UTAH SCIENTIFIC UCP LC Series Setup guide

UCP LC Series
Basic Setup and Operation
UCP 16, 32, and 80

ii UCP LC 32/80
UCP LC Series - Setup and Operation Guide
• Document Number: 82102-0044
• Document Version: 1.2
• Date: June 26, 2017
• Printed in U.S.A.
Copyrights and Trademarks
© 2017 Utah Scientific, Inc., All rights reserved. Any use or reproduction of this guide’s contents
without the prior written consent of Utah Scientific, Inc. is strictly prohibited.
•All other product names and any registered or unregistered trademarks mentioned in this guide are
used for identification purposes only and remain the exclusive property of their respective owners.
Notice
Information contained in this guide is subject to change without notice or obligation. While every effort
has been made to ensure that the information is accurate as of the publication date, Utah Scientific, Inc.
assumes no liability for errors or omissions. In addition, Utah Scientific, Inc. assumes no responsibility
for damages resulting from the use of this guide.
FCC Compliance (USA) and Digital Equipment Compliance (Canada)
This equipment has been tested and found to comply with the limits for a Class A, digital device,
pursuant to Part 15, Subpart B of the FCC Rules and the Canadian EMC Requirement (ICES-003).
These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case, the user will be required to correct the interference at
their own expense. Shielded cables must be used to ensure compliance with the FCC Class A limits.

UCP LC 32/80 iii
Declaration of Conformity
Utah Scientific, Inc.
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
We declare our sole responsibility that the Utah-400 Digital Routing Switcher is in conformance with
the following standards:
Emission
•EN55022:1994+A1&A2
Immunity
•EN55024:1998
•EN61000-3-2
•EN61000-3-3
Safety
•IEC 60950-1:2001 /EN 60950-1:2001
Following the provisions of the Directive(s) of the Council of the European Union:
•EMC Directive 89/336/EED
•Low Voltage Electrical Directive 72/23/EEC
Utah Scientific, Inc. hereby declares that the product specified above conforms to the above Directive(s)
and Standard(s).

iv UCP LC 32/80
Important Safeguards and Notices
This section provides important safety guidelines for the Operator and Service Personnel. Specific
warnings and cautions are found throughout the guide where they apply, but may not appear here. Please
read and follow the important safety information, specifically those instructions related to risk of fire,
electric shock, or injury to persons.
Safety Symbols
•Hazardous Voltage symbol
•Caution symbol. The product is marked with this symbol when it is necessary to
refer to the manual to prevent damage to the product.
Warnings
Please observe the following important warnings:
•Any instructions in this guide that require opening the chassis, changing a
power supply, or removing a board, should be performed by qualified personnel
only. To reduce the risk of electric shock, do not perform any service unless you
are qualified to do so.
•Heed all warnings on the unit and in the operating instructions.
•Do not use this product in or near water. Disconnect AC power before installing
any options or servicing the unit unless instructed to do so by this manual.
•This product is grounded through the power cord ground conductor. To avoid
electric shock, plug the power cord into a properly wired receptacle before con-
necting the product inputs or outputs.
•Route power cords and other cables so they won’t be damaged.
•The AC receptacle (socket) should be located near the equipment and be easily
accessible.
•Disconnect power before cleaning. Do not use any liquid or aerosol cleaner -
use only a damp cloth.

UCP LC 32/80 v
•Dangerous voltages exist at several points in this product. To avoid personal
injury, do not touch exposed conductors and components while power is on. Do
not insert anything into either of the systems two-power supply cavities with
power connected.
•Do not wear hand jewelry or watches when troubleshooting high current cir-
cuits, such as power supplies. During installation, do not use the door handles
or front panels to lift the equipment as they may open abruptly and injure you.
•To avoid fire hazard when replacing fuses, use only the specified correct type,
voltage and current rating as referenced in the appropriate parts list for this
product. Always refer fuse replacement to qualified service personnel.
•Have qualified personnel perform safety checks after any service.
Cautions
Please observe the following important cautions:
•When installing this equipment do not install power cords to building surfaces.
To prevent damage when replacing fuses, locate and correct the problem that
caused the fuse to blow, before reconnecting power.
•Use only specified replacement parts

vi UCP LC 32/80
Company Information
Utah Scientific, Incorporated
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
•Telephone: [phone]
•FAX: [phone]
•Technical Services (voice): [phone]
•Technical Services (FAX): [phone]
•E-Mail -General Information: [email protected]
•E-Mail -Technical Services: [email protected]om
•World Wide Web: http://www.utahscientific.com
•After Hours Emergency: [phone]. Follow the menu instructions for Emergency Service.

