Unox SpidoCook User manual

Instruction manual ENGLISH
ATTENTION:
Read the instruction before use
XP
596.042 - 596.047 - 596.052 - 596.057
596.040 - 596.045 - 596.050 - 596.055

The company reserves the right to apply improvement modications to appliances and accessories at any time without ad-
vance notice.
INTRODUCTION _____________________________________3
EXPLANATION OF PICTOGRAMS ______________________4
SAFETY REGULATIONS ______________________________5
INSTRUCTIONS FOR THE INSTALLER _____________________7
INSTRUCTIONS FOR THE USER __________________________14
english 2

INTRODUCTION
Dear Customer,
We would like to congratulate and thank you for choosing to purchase an appliance in the SpidoCook™
range by Unox; we hope this is just the beginning of a fruitful and long-lasting partnership.
As you are aware, the SpidoCook™ range of grills, are equipped with the SHB system for contact and infra-
red cooking, and ultra-rapid and uniform heating hobs.
The contact grills of the SpidoCook™ by UNOX are available in the manual and digital version with the inno-
vative SpidoTouch control.
UNOX S.p.A.
Dealer: Installer:
Installation date:
english
3
SpidoCook™

Explanation of pictograms
english 4
Danger! Situation presenting immediate danger, or a hazardous situation which could cause
injury or death.
Danger: re hazard! Tips and useful information
Danger: electric shock! Protective earth symbol
Read operator’s manual Equipotentially symbol
Danger: risk of burns Consult other chapter

Safety regulations
Safety regulations for installation and maintenance
•Read this guide carefully before installing or maintaining the appliance, and conserve this guide with
care for any future consultation of users.
•All installation, assembly and non-routine maintenance operations must be performed exclusively by
qualied technicians that are authorised by UNOX, in compliance with the regulations in force in the
user country and with respect to the regulations on systems and work safety.
• Disconnecttheovenfromitselectricalmainssuppliesbeforeinstallationormaintenance
• Checkthatsystemsarecomplianttotheinstallationcountrystandardsandtothespecicationsindicatedon
the appliance rating plate before installing the appliance.
• Interventions,alterationsormodicationsnotexpresslyauthorisedthatdonotcomplywiththeindications
in this manual shall invalidate the guarantee.
• Installationormaintenancethatfailstorespecttheindicationsinthismanualmaycausedamage,injuryor
fatal accidents.
• Givenitspotentialdanger,thepackagematerialmustbekeptoutofreachofchildrenoranimals,andprop-
erly disposed of as called for by local regulation.
• Theratingsplateprovidesessentialtechnicalinformationthatisofutmostimportanceforanyappliance
maintenance or repairs. Do not remove, damage or modify the plate.
• Failuretofollowtheseregulationsmaycausedamageor(fatal)injury,subsequentlyinvalidatingtheguaran-
tee and reliving UNOX of all liability.
Safety regulations for use
•Read this guide carefully before using the appliance or performing routine maintenance, and con-
serve this guide with care for any future consultation of users.
•Following procedures other than those indicated in this guide to use and clean the appliances is con-
sidered inappropriate and may cause damage, injury or fatal accidents; in addition to invalidating the
guarantee and relieving UNOX of all liability.
• Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswithreducedphysical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazard involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by children without supervi-
sion.
• Childrenmustbesupervisedtoensuretheydonotplaywiththeappliance.
• Thisappliancecanonlybeusedforcookingfoodinindustrialandprofessionalkitchensuponcompletionof
scheduled training courses; all other uses are not compliant to the scope of use and therefore hazardous.
In particular, the appliance can be used for:
- Cooking food on the grill;
- Grill meat, sh and vegetables;
- Toasts, Sandwiches and Focaccia.
• Monitortheapplianceduringitsentireoperationcycle.
• Iftheappliancedoesnotfunctionorifthereareanyfunctionalorstructuralalterations,disconnecttheelec-
tricity and contact an UNOX authorised customer service agent. Do not attempt to independently repair the
appliance. Request UNOX original spare parts for any repairs necessary.
english
5
SpidoCook™

