Vebabox Tuc1800 User manual

User Manual VebaBox

equipped with TUC1800 or

TUC2000

VebaBox Cool Solutions

[email protected]

www.vebabox.com

TUC1800/2000-usm. rev.01

EN 3 User Manual VebaBox equipped TUC1800 or TUC2000

NL 21 Gebruikershandleiding VebaBox met TUC1800 of TUC2000

DE 39 Bedienungsanleitung für VebaBox mit TUC1800 oder

TUC2000

ES 58 Manual del usuario VebaBox equipado con TUC1800 o

TUC2000

FR 76 Manuel utilisateur Vebabox équipée de TUC1800 ou

TUC2000


TUC1800/2000-usm. rev.01
© 2020 VebaBox B.V. User Manual VebaBox+TUC1800 or TUC2000

Content

Introduction...........................................................................4
General safety rules during use of product ..........................9
Application............................................................................9
Product assembly specifications ........................................10
Operation............................................................................12
Cleaning and maintenance.................................................17
Packaging material and safe disposal of products.............17
Troubleshooting..................................................................18
Warranty.............................................................................19







TUC1800/2000-usm. rev.01

1. Introduction

Dear Customer,

Thank you for choosing VebaBox. This custom-made product is

designed for storage and transport of goods sensitive to temperature

fluctuations and assures stable temperature of your goods at desired

level. Read the following manual carefully prior to using your

product.

CAUTION:

This manual is published for informational purposes only. VebaBox company

makes no warranties, expressed or implied, with respect to the information and

descriptions contained in this manual. Such information and descriptions

should not be regarded as all-inclusive or covering all contingencies but with

intention for better understanding of our product. In the event you have any

questions or require further information, please contact your local VebaBox

authorized representative.

The procedures described herein should only be undertaken by suitably

qualified personnel. Failure to implement these procedures correctly may

cause damage to the VebaBox unit or other property or personal injury.

The VebaBox company and its affiliates shall not be liable in contract or tort

(including negligence and/or strict liability) or otherwise, to any person or

entity for any personal injury, property damage or any other direct, indirect,

special or consequential damage or liability whatsoever, arising out of or

resulting from any actions by any person that are contrary to this manual or

any of the information, recommendations or descriptions contained herein or

the failure of any person to implement the procedures described herein

correctly or to follow caution and safety decals located on the VebaBox unit!

Safety Precautions

VebaBox is a specialized custom-made product that contains electric

and cooling circuits, installation, use and maintenance of which are

subordinated to special directives and regulations for protection of

human health and global environment.

This is why the VebaBox company as legal owner of the product

design and manufacturer declares and warns that only appointed

qualified distributors and technical services are authorized to install

and to service the VebaBox products.

TUC1800/2000-usm. rev.01

During normal product usage the users should be aware of the

following dangers.

CAUTION: Danger of fatal injury from electric shocks! When using the

VebaBox, if the VebaBox is powered by 110-230 VAC, ensure that the power

supply has a power circuit breaker! Check that the voltage specification on the plug label

is the same as that of the power supply.

Only connect the VebaBox as follows:

• with the 12 V VebaBox power supply installation set installed by an authorized VebaBox

specialist to the electric circuit of the car and/or to the battery.

• or, with the 110-230 V connection cable included with the VebaBox to the 110-230 V AC

supply.

If the cable is damaged, it must be replaced to prevent possible electrical hazards.

Disconnect the connection cable before cleaning and maintenance, after use and before

changing a fuse.

CAUTION: Danger of injuries! Batteries contain aggressive and caustic

acids. Avoid battery fluid coming into contact with your body. If your skin does

come into contact with battery fluid, wash the part of your body in question thoroughly

with water. Disconnect the VebaBox and other electric devices from the battery before you

connect the battery to a quick charging device. Overvoltage can damage the electronics of

the VebaBox.

CAUTION: The VebaBox is not intended for use by children and teenagers

or invalid persons unless they have been adequately supervised by a responsible

person to ensure that they can use the appliance safely.

Do not operate the VebaBox if it is visibly damaged. The VebaBox may only be repaired

by qualified personnel. Inadequate repairs can cause considerable hazards. If your

VebaBox should need repairing, please contact your local distributor.

Do not open the refrigerant circuit under any circumstances!

The VebaBox is not suitable for transporting caustic substances or substances containing

solvents.

Food and pharma products should be stored in their original packaging and/or packed

into suitable containers only

TUC1800/2000-usm. rev.01

CAUTION: Use tools with insulated handles that during operation and

maintenance of VebaBox are in proper condition only.

CAUTION: Danger of fatal injury due to electric shocks! Do not touch

exposed cables with your bare hands. This especially applies when operating the

VebaBox from an AC power supply.

Before starting the VebaBox ,make sure that the power supply line and the plug are dry.

