Valore OP16 User manual

Wireless Outdoor Speaker
(OP16)
Thank you for purchasing the Valore Wireless Outdoor Speaker (OP16).
Bring your favourite tunes along with you for all your adventures. Designed for the outdoor
enthusiast, this speaker is the perfect companion for cycling, hiking or simply your next
outdoor barbeque/camping.
Important: Please read the user manual thoroughly before using your wireless speaker.
Specifications: Package Contents:
• Wireless range: Up to 10m
• Battery type: 2000mAh (lithium polymer battery)
• Support: TF card up to 32GB
• Standby time: Up to 25 days
• Charging time: Up to 3 hours
• Playback time: Up to 7 hours
• Power input: DC5V/0.5A 1000mAh
• Power output: 3Wx2
• Dimension (L x W x H): 173 x 57 x 57mm
• Material: ABS
• Weight: 310g
UNDERSTANDING THE PRODUCT
• Wireless outdoor speaker
• Micro USB charging cable (500mm)
• 3.5 Auxiliary cable (500mm)
• Carabiner
① Micro USB charging port
② TF card slot
③ Aux in port
④ On/Off/Multi-functional button (M)
⑤ Next song/Volume ‘+’
⑥ Previous song/Volume‘-’
⑦ Play/Pause/Call button
⑧ Mic
⑨ LED indicator
⑩ Torch On/Off
①
②③④
⑤
⑥
⑦
⑧
⑨
⑩

START USING THE WIRELESS SPEAKER
1) Charging the wireless speaker
Connect the USB charging cable to the speaker located on the left side of the speaker.
Note: Please charge the speaker for at least 8 hours before first use. Please make sure that the speaker is
switched off when charging is in progress.
Light indication:
Pairing: Blinking blue
Paired successful: Solid blue
Audio play: Slow flashing blue
TF card reader: Solid red
Charging: Solid red
Off when full charged
2) Pairing the wireless speaker (switched off)
Step 1: Activate Bluetooth function on your mobile device to begin pairing with speaker.
Step 2: Press and hold onto the On/Off button (M) located on the side of the speaker to turn
on, blue LED light will be blinking. The speaker now have entered pairing mode.
Step 3: Connect to the speaker by selecting ‘Valore OP16’ under the device list. Enter ‘0000’
for password if required.
Step 4: Once connected, the LED light at the Bluetooth button will be solid blue.
Note: If the pairing is not successful, please turn off wireless speaker first, and then re-pair again. After pairing
is successful, paired devices will remember each other. Unless pairing information is deleted because of new
pairing, no need to pair when using the next time.
If you want to pair the wireless speaker with other devices, please turn off Bluetooth function of existing source
device, and pair the wireless speaker with the new device according to steps 1-4 mentioned above.
3) Wireless speaker controls
On/Off/ - Press and hold to switch On/Off
Multi-functional button - When switched on, short press to switch between Bluetooth/TF card/Aux mode
Next song/Volume ‘+’ - Short press for next song / Long press for volume increase
Previous song/Volume ‘-’ - Short press for previous song / Long press for volume decrease
Play/Pause/Call button - When the call come in Short press to answer/Long press to hang up calls. Short
press for play/pause music. Long press for 2 seconds to redial last call.
Torch On/Off - Short press to On torch. Short press again for fast flicker. Short press again to
slower flicker. Short press again to off.

TROUBLESHOOTING
Issue 1:speaker is unable to connect successfully to your mobile device
Problem 1: speaker’s battery is flat
Solution: Fully charge the speaker (2.5 hours) and retry connection with your mobile device.
Problem 2: speaker not paired to your mobile device
Solution: Make sure that the speaker is successfully paired upon selecting ‘Valore OP16’ in
the device list.
Problem 3: speaker and mobile device too far apart
Solution: Make sure that the speaker is within a metre range during pairing and connection.
Problem 4: speaker is connected to other mobile device
Solution: Make sure that the speaker has already been disconnected before making a new
connection with a new device.
Issue 2: Sound from the speaker is too soft or silent
Problem 1: speaker’s battery is low / flat
Solution: Fully charge the speaker (2.5 hours) and retry connection with your mobile device.
Problem 2: speaker or mobile device’s volume is too low
Solution: Turn the volume of the speaker or mobile device up to increase the volume.
Problem 3: Music track may not be audible
Solution: Make sure that the music track is of a playable format for the mobile device.
Problem 4: speaker and mobile device might not be connected properly.
Solution: Repeat the connection step via Bluetooth/auxiliary cable again to make sure that it
is connected properly and try again.

TECHNICAL SUPPORT & WARRANTY
• For Technical Support, email us at [e-mail].
• For Warranty Registration, visit www.valore.sg.
Cautions:
Read all the instructions and warnings carefully prior to using this product.
• Do not store the speaker in a high temperature environment.
• Do not place the speaker near a fire or other excessively hot environments.
• Do not expose this speaker to moisture or submerge it in liquid. Keep speaker dry at all
times.
• Do not attempt to charge the speaker using any other method or connection other than the
speaker’s provided charging cable.
• Do not disassemble this speaker or attempt to repair or modify it in any manner.
• Be cautious of excessive drops, bumps, abrasions or other impacts to this speaker. If there
is any damage to the speaker such as dents, punctures, tears, deformities or corrosion, stop
using the speaker and contact us immediately via email at [e-mail], or return this
product to the store where you have purchased it from.
• If the product produces an abnormal smell, high temperature (low temperature during
normal use), discolours or changes shape abnormally, stop using the product and contact us
immediately via email at [e-mail].
DISCLAIMER & TRADEMARKS
All information, trademarks, logos, graphics, and images (“Materials”) provided on this user manual are
copyrighted or trademarked and are the property of Valore Lifestyle Pte Ltd. Any unauthorized use of any
material contained on the instruction manual may violate copyright laws, trademark laws, laws of privacy and
communications statutes.
The trademarks, service marks and logos used and displayed in the Materials are registered and unregistered
trademarks and service marks of Valore and others. All other registered and unregistered company names,
product names and marks mentioned herein the (“Materials”) are the property of their respective owners and
may be trademarks or registered trademarks.
Inspired by Valore Singapore
For full range of Valore products visit www.valore.sg
