UNV IPC340 Series User manual

Network Fixed Dome Cameras
Quick Guide
Manual Version: V1.01

Thank you for purchasing our product. If there are any questions,
or requests, please do not hesitate to contact the dealer.
Copyright
Copyright 2015 Zhejiang Uniview Technologies Co., Ltd. All rights
reserved. No part of this manual may be copied, reproduced,
translated, or distributed in any form or by any means without
prior consent in writing from our company.
Trademark Acknowledgement
and other Uniview’s trademarks and logos are the
property of Zhejiang Uniview Technologies Co., Ltd. Other
trademarks, company names and product names contained in this
manual are the property of their respective owners.

Disclaimer
The default password is used for your first login. To ensure
account security, please change the password after your first
login. You are recommended to set a strong password (no
less than eight characters).
To the maximum extent permitted by applicable law, the
product described, with its hardware, software, firmware
and documents, is provided on an "as is" basis.
Best effort has been made to verify the integrity and
correctness of the contents in this manual, but no statement,
information, or recommendation in this manual shall
constitute formal guarantee of any kind, expressed or
implied. We shall not be held responsible for any technical or
typographical errors in this manual. The contents of this
manual are subject to change without prior notice. Update
will be added to the new version of this manual.
Use of this manual and product and the subsequent result
shall be entirely on your own responsibility. In no event shall
we be reliable to you for any special, consequential,
incidental, or indirect damages, including, among others,
damages for loss of business profits, business interruption,
or loss of data or documentation, or product malfunction or

information leakage caused by cyber attack, hacking or virus
in connection with the use of this product.
Video and audio surveillance can be regulated by laws that
vary from country to country. Check the law in your local
region before using this product for surveillance purposes.
We shall not be held responsible for any consequences
resulting from illegal operations of the device.
The illustrations in this manual are for reference only and
may vary depending on the version or model. As a result,
some of the examples and functions featured may differ
from those displayed on your monitor.
This manual is a guide for multiple product models and so it
is not intended for any specific product.
Due to uncertainties such as physical environment,
discrepancy may exist between the actual values and
reference values provided in this manual. The ultimate right
to interpretation resides in our company.
Environmental Protection
This product has been designed to comply with the requirements
on environmental protection. For the proper storage, use and
disposal of this product, national laws and regulations must be
observed.

Safety and Compliance Information
Safety Symbols
The symbols in the following table may be found on
installation-related equipment. Be aware of the situations
indicated and take necessary safety precautions during
equipment installation and maintenance.
Symbol
Description
Generic alarm symbol: To suggest a general safety
concern.
ESD protection symbol: To suggest
electrostatic-sensitive equipment.
Electric shock symbol: To suggest a danger of high
voltage.
The symbols in the following table may be found in this manual.
Carefully follow the instructions indicated by the symbols to avoid
hazardous situations and use the product properly.
Symbol
Description
WARNING! Indicates a hazardous situation which, if
not avoided, could result in bodily injury or death.
CAUTION! Indicates a situation which, if not
avoided, could result in damage, data loss or

Symbol
Description
malfunction to product.
NOTE! Indicates useful or supplemental information
about the use of product.
Safety Information
Installation and removal of the unit and its accessories must be
carried out by qualified personnel. Please read all of the safety
instructions below before installation and operation.
Installation
This device is a class A product and may cause radio
interference. Take measures if necessary.
If the product does not work properly, please contact your
dealer. Never attempt to disassemble the camera yourself.
(We shall not assume any responsibility for problems caused
by unauthorized repair or maintenance).
Avoid squashing, shaking, or damping the camera during
transport, storage, and mounting. Keep the camera from
vibration sources during mounting.
Please make sure that the ceiling can support more than
50(N) Newton gravities if the camera is fixed to the ceiling.

Make sure the power supply voltage is correct before using
the camera. Use a proper power adapter or a PoE power
supply device. An improper power adapter may damage your
camera.
Disconnect the power before moving the camera, and take
cautions to avoid electric shock when moving it. Once the
cable is connected to the mains, the camera will be
powered.
During mounting, do not remove the protective film in the
outer layer of housing to keep it clean. After finishing the
mounting, remove the film when camera is powered off.
Verify that the length of the power cable between the power
adapter and the camera does not exceed 1.5 m. If the power
cable is longer than 1.5 m, the voltage of the camera is
lowered, causing the camera to work improperly. If it is
required to lengthen the power cable, lengthen the cable
between the power adapter and the mains.
Do not hold the tail cable by hand for weight bearing.
Otherwise, the cable connector of the camera could be
loosened.
Do not cut off the tail cable for connection purposes. A bare
tail cable may easily cause a short circuit, resulting in
abnormality of or damage to the camera.

Use the waterproof tapes to protect the end of tail cable,
and keep the tail cable from water.
When connecting to an external interface, use an existing
connection terminal, and ensure that the cable terminal
(latch or buckle) is in good condition and properly fastened.
Ensure that the cable is not tense during mounting, with a
proper margin reserved to avoid poor port contact or
loosening caused by shock or shake.
Ensure that the high-level signal of the alarm input is not
higher than 5 VDC when the alarm input interface is
connected.
As is often the case in the industry, dome housings tend to
have static electricity. To prevent dust absorption by the
static electricity, it is recommended to clean the dome
housing surface with antistatic gloves after removing the
protective film.
Do not touch sensor modules with fingers. If cleaning is
necessary, use a clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period
of time, put on the lens cap to protect the sensor from dirt.
Do not aim the camera lens at the strong light such as sun or
incandescent lamp. The strong light can cause fatal damage
to the camera.

