, general WB/AE value should
be applied.
- Refer following page to set special WB/AE.
PRESET SETUP
4
If the preset is defined, the information will be shown on the OSD
menu with the setting, and the alarm device (if defined) will be
activated.
PRESET NO.
CLR PRESET
GENERAL / SPECIAL
CAM ADJUST
- / 1
ALARM OUT
<EDIT SCENE>
<LABEL>
EDIT SCENE -PRESET1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO TARGET POSITION
[NEAR:SELECT/FAR:CANCEL]
0/0/x1/E
EDIT SCENE
3
1. Using joystick, move camera to desired position.
2. Using zoom key, move camera to desired screen size.
3. By pressing near key, the save current PTZ data
1
2
3
Press
Near/Enter
Key
Press
Near/Enter
Key
Press
Near/Enter
Key
Press
Near/Enter
Key
Press
Near/Enter
Key
Select <EDIT SCENE>,
Press Near/Enter Key
OSD - FUNCTION SETUP > PRESET SETUP
29
OSD - FUNCTION SETUP > PRESET SETUP
3
28

1
2
4
5
3
EDIT PATTERN 1
[NEAR:SAVE / FAR:DELETE]
0/0/x1/E
EDIT PATTERN 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO START POSITION
[NEAR:START/ FAR:CANCEL]
0/0/x1/E
EDIT PATTERN 1
[NEAR:SAVE / FAR:DELETE]
0/0/x1/E
EDIT PATTERN 1
TIME LIMITE...
1st POS.
1. CW direction
2. CCW direction
2st POS.
FUNCTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<PRESET SETUP>
<SCAN SETUP>
<PATTERN SETUP>
<GROUP SETUP>
<SCHEDULE SETUP>
BACK
EXIT
FUNCTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<PRESET SETUP>
<SCAN SETUP>
<PATTERN SETUP>
<GROUP SETUP>
<SCHEDULE SETUP>
BACK
EXIT
SCAN SETUP
2
- Up to 8 scans are available, which makes the camera to move
slowly between two preset positions.
-
When scan function runs, the camera moves from the preset
assigned as the 1st pos. to the preset assigned as the 2nd pos.
in CW(Clockwise) direction. Then camera moves from the preset
assigned as the 2nd pos. to the preset assigned as the 1st pos.
in CCW(Counterclockwise) direction. Then, it continues to move
from the 1st pos. to the 2nd pos. back and forth.
PATTERN SETUP
2
It records the free path of camera by joystic control.
SCAN SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
SCAN NO.
1ST POS.
2ST POS.
SCAN SPEED
CLEAR SCAN
BACK
EXIT
1
NOT USED
NOT USED
30/SEC
CANCEL
PATTERN SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
PATTERN NO.
CLR PATTERN
<EDIT PATTERN>
BACK
EXIT
1
UNDEFINED
CANCEL
>
> > > >
SCAN NO.
Select scan number to edit. If a selected scan is defined, 2 presets will be
displayed in the 1st position and the 2nd position.
1 ~ 8
1ST POS.
Set up the 1st position for scan function. If a selected preset is not defined,
‘UNDEFINED’ will be displayed as shown below.
Undefined preset cannot be assigned as position. If you press near key
when the selected preset is ‘UNDEFINED’, the preset will returned to
previous position(Available preset or ‘NOT USED’).
PRESET 1 ~ 128, NOT USED
PATTERN NO.
Select pattern number to edit. If a selected pattern number is not defined,
‘UNDEFINED’ will be displayed under selected pattern number.
1 ~ 4
CLR PATTERN
Deletes data in the current pattern.
<EDIT PATTERN>
Moves to edit the pattern assigned.
CANCEL / OK
EDIT PATTERN - Select the Position
3
2ST POS.
Same as the 1st pos. setup.
PRESET 1 ~ 128, NOT USED
SCAN SPEED
Sets the scan speed.
1/SEC ~ 180/SEC
CLEAR SCAN
Deletes the data in current scan.
CANCEL / OK
1
2
If the 1st POS. = the2nd POS.
