1APPLICATION..................................................................................2
2DESCRIPTION (FIG A) ....................................................................2
3PACKAGE CONTENT LIST.............................................................2
4SYMBOLS........................................................................................2
5SPECIFIC SAFETY WARNINGS.....................................................3
6ASSEMBLY......................................................................................3
6.1 Electrical connection..............................................................................................3
6.2 Earth ........................................................................................................................3
7OPERATION.....................................................................................3
7.1 Pressure hose.........................................................................................................4
7.2 Safety requirements................................................................................................4
8CLEANING AND MAINTENANCE...................................................5
8.1 Cleaning...................................................................................................................5
9TECHNICAL DATA..........................................................................5
10 NOISE...............................................................................................5
11 TROUBLE SHOOTING ....................................................................6
12 WARRANTY.....................................................................................7
13 ENVIRONMENT ...............................................................................8
14 DECLARATION OF CONFORMITY ................................................8

POWXG9571 EN
Copyright © 2018 VARO NV P a g e | 2www.varo.com
PRESSURE PUMP 600W 19L HOUSE
POWXG9571
1 APPLICATION
This electrical pressure pump with pressure tank is only suitable to use indoors.
Not suitable for professional use.
WARNING! Read this manual and general safety instructions carefully
before using the appliance, for your own safety. Your power tool should
only be passed on together with these instructions.
2 DESCRIPTION (FIG A)
1 On/off switch
2 motor housing
3 water inlet
4 water outlet
5 cable & plug
6 Carrying handle
7 Integrated filter
3 PACKAGE CONTENT LIST
▪Remove all packing materials
▪Remove remaining packaging and transit supports (if existing)
▪Check the completeness of the packing content
▪Check the appliance, the power cord, the power plug and all accessories for transportation
damages.
▪Keep the packaging materials as far as possible till the end of the warranty period.
Dispose it into your local waste disposal system afterwards.
WARNING Packing materials are no toys! Children must not play with
plastic bags! Danger of suffocation!
1 x Water Pump with 1.2m electric cable
1 x Manual
1 x Key for filter cover
When parts are missing or damaged, please contact your dealer.
4 SYMBOLS
In this manual and/or on the machine the following symbols are used:
Denotes risk of personal
injury or damage to the tool.
In accordance with essential
safety standards of applicable
European directives
This appliance cannot be used by children or people who are physically,
mentally or developmentally impaired, or people who lack experience or
knowledge, except in case these people receive instruction from a person
responsible for their safety, a supervisor, or by studying the preceding
instructions concerning use of this appliance.

POWXG9571 EN
Copyright © 2018 VARO NV P a g e | 3www.varo.com
5 SPECIFIC SAFETY WARNINGS
▪This water pump has no water-sprinkling protection feature and should be placed only in a
dry environment. Never place the water pump or operate it in the rain or in a humid space.
▪This water pump should not be used with flammable or harmful liquids.
▪Idle operation of the water pump must be avoided.
▪This water pump is for work in clean water. The scope of its application includes irrigation
in the garden, water supply to a household, sprinkling in a garden or on farmland.
▪This water pump may not be exposed for long periods to impurities, sand, stone, sticky
substances, etc., mixed in with the conveyed media. Because the conveyed media may
contain chemical corrosive substances, it is necessary to pay special attention to
preventing influence by these on the material of the pump body. It is not permitted to use
this water pump to convey drinking water.
This appliance cannot be used by children or people who are physically,
mentally or developmentally impaired, or people who lack experience or
knowledge, except in case these people receive instruction from a person
responsible for their safety, a supervisor, or by studying the preceding
instructions concerning use of this appliance.
6 ASSEMBLY
▪During the installation of the water pump, the power supply to the water pump must be
switched off.
▪During installation of the equipment, it is necessary to keep it under dry and well-ventilated
conditions, at an ambient temperature below 40°C.
▪If the required pumping water is excessive due to your own action, resulting in flooding of
the irrigation site, a number of protective measures may be taken (e.g. installation of a
device for discharging the excess water, an alarm, standby pump, water container, etc.).
However, our company is not responsible for any losses thus caused.
▪Before use, the water pump should be inspected for safety to ensure that there is no
damage to the power cable or the plug.
6.1 Electrical connection
▪The electrician responsible for installation must check to ensure that the electrical
connection is in accordance with the standard, including the earth terminal.
▪It is necessary to check the rated current of the electric contact with protective switch - this
must be 30mA.
6.2 Earth
The water pump must be well earthed. Short-circuiting will render the relevant articles of the
guarantee invalid. If it is necessary to increase the length of the original cable, a cable with the
same section as the original cable must be used.
7 OPERATION
The pumps are not self-priming pumps. This means that the suction hose should first of all be
fitted with:
1 Non-return valve with filter; this ensures that, after disconnecting the pump, the hose
and the pump do not run dry. This part of the hose is suspended in the water to be
pumped away.
2 Hose with coupling nut; this end of the hose is attached to the front of the pump.
3 Both accessories should be securely screwed on to the hose using a hose clip.

