VARO POWERplus POWXG9417 User manual

POWXG9417 EN
Copyright © 2015 VARO NV P a g e | 1www.varo.com
1APPLICATION..................................................................................2
2DESCRIPTION (FIG A) ....................................................................2
3PACKAGE CONTENT LIST.............................................................2
4GENERAL POWER TOOL SAFETY WARNINGS ..........................2
5BEFORE START-UP, NOTE THE FOLLOWING!...........................3
6INSTALLATION................................................................................3
7SETTING TO WORK........................................................................4
7.1 Setting the ON/OFF operating point.......................................................................4
8CLEANING AND MAINTENANCE...................................................4
8.1 Maintenance guidelines..........................................................................................4
8.2 Cleaning the impeller..............................................................................................5
9TECHNICAL DATA..........................................................................5
10 SERVICE DEPARTMENT................................................................5
11 TROUBLESHOOTING .....................................................................6
12 STORAGE ........................................................................................6
13 WARRANTY.....................................................................................6
14 ENVIRONMENT ...............................................................................7
15 DECLARATION OF CONFORMITY ................................................7

POWXG9417 EN
Copyright © 2015 VARO NV P a g e | 2www.varo.com
SUBMERSIBLE PUMP 750W WITH SENSOR
POWXG9417
1 APPLICATION
This pump is used primarily as cellar pump. When installed in a shaft, the pump provides
protection from flooding.
It is also used wherever water has to be moved from one place to another, e.g. in the home,
agriculture, horticulture, plumbing and many other applications.
It is not designed for commercial use.
Pollution of the liquid could occur due to leakage of lubricants.
WARNING !For your own safety, read this manual and the general safety
instructions carefully before using the appliance. Your power tool should
only be given to other users together with these instructions.
2 DESCRIPTION (FIG A)
1. Motor housing
2. Water inlet
3. Water outlet
4. Cable & plug
5. Sensor
6. Carrying handle
3 PACKAGE CONTENT LIST
Remove all packaging materials.
Remove remaining packaging and packing inserts (if included).
Check that the package contents are complete.
Check the appliance, the power cord, the power plug and all accessories for
transportation damage.
Keep the packaging materials as far as possible until the end of the warranty period. Then
take it to your local waste disposal system .
WARNING: Packaging materials are not toys! Children must not play with
plastic bags! There is a danger of suffocation!
Submersible pump with 10m electric cable (RNF) with earthed plug
Outlet connection.
Manual
When parts are missing or damaged,
please contact your dealer.
4 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to heed warnings and follow instructions
may result in electric shock, fire and/or serious injury. Keep safety warnings and instructions
for future reference. The term "power tool" in the safety warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless) power tool.

POWXG9417 EN
Copyright © 2015 VARO NV P a g e | 3www.varo.com
5 BEFORE START-UP, NOTE THE FOLLOWING!
The pump can be connected to any shock-proof plug which has been installed according
to regulations. The plug must have a supply voltage of 230V ~ 5 Hz. Fuse min. 6 Amp.
Caution!
When the pump is to be used near swimming pools or garden ponds and in their area of
protection, it must be equipped with a PRCD (residual current circuit breaker) with a nominal
trip current of max. 30 mA (according to VDE 0100, part 702 and 738).
The pump must not be operated while people are in the swimming pool or in the garden pond!
Please contact your electrician!
Attention!
(Important for your own security) Before starting to run your new submersible pump, please
have the following items checked by an expert:
Ground connection
Zero conductor
Fault current breaker switch must correspond to the safety regulations of the power plants
and they must work faultlessly.
The electrical connections must be protected from moisture.
If there is danger of flooding, the electrical connections must be taken to higher ground.
Circulation of aggressive fluids, as well as the circulation of abrasive materials must be
avoided at all costs.
The submersible motor-driven pump must be protected from frost.
The pump must be protected from running dry.
Access on the part of children should also be prevented with appropriate measures.
Consistency
Your submersible pump is designed for the circulation of water with a maximum temperature
of 35° C. This pump may not be used for other fluids, especially motor fuels, cleaning fluids,
and other chemical products!
6 INSTALLATION
The submersible motor pump is installed as follows:
In a stationary position with fixed pipeline
or
in a stationary position with a flexible hose pipe.
Please note!
You should never install the pump by suspending it unsupported from its delivery pipe or
power cable. The submersible motor pump must be suspended from the specially provided
handle or be placed on the bottom of the shaft. To guarantee that the pump works properly,
the bottom of the shaft must be kept free of sludge and dirt of all kinds.
If the level of water sinks too far, any sludge in the shaft will dry out quickly and stop the pump
from starting up. , Therefore it is necessary to check the submersible motor pump regularly (by
carrying out start-up tests). The “switch on” point can be adjusted by repositioning the sensor
(5) in one of the 4 available positions.
Mains supply
Your new submersible pump is equipped with a shock-proof plug according to regulations. The
pump is designed to be connected to a 230-240V ~50 Hz earthed socket. Make sure that the
socket is sufficiently secured (min. 6 Amp.) and is in excellent condition. Introduce the plug
into the socket and the pump is ready to go.