In case that the preset assigned as the 1st pos. is same as the
preset assigned as the 2nd pos., camera turns on its axis by 360°
in CW direction and then it turns on its axis by 360°in CCW direction.
If one preset is not defined between the 1st POS. and the 2nd POS.
If case that a position assigned is ‘NOT USED’, camera turns on
its axis by 360°in CW direction from the preset which is
‘NOT USED’ and then it turns on its axis by 360°in CCW direction.
SCAN SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
SCAN NO.
1ST POS.
2ST POS.
SCAN SPEED
1
PRESET 1
NOT USED
30/SEC
UNDEFINED
1. By using joystick, move to start position.
2. By using joystick, move to the appropriate zoom.
3. To start pattern recording, press near key.
EDIT PATTERN - Records the Path
4
1. Move camera with joystick of controller or run preset function
to memorize the path (mostly curve path) in a selected pattern.
2. The total memory size and the rest memory size is displayed in
the form of bar. (Refer screen 5)
If bar is full as below, the camera does not record any more
paths.
The pattern path includes the zoom magnification.
3. To save data and exit, press near key.
4.
To cancel recording and delete the recorded data, press far key.
Select <EDIT PATTERN>,
Press Near/Enter Key
When pattern is edited or ok, pan/tilt will turn to ‘AUTO FLIP>
OFF’ temporarily.
Press
Near/Enter
Key
Press
Near/Enter
Key
Move Camera to Area,
Press Near/Enter Key
Record the Path of the Pattern
by Camera Control
OSD - FUNCTION SETUP>SCAN SETUP
31
OSD - FUNCTION SETUP>PATTERN SETUP
3
30

4
5
3 8
FUNCTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<PRESET SETUP>
<SCAN SETUP>
<PATTERN SETUP>
<GROUP SETUP>
<SCHEDULE SETUP>
BACK
EXIT
GROUP SETUP SCREEN
2
The group function allows running sequence of presets, pattern
and/or scans. Max. 8 group can be stored. Each group can have
max. 20 action entities which can be preset, pattern or scan.
EDIT GROUP - Initial Screen
3
To edit group, press near key to move screen 4.
At the current screen, if moves joystick Down, the cursor will move
to ‘SAVE’ menu.
EDIT GROUP – Select Function Sequence
4
Note that max. 20 functions are allowed in a group.
Move cursor Up/Down to rotate among 20 functions.
EDIT GROUP - Assign Function
5
Move cursor to the ‘NO.’ to assign the function, press near key to
set up. Select the function by moving joystick Up/Down.
EDIT GROUP - Assign Function
6
Move cursor Left/Right to select items and move cursor Up/Down
to change each value.
EDIT GROUP - Select Function Sequence
7
The function undefined cannot be set as action.
e.g.)
If ‘PATTERN 1’ is not defined at ‘ROOT MENU>FUNCTION
SETUP>
PATTERN SETUP’, then the ‘ACTION 1’ will be
automatically changed to ‘NONE’.
EDIT GROUP- Saves the Setting
8
After finishing setting up all actions, place cursor on ‘SAVE’ . Then,
press near key to save data.
GROUP SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
GROUP NO.
CLEAR GROUP
<EDIT GROUP>
BACK
EXIT
1
UNDEFINED
CANCEL
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1NONE
2 NONE
3NONE
4NONE
5NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE
CANCEL [NEAR:EDIT]
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1NONE
2 NONE
3NONE
4NONE
5NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE
CANCEL
[NEAR:EDIT ACT]
[FAR :EDIT END]
Press Near Key
Select <EDIT GROUP>,
Press Near/Enter Key
> > > >
>
> >
GROUP NO.
Selects group number to edit. If a selected group number is not defined,
‘UNDEFINED’ will be displayed under the selected group number.
1 ~ 8
NO.
Means the sequence of the function in a group.
The functions will be run from lower no. to higher no. by sequence.
1 ~ 20
<EDIT GROUP>
Moves to edit the group assigned.
CLEAR GROUP
Deletes data in the current group.
CANCEL / OK
ACTION NO.
Select the function.
Select the function no. separately.
