Vees DH-309AC User manual

USER MANUAL
COOKER HOOD
DH-309AC

- 1 -
Dear Users:
Hello! Thank you for using the Vees Cooker Hood. This series
range hood is the result of comprehensive market research, space for
kitchen and cooking characteristics, focused on the introduction of a
new generation of range hoods. Vees Cooker Hood is through the
improvement of human design, in accordance with advanced
aerodynamics, so that it has a simple and smooth appearance, it is
also more in line with a kitchen features superior performance. In
order to enable you to make full use of its excellent performance,
please read the user manual carefully before use and keep it properly
for necessary review. If you encounter problems in the course,
please contact your local dealer, we will be ready to serve you.
Thanks for your cooperation!
Contents
Packing List…………………………………………………… 2
Specifications…………………………………………………..2
Product Appearance and Size………………………………….3
Using Precautions……………………………………………...4
Care and Maintenance………………………………………… 4
Tempered Glass Precautions………………………………….. 6
Installation Methods and Precautions………………………….6
8
9
Operation Instructions…………………………………………
Common Malfunction and Trouble Shooting………………….

- 2 -
Packing List
No
Name of the attachment
Quantity
Remarks
1
Cooker Hood
1
/
2
User Manual
1
/
3
Certificate
1
/
4
Oil Cup
1
/
5
Ducting Hose
1
/
6
Pothook
1
for cooker hood
7
Plastic Expansion Plugs
4
fix pothook
8
Screws and Washers
4/4
fix pothook
9
Pointed Screws
2
fix ducting hose
Notes: Please check the inventory carefully when you open the box
and confirm all the accessories are complete.
Specifications
Product Name
Cooker Hood
Model Number
DH-309AC
N.W.
27Kg
G.W.
31.5Kg
Body Size
880 x 405 x 990 mm
Voltage
220V ~ 240V
Frequency
50Hz / 60Hz
Lighting Power
3W x 1
Input Power
400W
Ventilation Power
1600m3/h
Noise Level
70dB
Lightwave Cleaning Power 900W

-3-
Product Appearance and Size (mm)

-4-
Using Precautions
1. The room must be well ventilated when the cooker hood is used
in conjunction with a stove that burns gas or other fuels.
2. The supply voltage, frequency and product usage required to be
used, the three-core power outlet must have a reliable ground, the
ground wire must not be connected to the water pipe or gas pipe.
3. The power supply must be switched off when replace the lamp,
maximum power of lamp is 1.5W.
4. During the use, where there is noise anomalies, no turning of
wind wheels, odor, smoke, etc., should cut off the power supply
immediately for inspection and repair. In the case of electrical
failure, non-professionals may not disassemble and install without
authorization, must be send to maintenance department.
5. Wear protective gloves when cleaning to prevent get hurt from
metal plates.
6. It is strictly forbidden to burn the gas stove empty or to burn in
the pot. It is strictly forbidden to bake the cooker hood directly on
the stove.
7. Please clean the oil in the oil tank in time, the oil accumulation
should be discarded and not edible.
Care and Maintenance
Good performance comes from maintenance, timely maintenance in
order to maintain good performance.
1. Please shut down and unplug it when you clean the cooker hood.
2. The cooker hood should clean the filter twice a month, and also
clean the oil in the oil tank in time to ensure good effect of the
cooker hood.

-5-
3. Should be fully maintained in every six months, the removal of
oil pollution in various parts, especially wind turbines, ducts, oil
guide rings, etc. should be thoroughly cleaned (professionals only),
to ensure that the smoke discharge is unimpeded.
• How to do it
1. Rub the body surface with a damp cloth soaked by the neutral
cleaning agent.
2. Remove the oil cup & filter then soak in warm water with neutral
detergent and clean it with soft brush.
3. Use a screwdriver to remove the filter, loosen the nut according to
the loose mark on the wind turbine nut, remove the wind wheel.
4. Clean the above parts and the inner surface of the air duct.
Warning: Must be careful of the metal blade edge during remove
and installation when cleaning the filter.
• Precautions
1. If the cleaning is not carried out in accordance with the
instructions, the cooker hood is in danger of catching fire.
2. The removed parts should be lightly placed to avoid deformation.
3. Switch, junction box and other electrical components are strictly
prohibited to put in the water.
4. The use of organic solvents is strictly prohibited to avoid
damaging the coating of the surface.
5. When installing the wind wheel after cleaning, the mounting
groove on the air wheel stois is to fall on the positioning pin of the
motor, tighten the left and right wind wheel nuts according to the
left and right tightening signs of the nuts.

-6-
Tempered Glass Precautions
Due to the special nature of the tempered glass process,
self-explosion is the characteristics of tempered glass itself,
self-explosion rate in the industry is 3%-5% but our division is
strictly control it below 3%.
Installation Methods and Precautions
1. According to the supplied accessory of the hook holes position,
drill four holes with a diameter of 8mm at the mounting position.
Stuff four plastic expansion plugs into the holes respectively and
fasten the hook with screws.
Cautions:
• When installing a smoke machine, do not contact with the steel
bars in the building, the installation surface has sufficient strength to
withstand the weight of the cooker hood itself.
• When the whole machine is installed, the left and right level of the
cooker hood must be kept at the horizontal line.
• The minimum distance between the support surface of the cooking
utensil on the stove and the lowest part of the cooker hood, the
distance should be at least 65cm if the cooker hood is installed on
top of a gas stove. This should be considered if the installation
instructions for the steam-burning stove specify a large installation
distance.