POWXG9571 EN
Copyright © 2018 VARO NV P a g e | 4www.varo.com
Before fastening the hose to the pump, it is best to fill it with water first. After this you can
screw the three-way cock or another 25mm (1") connector to the outlet on the pump; this is
on the top of the pump.
Then you should fill the pump housing with water through the build-in filter; then re-seal it.
If the pump housing and the hose have both now been filled with water, you can switch on the
pump using the on/off switch. The pump now immediately begins to pump water (in the case
of the auto version, the pressure tank is first filled and it takes a few seconds before water
comes out of the connected hose).
If the pump is subsequently switched off again, water remains in the pump housing and the
hose which means that when the pump is next switched on it will pump water immediately.
If no non-return valve is fitted or if the seal between the valve and the hose is not working
properly (hose clip!) the whole unit may run dry again and must be re-filled to get the pump to
work properly.
7.1 Pressure hose
The pressure hose is used for conveying the water from the pump to the water consumption
point (e.g. tap, etc.). In order to minimize the friction loss caused by the water pressure, we
recommend that you use a pressure hose with a minimum diameter of 20mm (3/4").
▪When the garden pump is working, the water outlet (e.g. tap or water sprinkling outlet)
must be open so as to discharge the air from the hose. If the water outlet is closed, the
pump may be damaged due to overheating of the pump after working for more than 5
minutes.
▪Freezing of the pump or placing it in a frosty space in the winter must be avoided.
▪Sand and stones in the water taken in can rapidly wear the pump and reduce its effective
capacity. It is therefore necessary to install a filter.
▪This water pump is not suitable for long-term operation, e.g. in industrial or mining
enterprises or for a water recycling system.
7.2 Safety requirements
▪The power supply must comply with the specifications displayed on the product. Refer to
the instructions of your local energy supplier if necessary for connecting conditions. If the
pump or the power cable do not comply, do not connect the pump!
▪Never carry the pump by the cable.
▪Never remove the plug and never shorten the cable. If you do, you will invalidate your
guarantee. Keep the connection (plug and socket) dry.
▪The pump is not suitable for use in swimming pools and lakes or other situations where
persons could come into physical contact with the water, and must therefore not be used
for this purpose.
▪Always disconnect the pump from the power supply when cleaning it or carrying out
maintenance to the pond. This pump is suitable for pumping water with a minimum
temperature of 4 °C and a maximum temperature of 35 °C.
▪The pump must not run dry, as this will cause irreparable damage.
▪Always disconnect the pump from the mains supply before cleaning or maintenance.
▪Clean the chambers from time to time, rinsing them with clean water, to ensure they are
not clogged with dirt.

POWXG9571 EN
Copyright © 2018 VARO NV P a g e | 5www.varo.com
8 CLEANING AND MAINTENANCE
Attention !Before performing any work on the equipment, pull the power
plug.
8.1 Cleaning
Under normal conditions, the water pump is free of maintenance. However, the pump should
not be placed in the open air during rain, in a humid place, or dirty or frozen environment.
▪Freezing, idling or blocking by impurities should be avoided.
▪Always disconnect the power supply before maintenance of the pump.
▪If the power cable is damaged, it must be replaced by professional personnel. Damage
caused by short circuiting is not included in scope of the guarantee.
▪If trouble with the pump is experienced, guaranteed repairs must be carried out by an
authorized maintenance center.
Never use solvents such as petrol, alcohol, ammonia water, etc. These
solvents may damage the plastic parts.
9 TECHNICAL DATA
type
POWXG9571
Mains voltage / frequency
230V~ /50Hz
Rated power
600W
Max. pump capacity
3000 l/hour
Max. lift
35 m
Maximum suction level
7 m
Max. water temperature
35°C
Min. diameter of suction hose
1” (25mm)
Min. diameter of pressure hose
3/4” (20mm)
Cable length
1,2 m
Rated pressure
0,35 mPa –3,5 bar
Int. protection Degree
IPX4
Weight
11.56Kg
Suitable for
Clean water
Contents pressure tank
19L
Material pump housing / Tank
PP / Metal
10 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
67 dB(A)
Acoustic power level LwA
85 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).

