INSTALLATION, USE AND
MAINTENANCE GUIDE
>>
DUCTABLE AIR TREATMENT UNITS MI UTC 1105-0 VEN GB
ISO9001:2000 - Cert. n. 1368/1

INSTALLATION/USE/MAINTENANCE GUIDE
ISO 9001:2000 - Cert. n. 1368/1
are in the position 0 (off). If the unit is not oin to be used in winter when
temperatures are near to freezin , drain the system and ensure that the
unit heat exchan er has no water in it in order to prevent the formation of
ice and consequent breaka e. To make the unit inoperable, disconnect it
totally from the electricity supply. It is unsafe to alter or try to alter the
characteristics of this product. Any tamperin or alteration in any case makes
the warranty null and void. In the event of malfunction or failure, do not try
to repair the unit yourself; contact a qualified technician. Repairs carried out
by incompetent persons could cause dama e or accidents. Always keep
the unit clean. In particular clean the air filter periodically (at least once a
month).
!
FAILURE TO COMPLY WITH THE ASSEMBLY INSTRUCTIONS
GIVEN IN THIS GUIDE RELIEVES THE PRODUCER OF ALL AND
ANY LIABILITY. INCORRECT INSTALLATION COULD CAUSE
MALFUNCTIONING OR FAILURE OF THE UNIT. IT COULD ALSO
REPRESENT A HAZARD FOR THE USER
IDENTIFICATION OF THE UNIT
The air treatment units come with a ratin plate, which shows:
- The manufacturer's address - Supply volta e in "V"
- "CE" markin - Supply frequency in "Hz"
- Model - Input in "W"
- Lot number - Total coolin capacity in "W"
- Date of production - Sensible coolin capacity in "W"
- Rated absorbed current in "A" - Heat output.
- Number of phases, indicated with "Ph"
TRANSPORTATION, RECEIVING, HANDLING
The units and their accessories are enclosed in cardboard boxes up to
size 50, while the other sizes are palletised. The packs should be kept
intact until positioned in the final place of installation. Use suitable
handlin equipment accordin to the wei ht of the unit, as provided for
by directive 89/391/EEC and subsequent amendments. The wei ht of
each sin le machine is iven in this uide (table 2). Upon receivin the
unit, check all the parts for any dama e caused in transit. Any dama e
should be reported to the carrier by affixin an accepted with reservation
on the accompanyin note, specifyin the type of dama e. In the event
of prolon ed stora e, keep the units protected a ainst dust and far from
sources of vibration or heat. The number of units that may be positioned
on one pallet are iven in the table (table 1).
!
THE PRODUCER CANNOT BE HELD LIABLE FOR DAMAGE
DUE TO INCORRECT HANDLING OR LACK OF PROTECTION
AGAINST THE ELEMENTS.
SAFETY PROVISIONS
INDEX
INTRODUCTION
RECOMMENDATIONS
FIRST PART: FOR THE INSTALLER
IDENTIFICATION OF THE UNIT
TRANSPORTATION, RECEIVING, HANDLING
Safety provisions 2
DESCRIPTION OF THE UNIT 3
General size of the base unit 3
General size of the accessories 3
General technical data 4
UNIT INSTALLATION 4
Recommendations for installation 4
Installation of the air treatment unit 4
Installation of the accessories 4-5
WATER CONNECTIONS 6
Connection to the trunk line 6
Condensate water draina e 6
ELECTRICAL CONNECTIONS 6
Recommendations 6
Connections to the terminal blocks: UTC 10-40 6
Connections to the terminal blocks: UTC 50 7
Connections to the terminal blocks: UTC 60 7
Connections to the terminal blocks: UTC 70 8
TURNING THE COIL 8
SECOND PART: FOR THE USER
CLEANING AND MAINTENANCE 9
Routine maintenance 9
Cleanin the air filter 9
WHAT TO DO IF 9
DISMANTLING THE UNIT 9
INTRODUCTION
This installation and maintenance booklet should always accompany the
air treatment unit for ready consultation by the installer or user if necessary.
The unit should be installed in compliance with the re ulations in force
in each country and accordin to the manufacturer's or qualified person's
instructions. The manufacturer cannot be held liable for any dama e to
property or injury to persons and animals caused by incorrect installation
of the unit. Only qualified persons should install the unit and connect it
to the mains electricity supply. Before carryin out any work on the unit,
ensure that it is disconnected from the electricity supply. Read this
instruction booklet prior to installation.
RECOMMENDATIONS
This unit is easy to use, but it is important to read all the contents of this
uide before usin it for the first time. This will help you to:
- use the unit in all safety
- obtain best performance
- avoid incorrect actions
- respect the environment
- Do not allow children or unassisted handicapped persons to use the unit.
- Do not touch the unit with wet parts of the body or if barefoot.
- Do not tu , pull or twist electrical cables attached to the unit, even
when disconnected from the electricity supply.
- Do not open the flaps ivin access to the internal parts of the unit
without havin first put the system on-off switch to "off".
- Do not introduce sharp pointed objects throu h the air intake and outlet rilles.
- Do not leave packin material (boards, staples, plastic ba s, etc.)
within reach of children since they could be a source of dan er.
Dispose of correctly.
- Do not spray or throw water directly on the unit.
- Do not use the unit in places with suspended dust/powder or in
potentially explosive atmospheres, in very damp environments or in
the presence of oil in suspension or in particularly a ressive
atmospheres.
- Do not cover the unit with objects or drapes that even partially obstruct
the air flow.
The unit works by electricity at mains volta e (230 Vac, 50 Hz). Always bear
in mind that mains volta e is potentially dan erous and any appliance
connectedto it should be used with caution. Before carryin out any work
on the unit, disconnect it from the electricity supply (by pullin out the plu
from the mains socket or isolatin the supply line by puttin the on-of switch
OFF. If the unit is not be used for lon periods, make sure that the controls
- Secure packs durin transportation.
- Do not expose to the elements.
- Do not tread on packs.
- Protect hands with work loves when dismantlin the unit.
- Work in PAIRS if the appliance wei hs more than 25 k .
2

