US COOKING EQUIPMENT USCBLR-24 User manual

Gas Countertop Char Broilers with
Lava Rocks
Operating Instructions
Before you begin, please read these instructions carefully to use this
product correctly, to make the product perform ideally, and to avoid hazards.
Models: USCBLR-24 / USCBLR-36 / USCBLR-48

- 1 -
Dear customers and users：
Thank you for purchasing our product! In order to get the most out of this product,
please read these instructions carefully before operation. Follow the guide, to avoid
damage or injury.
Please keep this instruction manual for convenient reference and operation.
This instruction manual is subject to any change without further notice, and the
manufacturer reserves the right of final interpretation.
The appliance is designed for commercial purposes, not for household use.
A statement instructing the purchaser to post in a prominent location
instructions to be followed in the event the user smells gas. This information shall be
obtained by consulting the local gas supplier.

- 2 -
Gas Countertop Char Broilers with Lava Rocks
The Installation, Operation and Maintenance Guide
Contents
Safety Protection ……………………………………………………3
Brief Introduction……………………………………………………3
Manufacturer's Authority and Responsibility …………………3
Parameter Specifications……………………………………………4-6
Transport and Storage ………………………………………………7
Installation and Debugging…………………………………………7-8
Safety Notices and Precautions……………………………………10
Operating Instructions………………………………………………11-13
Cleaning and Maintenance……………………………………………14-15
Troubleshooting ……………………………………………………16
Spare Parts……………………………………………………………17-20
Accessories List……………………………………………………21

- 3 -
Safety Protection
Ensure that the operator is an authorized and licensed technician before you allow
him/her to install and operate the product. Be sure to strictly follow this instruction
guide during installation and use. The manufacturer is not responsible for any danger
or accidents caused by improper operation or maintenance.
Do not store flammable or explosive objects around the product. Keep all
flammable and explosive objects at a safe distance away from the product for normal
use.
Place the product in a reasonable position. Regarding related matters of gas,
customer should execute the requirements of local gas supply sector;
If you smell a gas leak, turn off the gas valves immediately and call the gas
company;
The product should only be operated by experienced persons over the age of 18, in
good mental and physical health.
Brief Instruction
This product is a series of gas char broilers in our company production. Which is
quality designed, reasonably structured, conveniently operated, durable, and
conveniently maintained. Equipped with a high efficiency stainless steel tubular burner
and pilot light, convenient to ignite the main fire burner. This is hotel, supermarket,
western restaurant, and food industry's ideal barbecue product equipment.
Manufacture’s Authority and Responsibility
Banning of all or partial transformation to the products without the manufacturer's
explicit authorization. Manufacturers refuse to undertake responsibility to third
parties as the following reasons:
Not following this instruction guidance and warning in using and testing;
Not in accordance with the requirements of technical parameters using this
product;
Incorrectly or irrationally using the product by untrained personnel;
Not obeying the local law using this product;
Repairs or changes made by unauthorized technicians;
Use the spare parts or accessories provided by non-manufacturers;
Accidents caused by force;
Not strictly complying with related guide of instruction by any reason.

- 4 -
Parameter Specifications
Outline Dimensions(in)*
USCBLR-24
USCBLR-36

- 5 -
USCBLR-48

- 6 -
Information of Gas Supply and Burner
The minimum supplied gas pressure regulator is factory set at 4”Natural Gas
W.C, and 10”L.P. Gas W.C. The external thread of product’s intake-tube is 3/4 inches.
Table 1
Model
#of burners
and control
method
Gas
Species
Intake-tube
pressure
（in W.C.）
Per BTU
B.T.U./h
Total BTU
B.T.U./h
Nozzle
No.
USCBLR-
24
2 pieces
Independent
control
Natural
Gas
4
35,000
70,000
#36
L.P.
Gas
10
35,000
70,000
#50
USCBLR-
36
3 pieces
Independent
control
Natural
Gas
4
35,000
105,000
#36
L.P.
Gas
10
35,000
105,000
#50
USCBLR-
48
4 pieces
Independent
control
Natural
Gas
4
35,000
140,000
#36
L.P.
Gas
10
35,000
140,000
#50