 Failuretoobservetheseregulationsmaycausedamageor(fatal)injuries,andalsoinvalidatestheguarantee.
• Toensurethattheapplianceisinperfectuseandinasafecondition,maintenanceandinspectionsshould
be performed yearly by an authorised customer service agent.
• DonotusethecontactgrillsSpidoCook™ by UNOX to heat pots or pans
• Shouldnotbeplacedontheglassceramicsurfacesaluminumfoilorplasticcontainers.
Do not install the appliance near ammable materials.
• Donotusefoodscontaininghighlyammableingredients(e.g.alcohol-basedfoods).Substanceswithalow
ammability point may burst into ames and therefore constitute a re.
• Iftheapplianceisplacedonasupportstructureonwheels,makesurethatanymovementwillnotdamage-
electrical wiring or any other components.
RISK OF BURNS and INJURY!
• Payhighattentionwhilethecontactgrillisworkingasitgetsveryhot,cancausesevereskinburns.Incaseof
burns immediately cool down the burned part with cold running water and seek medical advice To prevent
accidents and to avoid damaging the appliance, all personnel should be informed as to normal safety proce-
dures and given the necessary training.
RISK OF FIRE!
• Whenusingtheapplianceforthersttime,makesureoverthecookingsurfaceofthecontactgrillSpido-
Cook™ by UNOX there are no instruction manuals, plastic bags or accessories.
• Beforetoturnonthecontactgrillforthersttime,insertthefatcollectiondrawer.Thenyouneedtoclean
the glass ceramic surfaces with a damp cloth and a mild detergent to remove grease industrial protective
which is deposited on the surface during manufacture. Once it dries, turn the power on and let the appliance
run for at least an hour at the maximum temperature. Presence of smoke and odors are considered transient
phenomena due to the degradation of industrial oils in the stainless steel parts. This phenomenon will be no
longer present for successive starting of the appliance.
• Donotplacesourcesofheat(i.e.grills,fryers,etc.),highlyammablesubstancesorfuelsinthevicin-
ityoftheappliance(i.e.gasoline,petrol,bottlesofalcohol,etc...).
• Donotusehighlyammablefoodorliquidswhilecooking(ex.alcohol).
RISK OR ELECTRICAL SHOCK
• Donotopenthecompartmentsmarkedwiththesesymbols:accessisreservedtoqualiedinstallerauthor-
ised by UNOX.
 Failuretoobservethisregulationinvalidatestheguaranteeandmaycausedamageor(fatal)injuries.
english 6

english
7
INSTRUCTIONS FOR THE INSTALLER
Contents
Trasporting and unpacking _________________________________________________________________ 8
Getting started ___________________________________________________________________________ 9
Checking package contents______________________________________________________________ 9
Removing the protective lm_____________________________________________________________ 9
Fat collection drawer positioning _________________________________________________________ 9
Positioning _____________________________________________________________________________ 10
Characteristics of the installation area_____________________________________________________ 10
Models______________________________________________________________________________ 10
Appliance distances ___________________________________________________________________ 11
Electrical connections ____________________________________________________________________ 12
Checks ______________________________________________________________________________ 13
Replacing the power supply cable________________________________________________________ 13

Before installing the appliance carefully read chapter “Safety regulations”(page5).
Duringinstallation,wearappropriateprotectiveclothing(protectivefootwear,gloves,etc.).
Trasporting and unpacking
People necessary
for installation:
Make sure that the appliance is not in danger of tip-
ping over during transportation. Check the package
on recept for any visible damage. If damage is found,
immediatly contact UNOX and DO NOT install the ap-
pliance.
The packaging materials, given their po-
tential danger, must be kept out of reach
of children and animals, and correctly
disposed of in compliance with local regulations.
UNOX has followed the NON-STOP EffOrTS phi-
losophy for years to increase the environmental com-
patibility of its products to reduce energy consump-
tion and wastes.
UNOX wishes to protect the environment and invites
the consumer to dispose of waste in recycling bins.
2
4
3
3
3
NYLON
WOOD POLYESTYRENE
CARDBOARD
english 8