Sets dwell time between function by moving joystick Up/Down. If the
‘OPT’ of pattern/group is set to repeat more than twice, it means the repeat
interval.
NONE / PRESET 1~128(Excluding 95) /
PATTERN 1~4 / SCAN 1~4
DWELL TIME
It should be preset speed when preset is set in ‘ACTION’. It should be the
number of repeat when pattern or scan is selected in ‘ACTION’.
OPT
00:03 ~ 04:00 (min:sec)
PRESET: 2~360 / PATTERN & SCAN: 1~255
1
2
6
7
[ : MOVE CURSOR ]
[ : CHANGE VAL.]
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1
PATTERN 1 00:0 3 1
2 NONE
3NONE
4NONE
5NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE
CANCEL
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1
PATTERN 1 00:0 3 1
2 NONE
3NONE
4NONE
5NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE
CANCEL
[ : MOVE CURSOR ]
[ : CHANGE VAL.]
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1NONE
2 NONE
3NONE
4NONE
5NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE
CANCEL
Preset
1Preset 120
Pattern5
1 Times Pattern5 n Times
Dwell Time
Max. 20 Entities
Scan3
1
[NEAR:EDIT ACT]
[FAR :EDIT END]
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1
PATTERN 1 00:0 3 1
2 NONE
3NONE
4NONE
5NONE
- - - - - - - - - - - - - - - - - - - - - - - - - -
SAVE
CANCEL
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1
PATTERN 1 00:0 3 1
2 NONE
EDIT GROUP 1
- - - - - - - - - - - - - - - - - - - - - - - - - - -
NO. ACTION NO. DWELL OPT
- - - - - - - - - - - - - - - - - - - - - - - - - -
1NONE
2 NONE
<In case that ‘PATTERN 1’ is not defined.>
Press
Near/Enter
Key
Press
Near/Enter
Key
Press
Far Key
Press
Near/Enter
Key
Press
Near/Enter
Key
OSD - FUNCTION SETUP>GROUP SETUP
33
OSD - FUNCTION SETUP>GROUP SETUP
3
32

4
5
3
FUNCTION SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<PRESET SETUP>
<SCAN SETUP>
<PATTERN SETUP>
<GROUP SETUP>
<SCHEDULE SETUP>
BACK
EXIT
SCHEDULE SETUP SCREEN
2
- The schedule function allows running the appropriate function
like preset, scan, group, pattern, home move at designated day
and time.
e.g.) if you setup a rule ‘Tuesday at 9:00AM’ and ‘Preset 1 (say main
gate)’, the camera will move to main gate every Tuesday at
9:00AM.
- It is noted that due to the real time clock (ROOT MENU>SYSTEM
SETUP>DATE/TIME SETUP), the time data will be kept regardless
of blackout. The initial time and day setup is essential to proper
schedule function.
- Max. 7 schedules are allowed.
SCHEDULE SETUP - Assign Value
4 5
Each field (DAY, TIME, ACT, NO., ON) can be selected by Left/Right
keys and the values in the field are changed using Up/Down keys.
SCHEDULE SETUP - Save Edited Setting
6
To save data and exit, press near key.
If there are rules conflicts to each other, the higher number is,
the higher priority has.
e.g.) The camera will move to ‘Preset 127’ at 12:00 on every
Wednesday although ‘Preset 128 and 127’ were set at 12:00
on every Wednesday.
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE OFF
DAY TIME ACT NO ON
1UNDEFINED
2 UNDEFINED
3UNDEFINED
4UNDEFINED
5UNDEFINED
6UNDEFINED
7 UNDEFINED
BACK
> > > >
MASTER ENABLE
Decide whether schedule function is active or not.
ON / OFF
DAY
Set the day for scheduling.
- Undefined: Inactivate
- All: Applies to every day
- WKD: Applies to every day except Sunday
- SUN-MON: Applies to designated day only
TIME
Set the time.
UNDEFINED / ALL / WKD / SUN ~ MON
00:00 ~ 23:59 (hour:min)
ON
Decide to make this rule effective or not.
ON /OFF
ACT NO
Set the function and no.
Unlike the group, the undefined function can be assigned in schedule.
However, no action is taken at the schedule.
HOM(HOME) / PRS(Preset) 1~128(Excluding 95)
/ SCN(Scan) 1~8 / PTN(Pattern) 1~8
/ GRO(Group) 1~8
1
2
6
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE OFF
DAY TIME ACT NO ON
1UNDEFINED
2 UNDEFINED
3UNDEFINED
4UNDEFINED
5UNDEFINED
6UNDEFINED
7 UNDEFINED
BACK
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE OFF
DAY TIME ACT NO ON
1ALL 00:00 HOM OFF
2 UNDEFINED
3UNDEFINED
4UNDEFINED
5UNDEFINED
6UNDEFINED
7 UNDEFINED
BACK
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE OFF
DAY TIME ACT NO ON
1ALL 12:00 PRS 128 ON
2 UNDEFINED
3UNDEFINED
4UNDEFINED
5UNDEFINED
6UNDEFINED
7 UNDEFINED
BACK
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE OFF
DAY TIME ACT NO ON
1ALL 12:00 PRS 128 ON
2 UNDEFINED
3UNDEFINED
4UNDEFINED
5UNDEFINED
6UNDEFINED
7 UNDEFINED
BACK
SCHEDULE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MASTER ENABLE OFF
DAY TIME ACT NO ON
1ALL 12:00 PRS 128 ON
2 WED 12:00 PRS 127 ON
3UNDEFINED
4UNDEFINED
5UNDEFINED
Press
Near/Enter
Key
Joystick
Down
Assign Value
Joystick Down,
Press Near Key
OSD - FUNCTION SETUP>SCHEDULE SETUP OSD - FUNCTION SETUP>SCHEDULE SETUP
3
3534

4
5
3
CAMERA SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
FOCUS MODE
DIGITAL ZOOM
IMAGE FLIP
<WHITE BALANCE SETUP>
<AUTO EXPOSURE SETUP>
BACK
EXIT
CAMERA SETUP
1
Setup the general functions of zoom camera module. Setup the video related function of zoom camera module.
WB SETUP
2
WB SETUP - Set WB Mode to Manual
3
If WB mode changes to ‘MANUAL’, the value of ‘RED ADJUST’ and
‘BLUE ADJUST’ shows on the screen.
WB SETUP - Change WB Color Value
4 5
- If WB mode changes to ‘MANUAL’, the color value of ‘RED ADJUST’
and ‘BLUE ADJUST’ can be set up manually.
- To save data and exit, press near key.
Press Near Key,
Joystic Down
Joystic Down
> > > >
FOCUS MODE
Sets camera focus mode.
- SEMIAUTO: This mode exchanges focus mode automatically between
manual focus mode and auto focus mode. Manual focus mode activates
in preset operation and auto focus mode activates when jog operation
starts.
- MANUAL: With manual mode at presets, focus data is memorized in
each preset in advance and camera calls focus data in correspondence
with presets as soon as camera arrives at a preset.
AUTO / MANUAL / SEMIAUTO
DIGITAL ZOOM
Sets digital zoom function to ‘ON’ or ‘OFF’. If this is set to ‘OFF’, optical
zoom function runs but zoom function stops at the end of optical zoom
magnification.
IMAGE FLIP
Sets if the image should be reversed or not.
ON / OFF
ON / OFF
<WHITE BALANCE SETUP>
Move to ‘WHITE BALACE SETUP’ screen.
<AUTO EXPOSURE SETUP>
Move to ‘AUTO EXPOSURE SETUP’ screen.
WB MODE
Red and blue level can be set up manually only in manual mode.
AUTO / MANUAL
RED ADJUST
Adjust the red color value. It can be set only in manual mode.
BLUE ADJUST
Adjust the blue color value. It can be set only in manual mode.
10 ~ 60
10 ~ 60
AE SETUP
2
BACKLIGHT
Sets the backlight compensation.
OFF / LOW / MIDDLE / HIGH
MANUAL IRIS SCREEN
3
IRIS LEVEL 0 ~ 100
MANUAL SHUTTER SCREEN
4
SHUTTER SPD
AUTO SENS-UP SCREEN
5
SENS-UP LIMIT
x128 ~ 1/120000
x2 ~ x128
DAY/NIGHT
‘AUTO1’ exchanges day/night mode faster than ‘AUTO2’.
