Vadem Clio C-1050 Series User manual

C-1050 Series
User Manual

Notice
The information in this manual is subject to change without notice.
VADEM SHALL NOT BE LIABLE FOR TECHNICAL OR
EDITORIAL ERRORS OR OMMISSIONS CONTAINED HEREIN;
NOR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE FURNISHING, PERFOMANCE OR USE
OF THIS MATERIAL.
This manual contains information protected by copyright. No part of
this manual may be photocopied or reproduced in any form without
prior written consent from Vadem.
© 1999 Vadem.
Vadem, Vadem ViewFinder, CalliGrapher®and ClioTM are trademarks of
Vadem.
Microsoft®, MS, MSN, PowerPoint®, ActiveX, ActiveSync, Outlook,
InkWriter, Windows, Windows NT, Visual Basic, Visual C++, and the
Windows logo are registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries. Microsoft
products are licensed to OEMs by Microsoft Licensing, Inc., a wholly
owned subsidiary of Microsoft Corporation.
Product names mentioned herein may be trademarks and/or registered
trademarks of their respective companies.
Clio C-1050 User Manual
Second Edition (September 1999)
Part Number DA-00183
FOR YOUR RECORDS
For your assistance in reporting this product in case of loss or theft, please
record the model number and serial number (located on the bottom of the
device) below. Please retain this information.
Model Number ______________________________________
Serial Number _______________________________________
Date of Purchase _____________________________________
Place of Purchase_____________________________________

Contents
Clio User Manual iii
About this Manualx
Important Safety Instructionsxii
Operating Precautionsxiii
Where to Find Informationxiv
Conventionsxvi
1Getting Acquainted with Clio1-1
Attaching to AC Power1-3
Calibrating and Personalizing the Device1-4
Managing Power1-5
Cycling Power1-6
Notification LED/Switch1-7
Power Manager Control Panel1-7
Battery Status Tab1-8
Suspend Options Tab1-10
Backlight Tab1-11
Managing Battery Pack Life1-12
Recharging the Main Batteries1-12
Using Batteries Efficiently1-13
Using Display Modes1-14
Using Clio in Keyboard Mode1-14
Using Clio in Tablet Mode1-15
Adjusting Contrast/Brightness1-15
Using the Stylus1-16
Exploring the Desktop1-17
My Handheld PC1-17
Taskbar1-18
Start Menu1-18
Online Help1-18
Using Windows and Internet Explorer1-19

iv Clio User Manual
Windows Explorer1-19
Internet Explorer1-19
Communications and Connectivity1-20
Connecting to the Modem1-20
Using Infrared1-21
Removing or Replacing the Battery Pack1-22
Removing the Battery1-23
Replacing the Battery1-24
Memory1-26
Using Optional Flash Cards1-26
Installing a Compact Flash Card1-28
Installing ROM1-30
Resetting Clio1-32
Clearing Memory1-33
2Setting up a Partnership
with a Desktop PC2-1
Connecting with the Travel Dock2-2
Setting up Communications2-4
Customizing Synchronization2-7
Synchronizing Files and File Conversion2-9
Drag and Drop2-10
Synchronized Files2-10
Backup and Restore2-11
Remote Synchronization2-11
3Setting Up Remote Networking3-1
Connecting to an ISP3-2
Connecting to a Network3-3
Creating a Dial-up Connection to a Network3-4
Creating a Network (Ethernet) Connection3-5
Synchronizing with a Desktop Computer3-6
Creating a Dial-up Connection to a Modem3-9

Clio User Manual v
Inbox: Sending and Receiving E-mail Messages3-10
Setting up Inbox for Connecting to a Mail Server3-10
Connecting to a Mail Server3-13
Downloading Messages from a Mail Server3-13
Disconnecting From a Mail Server3-14
Managing Messages and Folders on a Mail Server3-14
Synchronizing E-mail Using ActiveSync3-15
Creating an Email Message3-18
Getting Help on Connectivity3-18
4A Tour of Windows CE4-1
Programs4-2
Using the Start Menu and Taskbar4-4
Using the Command Bar4-5
Finding Files and Exploring the Web4-5
Printing4-6
Customizing Clio4-7
Communications4-7
Dialing4-7
Display4-8
Keyboard4-8
Network4-8
Owner4-8
Password4-9
Power Manager4-9
Regional Settings4-9
Remove Programs4-10
Stylus4-10
System4-10
Tablet Mode AutoStart4-10
Volume and Sounds4-11
World Clock4-11