Checking package contents
x1 x1
XV-XB
Instructionmanual
ENGLISH
Bedienungsanweisung
DEUTSCH
ManualInstrucciones
ESPAÑOL
Manualed'istruzione
ITALIANO
Noticed’Utilisation
FRANÇAIS
xxxxxxxxxx
xxxxxx
Beforeinstallingtheappliance,checkthatthefollowing
packaged components are present and free of damage:
- SpidoCook™ grills
- technical documents(useandinstallationmanual,
“technicalspecications”sheet);
- scraper;
- brass scourer.
Removing the protective lm
Slowly remove the protective lms from the appli-
ance: clean any glue residue with appropriate solvents
without using tools, abrasive detergents or acids that
could ruin the surfaces.
The removed lm, given its potential danger,
must be kept out of reach of children and ani-
mals; and correctly disposed of in compliance
with local regulations.
Getting started
Fat collection drawer positioning
The supplied fat collection drawer to collect the liquid
waste that is deposited on glass ceramic surfaces. The
rounded drainage channel for the liquids, owing all
around the hobs, can easily convey liquids and dirt
into the removable drawer to further facilitate the cle-
aring.Beforetouseforthesttimethegrillinsertthe-
supplied fat collection drawer in the in the front seat
as shown in the ‘image.
english
9
SpidoCook™

Positioning
Characteristics of the installation area
Max 70%
Max 35°C
Min 5°C
Install the appliance in areas:
- dedicated and conforming to the cooking of indu-
strial foods;
- having adequate air ventilation;
- that comply with the local laws and recommendations;
- protected against the weather;
- with temperatures between +5° to +35°C maximum;
- having a maximum humidity of 70%.
Do not install the appliance near other
appliances that reach high temperatures
in order to avoid damaging electrical
parts.
For additional technical information on the ap-
pliance, consult the “technical specifications”
sheet attached to the appliance.
Models
Smooth black surfaces
MODELS CONTROL
SIZE
cooking surface
(mm)
SIZE
L x P x H mm
Electric power
(kW)
Weight
(kg)
XP 010 P manual 250x250 331x458x176 1,5 10
XP 010 E digital 250x250 331x458x176 1,5 10
XP 020 manual 250x250(x2) 619x458x176 2 17
XP 020 P manual 250x250(x2) 619x458x176 3 17
XP 020 E digital 250x250(x2) 619x458x176 3 17
Black furrowed upper surfaces
MODELS CONTROL
SIZE
cooking surface
(mm)
SIZE
L x P x H mm
Electric power
(kW)
Weight
(kg)
XP 010 PR manual 250x250 331x458x176 1,5 10
XP 010 ER digital 250x250 331x458x176 1,5 10
XP 020 R manual 250x250(x2) 619x458x176 2 17
XP 020 PR manual 250x250(x2) 619x458x176 3 17
XP 020 ER digital 250x250(x2) 619x458x176 3 17
Transparent smooth surfaces
MODELS CONTROL
SIZE
cooking surface
(mm)
SIZE
L x P x H mm
Electric power
(kW)
Weight
(kg)
XP 010 PT manual 250x250 331x458x176 1,5 10
XP 010 ET digital 250x250 331x458x176 1,5 10
XP 020 T manual 250x250(x2) 619x458x176 2 17
XP 020 PT manual 250x250(x2) 619x458x176 3 17
XP 020 ET digital 250x250(x2) 619x458x176 3 17
english 10

Appliance distances
min.
5 cm
min.
5 cm
min.
5 cm
Position the appliance respecting the indicated dis-
tances in the diagram and so that the back of the oven
is easily accessible for appliance connections and main-
tenance.
Do not install the appliance near
inammableorheatsensitive
materials, walls or furniture. Otherwise,
protect them with appropriate non
inammablematerialsincompliancewithre
prevention regulations.
min.
70 cm
min.
5 cm
min.
45 cm
min.
45 cm
FLAMEPROOF
PANEL
english
11
SpidoCook™

