Veilux VD-70IRC30L2812D User manual

700TVL WDR 3D DNR CAMERA
■
■
Sony 1/3” 960H (Super EXview HAD CCD II)
High Resolution 700TV Lines
■
■
■
■
■
■
■
■
■
■
■
WDR(Wide Dynamic Range)
3D DNR(Digital Noise Reduction)
Zero Defect
Sens-Up Function(x512)
Eclipse Function
Back Light Compensation
Day & Night (ICR-Optional)
Motion Detection
RS485 / PELCO-D
Privacy Mask(Polygonal,8 Colors)
O.S.D menu function
700TVL
SUPER WDR/3D DNR
IR DOME CAMERA
USER’S MANUAL
960H/ES 003

The lightning flash with an arrowhead symbol, within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
This installation should be made by a qualified service person
and should conform to all local codes.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference
at his own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
Do NOT use power sources other than that specified.
Do NOT expose this appliance to rain or moisture.

Precaution
Do not install the camera in
extreme temperature conditions.
To avoid malfunctions, never
use the camera close to a gas
or oil leak
Do not Keep the camera face to
strong light directly
Do not disassemble the camera
even if troubles happened
Do not drop the camera or
subject them to physical shocks.
Do not install the camera under
unstable lighting conditions
Do not install or use the camera
in an environment where the
humidity is high
Do not expose the camera to
rain or spill beverage on it.

1. Features
WDR(Wide Dynamic Range)
Delivers a powerful Wide Dynamic Range to the camera which provides superior
images, internally and externally, even under extreme light and dark contracts.
It automatically compensates the necessary light levels to get detailed information
in the dark part of the image without saturation from the bright part. It enables the
WDR function to be very efficient, using a normal CCD, by using a Dual Shutter
(long & short shutter) algorithm, a specialised AE (Auto Exposure) and intelligent
image processing.
700 TVL ULTRA HIGH RESOLUTION
The horizontal resolution of 700 TV Lines with Sony 1/3”960H CCD. It gives a vivid
image output with super high horizontal resolution using our own De-Mosaic
Interpolation algorithm and a specialised built-in sharpness filter.
3D DNR(Digital Noise Reduction)
Achieves excellent 3D-DNR (3-Dimensional Digital Noise Reduction) function
using upgraded 3D filtering.This function is automatically enabled when the
camera is being used and provides clear and superior images in very low light
luminance. Normally video noise increases in low light conditions, while the gain
level of the amplifier increases. It compensates for the dynamic noise using the
inactive information of a normal frame
ZERO DEFECT
Adaptive Defect Correction delivers clear picture capture in very low light luminance
using two algorithms for defect pixel compensation.
Sens-Up(x512, DSS)
Achieves high quality pictures by supporting a long exposure time - more than
1/50second - and enables recognition of the shape and color of a suspended
object under no light conditions - in cases where exposure time is greater than
8 seconds (x512).
POLYGONAL PRIVACY MASKING(Polygonal, 8colors)
Ensures privacy protection for private and specific areas on the video signal
output using a polygonal masking function. It allows the size and position of the
masking areas to be controlled very easily, and there are 8 mask areas which are
user programmable - color, brightness and mosaic.
ECLIPSE
Enables the recognition of a visible car license plate by blocking unwanted light
sources.
HIGH SENSITIVITY TRUE DAY&NIGHT
The Day & Night function delivers high quality color rendition and converts
automatically into monochrome as luminance levels drop.