vi Clio User Manual
5Using the Microsoft Office and Other
Companion Programs5-1
Pocket Word: Creating Documents5-2
Pocket Excel: Creating Workbooks5-4
Pocket Access: Viewing and Creating Data5-6
Pocket PowerPoint: Showing Presentations5-8
Voice Recorder and InkWriter5-10
Voice Recorder: Capturing Ideas and Thoughts5-10
InkWriter: Creating Notes and Drawings5-12
Microsoft Pocket Outlook5-14
Calendar: Scheduling Meetings and Appointments5-15
Contacts: Tracking Friends and Colleagues5-18
Tasks: Keeping a To Do List5-19
6Using the Bundled Programs6-1
Vadem ViewFinder™6-2
Viewing, Finding and Editing Your Personal Information6-3
Archiving and Restoring Notes6-4
CalliGrapher®5.36-6
Starting CalliGrapher6-6
Recognition Mode6-7
ScreenDraw mode6-9
BSQUARE® bFAX® Pro6-10
Sending a Fax via the Built-In Modem6-11
Receiving a Fax6-11
BSQUARE bUSEFULTM Backup Plus6-12
Starting a bUSEFUL Backup6-12
Some Helpful Tips and Tricks about bUSEFUL6-12
BSQUARE Publisher and Viewer6-15
Starting and running BSQUARE bREADY Publisher6-15
Starting and Running the BSQUARE bREADY Viewer on your
Clio6-16

Clio User Manual vii
AClio Troubleshooting
Guide and TipsA-1
What should I do if…A-1
…the power button won’t turn the device on?A-1
…my screen is dark?A-2
...Clio’s Notify button is not working?A-2
…the system is not responding properly to the stylus taps?A-2
…my Clio will not respond to screen taps or keystrokes?A-3
... my battery is not holding a charge?A-3
...I can’t install the battery?A-4
...my Clio doesn’t open and close properly?A-4
...my Clio’s AC adapter is not charging the unit?A-4
...my Clio is not receiving audio?A-4
...I can’t insert a PC card into the card slot?A-5
…I forget my power-on protection password?A-5
....the LCD on my Clio is flickering?A-5
...my Clio’s battery LED is not working?A-6
...my Clio’s serial port is not working?A-6
How do I…A-6
…minimize an application or window?A-6
…quickly access the desktop?A-6
…create a shortcut to my favorite application or file on the
desktop?A-6
…end an application that is not responding?A-7
…tell if the Caps Lock is active?A-7
…access the context menus (right mouse click in Windows
95)?A-7
…check battery levels?A-7
…find out how much memory I have left for storage and
applications?A-7
…maximize my battery life?A-8

viii Clio User Manual
BHardware SpecificationsB-1
CRegulatory Information for the
C-1050 SeriesC-1
DSupported PC CardsD-1
ELimited WarrantyE-1
FVadem Software License AgreementF-1
GBSQUARE® EULAG-1
HSoftware ProgramsH-1
Glossary Glossary-1
Index

Clio User Manual ix
Preface
Congratulations on purchasing Clio, the ideal PC Companion
powered by the Microsoft®Windows®CE operating system. The
size and capabilities of this device let you keep your most impor-
tant business and personal information up-to-date and close at
hand. Windows ActiveSync®with CE Services increases the
power of Clio by letting you synchronize the information on your
desktop or laptop computer with this device. Picture yourself in
the following situations:
•You’re on a business trip, getting important customer
feedback that you want to discuss with your colleagues back
in the office. Using Calendar, Contacts, and Inbox, you
schedule a meeting and send it to your colleagues while still
on the road.
•You are on the road taking customer orders. Using Pocket
Access, you create records for each customer with their order
information. At night, you connect to your network and
update the global database with your new orders. You also
download updates to the product information database you use
when making sales.
•You glance at the time and realize that you are going to be late
for the bus. You grab Clio and catch the bus just in time.
Because ActiveSync keeps the information on your device
always up-to-date, while on the bus, you leisurely read and
respond to the e-mail messages you did not have a chance to
get to during the day. Once at home, you use your device to
dial into the network at your company and send your replies.