Electrical connections
Before installing the appliance carefully read chapter“Safety regulations“(page5).
Connections to the main power and the electrical system must comply with the regulations in force in
the country of installation of the appliance; and all connections must be performed by qualied in-
staller authorised by UNOX. Failure to comply with these regulations may cause damage and injuries,
invalidates the guarantee and relieves UNOX of all liabilities.
Madeby:UNOXS.p.A.Via Majorana 22,35010Cadoneghe - Padova (ITALY)
Pht:44,2kWQn:35kWPe:8,2 kW 220-240V 1N˜220-240V 3N˜/380-415V3N˜50/60Hz 150-600 kPa
GROSSWEIGHT:235 kgNE T WEIGHT:220kg
2014
S/N
7143
INT:
0705N°705CL234
SpidoCook
TM
XP
3902067143
Made by: UNOX S.p.A. Via Majorana 22, 35010 Cadoneghe - Padova (ITALY )
Pht:44,2 kW Qn: 35 kW Pe: 8,2 kW 220-240V 1N˜220-240V 3N˜/380-415V 3N˜50/60 Hz 150-600 kPa
GROSS WEIGHT: 235 kg NET WEIGHT: 220 kg
2014
S/N
7143 MOD.
INT:
10 0705 N°705CL234
SpidoCook
TM
XP
3902067143 3902067143
3902067143
LI2293A0-Printed:06-201 2
Subjecttotechnicalchanges.
UNOXS.p.A.
ViaMajorana,22-35010-Cadoneghe (PD)-Italy
Tel.:[phone]-Fax:[phone]
[e-mail]
Madeby:UNOXS.p.A.Via Majorana 22, 35010 Cadoneghe -Padova (ITALY)
Pht:44,2kWQn:35kWPe:8,2 kW220-240V 1N˜220-240V3N˜/380-415V3N˜50/60 Hz 150-600kPa
GROSSWEIGHT:235kgNET WEIGHT:220kg
2012
S/N
7143 MOD.
INT:
100705 N°705CL234
ChefTop
TM
XVC715EG
39020671433902067143
3902067143
Beforeconnectingtheappliancetothemainselectricity,al-
ways compare the power supply data with that of the appli-
ance specied on the rating plate.
The appliance must be positioned so that the power plug is
accessible(forappliancesttedwithSchukoplugs).
The appliance has its power cable already factory mounted
to the terminal board: not undergo any other type of elec-
trical connection and no dimensional modication of the
cable other than extensions, replacing it only with one hav-
ingspecicationsequaltotheoriginalfactorycable(typeof
rubber,cross-section,etc.).
The cable must be replaced by UNOX or by its technical assistance service, and in all cases by a person
with similar qualication in order to avoid possible risks.
Madeby:UNOX S.p.A. Via Majorana 22, 35010Cadoneghe - Padova(ITALY)
Pht:44,2kW Qn: 35kW Pe: 8,2 kW 220-240V 1N˜220-240V 3N˜/380-415V 3N˜50/60Hz 150-600kPa
GROSSWEIGHT: 235 kg NET WEIGHT: 220 kg
2014
S/N
7143
INT:
0705 N°705CL234
SpidoCook
TM
XP
3902067143
The wiring diagrams, wire specications and the
technical data are indicated on the “Technical
specications ”sheet attached to the appliance.
english 12

For proper electrical connections, the appliance must:
- Bewiredintoanequipotentialsysteminaccordancewithcurrentregulations.Thisconnectionmustbeper-
formed between dierent appliances with the terminal marked with the equipotential symbol . The wire
musthaveamaximumcross-sectionof10mm2(accordingtoIECEN60335-2-42:2003-09standard)andbe
yellow-green.
- Must be grounded totheearthing(green-yellowwire).
- Must be connected to a thermal dierential switch in compliance with the regulations in force.
- Must be connected to an omnipolar circuit breaker.
Madeby: UNOX S.p.A. Via Majorana 22, 35010 Cadoneghe - Padova (ITALY)
Pht:44,2kW Qn: 35 kW Pe: 8,2 kW 220-240V 1N˜220-240V 3N˜/380-415V 3N˜50/60 Hz150-600 kPa
GROSSWEIGHT:235 kg NET WEIGHT: 220 kg
2014
S/N
7143
INT:
0705 N°705CL234
SpidoCook
TM
XP
3902067143
Checks
- The copper jumper and the electrical cable must be secured together beneath the screw in its tightening direction; and
the electrical connections must be well secured before connecting the appliance to the mains electricity.
- check for any electrical dispersion between the phases and the ground, and for electrical continuity between
the external casing and the main ground line.
- Check that the power supply voltage does not deviate from the nominal voltage value specied on the ap-
pliance rating plate when the appliance is operating.
Replacing the power supply cable
35010 Cadoneghe - Padova (ITALY)
20-240V 3N˜/380-41
,
5V 3N˜50/60 Hz 150-600 kPa
2014
4
SpidoCook
P
TM
The cable must be replaced by UNOX or by
its technical assistance service, and in all
cases by a person with similar qualication
in order to avoid possible risks.
Follow the procedures below to replace the power
supply cable:
- open the terminal board cover;
- remove the cable by disconnecting it from the ter-
minal board;
- consult the “Technical Specications” sheet (Power
supply-Connection Diagram: the sheet indicates
all possible wiring diagrams and the specications
that the new cable must have in reference to the
wiring selected (CableType) ;
- secure the new cable using the cable clamp;
- Close the terminal board cover.
english
13
SpidoCook™