Do not place any electrical devices connected to a live electric power source inside the

cooling container.

Set up the VebaBox in a dry location where it is protected against splashing water. Protect

the VebaBox and the cable against rain and moisture. Do not place it near open flames or

other heat sources (heaters, direct sunlight, gas ovens etc.).

CAUTION: Danger of overheating! Always make sure there is sufficient

ventilation so that heat generated during normal operation can dissipate.

Ensure that the ventilation slots are not covered.

Leave at least 100 mm free from the top and around the VebaBox to ensure adequate

ventilation.

Never immerse the VebaBox in water. Do not fill the inner container with ice or fluid.

WARNING: Always wear goggles or safety glasses when working with or

around the refrigeration system or battery. Refrigerant or battery acid cancause

permanent damage if it comes in contact with your eyes.

WARNING: Control circuits (except of 110 –230V AC power supply input)

used in the VebaBox are low voltage. This voltage potential is not considered life

threatening, but the large amount of current available can cause severe burns if shorted

to ground.

WARNING: Do not wear jewelry, watches, or rings. These items can shortcut

electrical circuits and cause severe burns to the wearer.

TUC1800/2000-usm. rev.01

IMPORTANT: VebaBox cannot be held liable for claims

for damage resulting from the following:

• Misuse, improper installation, abnormal servicing, storage of

hazardous chemicals, use of corrosive substances, transit damage,

recharging of cooling system, accident, fire, improper repair, tampering

or abuse.

• Incorrect voltages or faults with regard to power supply which falls

outside of the VebaBox operating parameters.

First Aid

First Aid–Refrigerant

Eyes: After contact with liquid, immediately flush eyes with large amounts of

water. Get prompt medical attention.

Skin: Flush touched areas with large quantities of lukewarm water. Donot apply

heat. Wrap burns with dry, sterile, bulky dressing to protect from infection or

injury. Get prompt medical attention.

Inhalation: Move affected person to fresh air and restore breathing if

necessary. Stay with victim until arrival of emergency medical personnel.

First Aid –Refrigerant Oil

Eyes: Immediately flush eyes with large quantities of water for at least 15

minutes while holding the eyelids open. Get prompt medical attention.

Skin: Remove contaminated clothing. Wash thoroughly with soap and water. Get

medical attention if irritation persists.

Inhalation: Move the victim to fresh air and restore breathing if necessary. Stay

with the victim until arrival of emergency personnel.

TUC1800/2000-usm. rev.01

Ingestion: Do not induce vomiting. Immediately contact local poison control

center or physician

First Aid –Electric shock

First: Immediately disconnect the electric power source in the safest way (switch

off the car engine, or emergency switch or disconnect / cut off the live circuit with

a suitable insulated tool).

Second: When you are sure that the power is off remove the victims from the

dangerous area and put them in anti-shock position

Third: Call your local medical emergency aid and act according to their

instructions until the medical aid specialist comes to take over and provide

further aid.

First Aid–Burns from heat

First: Immediately remove the victims from the source of heat in the safest way.

Second: When you are sure that the heat source is eliminated put the victims in

anti-shock position

Third: Call your local medical emergency aid and act according to their

instructions until the medical aid specialist comes to take over and provide further

aid.

TUC1800/2000-usm. rev.01

2. General safety rules during use of product

WARNING: Failure to comply with safety regulations may result in

death or serious injury and/or damage to the product or its

surroundings. Read this manual carefully and keep it with the

product at all times.

•Pay attention to the weight of the product and make sure that

you, or the devices used, can carry the weight.

•The product must not be placed on sloping surfaces.

•Load in VebaBox has to be placed securely. Sidewalls must

not be exposed to permanent pressure. VebaBox sidewalls

are not designed to carry permanent loads.

•Please read the operating instructions carefully before

connecting the product.

•Never insert objects into the ventilation openings or fans.

•Do not obstruct air circulation by covering the grilles with

objects.

•Do not damage any parts of the cooling system containing

refrigerants by punching, perforating, crushing, bending or

otherwise. Risk of serious frostbites from evaporating

refrigerant.

•Follow your local regulations for hazardous substances as

refrigerants: risk of fire or explosion.

•Never touch the heat exchanger with bare hands. Risk of

finger cuts on sharp ribs.

•Floor might be slippery.

3. Application

The basic function of VebaBox is to maintain the goods inside it at a

regulated, stable and adjustable temperature while the box is

TUC1800/2000-usm. rev.01

submitted to fluctuating ambient temperatures in the range of -20;

+40°C for TUC1800 or -20;+50°C for TUC2000.

CAUTION: The VebaBox is not constructed for cooling goods down. This

means, that goods should be preconditioned to the required temperature

before being put into the box.

CAUTION: When loading the box, allow clearance around air intake and

outlet of the unit. Goods should be stacked to allow at least a 10 cm gap directly

below the ceiling of the box. Do not place goods directly under the heat

exchanger –risk of dripping water.

