Utopia MONTSERRAT User manual

MONTSERRAT
LED TABLE LAMP
Operating Instructions

MONTSERRAT
LED TABLE LAMP
LED 2.7K - 3.3K switchable
2.3W - DC 5V - IP54
110mm
300mm
Model Application Net Weight Dimensions Inner Box Outer Carton Pcs/Ctn
Montserrat Rechargable 820g 110 x 300mm 145 x 120x 345mm 380 x 305 x 365mm 6
table light
Input Voltage Power Safety Class Ingress Protection Beam Angle Light Source Luminaire Flux
DC5V 2.3W CLASS III IP54 120˚ LED 240 lm
Materials
Die-cast aluminium alloy, polycarbonate diuser
How to use
This product is made exclusively for lighting purposes.
It must not be exposed to heavy mechanical loads or contamination. Please install and use only after thoroughly checking that it is undamaged.
Any installation or maintenance must be carried out while the product is turned o. Any alterations to the product, tampering with the product,
or failure to comply with the instructions may harm the product and make it hazardous. When fully assembled, the lamp (not including the
charging base), reaches an IP54 rating making it suitable for outdoor use. When assembled fully and on top of the charging base it has an IP20
rating which means it is not suitable for outdoor use. All metal and plastic surfaces should be cleaned with a soft dry cloth. Utopia shall not be
held liable for any damage caused due to its products being assembled or used in any manner that does not comply with these instructions.
Battery charger technical data
• Contact charging base : INPUT/OUTPUT 5Vdc -1A; cavo USB 1.2 Mt.
• Charger: INPUT AC100-240V 50/60Hz; OUTPUT 5Vdc -1A.
• This lamp may also be used when connected to the charging base.
• It is advised that only the original provided charging base is used. Alternatively, 1A max chargers can be used.
Important to know
• The lamps supporting surface should not exceed 15° of tilt or it will fall.
• To preserve the integrity of this battery, we recommend keeping the charging to 20% minimum to 80% maximum; if the lamp is not used
regularly it is advised to regularly charge/discharge it.
• Please refer to local laws/guidance for proper disposal/recycling of the battery.
Product Description
CHARGE
CHARGE
MODE
CHARGE
MODE
RED LIGHT
ON
GREEN LIGHT
ON
IN
CHARGE
FULL
CHARGE
ON/OFF TOUCH SWITCH
Turn lamp on with one touch, twice to turn o
Table Lamp IP54
Contact Charging
Base IP20
X1 X2
STEPLESS DIMMER
Press and Hold On/O Switch
Only works when light is on.
CCT SETTING
Short Press and Release On/O Switch, Warm/Cool
White
Only works when light is on.