Contents
General appliance operating instructions_____________________________________________________ 15
Manual control operation _________________________________________________________________ 15
SpidoTouch digital control operation ________________________________________________________ 16
Oven-usercommunication(onlyformodelswithdigitalcontrol)__________________________________ 17
Routine maintenance ____________________________________________________________________ 18
Inactivity _______________________________________________________________________________ 19
Disposal _______________________________________________________________________________ 19
After-sales assistance _____________________________________________________________________ 20
Certication ____________________________________________________________________________ 21
Guarantee _____________________________________________________________________________ 21
INSTRUCTIONS FOR THE USER
english 14

INSTRUCTIONS FOR THE USER
Before using the appliance:
- make sure that you have a system conformity and use permit certicate that is issued by a
UNOX authorised installer;
- carefully read chapter“Safety regulations“(page5.
General appliance operating instructions
• Thoroughlycleantheappliancewhenusingitforthersttime(refertothe “ Routine maintenance”section
onpage18); let it run without foodon the plate and at the maximum temperaturefor approximately1
hour in order to eliminate any unpleasant odours caused by the protective grease used in the factory.
This phenomenon will be no longer present for successive starting of the appliance.
• OperatetheSpidoCook™ byUNOXataroomtemperaturebetween+5°Ce+35°C(41e95°F).
• DonotusethecontactgrillsSpidoCook™ by UNOX to heat pots or pans.
• Shouldnotbeplacedontheglassceramicsurfacesaluminumfoilorplasticcontainers.
RISK OF BURNS and INJURY!
•Payhighattentionwhilethecontactgrillisworkingas
it gets very hot, can cause severe skin burns. In case of
burns immediately cool down the burned part with cold
running water and seek medical advice To prevent acci-
dents and to avoid damaging the appliance, all person-
nel should be informed as to normal safety procedures
and given the necessary training.
Manual control operation
C
AB
120
150
200
240
280
320
360
0
04
Control Panel:
Powerswitch(A)
Activates the unit.
Buttonlocatedoutside:contactgrillo
Buttonlocatedinside:contactgrillon
Thermostatknob(B)
Rotate clockwise the thermostat knob and
set the cooking temperature (from 120 to
140C°).
Temperaturelight(C)
Light on: Heat is on.
Light o: Set temperature reached
SpidoCook™
english
15

C
AB D3D1 D2
SpidoTouch digital control operation
Control Panel:
Powerswitch(A)
Activates the unit.
Buttonlocatedoutside:contactgrillo
Buttonlocatedinside:contactgrillon
SpidoTouch digital control(B)
Allows you to set the cooking time and tem-
perature and store up to 4 programmes.
Temperaturelight(C)
Light on: Heat is on.
Light o: Set temperature reached
Time and cooking temperature parameter setting
temperature
 (max.300°C)
Time
0 = STOP (grill OFF)
00:01....9:59 (maximum time)
INF= innite operation (plate always on)
• Setthecookingdurationbyrepeatedlypushing(slowmode)orholdingdown(fastmode)the button
untilthedesiredtimeappearsonthescreen(thevaluehasbeensavedwhentheLED(D1)stopsashing).
• The countdown starts right after having set the duration with a value other than “0”, and the plate will start
to heat until reaching the pre-set temperature of 200°C. To change this value, push the button until the
desiredtemperatureappearsonthescreen(thevaluehasbeensavedwhentheLED(D2)stopsashing).
NOTE: if you press the buttonbeforethedurationLED(D1)hasstoppedashing,theplatewillheatuntil
it reaches a temperature of approximately 200°C.
• To prematurely stop cooking, repeatedly press the button until 00:00 appears on the screen.
• Example:Ifyouwanttocookatatemperatureof220°Cfor5minutesand30seconds.
Turn on the plate with the button (A), hold down the button until 5.30 (5 minutes and 30 seconds) appears on
the screen. After a few seconds, the LED (D1) stops ashing: the cooking time has been saved, the countdown starts
and the plate starts to heat to the pre-set temperature of 200°C.
To increase the temperature, hold down the button until the temperature of 220°C appears on the screen.
After a few seconds, the LED (D2) stops ashing: the cooking temperature has been saved.
When the pilot light (C) turns o, the plate has reached the set temperature (220°C).
Program storage and use
Up to fourprogrammes(P1, P2, P3 andP4) can be saved for subsequent use.
PROGRAM STORAGE
Set the time and temperature parameters as describe previously (example 8 min. / 220°C).
To store the program press and hold the button P1, P2, P3 or P4 (ex. P3) for at least 3 seconds: the conrmation
ofrecordingtakesplacewiththelightonforonesecondoftheLEDlight(D3)andthebuzzer.
E.g.: Programme P3 = the plate will work at 220°C for 8 minutes
english 16

