Vanten SY126 User manual
CONTROL PANEL QUICK START CONNECT TO A DEVICE
Flame
Light on/Off/Cycle Modes
Speaker
2.Connect to a Bluetooth enabled device
3.Begin listening!
Power
Tum the Speaker On/Off
Bluetooth
Activate Party Sync Mode
Plus
Next Song/Volume Up
Minus
Last Song/Volume Down
Play/Pause
Play/Pause the Song
Battery
Check the Battery Level
1.Power on the ( )
Note:
If you are connecting multiple speakers for the
first time, please follow the steps below to enter
Light
Modes: Flicker IPulsing ISolid
Single click the Flame ( ) button to
turn on & cycle through the modes.
Press and hold the Flame ( ) button
to turn off the light without cycling
through the modes.
2.Turn on the Bluetooth feature in your
device's settings.
4.Select "SY126" from the list of devices.Once
you hear the voice prompt "connected",you
are ready to begin streaming.This will be the
"Parent" speaker.
1.Press and hold the power （ ） button.
3.If you are connecting this speaker for
the first time, you need to single click
the Bluetooth ( ) button first, you
will hear “dongdong” , then you can
find the Bluetooth device "SY126" on
your list; If you have already connect
ed this speaker, you don't need to
click Bluetooth ( ) button, it will
connect automatically.
Do you have more than one "SY126"?
Continue with steps 4-7!
User Manual
CONTROL PANEL QUICK START CONNECT TO A DEVICE
Flame
Light on/Off/Cycle Modes
Speaker
2.Connect to a Bluetooth enabled device
3.Begin listening!
Power
Tum the Speaker On/Off
Bluetooth
Activate Party Sync Mode
Plus
Next Song/Volume Up
Minus
Last Song/Volume Down
Play/Pause
Play/Pause the Song
Battery
Check the Battery Level
1.Power on the ( )
Note:
If you are connecting multiple speakers for the
first time, please follow the steps below to enter
Light
Modes: Flicker IPulsing ISolid
Single click the Flame ( ) button to
turn on & cycle through the modes.
Press and hold the Flame ( ) button
to turn off the light without cycling
through the modes.
2.Turn on the Bluetooth feature in your
device's settings.
4.Select "SY126" from the list of devices.Once
you hear the voice prompt "connected",you
are ready to begin streaming.This will be the
"Parent" speaker.
1.Press and hold the power （ ） button.
3.If you are connecting this speaker for
the first time, you need to single click
the Bluetooth ( ) button first, you
will hear “dongdong” , then you can
find the Bluetooth device "SY126" on
your list; If you have already connect
ed this speaker, you don't need to
click Bluetooth ( ) button, it will
connect automatically.
Do you have more than one "SY126"?
Continue with steps 4-7!
User Manual
CONTROL PANEL QUICK START CONNECT TO A DEVICE
Flame
Light on/Off/Cycle Modes
Speaker
2.Connect to a Bluetooth enabled device
3.Begin listening!
Power
Tum the Speaker On/Off
Bluetooth
Activate Party Sync Mode
Plus
Next Song/Volume Up
Minus
Last Song/Volume Down
Play/Pause
Play/Pause the Song
Battery
Check the Battery Level
1.Power on the ( )
Note:
If you are connecting multiple speakers for the
first time, please follow the steps below to enter
Light
Modes: Flicker IPulsing ISolid
Single click the Flame ( ) button to
turn on & cycle through the modes.
Press and hold the Flame ( ) button
to turn off the light without cycling
through the modes.
2.Turn on the Bluetooth feature in your
device's settings.
4.Select "SY126" from the list of devices.Once
you hear the voice prompt "connected",you
are ready to begin streaming.This will be the
"Parent" speaker.
1.Press and hold the power （ ） button.
3.If you are connecting this speaker for
the first time, you need to single click
the Bluetooth ( ) button first, you
will hear “dongdong” , then you can
find the Bluetooth device "SY126" on
your list; If you have already connect
ed this speaker, you don't need to
click Bluetooth ( ) button, it will
connect automatically.
Do you have more than one "SY126"?
Continue with steps 4-7!
User Manual
CONTROL PANEL QUICK START CONNECT TO A DEVICE
Flame
Light on/Off/Cycle Modes
Speaker
2.Connect to a Bluetooth enabled device
3.Begin listening!