The VebaBox TUC180 / TUC2000 is intended to be installed in the

closed superstructures of any type of cargo vans equipped with an

alternator power source of 12V / 100A DC minimum. The unit is

available both for installation on one side panel of the box (TUC180B

/ TUC200B) or installation on top of the box (TUC180T / TUC200T).

4. Product assembly specifications

The product assembly consists of

a) Basic parts

1. VebaBox body

2. Thermal unit TUC1800 / TUC2000–monoblock

3. Power supply cable set

4. Mechanical fixing set

b) Accessories (optional)

1. Remote controller

2. LED lighting inside the VebaBox

3. Power packs

TUC1800/2000-usm. rev.01

VebaBox body

Volume range

(0.5-2) m³

Wall thickness

Min. 50 mm

Heat transfer coefficient

k < 0,7 W/m²,°K

Thermal unit TUC1800 / TUC2000

Dimensions cooling unit

(WxHxD)

451 x 598 x 326 mm

Weight

27 kg

Max. power consumptions

50A at 12VDC / 3.6A@230V or

7.2A@110V

Cooling power measured at

+4°C of regulated temperature

and +30°C of ambient

temperature according to ATP

+/- 400W

Heating power

+/- 550W

TUC1800/2000-usm. rev.01

Operating conditions

Ambient temperatures

-20°C to 50°C (TUC2000)

-20°C to 40°C (TUC1800)

set temperature range

+2°C to +25°C

Power packs

SB-75 power capacity

12V DC / 75Ah

SB-150 power capacity

12V DC / 150Ah

SB-250 power capacity

12V DC / 250Ah

5. Operation

The thermal unit detects the temperature in the VebaBox by means of

a temperature sensor. If the temperature exceeds the set values, the

cooling unit is switched on and controlled space is then cooled or

heated. When the temperature has reached the set temperature, the

thermal unit switches off automatically.

The fans will rotate at all times for optimal air circulation so that the

temperature in the VebaBox remains stable.

Controls

The thermal unit is equipped with a digital temperature controller.

This allows easy setting and checking of the required temperature.

TUC1800/2000-usm. rev.01

1. Temperature controller display

2. Main switch

3. High pressure warning

4. Evaporator

5. 110/230 Volt connection (optional)

6. 12 Volt connection

7. Master out connection

8. Remote/slave in connection

9. Cooling active indicator

10. Heating active indicator

11. Selecting buttons/temperature setting

12. SET button

13. Temperature display

14. Alarm signal

TUC1800/2000-usm. rev.01

Turning on the unit:

To switch on the unit, use the power switch (2). Note that if the

remote control is installed, the power switch on the thermal unit

needs to be always switched off. Use the power switch on remote

control in this case to turn on the thermal unit.

Note the unit will operate only when car engine is running, unless a

Powerpack has been installed or you use 110/230 VAC external

power supply.

Temperature setting:

During normal operation display shows the actual internal

temperature. To change the SET temperature:

•Press the SET button, the set temperature value starts to

blink.

•Use selecting buttons (arrows) to change the set

temperature.

•Press the SET button again to confirm the temperature and

return to the current temperature display. (If no button is

pressed within 6 seconds, the current temperature is

automatically displayed).

Indicators:

The unit has one of 4 possible operational states:

•Cooling active –indicated by symbol (9)

•Heating active –indicated by symbol (10)

•On temperature (in pre-set tolerance band) –neither symbol

9 or 10 is lit.

•Delay of operation mode change –blinking of symbol 9 or

10 indicates that unit is changing its mode (cooling to

heating or vice versa) and is waiting for preset time delay (3

minutes by default)

TUC1800/2000-usm. rev.01

Alarm function is available on temperature controller. By default, this

will signal any deviation of more than 3°C from the set temperature.

Alarm sound can be muted by pressing any button (alarm will be still

signalized by the display blinking and symbol 14 lit).

Remote control

Thermal unit installation can contain remote dashboard control. If

installed, some specific conditions apply:

•Remote display has priority in control of temperature. If

connected, the display on the thermal unit cannot be used

for setting of temperature and is not taking part in

temperature regulation.

•The same rules as described in section “controls” apply to

the remote display (including setting of temperature in the

box)

•Do not use power switch on thermal unit. This switch should

be in position “0” all the time. Use switch on remote control

to operate the unit.

Master/slave operation

If the box volume requires it, the box can be equipped with 2 thermal

units connected in series. This allows higher volumes to be

controlled. The first unit in the chain becomes the master device,

and this is the only device that shows or controls the temperature in

the box. The master device can be either the remote control or

thermal unit. The other units are connected with control cables and

their operation is synchronized with the master device. The display

of these so called slave units remains switched off. Power needs to

be supplied to each unit individually.