2. Components
3. Names and Functions of Parts
IR LED Vandal Dome Camera
DOME COVER OPENER
IR LED Plastic Dome Camera
SCREW
SERVICE VIDEO MANUAL
Option
RS-485
Terminal Block
WDR / 3D DNR
IR DOME CAMERA
USER’S MANUAL
WDR/3D DNR IB DOME CAMERA
WDR/3DDNR
ZeroDefect
HighResolution of 600 TV Lines
SensUp(x512, DSS)
DIS(DigitalImage Stabilization)
PolygonalPrivacy Masking
D.Zoom(x1~x10)
Eclipse
HighSensitivity Day&Night
IR LED Vandal Dome Camera
②
①
⑥
145(DIMESION: Ø ) X 106(H)mm
144(DIMESION:
Ø ) X 103(H)mm
IR LED Plastic Dome Camera

①Base
②Dome Cover Ring
③ Dome Cover
④ Focus Handle
Used to provide for accurate of an object within the
lens field of view
⑤ Zoom Handle
Used to adjustzoom magnification by turning
⑥IR LEDs
⑦ OSD Board
Used to connect it with external viewer as follows.
UP
DOWN
RIGHT
LEFT
ENTER
Service Video
Service Video
UP
DOWN
RIGHT
LEFT
ENTER
RIGHT
LEFT
ENTER

Note :
* Rubber pad(gasket) should be sticked to above base in installation
place. (A & B type)
* Wall mounting backet and other instruments should be used
with dome camera if the installation condition is not appropriate
to cover the whole dome base. (A & B type)
Wall
IR LED Plastic Dome Camera

DVR Monitor
Monitor
Power
(Adaptor Plug)
Adaptor
Adaptor
Video Cable
Video Cable
RS485 +
(Option)
RS485 -
AC24V + (RED)
AC24V - (BLACK)
DC Power Connecting
AC Power Connecting
DVR
RS485 +
(Option)
RS485 -
PORT2
TX
+
_+ _+ _+ _
RX TX RX
PORT1
PORT2
TX
+
_+ _+ _+ _
RX TX RX
PORT1

5. Setup Menu Flow
EXPOSURE LENS DC, ELC
E.SHUTTER AUTO, 1/50,1/60(NTSC),
1/100,000
BLC ON<1~255>, OFF
WDR OFF
ON
WDR LEVEL<0~20>
WEIGHT<0~20>
AGC OFF,LOW,MID,HIGH
SENS-UP
AUTO, OFF, MANUAL (x512 ~ x2)
RETURN
COLOR WB MODE AWC, ATW, MANUAL, PUSH
R-Y GAIN
B-Y GAIN
RETURN
DAY&NIGHT D&N MODE AUTO, DAY, NIGHT, EXT
LEAD TIME <1, 5, 30, 60>
BURST ON, OFF
RETURN
FUNCTION MIRROR ON, OFF
SHARPNESS <0~40>
GAMMA 0.45, 0.6, 1.0
NEGA OFF, ON
3D DNR OFF, LOW, MID, HIGH
ECLIPSE OFF
ON
SET LEVEL-LOW/MIDDLE/HIGH
HI-INV -ON/OFF
RETURN
MOTION ALARM OFF, ON
SET WINDOWS
ALL SET
ALL CLEAR
SENSITIV
SHOW OFF, ICON, TRACE
DELAY TIME <1~15>
RETURN