AUTO1 / AUTO2 / DAY / NIGHT
BRIHGTNESS
Adjusts the brightness of images.
IRIS
- If iris is set to ‘AUTO’, iris should have highest priority in adjusting AE
and shutter speed should be fixed.
- If iris is set to ‘MANUAL’, iris should be fixed and iris has lower priority
in adjusting AE, in comparison with others.
0 ~ 100
AUTO / MANUAL
SHUTTER
- If iris is set to ‘MANUAL’ and shutter speed is set to ‘ESC’, shutter speed
should have highest priority.
- Shutter speed is set to ‘A. FLICKER’, to remove flicker, shutter speed
should be set to 1/100 sec. for NTSC and 1/120 for PAL.
ESC / A.FLICKER / MANUAL
AGC
Enhances the image brightness automatically in case that luminance level
of image signal is too low.
OFF / NORMAL / HIGH
SSNR
Enhances the images by deducting noises when gain level of images is
too high.
OFF / LOW / MIDDLE / HIGH
SENS-UP
- Activates the slow shutter function when luminance of image (signal) is
too dark.
- It is possible to set up the maximum number of frames piled up one on
another by Slow Shutter function.
AUTO / OFF
1
2
SEMIAUTO
ON
OFF
WB SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
WB MODE
- RED ADJUST
- BLUE ADJUST
BACK
EXIT
AUTO
- - -
- - -
WB SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
WB MODE
- RED ADJUST
- BLUE ADJUST
BACK
EXIT
MANUAL
1 1 7
4 0
WB SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
WB MODE
- RED ADJUST
- BLUE ADJUST
BACK
EXIT
MANUAL
1 1 7
4 0
WB SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
WB MODE
- RED ADJUST
- BLUE ADJUST
BACK
EXIT
MANUAL
1 1 7
4 0
CAMERA SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
FOCUS MODE
DIGITAL ZOOM
IMAGE FLIP
<WHITE BALANCE SETUP>
<AUTO EXPOSURE SETUP>
BACK
EXIT
>
1
2
SEMIAUTO
ON
OFF
AE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
BACKLIGHT
DAY/NIGHT
BRIGHTNESS
IRIS
SHUTTER
AGC
SSNR
SENS-UP
BACK
EXIT
OFF
AUTO1
25
<MANUAL>
<MANUAL>
NORMAL
MIDDLE
<AUTO>
5
AUTO SENS-UP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
SENS-UP LIMIT
EXIT
x2
4
MANUAL SHUTTER
- - - - - - - - - - - - - - - - - - - - - - - - - - -
SHUTTER SPD
EXIT
x2
3
MANUAL IRIS
- - - - - - - - - - - - - - - - - - - - - - - - - - -
IRIS LEVEL
EXIT
0
Press
Near/Enter
Key
Press
Near/Enter
Key
Press
Near/Enter
Key
OSD - CAMERA SETUP>WB SETUP
37
OSD - CAMERA SETUP>AE SETUP
3
36

4
3
SYSTEM SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
<DATE/TIME SETUP>
<RELAY TYPE>
<PASSWORD>
<SET HOME POSITION>
<SET NORTH DIRECTION>
LANGUAGE
<FAN/HEATER SETUP>
BACK
EXIT
SYSTEM SETUP
1
>
- Home position means the origin of pan angle calculation. The
value of pan angle displayed on the screen is based on this
home position.
- By using joystick, move the camera to the desired position and
press near key.
- Home is not effective to tilt angle.
- If you change the location of the home position, all horizontal
location of functions such as preset, scan, pattern, group and
privacy zone mask will be shifted based on the changed home
position.
Set Home Position?
When you replace the camera block or the orientation of camera is
changed due to maintenance operations, it is very difficult to maintain the
same pan orientation. Therefore, all function data depending on pan
orientation such as preset, scan, pattern, group and privacy zone mask are
not useful any more accordingly. However, even in this case, you can reuse
the data if you redefine set home position on the previous home position.