POWXG9417 EN
Copyright © 2015 VARO NV P a g e | 4www.varo.com
Important Note!
If the mains cable or plug suffers any damage from external action, repairs to the cable are
prohibited.
7 SETTING TO WORK
After having read these instructions carefully, you can set your pump to work, reconsidering
the following:
Check if the pump rests on the ground of the shaft.
Check of pressure cord has been attached properly.
Check if electrical connection is 230V ~ 50 Hz.
Check if socket is in good condition.
Make sure that water and humidity can never come to the mains supply.
Avoid pump running dry.
7.1 Setting the ON/OFF operating point
The “switch on” point can be adjusted by repositioning the sensor (5) in one of the 4 possible
positions. (16, 20, 24 or, 28cm)
The switching on and off of the pump is based on the “Hall voltage” principle (the Hall effect).
(Edwin Herbert Hall (° November 7, 1855 - + November 20, 1938).
The switching on and off of the water pump is controlled by the combination of two signals: the
change of the motor speed (loaded / no load) and the change of the water level (submerged /
dry).
Operation:
1. When the pump is not submerged or runs at no load (dry), the electronic switch will
switch the pump off. If the sensor is still under water, the pump can only be restarted by
pulling the mains plug and then plugging it in again (reset).
2. When the pump is under water (loaded) and the water level is above the two touch points
(submerged), the electronic switch will start the pump after 5-6 sec.. When the water
level is below the minimum pump level (dry), the electronic switch will stop the pump.
1. When the pump motor is blocked (overloaded), the electronic switch will stop the pump.
The pump can only be restarted by pulling the mains plug off and then putting it in again
(reset).
This appliance cannot be used by children or people who are physically, mentally or
developmentally impaired, or people who lack experience or knowledge, except in case
these people receive instruction from a person responsible for their safety, a
supervisor, or by studying the preceding instructions concerning use of this appliance.
8 CLEANING AND MAINTENANCE
Attention ! Before performing any work on the equipment, pull the power
plug.
Never use solvents such as petrol, alcohol, ammonia water, etc. These
solvents may damage the plastic parts.
8.1 Maintenance guidelines
This submersible pump is an approved, maintenance-free high quality product, which is
subject to severe final controls. We recommend regular inspection and maintenance to ensure
long equipment life and uninterrupted operation.

POWXG9417 EN
Copyright © 2015 VARO NV P a g e | 5www.varo.com
Important ! Note!
Remove the mains plug before all maintenance work.
When the pump is often transported in the course of operation, it should be cleaned out
with clear water after every use.
All fibrous particles which may have built-up inside the pump housing should be removed
with a water jet.
Every 3 months the shaft ground and as should be cleaned from mud.
Remove deposits on the floater with clear water.
8.2 Cleaning the impeller
If excessive deposits collect in the pump case you must dismantle the bottom part of the pump
as follows:
1. Remove the intake cage from the pump case.
2. Clean the impeller with clear water.
Important! Do not put down or rest the pump on the impeller!
3. Re-assemble in reverse order
9 TECHNICAL DATA
type
POWXG9417
Voltage / frequency
230V~ 50Hz
Power input
750W
Delivery rate max..
13500 l/h
Delivery height max
7.5 m
Immersion depth max.
max. 7 m
Water temperature max.
35° C
Hose connection
5/4"
Foreign bodies up to
35 mm
Switching point high: ON
16, 20, 24 or, 28cm
Switching point high: OFF
ca. 5 cm
For clean/dirty water:
Dirty
Housing (plastic(P) / Stainless Steel (SS) )
SS
Water inlet (plastic / Stainless Steel (SS) )
SS
Weight
6.81kg
10 SERVICE DEPARTMENT
Damaged switches must be replaced by our after-sales service department.
If the connecting cable (or mains plug) is damaged, it must be replaced by a special
connecting cable which is available from our service department. Replacement of the
connecting cable should only be carried out by our service department (see last page) or
by a qualified specialist (qualified electrician).