-7-
2. Clamp the air outlet buckle with the plastic end of the ducting
hose (make sure to be fastened), then stick a sponge strip to the
bottom of the air outlet and fix the air outlet with the cooker hood by
4 screws, so finally led the pipe outside.
Cautions:
• The section of the pipe extending outdoor or the public flue should
avoid the natural wind blowing as much as possible, so as not to
reduce the effect of exhaust smoke.
• The smoke exhausted by the cooker hood should not be discharged
into the hot flues that used to remove smoke from burning gas or
other fuels.
3. Install the oil cup.
4. Confirmation of after installation
After installation, connect the power plug into the power socket,
turn on the power for the test run, check whether the functions of the
cooker hood is normal. Meanwhile, check also whether the body has
abnormal vibration. Must confirm that there is no undesirable
phenomenon before use.
Caution:
* Used of the three-core power outlet must be reliably earth
terminal.

- 8 -
Common Malfunction and Trouble Shooting
Common
Malfunction
Cause of Malfunction Advice / Solutions
Motor running
without lighting
Damage of light bulb
Change a new light bulb
Poor connection between light
cover and light holder
Repair
Motor and
lighting no
function
The plug is not in good contact
with the socket
Repair
Damage of power cable Check the status of power
cable
Motor no
function with
lighting
Overheat of motor protection
function
Restart it after several
minutes
Capacitor problems
Change a new capacitor
Motor problems
Change a new motor
Power and control panel
problems
Repair
Intense vibration
of the cooker
hood with noise
The cooker hood not install
properly
Install correctly
Loosing of screws connection
Fasten the screws
The wind wheel not install
properly
Fasten the screws
Weak power
suction
Damage or lost balancing of
wind wheel
Change a new wind wheel
Too high of installation height
Adjust to standard height
Too strong of kitchen air
convection or over sealed
Reduce the air convection
or open door / window
Too long of ducting hose or too
many bends
Follow installation
instruction
Strong wind from outdoor Install anti-retrofitting
hood for air outlet

1) On/Off: Touch this key once to turn into "standby" mode and the
glass panel is opened; touch it again to turn into "shut down" mode
then the glass panel will close. (Note: If there is no continue
operation after 1 minute, the cooker hood will shut down
automatically)
2) Delay: Touch this key when the motor is working then the cooker
hood will turn off after 1 minute.
3) Light / Auto Clean
A. Lighting function: When "standby" mode, touch this "light" key
once to turn on the light and touch again to turn off.
B. Auto clean function: When "standby" mode, long press this "light"
key for 3 seconds to turn on/off the auto clean function. Auto clean is
running at the starting 11 minutes then the panel will open
automatically and the motor will run fast. The cooker hood will shut
down automatically after finish all the process.
4) Left motor:
In "standby" mode:
I. Touch this key once to turn on low fan speed then will show "F1"
on control panel, the rotate of dynamic circle and left motor will run
in low speed.
II. Touch again this key to turn on high fan speed then will show "F2"
on control panel, the rotate of dynamic circle and left motor will run
in high speed.
III. Touch this key for third time to turn back to "standby" mode.
- 9 -
Operating Instructions
DelayLightLeft Turbo Right

- 10 -
5) Right motor:
In "standby" mode:
I. Touch this key once to turn on low fan speed then will show "F1"
on control panel, the rotate of dynamic circle and right motor will run
in low speed.
II. Touch again this key to turn on high fan speed then will show
"F2" on control panel, the rotate of dynamic circle and right motor
will run in high speed.
III. Touch this key for third time to turn back to "standby" mode.
6) Turbo motors:
In "standby" mode:
I. Touch this key once to turn on turbo fan speed then will show "F2
F2" on control panel, the rotate of dynamic circle and left & right
motors will run together in high speed.
II. Touch again this key to turn on low fan speed then will show "FI
FI" on control panel, the rotate of dynamic circle and left & right
motors will run together in low speed.
III. Touch this key for third time for turn back to "standby" mode.
Gesture sensing function
(This function is only valid after turn on the cooker hood):
I. First time gesture slide from left to right to turn on high speed
turbo motors mode then will show "F2 F2" on control panel and the
lighting is on at the same time, the middle rotate of dynamic circle
and left & right motor will run in high speed.
II. Second time gesture slide from left to right to turn on low speed
turbo motors mode then will show "F1 F1" on control panel and the
lighting is on at the same time, the middle rotate of dynamic circle
and left & right motor will run in low speed.
III. Third time gesture slide from left to right to turn back into
"standby" mode.
IV. Once gesture slide from right to left, the cooker hood and all the
outputs will shut down directly.
https://cdn1.npcdn.net/userfiles/23130/attachment/3680591/20220907_
7e301d48dff77ddc646f0ec78aaff11b/User_Manual-DH-309AC.pdf
User Manual Link:
