Vector GSM-DSA User manual

GSM-DSA Gateway Server
Overview
Doc: 70-00-0667, V1.0, Date: 20170512 © Vector Controls GmbH, Switzerland Page 1
Subject to alteration www.vectorcontrols.com
GSM-DSA Gateway Server with embedded DGLUX5
General description
Vector GSM-DSA is a programmable HMI-Server
with fully embedded DGLUX5. It features multiple
protocols, uses flash memory and runs on Linux on
a DSA framework.
The GSM-DSA features a 1.2 GHz 64-bit quad-core
ARMv8 CPU with an 802.11n wireless LAN, 1 GB
RAM and 4 USB ports.
Programming is browser based, drag and drop and
easy to learn.
Meanwhile it also provides advanced functionality
such as supervision, data logging, alarming,
scheduling and network management functions
with internet connectivity and web-serving
capabilities.
Application / Operational area
The Vector GSM-DSA is designed as a high power server for connection to Ethernet bus systems.
The device is designed for control and regulation of building services. Via the integrated Ethernet bus system, the
integration in modern buildings is used efficiently in central as well as in decentralized information focuses. Across the
broad range of connectable Vector communicating devices, the scalable controllers can be extended at any time
concerning the individual project requirements.
About the free programmability a maximum of flexibility and comfort is guaranteed. As a result, the projects are ideally
suited to the particular requirements both in the modernization of existing installations as well as for implementing
current and future automation projects.
DGLUX5
DGLUX5 is a modern toolset to design real-time, data-driven applications and dashboards with drag and drop
configuration. It runs on a browser and enables faster communication through real-time, data-driven dashboards for web,
desktop and mobile devices. It is cost effective because, there is no special software or tool needed, no PC required on
site and no certification classes necessary.
Licensing
Licensing is based solely on data being utilized in the interfaces built with DGLux5. This is achieved by keeping track of
the number of topics a DGLux5 project employs when end users navigate through various pages and components. All
DGLux5 licenses include unlimited user seats and projects on a single host device (embedded, personal or server).
Topics
A topic is defined as a unique interaction with the server such as a subscription to a data point, an executed query, or a
command like a set value. For example: a page with 3 gauges showing one unique value per gauge, a chart displaying
two trends, and a graphic of a fan displaying and allowing control of fan status, would equate to 7 topics.
Ordering
Item
Item code
DGLUX5 License
Description
GSM-DSA
40-12 0007
Gateway Server, 10/100 Ethernet,
Wi-Fi 2.4 GHz 802.11n, 4 x USB 2.0 ports
GSM-100-DSA
40-12 0008
100 topics
GSM-1500-DSA
40-12 0009
1500 topics

GSM-DSA Gateway Server
Technical Specification
Doc: 70-00-0667, V1.0, Date: 20170512 © Vector Controls GmbH, Switzerland Page 2
Subject to alteration www.vectorcontrols.com
Important notice and safety advice
This device is for use as operating controls. It is not a safety device! Where a device failure endangers human life and/or
property, it is the responsibility of the client, installer and system designer to add additional safety devices to prevent a
system failure caused by such a device failure. Ignoring specifications and local regulations may cause equipment damage
and endangers life and property. Tampering with the device and misapplication will void warranty.
Technical specifications
Power supply
Power requirements
5 V DC (2.5 A)
Power consumption
Max. 12.5 VA
Max. back-up fuse
2.5 A
Microprocessor
and memory
CPU
RAM memory
Flash memory
Clock
Watchdog
1.2GHz 64-bit quad score ARMv8
1 GB
8 GB microSD card
battery buffered real time clock
Hardware-Watchdog
Interfaces
Fast ethernet
Wi-Fi
USB
1 x 10/100 BaseT (RJ45) with LED display
2.4 GHz Wireless LAN 802.11n
4 x USB 2.0
Ratings
FCC
CE
Part 15 class A
Enclosure
Dimensions (W x D x H)
90.5 mm x 71.3 mm x 62 mm
Material
Plastic
Mounting
On Standard mounting rail 35 mm
Protection class
IP 20
Cooling
No fan; by convection
Temperature range
0…50°C
Connection
Ethernet, HDMI, USB 2.0
Installation
The assembly is to be executed following installation standards by trained personnel. The installation of the device takes
place on standard (norm) DIN rail 35 mm in electrical cabinets. For the assembly in intermediate ceilings suitable
housings have to be used. If necessary, inspection openings have to be provided.
When installing it is important to make sure that the open parts of the device are free from pollution.
Software
The device is delivered without a loaded program. A suitable program for the purpose must be loaded by trained
personnel.
Commissioning
Commissioning has to be performed by a licensed and trained professional. Local rules and regulations have to be
observed.
Service / Maintenance
The GSM-DSA is maintenance-free.
The program is saved in flash memory and is saved during power blackout. The GSM-DSA features an internal UPS which
keeps the device running for 2 minutes after removal of power. After 2 minutes the device will perform a save shut down.
The power backup serves additionally to maintain the system time. At initial power up, the battery needs to be charged
for 4 hours before power backup operation works reliably.
Connection options
The GSM-DSA is appropriate for the application in the building technology environment. With its extensive features of
standard communication interfaces and protocols, it is also able to link a large variety of external devices besides Vector’s.
Available as interfaces are the serial interfaces (RS485), as well as connections for the Ethernet network. Wired or Wi-Fi.
Dimensions mm (inch)

GSM-DSA Gateway Server
Configuration
Doc: 70-00-0667, V1.0, Date: 20170512 © Vector Controls GmbH, Switzerland Page 3
Subject to alteration www.vectorcontrols.com
Terminal configuration / Display and control elements
USB Power Interface
1 USB MICRO
Plug Pin
Function
1
Ground
2
Mode Detection (ID)
3
Data +
4
Data -
5
+5 V DC
Network (LAN)
2 Ethernet RJ 45
Plug Pin
Function
1
Tx +
2
Tx -
3
Rx +
4
-
5
-
6
Rx -
7
-
8
-
USB serial interface (4x)
3 USB V2.0
Plug Pin
Function
1
+5 V DC
2
Data -
3
Data +
4
Ground
Operating and status LEDs
LED
Name
Function
1
PROT
If the GSM-DSA is running in power protected mode, the
PROT-LED flashes white.
The PROT-LED is steady on, if the GSM-DSA is booting or
shutting down.
2
ACT
The ACT-LED flashes green, during SD cart activity.
The ACT-LED is steady on, if no SD card during boot.
3
PWR
If the GSM-DSA is powered, the PWR-LED is steady on
(red).
After switching on the power supply, all LEDs will light up for a few seconds.

GSM-DSA Gateway Server
User Manual
Doc: 70-00-0667, V1.0, Date: 20170512 © Vector Controls GmbH, Switzerland Page 4
Subject to alteration www.vectorcontrols.com
User manual
Introduction
Vector GSM-DSA is a programmable HMI-Server with fully embedded DGLUX5. It features multiple protocols, uses flash
memory and runs on Linux on a DSA framework.
Get Started with GSM DSA
1) Set up GSM DSA
a. Connect the GSM DSA with a router via an ethernet cable
b. Power GSM DSA with micro USB power supply
2) Sign into GSM DSA
a. Open browser on a computer connected with the same router
b. Type IP address of DSA (default: 192.168.170.151)
c. Login with
i. Username: dgSuper
ii. Password: dglux1234
Note: To ensure your connection to GSM DSA runs smoothly, please use the following browsers.
Chrome
Firefox
Safari: 5.0 or later
Internet Explorer: 8.0 or later