Power
Tum the Speaker On/Off
Bluetooth
Activate Party Sync Mode
Plus
Next Song/Volume Up
Minus
Last Song/Volume Down
Play/Pause
Play/Pause the Song
Battery
Check the Battery Level
1.Power on the ( )
Note:
If you are connecting multiple speakers for the
first time, please follow the steps below to enter
Light
Modes: Flicker IPulsing ISolid
Single click the Flame ( ) button to
turn on & cycle through the modes.
Press and hold the Flame ( ) button
to turn off the light without cycling
through the modes.
2.Turn on the Bluetooth feature in your
device's settings.
4.Select "SY126" from the list of devices.Once
you hear the voice prompt "connected",you
are ready to begin streaming.This will be the
"Parent" speaker.
1.Press and hold the power （ ） button.
3.If you are connecting this speaker for
the first time, you need to single click
the Bluetooth ( ) button first, you
will hear “dongdong” , then you can
find the Bluetooth device "SY126" on
your list; If you have already connect
ed this speaker, you don't need to
click Bluetooth ( ) button, it will
connect automatically.
Do you have more than one "SY126"?
Continue with steps 4-7!
User Manual
LISTENING TROUBLESHOOTING TECH SPECS
BATTERY
Connecting To Bluetooth Pairing Name: SY126
Version: 5.3
Pairing Capacity: Up to 100Speakers
Water Resistant: IPX6
Battery Type: Li-Ion 3.7 V DC 1,800mAh
Recharging Time: 5-6Hours (from 0%)
Type-C Input: 5V/1A
Playtime: Up to 12Hours
Max Output Power: 10W
Transmission Distance: 50ft
RF Frequency: 2.40 GHz-2.48 GHz
Drive Unit: Φ57mm
Impedance: 4 ohm
Sensitivity: -85dBm
S.P.L.: 95 dB
Dimensions: 7.4"x 3.9 "
Weight: 1.25 lbs
•varies by audio volume and light brightness.
the PartySync Mode; if you have already connected,
just turn on all speakers and wait for 5-10seconds
to connect automatically.
7. Wait for 5-10 seconds until you hear “connected”,
it means you enter the PartySync Mode successfully.
8. Repeat steps 5-7 for each additional "SY126" you
would like to connect.
Audio can be adjusted from the Control
Panel or directly on your device. If " SY126 " does not show up in your
Bluetooth menu, try:
If the audio being streamed to " SY126 " is
skipping or has poor sound quality, try:
When charging , the blue grid in the working
state will increase gradually according to the
amount of electricity; When discharging, the
number of squares of the gray icon will
gradually increase according to how much
power is consumed.
It is recommended to charge the speaker
to 100% before each use to achieve the
longest playtime.
To charge , connect the included Type-C
to USB Cable to a USB output.
Recharging time: 5-6 Hours.
The lights on the battery level ( ) will flash
while charging. Once fully charged, the lights
will be always-on mode.
•Plus(+)
Single click = next song
Press and hold =volume up
•Minus (-)
Single click = restart song
Press and hold = volume down
Sound Quality
When multiple speakers
are connected the LED
lights of the control
panel will slowly blink
to indicate which
speaker is the Parent.
Tip: Disconnecting Speakers
Tip: Indicating the Parent Speaker
Turning the device's Bluetooth off, wait 15
seconds, then turn it back on.
Moving the Main " SY126 " closer to the
connected device.
Moving all paired " SY126 " Speakers
closer to the Main Speaker.
Checking for interference between the
device and the Main Speaker (walls, metal
structures , ect).
Turning the " SY126 " off, wait 15 seconds,
then turn it back on.
Forget "SY126" from all other near-by
mobile devices.
6. Power on the second speaker and single click the
Bluetooth button ( ) to turn on PartySync Mode,
you will hear "didi ”.This speaker and all additional
will be called the "Child".
Single click the Bluetooth ( ) button on any Child
speaker to disconnect from the Parent.
Single click the Bluetooth ( ) button on the Parent
speaker to disconnect all Child speakers.
5. Turn on PartySync Mode on the Parent speaker by
single clicking the Bluetooth button （ ）, you will
hear "didi ”.