UCP LC 32/80 vii
Warranty Policies
Hardware Warranty
Utah Scientific, Inc. warrants to the original purchaser that the Utah Scientific hardware is free
from defects in materials and workmanship and will perform substantially in accordance with
the accompanying written materials under normal use and service for a period of ten (10) years
from the date of shipment. Any implied warranties on hardware are limited to ten (10) years.
Some states/jurisdictions do not allow limitations on duration of an implied warranty, so the
above limitation may not apply to certain specific purchasers.
Software Warranty
Utah Scientific warrants that the software will perform substantially in accordance with the
accompanying written materials for a period of one (1) year from the date of shipment.
Customer Remedies
For the first one (1) year after purchase of the software and the first ten (10) years after the date
of purchase of the hardware, Utah Scientific’s and its suppliers’ entire liability and purchaser’s
exclusive remedy shall be, at Utah Scientific’s option, either:
• Return of the price paid, or
• Repair or replacement of the software or hardware that does not meet the above warranties
and is returned to Utah Scientific under the returned materials authorization (RMA)
process with freight and forwarding charges paid.
After the initial warranty periods, purchaser’s exclusive remedy is the repair or replacement of
the hardware upon payment of a fixed fee to cover handling and service costs based on Utah
Scientific’s then-current price schedule. The above warranties are void if failure of the
software or hardware has resulted from an accident, abuse, or misapplication. Any replacement
software or hardware will be warranted for the remainder of the original warranty period or
thirty (30) days, whichever is longer.
No other warranties. To the maximum extent permitted by applicable law, Utah Scientific and
its suppliers disclaim all other warranties, either express or implied, including, but not limited
to implied warranties of merchantability and fitness for a particular purpose, with regard to the
software, the accompanying written materials, and any accompanying hardware. This limited
warranty gives the purchaser specific legal rights. These rights may vary in certain states/
jurisdictions.
No liability for consequential damages. To the maximum extent permitted by applicable law,
in no event shall Utah Scientific or its suppliers be liable for any damages whatsoever
(including without limitation, damages for loss of business profits, business interruption, loss
of business information, or any other pecuniary loss) arising out of the use of or inability to use

viii UCP LC 32/80
Utah Scientific products, even if Utah Scientific has been advised of the possibility of such
damages. Because some states/jurisdictions do not allow the exclusion or limitation of liability
for consequential or incidental damages, the above limitation may not apply in those
circumstances.

UCP Panel Operations i
Section 1
Section 1
Section 1
Overview - LC Panel Operation ...................................................................... 1-1
Contents ............................................................................................. 1-1
Basic Chassis Configuration .................................................................... 1-2
System Introduction ................................................................................. 1-5
Launching UCON ............................................................................... 1-5
Layout Selection - Examples ....................................................... 1-9
7x2 and 1x2 ................................................................................. 1-11
18x2 ............................................................................................ 1-12
Partition Display - 8x2 Configuration ........................................... 1-12
Blank Panel Setup ............................................................................. 1-14
Functions ..................................................................................... 1-15
Basic Layout and Definitions ....................................................... 1-16
Panel Type (Top middle) ............................................................. 1-17
Default Colors ............................................................................. 1-17
Save Button ................................................................................. 1-18
Program ...................................................................................... 1-18
Cancel ......................................................................................... 1-19
OK ............................................................................................... 1-19
Menu Dialog Box (Upper-right area, middle of the display) ........ 1-19
Panel Operation ....................................................................................... 1-20
Setting the System up with a standard issue template ...................... 1-20
Top Menu Button Population ............................................................. 1-24
Saving and Program ................................................................................ 1-25
Setup - Review ................................................................................... 1-25
Programming - Review ...................................................................... 1-28
Simulating Your Panel Configuration ....................................................... 1-31
System Salvo Entry .................................................................................. 1-32
Setting Up a Salvo ............................................................................. 1-32
Panel Template Definition for Salvo Use ........................................... 1-34
System Salvo Definition ..................................................................... 1-38
Salvo Rename ............................................................................. 1-40
Adding Existing Salvos to New Buttons ............................................. 1-41
Operation ........................................................................................... 1-44