- 7 -
Transport and Storage
During transportation, handle carefully and keep upright to prevent damage of the
product packing. Wrapped equipment should not be in open air for a long time, and shall
be placed in a well-ventilated and non-corrosive gases warehouse. When equipment
needs temporary storage, rainproof measures should be taken.
Installation and Debugging
Any erroneous installation, adjustment, refit, overhaul or maintenance may cause
property damage or personal injury. The work shall be performed by authorized and
licensed technicians, otherwise the manufacturer has the right to void warranty
service;
Must be installed in accordance with the local code. If no similar standard, you
should conform to the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the National Gas
Installation Code, CSA-B149.1, or the L.P. Gas Installation Code, CSA-B149.2 as
applicable;
The appliance individual shutoff valve must be disconnected from the gas supply
piping system during any pressure testing of that system at test pressures in excess of
1/2psi (3.45kPa).
Unpacking and Installation
Please dispose of all packaging materials and residues after unpacking;
Check the equipment. If it is damaged, please keep wrappers and receipts which
must be signed by the carrier representative (Driver), and contact the carriers to pursue
a claim within 15 days after receiving;
Check all accessories complete. Refer to table 5;
Be sure to install supporting legs before using, and do not damage any label or logo
before use;
Please read these instructions carefully before installation and operation. Please
contact your local agent if you have any questions;
The char broiler shall be installed on a level, solid, non-skid and incombustible
surface, and placed in a well-lit waterproof work area, and away from children and
customers;
The installation position is a well-ventilated place in accordance with the local
regulations;
The char broiler must be installed under the matched cooking fume exhauster according to
the local regulations;

- 8 -
Important: Installation and ventilation laws, and codes are very different, you
should state and comply with all codes of the National Fire Protection Association Inc
when it comes to requirements for installation of equipment;
Screw 4 adjustable stainless steel legs in the tapping hole with four corners of the
char broiler bottom, ensure sufficient space for ventilation;
Adjustable stainless steel legs to make the equipment
level, and get the same level with other series of the same
stove; Please lift the equipment rather than drag if needs
moved;
Take away grate (Fig.12-18), take out bottom support,
ensure fire shield （Fig12-20,21) under the bottom frame
(Fig.12-17) without moving. Then symmetrically put Lava
Rocks (requirement: its diameter is about 3-5cm) on the
bottom frame(Fig.1), replace grate and check the support; Fig.1
Supplied gas pressure regulator is factory set at 4”Natural Gas W.C, and 10”L.P. Gas
W.C;
The equipment can only be placed on the incombustible counter top, and keep a
distance of at least 6 inches(152mm) to equipment’s both sides and back, and distance
of at least 4 inches(102mm) to the bottom;
Do not put anything around the equipment, or on the counter top and bottom, in
order to avoid influencing combustion and air circulation;
Leave enough distance in front of the equipment to take apart the control panel. All
major parts, in addition to the burner remove from the front intake-tube;
It may be necessary to adjust the balance of air input by authorized and licensed
technicians;
Thread glue must be resistant to the action of liquefied petroleum gases.
Warning! Use soap water or testing instrument to test whether piping joint leaks
before use, and forbid using an open flame to test!
After installing completely, check gas supply pressure. Use a pressure gauge which is
equipped with liquid (such as U-type pressure gauge, the minimum value is 0.1mbar) or
a digital pressure gauge to test.

- 9 -
Steps are as follows:
●Remove top panel, and needle type pressure
joint screw arbor (Fig.2), then slip rubber tube
of pressure gauge over needle type pressure
joint;
●Start the equipment in accordance with the
instructions, measuring gas supply pressure
(dynamic pressure) in the work state;
●Access to the equipment if measured data
within the limits of Table 1, otherwise, you will
need to adjust gas pressure regulating valve or
contact gas supplier to bargain; Fig.2
●Unplug pressure gauge after you accomplish pressure testing, then install needle
type pressure joint screw arbor. Important: make sure to screw the needle
valve to prevent gas escape!
Debugging
It’s very important to debug the new stove. Through the comprehensive system test
of equipment, we can ensure function and safety performance of products. Discovering
any potential problems before use (such as equipment’s placement, ventilation,
operation, etc.), can avoid costly losses.