For setup, refer ‘EDIT SCENE’ on page 28.
The direction will be displayed on the right-bottom of the screen,
pan is ‘0’ and direction is ‘N’.
30°C ~ 80°C (86°F ~ 176°F)
-10°C ~ 20°C (14°F ~ 68°F)
SET HOME POSITION
5
SET NORTH DIRECTION
6
1
2
ENGLISH
5
6
DATE/TIME SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
DATE
TIME
BACK
EXIT
01/JAN/2008(TUE)
00:00:01(H/M/S)
7
FAN/HEATER SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
FAN RUN TEMP
HEATER RUN TEMP
BACK
EXIT
40 C
5 C
RELAY TYPE SETUP
- - - - - - - - - - - - - - - - - - - - - - - - - - -
RELAY1
BACK
EXIT
NORMAL OPEN
EDIT PASSWORD
- - - - - - - - - - - - - - - - - - - - - - - - - - -
[ ]
OK
CANCEL
- - - - - - - - - -
12 3 4 5 6 7 8 9 0
A B C D E F G H I J
K LMN O P Q R ST
U V WX Y Z a b c d
e f g h i j k l m n
o p q r s t u v w x
y z < > - / :.
DISABLE
SET HOME POSOTION
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO TARGET POSITION
[NEAR:SELECT/FAR:CANCEL]
0/0/x1/E
SET NORTH DIRECTION
- - - - - - - - - - - - - - - - - - - - - - - - - - -
MOVE TO TARGET POSITION
[NEAR:SELECT/FAR:CANCEL]
0/0/x1/N
[NEAR:SELECT/FAR:CANCEL]
0/0/x1/N
DATE/TIME SETUP
2
<DATE/TIME SETUP>
Moves to ‘DATE/TIME SETUP’ screen. Refer screen 2 below.
<RELAY TYPE>
Moves to ‘RELAY TYPE’ setup screen. Refer screen 3 below.
<PASSWORD>
Moves to ‘PASSWORD’ setup screen. Refer screen 4 below.
<SET HOME POSITION>
Moves to ‘SET HOME POSITION’ screen. Refer screen 5 on page 39.
<SET NORTH DIRECTION>
Moves to ‘SET NORTH DIRECTION’ screen. Refer screen 6 on page 39.
<FAN/HEATER SETUP>
Moves to ‘FAN/HEATER SETUP’ screen. Refer screen 7 on page 39.
- Contacts type of relay out are defined.
- Refer page 14 for the detailed information.
This setup is only applicable for fan/heater model.
LANGUAGE
Select a preferred language among English, Spanish, French, German,
Italian, Russian and Portuguese.
DATE
Date is displayed in dd/mm/yy format.
1. If you press the near key, the focus will be placed on ‘dd’.
2. Sets date moving joystick Up/Down.
3. Moves joystick Left/Right to move to date-month-year.
4. The values in the field are changed using Up/Down keys.
The day is automatically calculated when you set the day.
ENGLISH / ESPAÑOL / FRANÇAIS / DEUTSCH
/ ITALIANO / РУССКИЙ / PORTUGUÊS
TIME
Time is displayed in HH:MM:SS format.
Sets time same as setting date.
01 / JAN / 2000 ~ 31 / DEC / 2037
RELAY TYPE SETUP
3
RELAY1
- Sets the 4 characters long password. If this function is set to
‘ENABLE’, the password is required whenever you enter OSD
menu. The master password is ‘4321’.
To input password, refer ‘LABEL’ on page 29.
EDIT PASSWORD
4
NORMAL OPEN(N.O) / NORMAL CLOSE(N.C)
FAN/HEATER SETUP
7
Sets the fan/heater enabled/disabled according to the
temperature.
This menu will be displayed only for fan/heater model.
FAN RUN TEMP
Above this temperature, the blower fan will start automatically.
HEATER RUN TEMP
Below this temperature, the heater will be tuned on automatically.
Press
Near/Enter
Key
OSD - SYSTEM SETUP
39
OSD - SYSTEM SETUP
3
38