xClio User Manual
•During a few spare minutes in the airport, you check your e-
mail and send a note to your daughter wishing her luck at the
gymnastics meet.
About this Manual
Table P-1 provides a description of each section in this manual.
TABLE P-1 Contents of this Manual
SectionContent
Chapter 1:
Getting Acquainted with Clio Essential information about Clio, including its
hardware, software applications, supported PC
cards, and essential set-up tasks you should
perform.
Chapter 2:
Setting up a Partnership with a
Desktop PC Instructions for setting up a partnership and synchronizing Clio with a desktop PC.
Chapter 3:
Setting Up Remote
Networking Instructions for configuring and using dialup and network connections.Instructions for
sending and receiving email messages with the
Inbox program.
Chapter 4:
A Tour of Windows CE Description of the features of the Windows CE
desktop environment.
Chapter 5:
Using Microsoft Office and
Other Companion Programs Information about using the Microsoft appli- cations bundled with Clio.
Chapter 6:
Using the Bundled Programs Information about using the Vadem applica-
tions bundled with Clio: ViewFinder, CalliG-
rapher, BSQUARE bFAX Pro, bUSEFUL
BACKUP Plus and bREADY Publisher and
Viewer.

Clio User Manual xi
About this Manual
Appendix A:
Clio Troubleshooting Guide
and Tips Symptom, Cause, and Solution information for commonly encountered difficulties
Appendix B:
Hardware Specifications System specifications for Clio
Appendix C:
Regulatory Information for the
C-1050 Series Regulatory information regarding Clio
Appendix D:
Supported PC Cards Listing of PC Cards supported by Windows
CE
Appendix E:
Vadem Limited Warranty Complete text of Vadem limited warranty
Appendix F:
Vadem Software
License Agreement Complete text of software license agreement
Appendix G:
BSQUARE®End-User
License Agreement (EULA) BSQUARE®bFAX®Pro, BSQUARE®
bUSEFULTMBACKUP Plus, bREADYTM Pub-
lisher and Viewer EULA
Appendix H:
Software Programs Complete listing of software programs
included with C-1050 Series
Glossary Translations of commonly used terms
TABLE P-1 Contents of this Manual
Section (Continued) Content

xii Clio User Manual
Important Safety Instructions
Follow basic safety precautions to reduce the risk of fire, electric
shock, or personal injury:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the
product.
3. Never install telephone wiring during a lightning storm.
4. Never install telephone jacks in wet locations unless the
jack is specifically designed for wet locations.
5. Never touch uninsulated telephone wires or terminals
unless the telephone line has been disconnected at the
network interface.
6. Use caution when installing or modifying telephone wires.
7. Avoid using a telephone (other than a cordless type) or
modem during an electrical storm. There may be a remote
risk of electric shock from lightning.
8. Use only the power adapter supplied with Clio. If you need
to replace the supplied power adapter, go to the Vadem
web site,
http://www.vadem.com,
for information on how to order a replacement.
9. Do not overload wall outlets and extension cords as this
can result in the risk of fire or electric shock.
10. Never spill liquid of any kind on the product.
11. To reduce the risk of electric shock, do not disassemble the
product. Instead, take it to qualified service personnel
when service or repair work is required. Opening or
removing covers may expose you to dangerous voltage or
other risks. Incorrect reassembly can cause electric shock
when the product is next used.

Clio User Manual xiii
Operating Precautions
Operating Precautions
Clio is a precision digital instrument. Be sure to observe the
following important precautions in order to prevent malfunction
that can result in improper operation or corruption of data in
memory.
•Never continue to use the device when battery power is low.
Low battery power can cause corruption or loss of data stored
in memory. Recharge batteries as soon as possible after low
power is indicated. Charge whenever possible.
•Avoid using the device in areas subjected to the conditions
listed below. Such conditions can create the danger of fire or
personal injury, as well as damage to and malfunction of the
device.
•Electrostatic charge
•Extreme heat
•Very high humidity
•Sudden temperature change
•Large amounts of dust
Also note the following important precautions. Failure to do so
can create the danger of fire, personal injury, as well as damage to
and malfunction of the device.
•Never drop the device, allow it to be hit by other objects or
otherwise subject it to strong impact.
•Never place heavy objects on top of the device.
•Never disassemble the device.
•Never insert foreign objects into the connectors or slots of the
device.
•Never allow water or other liquids to come into direct contact
with the device.

xiv Clio User Manual
•Always use the stylus that comes with the device when
operating its touch screen, and only use the shiny end of the
stylus.
•Never use paint thinner, benzene, or other volatile agents to
clean the device or its display panel. Instead, use a soft cloth
moistened with water. Wring out all excess liquid from the
cloth before wiping the device or display panel.
Where to Find Information
This manual describes your Clio hardware, provides an overview
of the programs included, and describes how to set up
communications between your device and your desktop
computer. Table P-2 is a guide to the different types of
information available to help you use your device. Note that
although this book introduces the programs on your Clio, it does
not describe them completely. For more information, see the
comprehensive online Help for each program.
TABLE P-2 Clio Information
Information Source
Program Documentation This User’s Manual
-or-
Online Help on your device.
Select Start > Help.
Synchronizing and exchanging files
with a desktop computer This User’s Manual. -or-
Online Help on your device.
Select Start > Help.
-or-
Microsoft ActiveSync online Help on
your desktop computer. In the Active-
Sync window, click
Help > Windows CE Services Help
Topics.