TUC1800/2000-usm. rev.01

WARNING: For proper functioning of chained units, the main switches on

slave devices need to be always in position “0”. Only main switch on master

device should be used to operate all chained units.

Connecting in series with remote control as master device

Connecting in series with TUC1800/TUC2000 unit as the master device

High pressure warning

The thermal unit is protected against extreme conditions that can

cause high refrigerant pressures, such as extremely high ambient

temperatures or dirty/blocked heat exchangers. The triggering of this

protection is indicated by a red control light (3).

If you notice the protection has been triggered, ensure proper

ventilation of thermal unit in the car (check the roof fan function). If

the problem is not solved by setting the unit to proper ambient

temperatures (-20°C to +40°C), the heat exchanger can be dirty or

blocked –please contact your local dealer for service.

Master

Slave

Master

Slave

TUC1800/2000-usm. rev.01

6. Cleaning and maintenance

WARNING: Never allow water or other liquids to enter the thermal

unit and electronics.

•Turn off the product and disconnect all power cables.

•The VebaBox is not designed for automatic defrosting (not

necessary for normal operation). If excessive frost builds up,

shut off the unit and wait until the ice melts. Do not remove

the ice by mechanical means.

•Clean the product with a damp cloth, using a detergent if

necessary. NOTE: do not use abrasive or corrosive agents

as these may damage the surface.

•Carefully dry all remaining damp parts with a dry cloth.

•The door seals must be greased every three months to

prevent the doors from jamming or cracking. This can be

done with, for example, medical vaseline.

•Repairs and maintenance must be carried out by qualified

personnel. It is recommended to check the unit and clean

the internal heat exchangers at least once a year.

7. Packaging material and safe disposal of products

The packaging protects the product from transport damage. Store

the original packaging parts for possible future transport of the

thermal unit.

Old electrical and electronic products usually contain

valuable materials. However, they also contain harmful

substances that have been necessary for the products to

function properly and safely. The disposal of such products

or impropriate handling of these substances can be harmful to health

and the environment. Dispose of the product in a municipal

collection depot for electrical and electronic equipment. The

TUC1800/2000-usm. rev.01

discarded product must be stored out of reach of children. Please

note that the cooling unit contains refrigerants which must be

disposed of in accordance with local legislation and directives.

8. Troubleshooting

Problem

Analyze

Solution

The cooling

unit does not

work.

The power plug is

not connected

properly.

No input voltage of

12V.

Remote control not

connected properly.

On/off switch in the

correct position.

Connect the plug and

check 12V or

110V/230V jack.

Make sure the car

engine is running.

Check the fuse.

Check the connection

plug of remote control.

Switch on/off button.

Hint: if you have a

remote control, the

main switch on the unit

should be in position “0”

The cooling

unit does not

switch off

On/off switch in the

correct position.

Check if main switch is

turned off (also on

remote control).

The

cooling/heating

unit is working

but does not

cool or heat

properly.

The doors are not

closed properly.

There is a heat

source in the box.

temperature set

correctly

The evaporator is

frozen.

Close the doors. Check

sealing for damage or

wear.

Use only preconditioned

goods.

Set temperature.

Allow the evaporator to

defrost by turning the

TUC1800/2000-usm. rev.01

Refrigerant leak.

unit off and allowing the

temperature in the box

to rise above freezing

point.

Call VebaBox service.

Red control

light indicator

(high pressure

warning) is on,

unit is working

but not cooling

The air passages

are clogged or dirty.

The ambient

temperature is more

than 40°C. (104°F)

Remove the

obstruction, dust or dirt.

Contact distributor for

regular maintenance

Ensure an ambient

temperature < 40°C

(104°F) by a roof fan.

The

cooling/heating

is working but

fan is stopped

Defective wire

connection / fan

defective.

Call VebaBox service.

Display error

code

Display shows

symbols LL or HH.

Defective temperature

sensor, call VebaBox

service.

Note: self-installed temperature gauges may differ from the VebaBox

temperature display. This is due to the position of the measuring

sensors.

9. Warranty

VebaBox products have a manufacturing warranty of 12 months

after delivery of the products. Power packs, which contain a battery

inside have the same warranty with a limitation to 18 months after

production date.

VebaBox Cool Solutions

www.vebabox.com


TUC1800/2000-usm. rev.01
© 2020 VebaBox B.V. User Manual VebaBox+TUC1800 or TUC2000

Inhoud

Inleiding ..............................................................................21
Algemene veiligheidsvoorschriften tijdens het gebruik van het
product....................................................................................26
Toepassing.........................................................................27
Productspecificaties............................................................27
Werking...............................................................................29
Reinigen en onderhoud......................................................34
Verpakkingsmateriaal en afgedankte producten................35
Problemen oplossen...........................................................36
Garantie..............................................................................38