ii Table of Contents

UCP LC 32/80 1-1
1
Section 1
Overview - LC Panel Operation
This guide describes the basic layout and operation of the LC 32/80 panel within the UCON
interface.
Contents
Basic Chassis Configuration .................................................................... 1-2
System Introduction ................................................................................. 1-5
Launching UCON ............................................................................... 1-5
Blank Panel Setup ............................................................................. 1-14
Panel Operation ....................................................................................... 1-20
Setting the System up with a standard issue template ...................... 1-20
Top Menu Button Population ............................................................. 1-24
Saving and Program ................................................................................ 1-25
Setup - Review ................................................................................... 1-25
Programming - Review ...................................................................... 1-28
Simulating Your Panel Configuration ....................................................... 1-31
System Salvo Entry .................................................................................. 1-32
Setting Up a Salvo ............................................................................. 1-32
Panel Template Definition for Salvo Use ........................................... 1-34
System Salvo Definition ..................................................................... 1-38
Salvo Rename ............................................................................. 1-40
Adding Existing Salvos to New Buttons ............................................. 1-41
Operation ................................................................................................. 1-44

1-2 UCP Series
Basic Chassis Configuration
Figure 1-1. LC16 Configuration

UCP LC 32/80 1-3
Figure 1-2. LC32 Configuration

1-4 UCP Series
Figure 1-3. LC80 Configuration

UCP LC 32/80 1-5
System Introduction
Launching UCON
Launch UCON by double-clicking the application icon inside the directory.
FIGURE 1-1.
Next, open the .ucn file saved for your current configuration.
FIGURE 1-2.

1-6 UCP Series
Once opened, your saved configuration will appear within the UCON display.
Figure 1-4.
Now double-click the layout configuration (noted icon above) to activate your working
interface. You can also activate the panel editing window (shown below) by right-clicking the
icon and selecting ‘Edit’ from the drop-down menu.
FIGURE 1-3.
The LC-32 is displayed in the example above.

UCP LC 32/80 1-7
Previously created sources and destinations are listed alphabetically in the two lists at the right side of
the display. The items contained in the functions list (lower-right) can be directly applied to individual
buttons.
FIGURE 1-4.
The items that will be placed in the Name column are known as “Menus”, and in our example there are
32. When added to a button, the menu becomes a set of functions, described in more detail within the
center table. Each menu can contain up to 256 different buttons.
FIGURE 1-5.

1-8 UCP Series
The layouts within the corresponding column are available for any one of the indicated ‘menus’ to the left
(Name column). The Panel Layout selection is made by clicking the drop down menu within the layout
column (illustration below) and making a selection from the list provided.
Figure 1-5. Initial Build
When a layout is selected, the ‘Fixed’ button (on the actual panel, upper left) will change the button color
state of all Source buttons on the panel.
Figure 1-6. Panel Example

UCP LC 32/80 1-9
Layout Selection - Examples
The illustration below contains a partition (1) 16x2 navigation panel. Sixteen buttons along the top by two
rows.
Figure 1-7. 16x2.
In the following config there is no ‘Partition 2’, as partition 2 would contain the navigation buttons, which
are not modifiable.
Figure 1-8. 16x1 (containing 2 partitions)
In the above layout, the first partition corresponds to the light green buttons, while the section partition
corresponds to the yellow buttons.
The navigation buttons are also included (red buttons, far right). The 8x2 layout illustrated below is
defined by two partitions - 8 buttons along the top by two rows (light green and blue buttons)
Figure 1-9. 8x2
The illustration below is a 'Single Mode' panel, which contains a total of 38 buttons
Figure 1-10. Single Layout

1-10 UCP Series
The buttons to the far right are typically used as navigation buttons, and can include page up and page
down controls.
Important note concerning the ‘single mode' operation
• It is always a good idea to include a ‘back’ button for the purpose of returning to a previous
menu layout, otherwise the user is isolated in the current button layout.
The Page Up and Page Down buttons are recommended for convenient navigation.
Drag the page up and down buttons from the location shown (lower right column) to the specified button
number inside the table (middle). You simply drag this button definition to the specific button number for
the specific location you would like to assign this command.
Figure 1-11. Page Navigation