POWXG9417 EN
Copyright © 2015 VARO NV P a g e | 6www.varo.com
11 TROUBLESHOOTING
Incidents
Causes
Remedies
Pump does not start
- No mains supply
- Check mains supply
No flow
- Inlet sieve is clogged
- Pressure hose in bent
- Clean inlet sieve water jet
- Reset hose
Insufficient flow
- Inlet sieve is clogged
- Reduced pumping capacity
by dirty and abrasive water
- Clean inlet sieve
- Clean pump and replace worn-
out parts
Pump switches of after
short operating period
- Thermal cutout stops pumps
due to dirty water
- Water too hot. Thermal-
cutout stops pump
- Remove mains plug. Clean
pump and shaft
- Make sure that a water tem-
perature of max. 35°C is not
exceed
12 STORAGE
Thoroughly clean the whole machine and its accessories.
Store it out of the reach of children, in a stable and secure position, in a cool and dry
place, avoid too high and too low temperatures.
Protect it from exposure to direct sunlight. Keep it in the dark, if possible.
Don’t keep it in plastic bags to avoid humidity build-up.
13 WARRANTY
This product is warranted as provided by law for a 36 months period effective from the
date of purchase by the first user.
This warranty covers all material or production flaws excluding : batteries, chargers,
defective parts subject to normal wear & tear such as bearings, brushes, cables, and
plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects
resulting from maltreatment, accidents or alterations; nor the cost of transportation.
Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
Repairs may only be carried out by an authorised customer service centre for Powerplus
tools.
You can always obtain more information at the number 00 32 3 292 92 90.
Any transportation costs shall always be borne by the customer, unless agreed otherwise
in writing.
At the same time, no claim can be made on the warranty if the damage of the device is
the result of negligent maintenance or overload.
Definitely excluded from the warranty is damage resulting from fluid permeation,
excessive dust penetration, intentional damage (on purpose or by gross carelessness),
inappropriate usage (use for purposes for which the device is not suitable), incompetent
usage (e.g. not following the instructions given in the manual), inexpert assembly,
lightning strike, erroneus net voltage. This list is not exhaustive.
Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
We reserve the right to reject a claim whenever the purchase cannot be verified or when
it is clear that the product has not been properly maintained. (Clean ventilation slots,
carbon brushes serviced regularly, etc.).
Your purchase receipt must be kept as proof of date of purchase.

POWXG9417 EN
Copyright © 2015 VARO NV P a g e | 7www.varo.com
Your appliance must be returned undismantled to your dealer in an acceptably clean
state, (in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.
14 ENVIRONMENT
Should your appliance need replacement after extended use, do not dispose of it
with the household refuse, but in an environmentally safe way.
Waste produced by electrical machine items should not be handled like normal
household rubbish. Please recycle where recycle facilities exist. Check with your
Local Authority or retailer for recycling advice.
15 DECLARATION OF CONFORMITY
VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that,
product : submersible pump
trade mark : POWERplus
model : POWXG9417
is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives, based on the application of European harmonized standards. Any
unauthorized modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amendments up to the date of signature);
2011/65/EU
2006/95/EC
2004/108/EC
European harmonized standards (including, if applicable, their amendments up to the date of
signature);
EN60335-1 : 2013
EN60335-2-41 : 2003
EN55014-1 : 2006
EN55014-2 : 1997
EN61000-3-2 : 2006
EN61000-3-3 : 2013
Keeper of the Technical Documentation : Philippe Vankerkhove, VARO –Vic. Van Rompuy
N.V.
The undersigned acts on behalf of the company CEO,
Hugo Cuypers
Regulatory Affairs –Compliance Manager
Date: 31/10/2014