EXPOSURE LENS DC, ELC
E.SHUTTER AUTO, 1/50,1/60(NTSC),
1/100,000
BLC ON<1~255>, OFF
WDR OFF
ON
WDR LEVEL<0~20>
WEIGHT<0~20>
AGC OFF,LOW,MID,HIGH
SENS-UP
AUTO, OFF, MANUAL (x512 ~ x2)
RETURN
COLOR WB MODE AWC, ATW, MANUAL, PUSH
R-Y GAIN
B-Y GAIN
RETURN
DAY&NIGHT D&N MODE AUTO, DAY, NIGHT, EXT
LEAD TIME <1, 5, 30, 60>
BURST ON, OFF
RETURN
FUNCTION MIRROR ON, OFF
SHARPNESS <0~40>
GAMMA 0.45, 0.6, 1.0
NEGA OFF, ON
3D DNR OFF, LOW, MID, HIGH
ECLIPSE OFF
ON
SET LEVEL-LOW/MIDDLE/HIGH
HI-INV -ON/OFF
RETURN
MOTION ALARM OFF, ON
SET WINDOWS
ALL SET
ALL CLEAR
SENSITIV
SHOW OFF, ICON, TRACE
DELAY TIME <1~15>
RETURN
PRIVACY MASK1 OFF
ON
SETWINDOWS
COLOR SET<1~8>
MASK8 OFF
ON
SET WINDOWS
COLOR SET<1~8>
RETURN
SYNC SYNC MODE AUTO, INTER
V-PHASE <0~199>
RETURN
COMMUNICATION ADDRESS <0~255>
BAUDRATE OFF, 2400~38400
PROTOCOL PELCO-D
RETURN
SPECIAL TITLE OFF
ON
EDIT
RESET
POSITION
LANGUAGE ENG
DPC AUTO,OFF
RETURN
EXIT SAVE&EXIT
FACTORY SET
EXIT
RETURN

6. Special Features
1. WDR(Wide Dynamic Range)
Wide Dynamic Range is essential for capturing the images at all
light levels.
1) WDR LEVEL :
You can set the WDR(Entry) LEVEL on the entry timing for this function.
You have to set the level into low number if you need a WDR function just
in more strong light.
On the contrary you have to set the level into high number if you need a
WDR function just in normal conditions(or low light) without strong lights as
like sunshine.
EXPOSURE
LENS DC
E.SHUTTER 1/60
BLC ON
WDR ON
AGC HIGH
SENS-UP MANUAL
RETURN
WDR
WDR LEVEL 11
WEIGHT 10
RETURN
WDR Entry Level
(Day Time)
(0~20)
Strong Sunshine Light
(Day Time)
Middle Light
(Day Time)
0 2 4 6 8 10 12 14 16 18 20
Low Light
(Day Time)
※Eclipse mode should be Off while you use WDR function.
 (Eclipse is just a special WDR function for car license plate)
2) WEIGHT : This is a level to make the dark area more bright.
Low number for more dark condition and high number for
more brightness condition.

PRIVACY MASK1 OFF
ON
SETWINDOWS
COLOR SET<1~8>
MASK8 OFF
ON
SET WINDOWS
COLOR SET<1~8>
RETURN
SYNC SYNC MODE AUTO, INTER
V-PHASE <0~199>
RETURN
COMMUNICATION ADDRESS <0~255>
BAUDRATE OFF, 2400~38400
PROTOCOL PELCO-D
RETURN
SPECIAL TITLE OFF
ON
EDIT
RESET
POSITION
LANGUAGE ENG
DPC AUTO,OFF
RETURN
EXIT SAVE&EXIT
FACTORY SET
EXIT
RETURN

2. 3D DNR(Digital Noise Reduction)
Select 3D DNR ON or OFF.
3D-DNR function reduce the background noise in a low luminance
environment. Upgraded 3D filtering ensures even more clear image.
[DNR Level High : Picture image is more clear but Ghost is more increased.
DNR Level Low : Picture image is not clear but less Ghost.]
3. ECLIPSE
If there is a highlight within a limited environment such as car park,
It makes it possible to review vehicle license plates by removing the
highlight.
[Only used for car license plate in low light condition and the WDR
in OSD menu should be Off mode while Eclipse work as On mode]
FUNCTION
MAIN MENU
EXPOSURE
COLOR
DAY & NIGHT
MOTION
FUNCTION
PRIVACY MASK
SYNC
COMMUNICATION
SPECIAL
EXIT
FUNCTION
MIRROR
ON/OFF
SHARPNESS <0~40>
GAMMA 0.45
NEGA ON/OFF
3D DNR MIDDLE
ECLIPSE OFF
RETURN
MIRROR
ON/OFF
SHARPNESS <0~40>
GAMMA 0.45
NEGA ON/OFF
3D DNR MIDDLE
ECLIPSE OFF
RETURN
MAIN MENU
EXPOSURE
COLOR
DAY & NIGHT
MOTION
FUNCTION
PRIVACY MASK
SYNC
COMMUNICATION
SPECIAL
EXIT