The sensor may be burned out by a laser beam, so when any
laser equipment is being used, make sure that the surface of
the sensor not be exposed to the laser beam.
Maintenance
If there is dust on the lens or the transparent dome cover,
remove the dust gently using an oil-free brush or a rubber
dust blowing ball.
If there is grease on the lens, remove the grease using an
oil-free cloth gently and then clean the lens in a circular
spiral from the center outward using an oil-free cloth or a
lens cleaning paper dipped with small amount of cleaning
solution. If the grease still cannot be removed, change
another oil-free cloth or lens cleaning paper and clean the
lens gently until it is removed.
If there is grease or a dust stain on the transparent dome
cover, clean the cover gently from the center outward using
anti-static gloves or an oil-free cloth. If the grease or the
stain still cannot be removed, use anti-static gloves or an
oil-free cloth dipped with detergent and clean the dome
cover gently until it is removed.
Do not use organic solvents, such as benzene or ethanol
when cleaning the transparent dome cover.

Never look at the transmit laser while the power is on.
Never look directly at the fiber ports and the fiber
cable ends when they are powered on.
Use of controls or adjustments to the performance or
procedures other than those specified herein may
result in hazardous laser emissions.
Regulatory Compliance
FCC Part 15
This equipment has been tested and found to comply with the
limits for digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the
interference at his own expense.
This product complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
LVD/EMC Directive
This product complies with the European Low Voltage Directive
2006/95/EC and EMC Directive 2004/108/EC.

WEEE Directive–2002/96/EC
The product this manual refers to is covered by the Waste
Electrical & Electronic Equipment (WEEE) Directive and must be
disposed of in a responsible manner.

i
Contents
1 Appearance ........................................................................... 1
Dimensions and Appearance ................................................... 1
Cable Connection..................................................................... 2
Camera Structure..................................................................... 4
2 Installation ............................................................................ 5
Hardware Installation .............................................................. 6
Insert the Micro SD Card (Optional).................................... 6
Mount your Camera............................................................ 9
Start the Camera............................................................... 37
Reset the Camera to Default Settings............................... 37
Waterproof Measures............................................................ 38
Waterproof Components for an RJ45 Plug ....................... 38
Waterproof Tail Cable....................................................... 41

ii
3 Set Your Camera over the LAN..............................................43
4 Access Your Camera..............................................................45
System Requirements for Your PC ......................................... 45
Access Your Camera............................................................... 46
Install the ActiveX .................................................................. 47
Adjust the Display .................................................................. 48

1
1 Appearance
Dimensions and Appearance
The following takes the infrared camera as an example. The actual
appearance may vary with the product. For the detailed
information about the product, please refer to the datasheet.
50 mm
105 mm
R 50 mm
Φ149 mm
(5.9”)
(4.1”)
(2.0”)
(2.0”)
Do not remove this shield ring
as the ring is used to reduce
the interference caused by
infrared entering the lens.

2
Cable Connection
All the cables are tagged to indicate their functions. This section
takes full cable as an example. You can connect cables by referring
to the following figure.
1: Local video output interface (outputting composite video
signals), BNC connector
2: RS485 serial port
3: Audio input
4: Audio output
5: Alarm input
6: Alarm output
7: Power interface. The white cable is used to ground the camera.
Display
device
Third-party
device connected
through RS485
interface
Audio input
(Sound pickup)
Audio output
(Outdoor sound
box)
Alarm input
(Voice
activated
switch)
Alarm
output
(Alarm
indicator) Power
adapter
1
234567
8
Network
access device
connected
through
copper
interface

3
Note:
The power interface can serve as a 12 VDC power input interface,
or serve as a power output interface to support the charging
function (see datasheet).
8: 10M/100M Base-TX adaptive Ethernet interface, RJ45
For the latest specifications, see the product datasheets.

4
Camera Structure
The camera structure may vary with your product.
Figure 1 Camera Structure
1: Front cover (containing a transparent dome bubble)
2: Lining
3: Darkening ring
4: Focusing knob (supported by manual-focusing cameras)
1
2
3
4
5
6
7
8
9

5
5: Zooming knob (supported by manual-focusing cameras)
6: Micro SD card slot
7: System status indicator
Note:
The indicator has the following states: If the indicator is yellow,
the system is being started; if green, the system has been started;
if red, a device alarm is generated.
8: Infrared lamp (supported only by infrared cameras)
9: Reset button
Note:
Press and hold the Reset button for about 15 seconds to restore
factory default settings. The reset button only works within ten
minutes after the device is powered on. Some model may not
support this function, please refer to the actual internal structure.
2 Installation
There are two types of cameras (metal type and plastic
type). The following mounting steps are for your reference
only. Please install your camera according to the actual
product and field conditions.

6
Hardware Installation
Insert the Micro SD Card (Optional)
The Micro SD card slot is inside the camera. Therefore, you need
to open the bottom cover of the camera. Do not hot plug the
Micro SD card after it is inserted. Otherwise the camera or the SD
card might be damaged.
For details about recommended SD card specifications,
contact your dealer.
Metal Camera
1. Remove the dome bubble
Remove the three socket fillister-head screws along the edge
of the transparent dome bubble.
Socket
fillister-head
screw