POWXG9571 EN
Copyright © 2018 VARO NV P a g e | 6www.varo.com
11 TROUBLE SHOOTING
PROBLEM
POSSIBLE CAUSE
SOLUTION
The electric motor is
running but the pump
does not suck water
After the pump
starts, the pump
body does not fill
with water
Fill the pump with water
Insufficient tightness
of the suction hose
Check the recommended and used pans
and components of the pump, e.g. joint of
the suction nose, joint of the pressure hose,
clamping ring, suction hose, etc., including
screw sealing strip made from Teflon or
hemp cord. The pump can work only when
well sealed
The filter screen of
the non-return valve
of the sucking inlet is
blocked
Clean the non-return of the sucking inlet and
the filter screen
The air can't be
released from the
pressure hose
because the water
outlet is closed
When the pump starts sucking, open the
water outlet (e.g. the tap. sprinkling nozzle
etc.)
The waiting time
does not correspond
to the regulations
Fill the whole suction hose with water, or
recheck it at least 7 minutes after the pump
starts
Excessive suction
head (>8m)
Reduce the suction head
The non-return fails
to suck water
Check the water level of the well or the
water pool. If possible, increase the length
of the suction hose.
The electromotor
cannot run
No power supplied
Check the power supply
The ventilator hood
obscures rotation of
the vane
Pull out the power plug, remove the
ventilator hood with a screwdriver, then
reinstall it again by slightly rotating the vane
and check to see if it rotates freely
Fan blocked
Pull out the power plug, move the shaft with
the screwdriver through the ventilator hood.
If the shaft is blocked, send it to a service
center for inspection
Insufficient water flow-
out
Excessive suction
head (>8m)
Check the suction head
The filter screen of
the non-return is
blocked
Clean the filter screen
The suction water
level lowered too
much
Immerse the non-return in deep water

POWXG9571 EN
Copyright © 2018 VARO NV P a g e | 7www.varo.com
PROBLEM
POSSIBLE CAUSE
SOLUTION
Impurities have
reduced the effective
capacity of the pump
Wash the shell of the pump, the suction
hose and the outlet pressure hose with
pressurized water
The heat-sensitive
switch cannot switch-
off the pump
Over-load of the
electric motor due to
friction caused by
impurities entering
the motor
Wash the shell of the pump with pressured
water
The switch of the
pump is always OFF
or ON
No non-return valve
installed on the
suction hose
Check to see if a valve is installed on the
suction hose
Frequent switching
ON/OFF of the pump
switch (when used for
household water
supply system)
Rupture of the
rubber envelope in
the pressure tank
Replace the rubber envelope or the
container
No compressed air
in the container
Use an adequate valve and conned this with
a compressed air supply at 1.8 bar, and fill
the container with air
12 WARRANTY
▪This product is warranted as provided by law for a 36 months period effective from the
date of purchase by the first user.
▪This warranty covers all material or production flaws. It does not include defective parts
subject to normal wear & tear such as bearings, brushes, cables, and plugs, or
accessories such as drills, drill bits, saw blades, etc. ; damage or defects resulting from
maltreatment, accidents or alterations; nor the cost of transportation.
▪Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
▪We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
▪Repairs may only be carried out by an authorized customer service center for Powerplus
tools.
▪You can always obtain more information at the number 00 32 3 292 92 90.
▪Any transportation costs shall always be borne by the customer, unless agreed otherwise
in writing.
▪At the same time, no claim can be made on the warranty if the damage of the device is the
result of negligent maintenance or overload.
▪Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike,
erroneus net voltage. This list is not exhaustive.
▪Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
▪Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
▪We reserve the right to reject a claim whenever the purchase cannot be verified or when it
is clear that the product has not been properly maintained. (Clean ventilation slots, carbon
brushes serviced regularly, etc.).
▪Your purchase receipt must be kept as proof of date of purchase.

POWXG9571 EN
Copyright © 2018 VARO NV P a g e | 8www.varo.com
▪Your appliance must be returned undismantled to your dealer in an acceptably clean state,
(in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.
13 ENVIRONMENT
Should your appliance need replacement after extended use, do not discard it
with the household rubbish but dispose of it in an environmentally safe way.
Waste produced by electrical machine items should not be handled like normal
household rubbish. Please recycle where recycle facilities exist. Check with your
Local Authority or retailer for recycling advice.
14 DECLARATION OF CONFORMITY
VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that,
Product: Pressure Pump 600W 19l House
Trade mark: POWERplus
Model: POWXG9571
is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives, based on the application of European harmonized standards. Any
unauthorized modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amendments up to the date of signature);
2014/30/EC
2014/35/EC
2000/14/EC Annex V LwA 80dB(A) / 85dB(A)
2011/65/EU
European harmonized standards (including, if applicable, their amendments up to the date of
signature);
EN60335-1: 2012
EN60335-2-41: 2003
EN55014-1: 2006
EN55014-2: 2015
EN61000-3-2: 2014
EN61000-3-3: 2013
Keeper of the Technical Documentation : Philippe Vankerkhove, VARO –Vic. Van Rompuy
N.V.
The undersigned acts on behalf of the company CEO,
Hugo Cuypers
Regulatory Affairs –Compliance Manager
28/09/2017
