Vees Delicooker HL-400NEG User manual

User Manual
HL-400NEG
ENGLISH

Contents
Thank you for purchasing VEES Delicooker series products. Please read this manual
before using to ensure the product is being properly operated, used and maintained.
Please keep this manual properly for future perusal. The VEES Delicooker series
products will give you a brand new, simple as well as a wonderful smoke-free cooking
experience.
1
Before use Vees Delicooker. ............................................................................... 02
When using Vees Delicooker.. ............................................................................. 02
After using Vees Delicooker. ............................................................................... 03
Basic Principles.. ................................................................................................ 04
Product Specifications. ....................................................................................... 04
Appearance of Product.. ..................................................................................... 04
How to Install.
..................................................................................................... 05
Operation and Use ..
........................................................................................... 07
How to Operate the Vees Delicooker ........................... ........................................ 07
How to start the Time-setting Function ................................................................. 08
How to start the Locking System ......................................................................... 08
How to unlock the system .................................................................................... 08
Choice of Cookware ............................................................................................ 09
Use of Cookware ................................................................................................ 09
Maintenance and Cleaning .................................................................................. 10
Warranty. ............................................................................................................ 12
Troubleshooting .................................................................................................. 13

2
Cautions
Before use Vees Delicooker
1. Unpack and inspect. If you find any damage to the Delicooker, do not install and use it,
contact our customer service department immediately.
2. Use good quality socket, as poor quality socket may lead to the burning of the Delicooker
or affecting its normal operation.
3. When the socket wire is damaged, wire or power plug is not securely plugged in the socket,
do not use the Delicooker.
4. Do not bend, bind or use excessive force to the wire to avoid damaging them.
5. Do not plug in a socket already plugged with several appliances; the power shall not exceed
the limit of the socket.
6. Do not use wet hand to plug in the socket or turn on the power plug.
7. Do not use the Delicooker in a damp place or near the fire, nor in places with
high-temperature, such as near the gas or kerosene cooker.
8. Do not place any detergent or inflammable materials underneath the Delicooker.
9. Before using the Delicooker, wipe and clean the water and dirt at the bottom of cooker
to prevent the panel from turning yellow in the heating process.
10. This Delicooker comes with a special environmental packaging, so please do your part to
protect the environment by collecting the package for recycling.
When using Vees Delicooker
1. Do not place Delicooker on an unstable surface.
2. Do not block ventilation holes of the Delicooker to avoid over-heating of the Delicooker.
3. Do not use the Delicooker in places accessible to children. Children and elderly people can
only use the Delicooker under adults’ supervision.
4. Place food in cookware for warming, not directly on the Delicooker surface.
5. Do not heat inflammable fabric and paper on the Delicooker surface.
6. Do not heat or over-heat an empty cookware.
7. Sealed foods, such as canned food, should not be heated unopened to avoid the risk of
explosion caused by expansion of the cans.

3
8. Do not remove the Delicooker with cookware on it.
9. Do not use the Delicooker in places with little space in the surrounding, and make sure that
the front portion and the left and right sides of the Delicooker are clean.
10. Do not insert metal wire and foreign objects into the gap of ventilation holes of the Delicooker.
11. Do not let things fall on the Delicooker surface. If there are cracks on the Delicooker surface
or the surface is damaged, immediately turn off the power, unplug and sent it for repair.
12. Do not place fatty or oily foods in the Delicooker as oil gets heated up easily and may cause
a fire. If fire is caused by oil, instead of putting it off with water, cover the Delicooker with
a lid and shut it down immediately.
After using Vees Delicooker
1. After using, adjust the power to the lowest, turn off the power, then remove the cookware.
2. Remove hot cookware from the Delicooker or the heat from the hot cookware will affect
and damage the Delicooker’s internal structure and shorten its life.
3. Do not touch the Delicooker surface after cooking to avoid being scalded as the heat
generated by cookware will transfer to the Delicooker surface.
4. Do not put wire on the Delicooker surface to avoid wire insulation and burning on Delicooker
surface.
5. Do not unplug by pulling out wire.
6. Disconnect the power when you are not using the Delicooker.