- 10 -
Safety Notices and Precautions
Warning! For your safety, do not place petrol and other flammables nearby. Please
keep clean and free of flammables surroundings. (Read ANSI Z83.14B, 1991 for
reference)
Warning! Any erroneous installation, adjustment and refit may cause property
damage or personal injury and maintenance failure. Read the instructions carefully
before installation and using.
Warning! Operation instruction must be placed in a conspicuous location. When
customers smell gas in the process of using, should take safety precautions
immediately. Immediately turn off the main gas valve, extinguish all heat and flames,
and call 911. Safety information can be obtained from your local gas suppliers.
When using this equipment, safety precautions should always be followed,
including the following:
The char broilers burners, grates and outside surfaces may become hot after use, so
you must be careful to touch;
During operation, do not directly touch burners and grates;
Turn off the equipment when repairing, maintaining and cleaning;
If the equipment has any signs of equipment damage, gas piping leaks, igniter or
valves damage, or lose product accessories, do not operate, and call for the service
immediately;
The use of attachments not recommended or sold by the manufacturer may cause
fire, personal injury or even death;
Do not use outdoors;
The equipment is used for barbecue, not available for any other use;
The equipment does not contain any user-serviceable parts. Dealers or technicians
will repair it. Do not take apart any spare parts without authorization;
Never change any other parts without authorization to this equipment, otherwise,
may cause hazards. Manufacturer has the right to void warranty service;
Steel cutting producers used to manufacture with sharp edges. The manufacturer
has dealt with these sharp edges during production, however, we insist the operator take
care when in contact with this piece of equipment;
Always keep hands, hair and clothing away from heating source.

- 11 -
Operating Instructions
Before operating, make sure to place the unit horizontally by adjusting bottom
adjustable legs, and place the catch tray properly.
The pilot light has been set at the factory. Each burner has a pilot light.
Lighting the pilot light
Turn the control valve at the position of “0” (Fig.3), make sure all knobs are in the
close state. Light and hold an ignition source at the pilots. The pilot light may not light
immediately, for existing gas in the pipe. Wait a minute, the pilot light will light after the
gas has extinguished.
Tips: You can use a screwdriver to adjust the height of the flame (Fig.4).
Igniting the main burner
Turn the main fire control valve knob counter clockwise after lighting the pilot light,
and then the main fire burner is lit by the pilot light. The power of the burner increases
as angle increases. When knob reaches to " ", burner is at maximum power (Fig.5).
Fig.3 Fig.4 Fig.5
Make sure there is air circulation at the bottom of equipment;
Do not use fan or air-conditioning blowing toward the flame, in order to avoid
extinguishing flame and causing safety accidents;
Install the matched cooking fume exhauster according to the local regulations over
the char broiler;
Make sure to keep the natural circulation in the kitchen.

- 12 -
Turn off the valve
Turn the control valve knob clockwise to "0" (Fig.3), to extinguish flame of the main
burner, but the pilot light still works.
After turn off the equipment, the main fire should be out more than 5 minutes
before next use.
Stove Operation
Before using the stove for the first time, please use a mild detergent to wipe clean.
Do not use corrosive or abrasive detergents.
Turn the burners on about 15-20 minutes before broiling for preheating, according
to the cooking requirement to adjust the flame size.
Notice: When first preheating, the furnace will smoke above. This is caused by
protective lipids on the grates and other parts are heated, it is normal, and it will be
eliminated after it is at maximum power for an hour.
One side of grate with grease trough (Fig.6), and on the other side of grate is flat
(Fig.7), users can choose a side according to demand. Users also can adjust grate’s slope
according to demand (Fig.8). The side of grate with grease trough up if roasting food
with more oil, the oil will drop into grease trough, then flow to catch tray.
Fig.6 Fig.7 Fig.8