LISTENING TROUBLESHOOTING TECH SPECS
BATTERY
Connecting To Bluetooth Pairing Name: SY126
Version: 5.3
Pairing Capacity: Up to 100Speakers
Water Resistant: IPX6
Battery Type: Li-Ion 3.7 V DC 1,800mAh
Recharging Time: 5-6Hours (from 0%)
Type-C Input: 5V/1A
Playtime: Up to 12Hours
Max Output Power: 10W
Transmission Distance: 50ft
RF Frequency: 2.40 GHz-2.48 GHz
Drive Unit: Φ57mm
Impedance: 4 ohm
Sensitivity: -85dBm
S.P.L.: 95 dB
Dimensions: 7.4"x 3.9 "
Weight: 1.25 lbs
•varies by audio volume and light brightness.
the PartySync Mode; if you have already connected,
just turn on all speakers and wait for 5-10seconds
to connect automatically.
7. Wait for 5-10 seconds until you hear “connected”,
it means you enter the PartySync Mode successfully.
8. Repeat steps 5-7 for each additional "SY126" you
would like to connect.
Audio can be adjusted from the Control
Panel or directly on your device. If " SY126 " does not show up in your
Bluetooth menu, try:
If the audio being streamed to " SY126 " is
skipping or has poor sound quality, try:
When charging , the blue grid in the working
state will increase gradually according to the
amount of electricity; When discharging, the
number of squares of the gray icon will
gradually increase according to how much
power is consumed.
It is recommended to charge the speaker
to 100% before each use to achieve the
longest playtime.
To charge , connect the included Type-C
to USB Cable to a USB output.
Recharging time: 5-6 Hours.
The lights on the battery level ( ) will flash
while charging. Once fully charged, the lights
will be always-on mode.
•Plus(+)
Single click = next song
Press and hold =volume up
•Minus (-)
Single click = restart song
Press and hold = volume down
Sound Quality
When multiple speakers
are connected the LED
lights of the control
panel will slowly blink
to indicate which
speaker is the Parent.
Tip: Disconnecting Speakers
Tip: Indicating the Parent Speaker
Turning the device's Bluetooth off, wait 15
seconds, then turn it back on.
Moving the Main " SY126 " closer to the
connected device.
Moving all paired " SY126 " Speakers
closer to the Main Speaker.
Checking for interference between the
device and the Main Speaker (walls, metal
structures , ect).
Turning the " SY126 " off, wait 15 seconds,
then turn it back on.
Forget "SY126" from all other near-by
mobile devices.
6. Power on the second speaker and single click the
Bluetooth button ( ) to turn on PartySync Mode,
you will hear "didi ”.This speaker and all additional
will be called the "Child".
Single click the Bluetooth ( ) button on any Child
speaker to disconnect from the Parent.
Single click the Bluetooth ( ) button on the Parent
speaker to disconnect all Child speakers.
5. Turn on PartySync Mode on the Parent speaker by
single clicking the Bluetooth button （ ）, you will
hear "didi ”.
LISTENING TROUBLESHOOTING TECH SPECS
BATTERY
Connecting To Bluetooth Pairing Name: SY126
Version: 5.3
Pairing Capacity: Up to 100Speakers
Water Resistant: IPX6
Battery Type: Li-Ion 3.7 V DC 1,800mAh
Recharging Time: 5-6Hours (from 0%)
Type-C Input: 5V/1A
Playtime: Up to 12Hours
Max Output Power: 10W
Transmission Distance: 50ft
RF Frequency: 2.40 GHz-2.48 GHz
Drive Unit: Φ57mm
Impedance: 4 ohm
Sensitivity: -85dBm
S.P.L.: 95 dB
Dimensions: 7.4"x 3.9 "
Weight: 1.25 lbs
•varies by audio volume and light brightness.
the PartySync Mode; if you have already connected,
just turn on all speakers and wait for 5-10seconds
to connect automatically.
7. Wait for 5-10 seconds until you hear “connected”,
it means you enter the PartySync Mode successfully.
8. Repeat steps 5-7 for each additional "SY126" you
would like to connect.
Audio can be adjusted from the Control
Panel or directly on your device. If " SY126 " does not show up in your
Bluetooth menu, try:
If the audio being streamed to " SY126 " is
skipping or has poor sound quality, try:
When charging , the blue grid in the working
state will increase gradually according to the
amount of electricity; When discharging, the
number of squares of the gray icon will
gradually increase according to how much
power is consumed.
It is recommended to charge the speaker
to 100% before each use to achieve the
longest playtime.
To charge , connect the included Type-C
to USB Cable to a USB output.