USING A PROGRAMME
Tostartoneoffourprogramsfromthestate“STOP”(0-grillOFF)or“INFINITY”(INF-platecontinuouslyon)
push P1, P2, P3 or P4.
Attheendoftheprogramwillberestoredtheinitialstate(STOPoINFINITY).
In case the user start a program the cooking time can be stopped press the key by taking the time to zero
or by pushing the button of the program in use.
Oven-user communication (onlyformodelswithdigitalcontrol)
The digital control panel SpidoTouch used in SpidoCook™ digital grills is designed to alert the user to possi-
ble error messages or failure.
If there is any warning or allarms push the button“P4” to slide them.
Warningmessages:
When a malfunction is detected which allows the appliance to continue operating, abeit in a limited manner,
a WARNING message is displayed. The device continues to run and the WARNING message remains on the
display until any operation button is pressed.
DISPLAY
MESSAGE Description Eect Problem solution
W01 The temperature of the applian-
cepowerP.C.B.istoohigh
The appliance continues to opera-
te but there is a risk of permanent
damage to the power P.C.
Contact the Customer Assi-
stance Service
W02 The temperature of the applian-
ce control board is too high
The appliance continues to opera-
te but there is a risk of permanent
damage to the control board
Contact the Customer Assi-
stance Service
W10 Basiccontrolboardsettingerror
The appliance keeps on working
(withsomelimitationsduetothe
settinginvolvedontheerror)
Contact the Customer Assi-
stance Service
Allarm messages:
When a condition arises which prevents the appliance from operating at all, an ALARM signal is displayed and
the appliance must be switched to its STOP status. The device stops operating and the ALARM message appe-
ars on the oven display until the problem is resolved. If the device is operating when the ALARM status occurs,
itwill shut down and the alert corresponding to the detected problem will be displayed. To resolve a problem
of this type, contact an Authorised Assistance Centre. Once the problem has been resolved, the appliance can
be reactivated by pressing the «START» button.
DISPLAY
MESSAGE Description Eect Problem solution
A01 Temperature probe alarm Appliance shutdown Contact the Customer Assi-
stance Service
A03
The control board is no longer
communicating with the power
board
Appliance shutdown Contact the Customer Assi-
stance Service
Maintenance in case of failure:
In case of failure, in case of failure, failure of the ceramic surface or in case of occurrence of cracks,
immediately disconnect the unit from the mains and call a service center for replacement of glass.
SpidoCook™
english
17

Routine maintenance
Any routine maintenance procedure must be performed:
- after disconnecting the appliance from the power supplies;
-afterhavingputontheproperpersonalprotectionequipment(i.e.gloves,etc...).
Clean the grill daily to maintain proper levels of hygiene.
When cleaning any component or accessory NEVERuse:
- abrasive or powder detergents;
- aggressiveor corrosivedetergents(i.e.hydrochloric/muriaticorsulphuric acid).Caution!Neverusethese
substances also when cleaning the appliance substructure and oors;
- abrasiveorsharptools(i.e.abrasivesponges,scrapers,steelbristledbrushes,etc...);
- water sprays.
External steel structures/drawing :
Waitforthesurfacestocoolo.
Use only a soft cleaning cloth dampened with a little
soap and water. Rinse and dry completely.
As an alternative, only use detergents recommended
by UNOX; other products may cause damage thereby
invalidating the guarantee. Read the instructions pro-
vided by the detergent producer for their use.
Glass ceramic contact grills:
The glass ceramic contact grills, even if very hot don’t give the feeling of the actual heat, the-
refor, before cleaning them o, make sure they have completely cooled.
Use only a soft cleaning cloth dampened with a little soap and water. Rinse and dry completely.
Donot useacids,solventsand /orammonia (alcohol,benzine,thinner,etc..)thatcouldself-ignitionwhen
thrown on the grill when it is not completely cooled.
For the cleaning of the appliance do not use any tools that might damage the glass ceramic, it is necessary to
use the scraper with rounded edges of the blade that came with the grill.
Use the scraper with caution and make sure the blade contact the plates very good. Do not use the edge of
the scraperas this may cause scratches on the plate that would compromise the overall appearance and cle-
anability.
Substitute the blade of the scraper whenever when it is no longer perfectly sharp.
After using the scraper cover the blade with the special protection and do not leave the scraper unattended
within the reach of children.
Collection of cooking waste:
The cooking residues are channeled through the hole in the gutter directly in the dripping tray under the con-
tact grill. Therefore proceed to empty the tray regularly to prevent internal overows.
english 18