- 13 -
Exchange main fire nozzle to switch gas source
Remove control panel, grate, vesuvianite, the barbecue frame and fire shield,
remove the pilot light head, and bottom tightening screw of the end of burner (arc), then
remove main fire nozzle with proper open spanner, exchange nozzle of another gas
source, then screw it (Fig.9). Reinstall burner, the pilot light head, fire shield, the
barbecue frame, vesuvianite, grate and control panel in proper place.
Caution: Each main fire orifice of the burner has been installed before delivery,
normal use without adjustment but only switching gas. Adjust only by authorized and
licensed technicians. When you converse the gas source, exchange the corresponding
pressure maintaining valve which installed on air intake. See 2 in P19.
Adjust air input
Remove control panel, unscrew damper solid screw (Fig.10), revolve damper left to
right (Fig.11), meanwhile, observe flame and adjust an appropriate opening degree.
Then screw damper solid screw, make sure the equipment will not get loose in the
process of moving and translation. Reinstall control panel.
Caution: Each burner damper has been adjusted before delivery (once air input),
normal use without adjustment but only switching gas. Adjust only by authorized and
licensed technicians.
Fig.9 Fig.10 Fig.11

- 14 -
Cleaning and Maintenance
Do not use any abrasive or flammable detergent to wipe;
Do not hose down, immerse or pressure wash any part of the char broiler,
excluding the catch tray;
Do not use abrasive cleaning matters to wash, even not use corrosive detergent!
Warning: Before cleaning, all control valves must be turned off. Strictly follow the
lighting instructions to work again after cleaning!
Warning: Wait for the equipment to cool down after the unit has been turned off
before you clean!
Cut off the gas source as not in using;
If the equipment is not used for a long time, clean the surface by wiping it with a
soft cloth and place it in a well-ventilated area;
Comprehensively check the equipment at least once every year by authorized and
licensed technicians;
The product is made of 90% metals, and cannot be discarded everywhere. Deal
with it in accordance with the local codes.
Instructions to clean appliance regularly with recommended cleaning agents, if
necessary

- 15 -
Recommended cleaning methods:
Table 2
Items
Methods
Times
Body
Wipe it with a soft cloth and mild detergent;
daily
Control panel
Turn off valves when not in use;
Wipe panel and control valve knob with mild
detergent.
daily
Grates
Caution: Wear insulated gloves when handling
grates, in order to prevent possible burns!
1.Take out grates;
2.Clean up grease and other impurity on grates with
a wire brush;
3.Clean grid slot with a scraper;
4. Spread cooking oil on the grates, open char
broiler to evaporate for 45 minutes, then close it.
Warning: Do not cover grates in the process of
evaporation!
Daily/as need
Char Grate
Back
Support
Brace
Remove grate until the equipment cools down. Take
off char grate back support brace, clean grease and
other crumbs. Spread cooking oil. Reinstall after
cleaning.
Daily/as need
Catch tray
Pull out catch tray from front body until the
equipment cools down. Clean grease and other
crumbs. Reinstall after cleaning and spread cooking
oil.
Warning: if the catch tray is permitted to fill too
high, should be cleaned!
Per use

- 16 -
Troubleshooting
Table 3
Problems
Possible causes
Problem solving
Not lighting
1.Insufficient gas pressure
in pipe
1.Contact the local gas
supply dept.
2.Nozzle occlusion
2.Dredge nozzle
Ignite the pilot light
but not the main fire
1.Insufficient gas pressure
in pipe
1.Contact the local gas
supply dept.
2.The main fire nozzle
occlusion
2.Dredge nozzle
3.Gas control valves have
problems
3.Change gas control
valves
4.The pilot light and the main
fire’s distance is too far
4.Adjust the distance
of them
5.Flame is too low
5.Adjust the height of
the pilot light
Close gas and heard
a sound of fire
1.Insufficient gas pressure
in pipe
1.Contact the local gas
supply dept.
2.Not match nozzle aperture
with gas resources
2.Adjust nozzle
diameter
3.Flow of connection pipe
is not enough
3.Increase pipe’s allowable
flow
4.Damper opening degree
is too large
4.Adjust damper
Yellow flame and
black smoke
1.Use bottom gas
1.Change gas
2.Not match nozzle aperture
with gas resources
2.Adjust nozzle
diameter
3.Not enough air to ignite
3.Increase damper
opening degree
4.In the peak of using gas,
sources of gas float heavy
4. Turn down valves
flow. Turn it up after
the peak
The problems mentioned above are only for reference. If any fault occurs, please stop
using, and contact technicians to check and repair. Safety first turn off the power, and gas
supply before maintenance.