Recharging time: 5-6 Hours.
The lights on the battery level ( ) will flash
while charging. Once fully charged, the lights
will be always-on mode.
•Plus(+)
Single click = next song
Press and hold =volume up
•Minus (-)
Single click = restart song
Press and hold = volume down
Sound Quality
When multiple speakers
are connected the LED
lights of the control
panel will slowly blink
to indicate which
speaker is the Parent.
Tip: Disconnecting Speakers
Tip: Indicating the Parent Speaker
Turning the device's Bluetooth off, wait 15
seconds, then turn it back on.
Moving the Main " SY126 " closer to the
connected device.
Moving all paired " SY126 " Speakers
closer to the Main Speaker.
Checking for interference between the
device and the Main Speaker (walls, metal
structures , ect).
Turning the " SY126 " off, wait 15 seconds,
then turn it back on.
Forget "SY126" from all other near-by
mobile devices.
6. Power on the second speaker and single click the
Bluetooth button ( ) to turn on PartySync Mode,
you will hear "didi ”.This speaker and all additional
will be called the "Child".
Single click the Bluetooth ( ) button on any Child
speaker to disconnect from the Parent.
Single click the Bluetooth ( ) button on the Parent
speaker to disconnect all Child speakers.
5. Turn on PartySync Mode on the Parent speaker by
single clicking the Bluetooth button （ ）, you will
hear "didi ”.
LISTENING TROUBLESHOOTING TECH SPECS
BATTERY
Connecting To Bluetooth Pairing Name: SY126
Version: 5.3
Pairing Capacity: Up to 100Speakers
Water Resistant: IPX6
Battery Type: Li-Ion 3.7 V DC 1,800mAh
Recharging Time: 5-6Hours (from 0%)
Type-C Input: 5V/1A
Playtime: Up to 12Hours
Max Output Power: 10W
Transmission Distance: 50ft
RF Frequency: 2.40 GHz-2.48 GHz
Drive Unit: Φ57mm
Impedance: 4 ohm
Sensitivity: -85dBm
S.P.L.: 95 dB
Dimensions: 7.4"x 3.9 "
Weight: 1.25 lbs
•varies by audio volume and light brightness.
the PartySync Mode; if you have already connected,
just turn on all speakers and wait for 5-10seconds
to connect automatically.
7. Wait for 5-10 seconds until you hear “connected”,
it means you enter the PartySync Mode successfully.
8. Repeat steps 5-7 for each additional "SY126" you
would like to connect.
Audio can be adjusted from the Control
Panel or directly on your device. If " SY126 " does not show up in your
Bluetooth menu, try:
If the audio being streamed to " SY126 " is
skipping or has poor sound quality, try:
When charging , the blue grid in the working
state will increase gradually according to the
amount of electricity; When discharging, the
number of squares of the gray icon will
gradually increase according to how much
power is consumed.
It is recommended to charge the speaker
to 100% before each use to achieve the
longest playtime.
To charge , connect the included Type-C
to USB Cable to a USB output.
Recharging time: 5-6 Hours.
The lights on the battery level ( ) will flash
while charging. Once fully charged, the lights
will be always-on mode.
•Plus(+)
Single click = next song
Press and hold =volume up
•Minus (-)
Single click = restart song
Press and hold = volume down
Sound Quality
When multiple speakers
are connected the LED
lights of the control
panel will slowly blink
to indicate which
speaker is the Parent.
Tip: Disconnecting Speakers
Tip: Indicating the Parent Speaker
Turning the device's Bluetooth off, wait 15
seconds, then turn it back on.
Moving the Main " SY126 " closer to the
connected device.
Moving all paired " SY126 " Speakers
closer to the Main Speaker.
Checking for interference between the
device and the Main Speaker (walls, metal
structures , ect).
Turning the " SY126 " off, wait 15 seconds,
then turn it back on.
Forget "SY126" from all other near-by
mobile devices.
6. Power on the second speaker and single click the
Bluetooth button ( ) to turn on PartySync Mode,
you will hear "didi ”.This speaker and all additional
will be called the "Child".
Single click the Bluetooth ( ) button on any Child
speaker to disconnect from the Parent.
Single click the Bluetooth ( ) button on the Parent
speaker to disconnect all Child speakers.
5. Turn on PartySync Mode on the Parent speaker by
single clicking the Bluetooth button （ ）, you will
hear "didi ”.
Table of contents