Disposal
In pursuit of article (No.). 13 of law 25 July 2005, No. 151“Implementation of the Directives 2002/95/EC,
2002/96/ECand2003/108/EC.
The product must undergo separate collection processes and cannot be disposed of as general waste
when reaching end of life; keep in mind that illegal or incorrect product disposal incurs penalties as
put forth by the current laws in force.
Allappliancesaremadewithrecyclablemetals(stainlesssteel,iron,aluminium,galvanizedsteel,cop-
per,etc..)formorethan90%ofoverallweight:disposaloftheproductattheendofitslifemustbe
performed by electronic and electrical waste recycling centres, or the appliance must be returned to the dealer
when buying a new equivalent product, on a one to one basis.
Render the appliance for disposal useless by removing the power cable and any compartment or cavity closure
latch(wherepresent)toavoidpossibleentrapmentofpersons.
Contact the local waste disposal centre for additional information.
Inactivity
Follow the precautions below during inactivity:
- disconnect the power supplies to the appliance;
- we recommend rubbing a soft cloth lightly doused with mineral oil on all stainless steel surfaces.
At rst reuse:
- cleantheapplianceanditsaccessoriesthoroughly(seechapter “ Routine maintenance”atpage18);
- restore the power supplies to the appliance;
- inspect the appliance before using it;
- switch on the appliance at minimum temperature for 50 minutes without any food on the grill.
It is best to have an authorised customer assistance service perform maintenance and in-
spection on the appliance at least once a year to ensure top working and safety condi-
tions.
SpidoCook™
english
19

After-sales assistance
In case of any malfunctions, disconnect the appliance from its power and contact a UNOX authorised technical
customer service. Provide the following information:
- the date of purchase;
- the appliance data on the serial plate.
Madeby:UNOXS.p.A.Via Majorana 22,35010Cadoneghe - Padova (ITALY)
Pht:44,2kWQn:35kWPe:8,2 kW 220-240V 1N˜220-240V 3N˜/380-415V3N˜50/60Hz 150-600 kPa
GROSSWEIGHT:235 kgNE T WEIGHT:220kg
2014
S/N
7143
INT:
0705N°705CL234
SpidoCook
TM
XP
3902067143
Made by: UNOX S.p.A. Via Majorana 22, 35010 Cadoneghe - Padova (ITALY )
Pht:44,2 kW Qn: 35 kW Pe: 8,2 kW 220-240V 1N˜220-240V 3N˜/380-415V 3N˜50/60 Hz 150-600 kPa
GROSS WEIGHT: 235 kg NET WEIGHT: 220 kg
2014
S/N
7143 MOD.
INT:
10 0705 N°705CL234
SpidoCook
TM
XP
3902067143 3902067143
3902067143
LI2293A0-Printed:06-201 2
Subjecttotechnicalchanges.
UNOXS.p.A.
ViaMajorana,22-35010-Cadoneghe (PD)-Italy
Tel.:[phone]-Fax:[phone]
[e-mail]
Madeby:UNOXS.p.A.Via Majorana 22, 35010 Cadoneghe -Padova (ITALY)
Pht:44,2kWQn:35kWPe:8,2 kW220-240V 1N˜220-240V3N˜/380-415V3N˜50/60 Hz 150-600kPa
GROSSWEIGHT:235kgNET WEIGHT:220kg
2012
S/N
7143 MOD.
INT:
100705 N°705CL234
ChefTop
TM
XVC715EG
39020671433902067143
3902067143
Manufacturer’s information:
UNOX S.p.A.
Via Majorana, 22
 35010Cadoneghe(PD)Italy
 Tel+3904986.57.511-Fax+3904986.57.555
[email protected] www.unox.com
english 20