- 17 -
Spare Parts
The use of parts provided by other companies, our company has the right to void
warranty service;
Order replacement parts from authorized representatives and after-sale service
agency.
Provide the model number, serial number, and description when ordering
components.
Fig.12

- 18 -
Table 4
No.
Matters Code
Component
name
Qty
Dimensions
(mm)/Model
Remark
1
301110001
Adjustable steel
legs
4
φ41.5*100
USCBLR-24\36\48
2
21105001001
Catch tray
1
507*620*26.5
USCBLR-24
21105002001
807*620*26.5
USCBLR-36
21105003001
1117*620*26.5
USCBLR-48
3
301080002
Galvanized flange
face nut
6
M6
USCBLR-24
9
USCBLR-36
11
USCBLR-48
4
301082001
Galvanized flat
grommet
4
φ6*φ10
USCBLR-24
6
USCBLR-36
7
USCBLR-48
5
301081006
Galvanized
American outside
six corner with
pad tapping
4
ST4.8*12.5
USCBLR-24\36\48
6
21105001002
Control panel
1
605*185
USCBLR-24
21105002002
905*185
USCBLR-36
21105002002
1215*185
USCBLR-48
7
301140001
Kirsite knob
2
USCBLR-24
3
USCBLR-36
4
USCBLR-48
8
301060001
Needle type
pressure joint
1
1/8"-27NPT
USCBLR-24\36\48
9
301060002
Needle type
pressure joint
screw arbor
1
M5*23
USCBLR-24\36\48
10
301030002
A18 stopcock
2
A18-318
USCBLR-24
3
USCBLR-36
4
USCBLR-48

- 19 -
11
301040006(NG)
301040007(LP)
A18 nozzle (NG)
A18 nozzle(LP)
2
NG36
LP50
USCBLR-24
3
USCBLR-36
4
USCBLR-48
12
301030001
Pilot light
valve-single unit
2
AP7-1
USCBLR-24
3
USCBLR-36
4
USCBLR-48
13
301070013
Air input pipe
2
USCBLR-24
3
USCBLR-36
4
USCBLR-48
14
301170015
Pilot light head
stator
2
USCBLR-24
3
USCBLR-36
4
USCBLR-48
15
301060003
Pilot light head
2
A73007/TiPφ4.7
USCBLR-24
3
USCBLR-36
4
USCBLR-48
16
21205001001
Countertop
1
610*700*218
USCBLR-24
21205002001
910*700*218
USCBLR-36
21205003001
1220*700*218
USCBLR-48
17
301020002
Bottom frame
4
ATOSA-0005
USCBLR-24
6
USCBLR-36
8
USCBLR-48
18
301020003
Grates
4
150*525*22
USCBLR-24
6
USCBLR-36
8
USCBLR-48
19
21205001003
Char grate back
support brace
1
L=600
USCBLR-24
21205002003
L=900
USCBLR-36
21205003003
L=1210
USCBLR-48
20
301170004
Short covering
fire board
2
92*103
USCBLR-24
3
USCBLR-36
4
USCBLR-48
21
301170003
Long covering fire
board
4
L=451
USCBLR-24
6
USCBLR-36
8
USCBLR-48
22
301010007
U-type burner
2
USCBLR-24
3
USCBLR-36
4
USCBLR-48
