VanTop Moment 4U User manual

Moment 4U
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch

2
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆[phone]
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz

3
Product Overview
[Red]
Charging Indicator
Lens
2.0“ Touch screen
Power/Mode Switch
[Blue]
Working Indicator

4
Tip:
In Video Mode, short press to turn off Wi-Fi; short press to turn on the remote
control.
Speaker
Shutter/OK
Wi-Fi Indicator
Microphone
Memory Card Slot
Micro HD Port
External Mic Port
Micro USB Port
Up/Previous
Down/Next

5
Safety Warnings
Please be sure to observe the following warning, as batteries contain flammable
substances which may cause heating, rupture or ignition.
•Keep batteries out of reach of small children.
•Do not dispose of the action camera or the battery in fire.
•Do not use or charge a battery if it shows any sign of swelling, pierced, or
damaged. Misuse or mischarge may lead to smoke or even explosion.
•Do not expose the battery to any heat source, direct sunlight or high
temperature.
•Please don’t leave battery pack and charger on the wood material or carpet and
unattended.
•Make sure the charging voltage should not exceed 5V and the charging current
should not exceed 1A.
•Only use the ORIGINAL power adapter provided to charge the battery.
•Remove the battery from the charger once charging is completed.
•Charge and store the battery on an open and dry area away from furniture or
anything flammable.
•The Li-ion battery in the action camera should be serviced or recycled by an
authorized service provider, and must be recycled or disposed of separately from
the household waste.
•Dispose of the battery according to your local environmental laws and
regulations.

6
Battery Installation
1. Hold the camera and pry the battery door out with your fingernail, then install
the battery into the battery compartment.
2. To install the batter cover in the camera, please slide one end of the battery
cover into the notch of the battery compartment, then press the other end
downward.
Note:
Please make sure to install the battery cover as shown in the pictures above. If the
battery cover is installed in the wrong order, you may not press the other end of the
battery cover into place.

7
Camera Modes
After the camera is turned on, it will enter Video Mode by default.
Tip:
When recording videos, tap or press to select Audio Record and enable it,
then connect the external microphone to the camera to reduce noise and make the
sound recording clearer.
How to Switch Camera Modes
Remaining Recordable Time
Wifi Status
Video Mode
Media Gallery
Audio Record
Video Reosulution
Settings
Mode Switch
Battery Status
Memory card
Inserted

8
Video
Record normal video
Time Lapse
Record a series of videos at the set times intervals
Slow Motion
Record video in slow motion
Capture a single photo
Photo Lapse
Capture a series of photos at the set time intervals
Burst Photo
Capture photos in quick succession
Tips
Time lapse intervals and Situations Recommended
[Available intervals for time lapse photo]:
2 sec, 5 sec, 10 Sec, 20 sec.
[Available intervals for time lapse video]:
1 sec, 5 sec, 10 Sec, 30 sec, 60 sec.
Interval
Examples
1 sec
Surfing, biking or other sports
2 sec
Busy street corner
5 sec- 10 sec
Clouds or outdoor scenes with long durations
10 sec – 60 sec
Lengthy activities, such as construction or art work

9
Press on the camera to switch among Video Mode, Photo Mode, Media Gallery,
Video Settings, Photo Settings, General Setting and System Settings.
Operate with remote control
If you want to operate with remote control, please enable the function of the Remote
Control first.
Option 1
In video mode, short press on the camera.
Option 2
Tap Remote Control, then tap On twice to enable it.

10
Mode
Operate with Remote
Control
Operate on the camera
Media Gallery
Tap or press twice to enter the Media Gallery

11
Check the videos/photos saved
Photo Files
Tap or press for 3 times to switch to the interface of the photo checking.
Back
Date and Time
Delete
Photo Format

12
Delete the videos/photos saved
Option 1
On the interface of the media gallery, tap to locate the video/ photo file that needs to be
deleted, then tap to bring up the deletion option and tap YES to confirm.
Option 2
On the interface of media gallery, press to locate the video/photo file that needs
to be deleted, then long press on the camera to bring up the deletion option and
tap YES to confirm.
Option 3
On the interface of photo checking, tap to delete the file directly.

13
Settings
In video mode, tap to enter Video Settings.
On the interface of the video settings, press on the camera to switch among Photo
Settings, General Setting, and System Settings.
Tips:
•Select and press to exit and return to the video mode.
•Directly tap the icons of to switch the setting interfaces accordingly.
App
Option 1
Search and download Live DC from the APP store or Google Play, then install the app
into your mobile device.

14
Option 2:
Scan the QR code below to download and install.
Note:
Google, Android, Google Play and Other marks are trademarks of Google LLC.
Wi-Fi Connection
Turn on Camera’s Wi-Fi
Option 1
Turn on moment 4U, then short press on the camera.
Option 2:
Turn on moment4U and tap Wi-Fi, then tap On twice.

15
Connect to Camera’s Wi-Fi
Find Moment 4U in your mobile device’s Wi-Fi settings, then input password 12345678.
Launch the App Live DV

16
Maintenance
Lens Cleaner
Organic
Solvent

17
FCC Statement
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter. Any Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
This device complies with part 15 of the FCC Rules. Operations is subject to the following
two Conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measured:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different
- Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.

18
ISEDC Warning
This device complies with Innovation, Science and Economic Development Canada
License exempt RSS standars(s).
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Caution
Risk of explosion if battery is replaced by an incorrect type.
Dispose of Used batteries according to the instructions.
The symbol indicates DC Voltage

19
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g. during transport, cleaning
by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.

20
EU Declaration of Conformity
Identification data of the manufacturer's / importer's authorized representative:
Importer: Alza.cz a.s.
Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7
IČO: 27082440
Subject of the declaration:
Title: Action Camera
Model / Type: MM4U
The above product has been tested in accordance with the standard(s) used to
demonstrate compliance with the essential requirements laid down in the
Directive(s):
Directive No. (EU) 2014/53/EU
Directive No. (EU) 2011/65/EU as amended 2015/863/EU
Prague, 27.1.2021