Product Speci cations
Appearance of Product
Basic Principles
4
Model Rated Voltage Rated Power Temperature
HL-400NEG 220-240V~50/60Hz 4000W (1800W+2200W) 620 C
VEES Delicooker
Duo Delicooker - HL400NEG
The Delicooker vertical heat radiation and heating will meet the various cooking requirements; it
operates with touch control, without a magnetic eld radiation and does not interfere with other
electrical appliances. It starts without instantaneous current and is the best choice for the modern
family. The personalized design of the product, the use of imported materials coupled with
advanced technology, so that the product has a safe and reliable performance, bringing comfort
to your life and helps you to fully enjoy the happy life. It does not harm your health and it has many
safe and protective devices, making your cooking more easier, more safety.

How to Install
5
The size of a mounting hole on the table should be in the same size with that respective model
(the diagram below is the diagram according to di erent models.) Please provide a space of
about 55mm around the mounting hole, the table should be at least 30mm in thickness. Choose
heat-resistant materials to avoid the table top from distorting that may be caused by the heat
generated by the Delicooker.
Model
: 200mm, 200mm
: HL-400NEG
Surface Dimension : 690mm x 420mm
Cut of Dimension : 670mm x 400mm
Heating Zone Diameter
HL-400NEG
670mm
400mm
55mm
30mm
420mm
Depth of Pan 90mm
690mm
90mm

6
Connection of power lines should be carried out in accordance with the relevant national
standard. The connection method is shown in (1):
Bottom Dimension : 660mm x 390mmHL-400NEG
10mm
Balanced
Seal
660mm
390mm
Note:
- A safe distance of more than 760mm between the surface of the Delicooker and a cabinet should be kept.
- The Delicooker must be installed by a professional technician.
During installation, please use the 3-hole socket. The 3-hole socket to be installed in a place
accessible to the people or easy to control, at a height of 1.3m-1.5m, and 3-hole socket required
to be equipped with is of speci cation 25A.
To ensure the rm installation of the Delicooker on the table, you may use the balanced seal
provided, as shown in the diagram below.
Installer must ensure the correct electrical connections being done in consistent with the safety
requirements. The cable can not be bent or compressed, must be regularly checked and replaced
by a professional technician.
Service Voltage Connecting Mode of Power Supply
220-240V
50/60Hz
1 2
L N
3
220V-240~
L
N
1
2
3
220V
240V

Operation and Use
Indications on Vees Delicooker
ON/OFF
Power
Cooking Zone Setting
Residual Heat Indicator
* Auto shut-off
After 30 minutes of being idle, Auto shut-off takes its effect.
7
4
1
3
5
6
123456
The pilot lamp will flickering when the power is on and the Delicooker is on when the button is pressed
(at this time, function selection pilot lamp will flickering and is on standby). It shuts down when the
button is pressed again.
Which shows that the surface area is still hot. Therefore do not touch the surface area when the
indicator light is ON.
To adjust power level from 1 to 9.
Locking System
The lock system is to prevent incorrect operation.
2Timer
This function can be used as time schedule for cooking ( 5 minutes - 480 minutes ).
Timer
Lock Power ON/OFF Hi
How to Operate the Vees Delicooker
Vees Delicooker is controlled by simply touching the control area on the surface of the ceramic
glass.
Ready to use
Turn on the control switch after switching on the power supply. The pilot lamp of power supply
is flickering, a “beep” sound will be heard and the electric range is ready to work.

