UVI Group GPS 202C (GW101) User manual

Model No.: GPS-202C (GW101)
User manual for GW101 GPS WATCH 1/ 8
GPS Watch Phone Tracker
（V1.0_GPS）
Please read the user manual carefully before using and abide by it. Please refer to the real product if any
appearance or color changes!
UVI Group Corporation
11C, HaiYue Building, HuiJing Garden,
Nanshan Technology Park, Shenzhen, China
Tel: [phone] Mobile: [phone]
E-mail:[e-mail] Website: www.uvi-group.com
3-in-one design: Wrist Watch + Watch Phone + Invisiable GPS Tracker

User manual for GW101 GPS WATCH 2/ 8
1. Accessory pictures

User manual for GW101 GPS WATCH 3/ 8
2. Appearance
3. Operation manual
3.1 power on/off
3.1.1 Power on
Long press the power button to turn on the mobile.
If there is prompt “insert the SIM card”, please power it off and check the SIM card.
3.1.2 Power off
Long press the power key to turn off the mobile. The mobile is power off after displaying the flash on
LCD.

User manual for GW101 GPS WATCH 4/ 8
3.2 UI Display
In the top of the screen is phone status information bar. It displays GSM signal status, ringtone, GPRS
icon, battery status, LBS status etc.
In the middle of the screen displays the operator’s name of the SIM card and time.
In the bottom of the screen displays main menu, inbox, missed calls.
3.3 Make a call
In idle mode, tap the icon on the bottom right corner to enter the dialing interface. Tap the numerical
keypad by the stylus and enter the number you want to dial in the cursor flashing box, then tap to make
a call.
3.3.1 Dialing status
Tap the dial icon on the bottom of the screen and then input any number, it will enter the dialing status.
A flickering stick indicates the location of the cursor.
Pressing “*” button twice to input “+”, which can be used to make international calls. Pressing “*” button
three times to input “P”, which can be used for automatic DTMF function (dial the extension number
automatically), such as 075521097618P613.
3.3.2 Connecting status
In the dialing mode, tap after inputting numbers to enter the connecting status.
If the number is not in the phonebook, the number will be displayed; otherwise the name will be displayed.
Press hang-up button or tap cancel icon to end the call.
3.4 Receive a call
When there is an incoming call, the ring will be sound or the handset will vibrate.
If the number is not in the phonebook, the number will be displayed; otherwise the name.
Press OK button to receive a call, or tap “answer” on the left bottom screen; press hang-up button to
refuse the call.
3.5 Conversations
3.5.1 Conversation process
The conversation begins once connected.
LCD display: number or the name, call duration
3.5.2 Function operation
During the conversation, enter the conversation options, press hang-up button to conclude it;
Press icon on the bottom middle of the screen to use the numeric buttons. If you make a new call,
the current call will remain.
Hang-up button: conclude the conversation

User manual for GW101 GPS WATCH 5/ 8
In the function menu, you can press left functional button or tap “Back” to quit some menu options;
short press hang-up button to return standby mode directly.
4. Function menus
4. 1 My Buddy (my friends)
You can choose the following functions in “My friends”:
Add friends: Add new entry to the SIM or the mobile
Search friends：Search the linkman by his name
Delete friends：Delete all the records on SIM or the mobile, or one by one.
Copy friends：Copy contact information from SIM to mobile or from mobile to SIM.
4. 2 Family number
It can be set 4 family numbers, which can be used for quick-dial or SOS emergency call.
Family numbers must be chosen in my friends group and can be added and modified pictures.
4. 3 My message
4.3.1 SMS
Enter into message menu interface from main menu interface.
Enter into message menu by taping “my message”.
If the memory is not full, the message will be saved into SIM card or mobile (user preset). If the memory is
full, the early message will be deleted automatically when receiving new message.
4.3.2 Write a message
After entering into write message interface, the operation way is under below:
When edit, directly use handwriting input or tap the input method on the bottom screen, select smart English
(ABC, abc), number input, then its edit interface will change into the corresponding input method interface.
When write a message, tap “option”, there are the following operation: finish/insert numbers/names /input
method to edit.
4.3.3 Inbox
You can check the existed messages in inbox and reply, delete, forward or delete all.
4.3.4 Outbox
You can check the messages you have saved in the out box which is already sent and send, edit, delete or
delete all.
4.3.5 Message settings
Enter into the sub menu, you can set the options under below:
Memory status: view the memory status of the SIM card or the mobile.
Default storage: SIM card or the mobile
4.4 Call log
Your mobile can store 10 recent missed numbers/ dialed numbers/ received numbers each. You can view it
via menu
4.4.1 Delete call log
You can delete all the lists, or you can choose to delete the lists separately.

