Varytec LED Par 14 x 8W User manual

User manual
LED Par 14 x 8W

2 / 8
Table of contents
1. Safety instructions............................................................................................................................ 3
1.1. FOR SAFE AND EFFICIENT OPERATION............................................................................ 3
2. Technical data.................................................................................................................................. 4
4. Operating Instruction:....................................................................................................................... 5
4.1. Auto function............................................................................................................................ 5
4.2. Master/Slave Function............................................................................................................. 6
5. Dmx Chart ........................................................................................................................................ 7

3 / 8
1. Safety instructions
•This device is suitable for indoor use only.
•All modifications to the device will void the warranty.
•Repairs are to carry out by skilled personnel only.
•Use only fuses of the same type and original parts as spare parts.
•Protect the unit from rain and humidity to avoid fire and electric shocks.
•Make sure to unplug the power supply before opening the housing.
1.1.FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32°F /0°C, or ex ceeding 104°F /40°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,
do not open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure
to hold the plug. When not using the device for an extended period of time, be sure to
disconnect the plug from the receptacle
.

4 / 8
Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems. Make sure the electrical connection is carried out by qualified
personnel. All electrical and mechanical connections have to be carried out
according to the European safety standards.
2. Technical data
Technical specifications:
Output
Lux@2m 2060Lux
Lux@4m 560Lux
Lux@6m 250Lux
Lux@8m 150Lux
Light source
LED Qty. 14*8W (4in1 LEDs)
Driver current 500mA
Color range 16.7million color
Electrical Input voltage 100-240VAC
Power 90W
Control
On-board Four digital display
Control protocol DMX512
Channel mode 8 Channels
Optical system
dimmer 0-100%
strobe 0-20Hz
Beam angle 25°
Weight 5kg
Size 240*190*280mm
Housing Die-cast aluminum
Fixture connection Signal in/out power in/out
Fixture Connection
Qty 220VAC：36pcs, 110VAC:18pcs
Cooling Convective heat transfer
Certificate CE and IP65
Environment IP65
Operation
Temperature
-40°C~50°C(operation)
-20°C~50°C(start up)

5 / 8
4. Operating Instruction:
1.Four Buttons: Menu, Up, Down, Enter
2.Four digital display dormant state after one minutes working,
4.1.Auto function
MENU is a function key ton enter the functions menu.
Press UP,DOWN keys to scroll the menu points
These menus are described as follows:
Addr: DMX function. Press ENTER key to display Axxx. Press UP to increase the data,
Press DOWN to reduce the data, press and hold UP or DOWN to adjust the value for
DMX address quickly.
rL-- Red Dimmer. Press ENTER key to display rLxx. Press UP to increase the data, Press
DOWN to reduce the data, press and hold UP or DOWN to adjust the value for
Brightness quickly. There are 16 steps for brightness from rL00 up to rL15.
gL -- Green Dimmer. Press ENTER key to display gLxx. Press UP to increase the data,
Press DOWN to reduce the data, press and hold UP or DOWN to adjust the value for
Brightness quickly. There are 16 steps for brightness from gL00 up to gL15.
bL -- Blue Dimmer. Press ENTER key to display bLxx. Press UP to increase the data, Press
DOWN to reduce the data, press and hold UP or DOWN to adjust the value for
Brightness quickly. There are 16 steps for brightness from bL00 up to bL15.

6 / 8
oL -- White Dimmer. Press ENTER key to display oLxx. Press UP to increase the data,
Press DOWN to reduce the data, press and hold UP or DOWN to adjust the value for
Brightness quickly. There are 16 steps for brightness from oL00 up to oL15.
FLAS Strobe effect. Press ENTER key to display FLxx. Press UP to increase the data, Press
DOWN to reduce the data, press and hold UP or DOWN to adjust the value for Strobe
speed quickly. There are 16 steps for speed from FL00 up to FL15.
ASC- Seven Colors running effect. Press ENTER key to display ASxx. Press UP to increase
the data, Press DOWN to reduce the data, press and hold UP or DOWN to adjust the
value for program speed quickly. There are 16 steps for speed from AS00 up to AS15.
CE-- Chasing way effect. Press ENTER key to display CExx. Press UP to increase the
data, Press DOWN to reduce the data, press and hold UP or DOWN to adjust the
value for the way of chasing quickly. There are 16 kind of chasing from CE00 up to
CE15.
FAdE Fade in and Fade out. Press ENTER key to display FAxx. Press UP to increase the
data, Press DOWN to reduce the data, press and hold UP or DOWN to adjust the
value for Fade speed quickly. There are 16 steps for speed from FA00 up to FA15.
4.2.Master/Slave Function
Set up the DMX address 1 for all slave items. The unit which you told to work in program or setting as
described above is automatically the master sending dmx data to the slaves. Make sure that the
master is always the first item in line. If you use other fixtures controlled by dmx in this line they will do
strange stuff because they will get the same dmx data as the other par cans.

7 / 8
5. Dmx Chart
CH1 0-255 Main dimmer
CH2 0-255 Red dimmer
CH3 0-255 Green dimmer
CH4 0-255 Blue dimmer
CH5 0-255 White dimmer
CH6
1-14：pure white 15-29：White 30-44：light blue 45-59：Blue 60-74：Purple
75-89：Bluish violet 90-104：reddish violet 105-119：peach blossom
120-134：pink 135-149：red 150-164：orange
165-179：yellow 180-194：lime 195-209：light green 210-224：green
225-239：bluish green 240-254：cyan
CH7 0-255 strobe peed from slow to fast(grey scale is set by CH1,
CH2, CH3,CH4,CH5 and CH6)
CH8
6-240 gradual change speed from slow to fast;
241-254 Running
255 off

8 / 8
Importer:
B & K Braun GmbH
Industriestraße 1
D-76307 Karlsbad
www.bkbraun.com