8
1. Select cooking zone area within 1 minute.
2. Lightly touching the or control key on the range area. The monitor will
display the digit(s).
Note: If selection is not made within 1 minute, the appliance will
automatically return to standby status.
3. Lightly touch or control key.
By lightly touching the , Level 4 working status will be set.
By lightly touching the , Level 9 working status will be set.
4. If the cooking zone is consisting of 2 different power stovesets, it works in
1000W automatically, lightly touch ? Hi ? the cooking zone will turn to 2200W.
Lightly touch ? Hi ? again the cooking zone will back to 1000W.
Once the area to be used is selected, choose the power level.
(For example: Level 7)
Operation Steps
Pow e r
Pow e r
H i
Touch the switch of the heating zone area to turned off until the number ?0? is
displayed. Lightly touch the ON/OFF to switch off the cooktop at any time.
Turning Off the Heating Zone
1. Lightly touch or control key. The indicator flashes ? 0 ? minutes.
By lightly touching the 4 times, time setting will be 40 minutes.
If the user want to change the heating time, just lightly touch or , until
you choose the time needed.
1. Lightly touch the control key for more than 2 seconds.
2. A ?Beep? sound will be heard.
eht gnitacidni )yek lortnoc eht evoba detacal( NO lliw pmal tolip lobmys ehT .3
locking system is activated.
Note: All control key cannot be used while in the locked status. However the
ON/OFF switch will function.
Lightly touch the control key for more than 2 seconds again and the ?Beep?
sound will be heard. The symbol pilot lamp will OFF and the locking system
has been turned off.
2. Heating time over.
While heard for ?BB? buzzers, showing the ?00? minute, the cooking zone
will shut off automatically and the function is cancelled.
How to start the Time-setting Function (For example: Set 40 minutes timing)
How to start the Locking System
How to unlock the system
O N /OF F
T i me r
Lo c k

Choice of Cookware
09
The suitable cookware:
1. Iron cookware (enamel, cast iron, stainless iron), stainless steel pan.
2. The diameter of the bottom of the pan should be between 12CM-26CM. Try to use cookware
with the size fitting with the burner. Cookware with the bottom of the same size with the burner
will transfer heat and function with efficiency. Diameters for respective burners are:
14CM, 18CM and 23CM.
Use of Cookware
All types of stainless steel, enamel, iron,
ceramic and copper pans can be used.
Avoid dragging pans on the glass surface
to prevent scratches. Always lift up the
pan.
Never use tin foil or plastic containers.
It may melt and fuse permanently with
the glass surface.
Aluminum pan are not recommended as
they may stain the surface, unless they
have stainless steel encapsulated.
Should not heat up without a pan on top.
The base of the pan should be flat and dry.
Pans that have been used on gas cookers
normally are not completely flat and poor
in heat absorbing.
Make sure that the diameter of the pan is
similar or larger to heating zone diameters.
Stainless steel
Aluminium
Plastic
Aluminium

Maintenance and Cleaning
10
(A) Power requirements
1. Use a 3-hole socket with earth wire which meets the standard technical indicators. Do not
replace it with a 2-hole socket without the earth wire as the 2-hole socket is not firm, tends
to loose and does not meet the national standard, and is also more dangerous.
2. Socket should not be located right above the Delicooker to prevent the socket from heating
up and disrupting power supply.
3. Electrical appliances which make sudden changes in electrical current such as welding
machine, drill, hammer etc., or other hi-power electrical appliances such as refrigerator,
washing machine, and water heater, should not be used to avoid damaging the
Delicooker. Try to use stable power and try not to switch on or off other electrical appliances
at the same time when the Delicooker is in operation to avoid damaging the Delicooker.
(B) Heat ventilation of the VEES Delicooker
There is a certain temperature within the Delicooker when it is in operation, for the Delicooker to
operate better and normal and to extend its life, the heat must be ventilated by ensuring that the
Delicooker is placed in a place with good ventilation and cooling.
(C) Cleaning and maintenance of the VEES Delicooker
1. Please unplug the power cord before cleaning. Cleaning work should be started when the
Delicooker is completely cooled down.
2. After using, wipe the Delicooker surface with a damp cloth. For easy removal of the oil, wipe
with neutral detergent and then clean it with damp cloth.
3. Do not directly rinse the Delicooker with water or immerse it in water.
4. Always keep the Delicooker clean to prevent cockroaches and insects from entering,
resulting in its failure.
5. Do not use high pressure or steam jet vacuum cleaner to clean the Delicooker.
6. Do not put stove grate on cooktop as it will scratches or damages the cooktop.
7. Do not use pot with rough bottom, as it may scratch the Delicooker surface. Users are
advised to check the pot bottom before using.
8. Do not put hot frying pan or oven tray on the control panel or other part of the Delicooker
to avoid damaging the Delicooker.
9. Do not wash vegetables on the Delicooker surface to prevent sand, salt or sugar from
scratching the Delicooker surface.