User manual for GW101 GPS WATCH 6/ 8
4.5 My settings
Main menu interface, enter into settings menu interface.
4.5.1 Touch-screen adjusting
You have to adjust the screen when you feel that the reaction is not correct. Click center until there is
a prompt that the adjustment has been completed. If it is not possible to adjust it well, please restore to
factory default.
4.5.2 Phones settings
Language: English and Chinese
Time and date
Set the city: choose time zone
Time setting: set the current time and date
Time format: 12 hours or 24 hours
Power on/off on time: you can set 4 different times
Input method: choose a default input method
LCD backlight: able to set five brightness
Wallpaper: to choose main screen wallpaper
4.5.3 Ringtone settings
Ringtone setting :set incoming call ring, alarm clock ring, Power on/off ring, message ring and key tone ;
Ring volume : adjust the volume of ring, 1-7 level for options.
Reminding type: Select one way of ring: only ring, only vibration, vibration and ring, ring after vibration.
4.5.4 Recover factory settings
In this menu, input the phone lock password 1234, then the phone will restore to the factory settings.
4.6 Tools
4.6.1 Calendar
4.6.2 Alarm clock
There are 5 alarm clocks for you to choose. You can set it according to need. If certain one is not activated,
there is no icon before it.
5. Settings and applications
5.1 Screen lock
Lock: In standby status, press power on/off button and then press OK button.
Unlock: In lock status, press power on/off button and then press OK button.
Note: The operation should be finished within 3s.
5.2 Switch interface
In standby status, short press power on/off button to switch interface among alarm clock interface, time

User manual for GW101 GPS WATCH 7/ 8
interface and main interface.
Short press power on/off button one time in time interface or two times in alarm clock interface to return
the main interface.
5.3 Operation guide
Preparation before operation
1) Open the packaging box to check the device model number and the accessories, if have any question
please contact your distributor.
2) To select SIM card: the watch phone needs to insert a GSM SIM card, please refer to the suggestion of
distributor, or check it by yourself. To activate the GPRS function, please make sure the access method of
the SIM card with your operator.
3) To install the SIM card: firstly open the back cover of the device, remove the battery, and put the model
face of SIM card downward, insert it to SIM card slot correctly, then cover it .
Notice: If your SIM card has been approved to input SIM PIN, please refer to your user guide and cancel it.
Please power off the device before inserting or removing the SIM card.
6. Operation
6.1 Charge
Keep the phone full charge in the first use.
6.1.1 Travel charger: Connect the phone with it and keep charge for 4 hours
6.1.2 USB charge: Connect the phone with PC by USB wire and keep charge for 4 hours
7. SOS emergency calls
Press SOS button for more than 3s to activate GPS automatically. Twice vibration will be happened, then the
device will send a LBS locating sms to the specific number, e.g.:“Emergency call (LBS): nearby Bao’an
Road Bao’an District, Shenzhen, Guangdong (22.571,113.876)”. Then it will dial the specific numbers by
cycle, if there’s no response after all the number been dialed for three cycles, it will stop. After dialing the
specific numbers, if GPS is located, the device will send an accurate address information, e.g.: “Emergency
call(LBS): Bao’an Road, Bao’an District, Shenzhen, Guangdong (N22.57139,E113.87710)”. If GPS is not
located in 5 minutes, the device will not send the accurate address information.
Notice: To realize this function, please set specific numbers first.
8 GPS locating function
GPS will be activated automatically with flashing Blue LED after power on the device, If GPS is located in
5 minutes, GPS LED keeps in solid bright and the device will send accurate address information to the
server, then the GPS will be off automatically. If GPS is not located after 5 minutes, GPS will be off and the
blue LED will in dark state.
GPS will turn off after 5 minutes if the device stays in the area without GPS signal cover.
At this time, GPS timing locating function will be activated. The default time interval is 30 minutes. The
GPS will start updating data every 30 minutes.
9. Activate GPS and check location
When GPS is off, there are following three different ways to activate it

User manual for GW101 GPS WATCH 8/ 8
9.1 Online to activate GPS
GPS will be ON only during the setting time. If you want to activate GPS at any other time, you can click
“Start GPS” on the platform. The device will start GPS after receiving the command from the platform.
Notice: Please ask your dealer for the platform website.
9.2 SMS to activate GPS
Only 4 specific numbers can check location via sms command. If using other numbers, the device will reply:
Error:110.
●9.2.1 Ask address information
SMS command: DW
If the command sent successfully, the device will reply LBS address information.
If GPS is located in 5 minutes, the device will reply accurate GPS address information. If it is not located in
5 minutes, then no accurate GPS address information.
Example of LBS address information: “Current location (LBS): nearby Bao’an Road Bao’an District,
Shenzhen, Guangdong (22.571,113.876)”.
Example of GPS address information: “Accurate location (GPS):Bao’an Road, Bao’an District, Shenzhen,
Guangdong (N22.57139,E113.87710)
●9.2.2 Ask coordinates
SMS command: WHERE#
Device will reply the coordinates:
e.g. Lat:N22.571285,Lon:E113.877115,Course:42.20,Speed:0.0740,DateTime:10-11-23 22:28:51
●9.2.3 Ask Google link
SMS command: URL#
Device will reply the google link.
e.g.: <DateTime:10-11-23 23:42:51>
http://maps.google.com/maps?q=N22.571490,E113.877103
Notice: GPS can only be located outdoor. It can not be located indoor, or the shade of tree, or tall building
where has low GPS or even no GPS signal. While LBS can be located in anywhere has GSM signal.
10. Global locating platform checking
Device will send location information to the server after power on. You can check the device location via
platform.
Please ask your dealer for the platform website.
LBS locating is not accurate. If you want accurate information, please activate GPS. The accurate range is
around 10 meters.
Notice: The SIM card must be available for GPRS.