Clio User Manual xv
Where to Find Information
Toolbar buttons Tap and hold on a toolbar button to see
its name. Drag off the toolbar button
before lifting to avoid activating the
button.
Troubleshooting information on
connections The Communications Troubleshooter on your desktop computer. In the
ActiveSync window, click Help >
Communications Troubleshooting.
Up-to-date information on Windows
CE-based devices The Microsoft Windows CE Home Page:
http://www.microsoft.com/win-
dowsce
Information on this release of
Windows CE Readme.doc file (located in the Microsoft ActiveSync folder on your
desktop computer).
Extensive online support for Clio spe-
cific tips, troubleshooting and FAQs
(Frequently Asked Questions)
The Vadem Home Page:
http://www.vadem.com
Information about accessories,
software and upgrades for Clio The Vadem Home Page: http://www.vadem.com
Vadem Technical Support Email to:
[email protected]
Vadem Technical Support, Service and
Repair 1-888-GO-VADEM
TABLE P-2 Clio Information (Continued)
Information Source

xvi Clio User Manual
Conventions
This manual uses several conventions to present information of
special importance.
Warning: Warnings are cautions and alerts of things that can interfere
with or damage the function of this device.
Note: Notes highlight helpful and important things to keep in mind
when using this mobile device. These include things like tips
and tricks, shortcuts, and hints.
Lists of items, points to consider, or procedures that do not need
to be performed in a specific order appear in bullet format:
•Item 1
•Item 2
Procedures that must be followed in a specific order appear in
numbered steps:
1. Perform this step first
2. Perform this step second
NOTE: The notation [tap] or [double-tap] may appear in this
document. It signifies a stylus or finger tapping the touch screen.

Clio User Manual xvii
Where to Find Information
The following general text conventions are used to denote special
circumstances.
[ENTER] Specific keyboard keys are shown in
square brackets and are capitalized.
[ALT]+[F4] Keys with a plus sign (+) between
them must be pressed simultaneously
{POWER} Buttons and knobs are depicted in
round brackets and are capitalized
and italicized.
\\HKEY\CURRENT_USER Path names to PC or Windows CE
resources are shown in Courier font.
Start>Settings>Control Panel Clio paths to resources are shown usually
in bold font
cd \letters\business\legal
[ENTER]
http://www.Vadem.com
PC keyboard entries or URLs you are
expected to enter exactly as shown are
indicated in Courier font.

xviii Clio User Manual

Clio User Manual 1-1
1Getting Acquainted with Clio
Before you start using Clio, you will need to charge the unit until
the orange indicator light on the front turns to green, indicating a
fully charged battery.
This chapter will show you how to:
1. Attach to AC power and charge the batteries.
When attached to AC power, the battery pack and backup
battery charge automatically, even when Clio is in use. Refer
to “Attaching to AC Power” on page 1-3.
Important: The first time you charge Clio, be sure that
your device remains connected to AC power
for twelve hours to fully charge both batteries.
You may use Clio during this time, but do not
remove it from the AC connection. This is only
required the first time you charge Clio.
2. Calibrate and personalize Clio.
Refer to “Calibrating and Personalizing the Device” on page
1-4.

Getting Acquainted with Clio
1-2 Clio User Manual
The names and locations of key components on your Clio are
shown below. Figure 1-1 shows a top view of Clio in Keyboard
Mode, and Figure 1-2 shows a bottom view of Clio.
FIGURE 1-1 Top view of Clio in Keyboard Mode
Warning: Be careful when opening Clio. The hinge arm may pinch skin
or clothing that is in contact with the back of the device when
it is opened. Always rest Clio on a flat surface before
opening.
Screen contrast control keys
Serial/
Docking Port IR Port Stylus
Notification LED/Switch
External
Power
Port
Modem Jack
Microphone
Birghtness control keys
Display Power Button