11
10. Do not hang any hard or sharp objects above the Delicooker as they may drop and damage
the Delicooker.
11. Do not clean the Delicooker by using wire ball, brush or spray mist or rust cleaning detergent
with corrosive materials.
12. The Delicooker may be damaged due to the following circumstances, but its normal operation
will not be affected:
i. Rusty : a result of spill over and the solution of sugar or food with high sugar.
ii. Scratch : can be caused by salt, sugar and sand etc., or the rough bottom of the pot.
iii. Fading : due to rubbing of the pot and the use of unsuitable cleaning materials.
The above damage is due to incorrect use, it has nothing to do with the product technology,
therefore it is not under warranty.
(D) Unusual circumstances
In the course of using the Delicooker, if unusual circumstances occur, such as abnormal
shutdown or warning sound etc., stop using the Delicooker and contact with the Customer
Service department immediately. If you notice that there is a malfunction, get the help from
professional maintenance staff. Do not disassemble the Delicooker by yourself.
(E) Store the Delicooker
If not using the Delicooker for a long time, clean and dry it, and then store it in a place with good
ventilation. Desiccant and pesticides can be placed inside the package. Do not press it as it can
be reused.

12
Warranty
1. During the one-year warranty period (based on receipt date), though users are operating
the Delicooker in accordance with instructions given in the manual, fault is still found in the
Delicooker, the company will provide free repair.
2. To enjoy the free maintenance service, users must produce official receipt.
3. During the warranty period, in the event of any incorrect use and the failure to produce
receipts, a reasonable and appropriate maintenance fee will be charged.
4. The company will provide maintenance services in respect of the fault occurred after
warranty period, and will charge a reasonable fee.
5. Users are not entitled to free replacements and are not under warranty service when the
followings occur:
a. Glass and decorative items;
b. Damage due to human error or incorrect use;
c. Damage due to errors, improper use or accident;
d. Damage occurred after the prescribed time limit.
6. Before calling the Customer Service Centre for assistance, please check the fault yourself
first and find out the cause.
7. Please provide the product informationto the Customer Service Centre. The information
may be found from the surface and bottom of the Delicooker or documents in the package.
With respect to damage caused by incorrect use or fault, our service centre will charge a
reasonable and appropriate fee.
8. Our products comply with the current safety standard of household appliances and can only
be maintained by qualified technicians. WARNING! Please do not modify the internal
structure of the Delicooker.

13
Troubleshooting
The faults
The Delicooker not
heated, the display
screen is off.
Circuit breaker trips
when power is on.
Power light flashes,
then the light is off.
Inspection and management
Whether the power is turned on?
Whether the plug is inserted properly?
Whether the socket is damaged?
Whether all the burners are having the same problem?
Whether the use of power exceeds the power rating?
For cooking at high power for a long period, the Delicooker
will start its automatic protection device to avoid overheating
of internal components. When the light stops flashing, the
user can continue to use it.
Disclaimer:
The company in publishing and printing of this manual has done its best to ensure
that all informations and its contents are correct, if there are errors or omissions, we
shall not be held responsible. In addition, with respect to any technical improvement
of the product, the information will be given in the revised edition of the manual.

www.vees.com.my
F-06-03, Setiawalk, Pusat Bandar Puchong, 47160 Puchong, Selangor.
Service Hotline: [phone]
Vees Kitchen Appliances Sdn. Bhd.
(1399548-P)
