Varytec LED Par 64 Floor 5in1 User manual

User manual
LED Par 64 Floor 5in1
7x10W RGBWA

2 / 8
Table of contents
1. Safety instructions............................................................................................................................ 3
1.1. FOR SAFE AND EFFICIENT OPERATION............................................................................ 3
2. Technical Information....................................................................................................................... 4
3. Menu structure ................................................................................................................................. 4
4. DMX Table ....................................................................................................................................... 6
4.1. DMX Mode 1 (1 Channel)........................................................................................................ 6
4.2. DMX Mode 2 (2 Channel)........................................................................................................ 6
4.3. DMX Mode 3 (7 Channel)........................................................................................................ 6
4.4. DMX Mode 4 (9 Channel)........................................................................................................ 6
5. Technical Data ................................................................................................................................. 8

3 / 8
1. Safety instructions
•This device is suitable for indoor use only.
•All modifications to the device will void the warranty.
•Repairs are to carry out by skilled personnel only.
•Use only fuses of the same type and original parts as spare parts.
•Protect the unit from rain and humidity to avoid fire and electric shocks.
•Make sure to unplug the power supply before opening the housing.
1.1.FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32°F /0°C, or exceeding 104°F /40°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,
do not open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure
to hold the plug. When not using the device for an extended period of time, be sure to
disconnect the plug from the receptacle
.

4 / 8
Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems. Make sure the electrical connection is carried out by qualified
personnel. All electrical and mechanical connections have to be carried out
according to the European safety standards.
2. Technical Information
- Full DMX 512 control
- DMX Modes with 1, 2, 7 or 9 Channels
- Sound controlled via built-in microphone
- Adjustable sound sensitivity
- Function: Colour mix
Automatic colour change
Built-in programs
Strobe effect with adjustable speed
Dimmer
Master/slave
- LED-display
- 3 Pin XLR Input & Output Neutrik
- Lens degree 15°
- 7 x 10W 5in1 LEDs
3. Menu structure
Addr
1 Adjust the DMX address: 1…512
512
Auto
Au 1 Au 1…Au 19: 19 programs
…
Au 20 Au 20: System all mode loop run
SPEd
0 Adjust Program speed
31 0=off 1-31=slow-fast
SLAU
SLA Light working master
CHNd
CH 1
4 DMX modes: CH 1…CH 9
CH 2
CH 3
CH 9
SenS
Off-99 Off: Close sound mode 1-99 Sound sensitivity adjust

5 / 8
Menu
Sound
Sou 1 static colour change
Sou 2 sound flash colour change
MASt
On/Off On: open master signal, Off: close master signal
ALLC
0…100 Setup LED master dimmer
rEd
0…100 Setup red LED dimmer
grEE
0…100 Setup green LED dimmer
bLUE
0…100 Setup blue LED dimmer
HITE
0…100 Setup white LED dimmer
AMb
0…100 Setup amber LED dimmer
Led
On Display on
30
Switch display off after 30, 60, 90, 120 seconds…
120
test
OFF OFF = close test function
1 Test red LED
2 Test green LEDs
3 Test blue LEDs
4 Test white LEDs
5 Test amber LEDs
disp
disp/dsip Display normal or inversion
uer
Readout software version
rset
Reset all values of the system
uPdA
Software update
sign
ON/OFF ON for master freeze, OFF for master blackout
CoLr
Selective colour 1-17
TEMP
Readout system temperature
Tips: Push the MENU-bottom to reach the first menu and use the UP/Down-bottoms to get to submenu. To open the
submenu you have to push the ENTER-bottom, here you can also reach other menu items with the UP/DOWN-
bottoms, confirm with ENTER. Push the MENU-bottom to store you settings.

6 / 8
4. DMX Table
4.1.DMX Mode 1 (1 Channel)
DMX Value Function
Channel
1 0-255 0 = Off 1-255 = 36 different colour macros
4.2.DMX Mode 2 (2 Channel)
DMX Value Function
Channel
1 0-255 0 = Off 1-255 = 36 different colour macros
2
0-255 0 = Off 1-255 = Master dimmer
4.3.DMX Mode 3 (7 Channel)
DMX Value Function
Channel
1 0-255 Adjust red LEDs dimmer low to high
2 0-255 Adjust green LEDs dimmer low to high
3 0-255 Adjust blue LEDs dimmer low to high
4 0-255 Adjust white LEDs dimmer low to high
5 0-255 Adjust amber LEDs dimmer low to high
6 0-255 0 = Off 1-255 = Master dimmer
7 0-255 0-8 = LED flash off
9-255 = speed of shutter/special functions slow-fast, sensitivity
4.4.DMX Mode 4 (9 Channel)
DMX Value Function
Channel
1 0-255 Adjust red LEDs dimmer low to high
2 0-255 Adjust green LEDs dimmer low to high
3 0-255 Adjust blue LEDs dimmer low to high
4 0-255 Adjust white LEDs dimmer low to high
5 0-255 Adjust amber LEDs dimmer low to high
6 0-255 0 = Off 1-255 = Master dimmer

7 / 8
7 0-255
0-8 = LED flash off
9-255 = speed of shutter/special functions slow-fast, sound
sensitivity
8 special function
0-9 LED flash
10-19 automatic dimming (upwards)
20-29 automatic dimming (downwards)
30-39 automatic dimming (upwards/downwards)
40-49 colour change (5 colours)
50-59 colour change (30 colours)
60-69 colour shift
70-79 colour shift (8 colours)
80-89 colour flash change (5 colours)
90-99 colour change (30 colours)
100-109 colour change (40 colours)
110-119 colour change (10 colours)
120-129 colour change (48 colours)
130-139 LED flash (32 colours)
140-149 colour shift red/green
150-159 colour shift red/blue
160-169 colour shift red/white
170-179 colour shift white/green
180-189 colour shift white/blue
190-199 colour shift green/blue
200-209 colour shift red/green/blue/white
210-219 colour shift red/green/amber/white
220-229 colour shift red/blue/amber/white
230-239 All program mode run
>240 colour change sound controlled
9 0-127 static colour change sound controlled
128-255 flash colour change sound controlled

8 / 8
5. Technical Data
Power supply: 100-240V AC, 50-60Hz
Power consumption: max. 100W
LED: 7 x 10W 5in1 RGBWA
LED lifetime: > 50.000 hours
Measurements: 290mm x 285mm x 410mm (L x W x H)
Weight: 3,40 kg
Housing material: Aluminium
Protection class: IP 20
Cooling: regulated fan cooling > 60°C
Importer:
B & K Braun GmbH
Industriestraße 2
D-76307 Karlsbad
www.bkbraun.com
[e-mail]
