V-Tec DT27 Series User manual

Product Information
DT27 Series
2-Wire Indoor Monitor
DESCRIPTION FEATURES
DIMENSION
2-wire system 7 inch Digital Color TFT Monitor
with touch screen
 Slim design with touch sensor button;
 Three color styles of housing for choice;
 Touch screen operation;
*1 Text menu or color icons menu(SD card
upgrade);
*1 Inner 128MB ash memory plus extended
max.16G SD card external picture
recording;
 12pcs 8-chord Melodies for choose freely;
 Compatible with all DT outdoor & Indoor
stations ;
*1 Multi language & Remote controller
operation(customized);
*1 Depends on models
225
125
23
24.5

1. Parts and Funcons
2. Monitor Mounng
Indicator
LCD Screen
UNLOCK Button
TALK/MON Button
MENU Button
Microphone
Speaker
SD card slot
Connection Port
Mounting Hook
1 2 3 4 5 6
ON
DIPS
L1
BT1 BT2 EH GND VD
L2
Mounting Hook
Wall Mounting Desktop Mounting

3. Specicaon
*Power Supply : DC 24V (supplied by PS4-24V or PS5-24V);
*Power Consumption: Standby 30mA; Working status 450mA;
*Display Device: 7” Digital TFT screen with 16:9 rate;
*Resolution: 800*480 pixels
*Memory: 128MB inner ash memory, Micro mini SD card;
*Picture Format: TVS (JPG);
*Wiring: 2 wires (non-polarity);
*Monitor Dimension: 125(H)×225(W)×23(D)mm
4. Ordering Informaon for Monitor
Model No. Brief Description Menu style*2
DT27/TD7-W 7 inch digital color TFT screen monitor with touch screen
operaon& white housing Text menu
DT27/TD7-B 7 inch digital color TFT screen monitor with touch screen
operaon & black housing
DT27SD/TD7-W 7 inch digital color TFT screen monitor with touch screen
operaon & picture memory & white housing Color icon
(upgraded)
DT27SD/TD7-B 7 inch digital color TFT screen monitor with touch screen
operaon & picture memory & black housing
Manual
Monitor
Monitor
Memory
Playback
Album User Setup
09/30/2010 Thu.16:41
Close
Intercom Multimedia
？About
Manual
Monitor
Monitor
Memory
Playback
Album User Setup
09/30/2010 Thu.16:41
Close
Intercom Multimedia
？About
Monitor ...
Manual Monitor
Intercom
User Setup
Close
About
i
Main Menu
Monitor ...
Manual Monitor
Intercom
User Setup
Close
About
i
Main Menu
DT27/TD7 DT27SD/TD7
Remark: NTSC, PAL must be specied on monitor with picture memory function;
*2 please refer to appendix part in each product information.

Item Brief Description Remark
SD-2 Micro SD card 2G/4G/8G/16G
DB1-W Desk top bracket in white color For desktop mounng
DB1-B Desk top bracket in black color For desktop mounng
5. Oponal Accessories (Not included)
6. Packing Informaon
7. App: Menu style*2
Dimensions: 163(H)×242(W)×38(D)mm
Gross Weight: 0.69Kg
Carton: 530 (H)×340 (W)×258 (D)mm
Quanlity: 24PCS
Text menu style Color icon style (upgraded)