7. SPECIFICATIONS
Design and specifications are subject to change without notice.
NTSC PAL
Sony 1/3” 960H (Super Exview HAD CCD II)
976(H) X 494(V) 976(H) X 582(V)
1020(H) X 508(V) 1020(H) X 596(V)
H/V 15.734/59.94Hz H/V 15.625/50Hz
H/V 15.750/60Hz H/V 15.625/50Hz
2:1 Interlace
700 TV Lines (Max.)
0.12Lux(15IRE), 0.2Lux(30IRE), 0.4Lux(50IRE) F1.2
0.0002Lux(15IRE), 0.0005Lux(30IRE), 0.0008Lux(50IRE) F1.2
1.0Vp-p/ 75ohm Video 0.714Vp-p
0.45, 0.6, 1.0
LENS,E-SHUTTER, BACKLIGHT,WDR, AGC, SENS-UP
WHITE-BALANCE, DAY&NIGHT, MOTION, MIRROR
SHARPNESS, GAMMA, DNR,
ECLIPSE, PRIVACY
COMMUNICATION, SYNC, TITLE, LANGUAGE
1/60~1/100,000 1/50~1/100,000
8 Windows(Polygonal, 8 Colors)
COLOR / BW / AUTO / EXT
ON / OFF
OFF ~x512
AUTO / INTERNAL / DIGITAL LINE LOCK
ATW / AWC / MANUAL / PUSH
ON / OFF(WDR LEVEL, WEIGHT)
120dB Max.
ON / OFF(OFF, LOW, MID, HIGH)
ON / OFF
LOW / MIDDLE / HIGH / OFF
TV System
S
Total Pixel
Eective Pixel
ensor
Synchronization Internal
Line Lock
Scanning System
Horizontal Resolution
Min. Illumination
Sens-Up On
Video Output
γ Correction
S/N
O.S.D
Electrical Shutter
Privacy Masking
Day & Night
Motion Detection
Sens-Up(Low Shutter)
SYNC
White Balance
WDR
WDR Level
3D-DNR
ECLIPSE
AGC
ON / OFF
NEGA
ON / OFF
MIRROR
More than 52dB(AGC o)
DPC
-20 ℃ ~60 ℃ /30% ~80%
-30
℃ ~60 ℃ /20% ~90%
Only DC12V (±20%) Dual AC 24 / DC 12V
550mA 600mA 280mA /
Operating Temperature/Humidity
Storage Temperature/Humidity
IR LEDs
Night View Distance(Outdoor)
30 units
25 m
LENS
Aspherical 2.8~12mm DC Auto Iris Lens
Aspherical 3.5~16mm DC Auto Iris Lens
LENS(Option)
Supply Voltage
Current
[Recommended - Voltage : +/-20%, Current :
Adapter with rated power of 2 times(than real using current ]

PRODUCT WARRANTY CARD
1) ITEM # :
2) S/N # :
3) INSTALLATION CONDITION
- Indoor  / Outdoor 
- Power supply SPECIFICATION :
DC12V  / AC24V 
CURRENT __________ mA
4) TROUBLESHOOTING
- No picture 
- Bad image 
- No power 
- Water damage 
- LED ON  / OFF 
- ETC.  :
* Please keep this warranty card with the manual.
* Please fill out this warranty card and send us this warranty card
with the faulty units together.
Following cases can be charged even within the warrany period.
a. When defects are caused by user’s carelessness.
b. When improper or unauthorized repairs are done or when the inside is
modified or damaged.
c. Defects caused by natural disaster or power problem.
d. When the warranty card is not filled out or corrected unconfirmed.
