Congratulations! You’ve purchased the most advanced, state of the art LiPO battery
available for the DJI Phantom 2 family of multi-rotor models. This is a quick guide to
help you get started with your new battery. You will find that there are multiple
information screens you can access depending on the batteries current activity. This
guide will help you navigate those screens like a pro. But first, you need to know
how to turn the battery on.
100% 12.582V
Battery INFO
5500mAh 1
Battery INFO More...
Serial Number:
Health State:
Soft Version:
Produce Date:
Current:
4.194V 4.189V 4.189V
1482
99%
V01.04
14.12.11
0.020A
TURNING THE BATTERY ON AND OFF:
RESTING MODE
To power on the battery, press the button on the end of the pack twice within one second holding the button
down on the second press. The green LED lights should begin to illuminate. When all four green LED’s are lit,
your battery will power on.
To turn the battery off, use the same method by pressing the button twice within one second, holding the button
down on the second press. The LED lights should begin to turn off. When all 4 LED’s are not lit, your battery is
off.
There are 3 modes the battery can be in depending on what it’s doing. There’s the Resting mode, where the
battery is simply waiting to be used. This could be when the battery is on, but not in the model, or when it’s
plugged into the model, but the model is not being flown.
The next mode is the Charging mode. This happens when the battery is plugged into your charger and you are
increasing the voltage of the battery.
The last mode is the Discharge mode. This mode is engaged by using the battery in your DJI Phantom 2. Your
drone must begin flying for this mode to start. Now let’s cover the details of each mode.
Without the battery plugged into the charger, power on the battery. This mode will also be activated when the
battery is turned on while plugged into the Phantom 2, but the drone is resting and not being flown. The
screen you will see is the “Battery Info” screen. This tells you the percentage the battery is charged, the
amount of power (represented in mAh, or milliamp hours) currently available in the pack, the resting voltage of
the battery, and finally in the lower right corner of the screen, the amount of times the battery has been
“cycled” or discharged and charged back up again.
By pressing the button once you can see additional information like the serial number, the health state of the
battery (All new batteries will start at 99%), the software version, the production date as well as the current
draw and individual cell voltages.
POWER
BUTTON
LED
LIGHTS
LCD SCREEN
RESTING MODE BATTERY INFO
RESTING MODE BATTERY
INFO MORE
SEE BACK FOR MORE DETAILS
Discharge Statistics
Discharge Time:
Max Current:
Vmax-Vmin:
Min Voltage:
Min CellVol:
Max Temperature:
Health State:
16:49
-20.290A
0.187V
9.610V
3.258V
51.1
99%
Charge Statistics
Vmax-Vmin:
Min CellVol:
FULL CAP:
Max Temperature:
Health State:
BalanceState:
0.078V
4.200V
5653mAh
5.7
99%
0
79% -10.049A
11.657V
Discharging
00:26 07:25
77% 3.837A
12.026V
4.010V
4.011V
4.008V
Charging
00:45
CHARGING MODE
DISCHARGE MODE
ERROR MODES
Connecting your battery to a charger and initiating a charge will put the battery into “Charge Mode”. Charge
this battery as you would normally charge your original DJI battery. You will notice that once the charge starts,
the screen will automatically light up giving you important information like the estimated time remaining for the
charge, the percentage the battery is charged, the amperage currently going into the battery and the overall
voltage reading as well as the individual cell voltages.
Pressing the button once will give you additional charge statistics like the Vmin-Vmax difference, max cell
voltage, full capacity, maximum temperature (in Celsius), health state and balance state of the pack. This
information is most useful when the battery is done charging, as the statistics will actively change while the
battery is being charged.
When your battery is plugged into your drone and powered on, it will display the “Resting Mode” information.
When your DJI Phantom 2 is in flight, it is in “Discharge Mode”. The screen will display the percentage of
power left in the battery as well as the estimated flying time left (Left side of the screen, represented in
minutes) and the actual flight time (Right side of the screen, represented in minutes and seconds) as well as
the current amp draw and overall voltage of the battery.
When your flight is done, the screen will show you the “Battery Info” from the “Resting Mode”. However, if you
press the button once you will get the “Discharge Statistics” screen that will show you the overall discharge
time, maximum current draw (in amps) while you were flying, the Vmax-Vmin, Minimum voltage in the battery,
the lowest cell voltage, the maximum temperature the battery reached (in Celsius) and the health state of the
battery.
CHARGING MODE
DISCHARGING MODE
DISCHARGE STATISTICS
CHARGING STATISTICS
VENOM GROUP INTERNATIONAL
14028 N. Ohio Street
Rathdrum, Idaho 83858 USA
North America: 800.705.0620
Outside North America: 208.762.0620 PART #:15150
CUSTOMER SERVICE
For Customer Service issues and the
quickest warranty service please visit
www.venom-group.com and click the support tab
Please read and fully understand all included LiPO battery warnings
and precautions BEFORE using this product.
NOTE:NOTE:
ERR1
5488mAh
12.572V
5
Battery INFO
ERROR ONE
Over Discharge Condition.
Parameter Value is 2.7V ±15mV
ERR2
5488mAh
12.572V
5
Battery INFO
ERROR TWO
Over Discharge Condition.
Parameter Value is 4.3V ±15mV