INSTALLATION/USE/MAINTENANCE GUIDE
DESCRIPTION OF THE UNIT
GENERAL SIZE OF THE BASE UNIT
BASE UNIT
400
A
SSP SRE PA M BAM RAM
B
B50
50
B 5050 B B
B50
50
B5050
046 6
A1111 A1111
341
A115
046 6
A1111 A1111
70
A
ØBAM
30
B51
51
L
B 5151
4444
P
6
H
A
9 9
76
6A76
ØAFØAC
ØC
Fig.
GENERAL SIZE OF DUCTWORK ACCESSORIES
Tab. 1
MODEL U.M. UTC 10 UTC 0 UTC 30 UTC 40 UTC 50 UTC 60 UTC 70
Max. number per pallet
Pallet size
Unit overall dim.
mm 650x533x299 1.000x533x299 1.100x533x324 1.339x533x324 1.339x533x374 1.341x853x674 2.028x853x674
N. 10 5 5 5 5 2 2
140x80 120x80 120x80 150x80 150x80 150x100 230x100
MODELS UTC 10, 0, 30, 40, 50
51
MODELS UTC 60, 70
51
B
44
44
37
L
51 51
B
44
44
37
L
9 9
P
6
A
76
H
107 Ø 0
9 9
P
6
A
76
H
107 Ø 0
Fig. 1
N.B.: the units may be stacked up to a maximum of 1.80 m in height
3

INSTALLATION/USE/MAINTENANCE GUIDE
ISO 9001:2000 - Cert. n. 1368/1
UNIT INSTALLATION
RECOMMENDATIONS FOR INSTALLATION!
Before installin the unit, ensure that:
1) the place of installation has sufficient space for carryin out installation as well as routine
and extraordinary maintenance work (see fi . 3). If the unit is installed behind a
suspended ceilin , an access should be provided;
2) there are no obstructions for air intake and delivery;
3) the water fittin s are of the sizes, in the position and spaced apart as required by the
unit;
4) the system pressure does not exceed 8 bar for the water-filled versions;
5) the electricity supply corresponds to the data on the unit ratin plate and that there is
a circuit breaker switch readily accessible to the user to cut off the power supply
whenever necessary;
6) the circuit breaker is in the OFF position so that there is no volta e on the unit supply
line.
GENERAL TECNICHAL DATA
Tab.
possible noise bein created by vibrations from the unit, it is advisable to insert a vibration-
dampin joint.
N.B.: the screw anchors, threaded rods and whatever e se is necessary for accomp ishing
the insta ation are NOT inc uded in the supp y of the air treatment unit.
INSTALLATION OF THE ACCESSORIES
Some examples are iven below of assemblin the accessories for ducted air
treatment units.
Example 1
First of all put the air filter section (SFA) on the unit intake, insertin it into the special
rim (male-female) and fixin it with the alvanised self-tappin screws 4.2x9.5.
Proceed as described above on the delivery end with the connectin flan e (FAM).
Put the vibration isolation joint (GAM) on the flan e and fix it usin the cheese-
headed screws M8x16 and hexa on bolts.
INSTALLATION OF THE AIR TREATMENT UNIT
Preliminary operations:
- check that the various unit components are perfectly intact;
- check that the installation accessories and documentation are in the pack;
- place the packed section as close as possible to the place of installation;
- do not place tools or wei hts of any kind on the packed unit.
Fig. 3
P
1,5 P
Fig. 4
Drill the holes in line with the relative slots for the 6 unit screw anchors (fi . 4). Inject
thermosettin resin into the holes and then insert the screw anchors (fi . 5).
MODELLO UTC 10 UTC 0 UTC 30 UTC 40 UTC 50 UTC 60 UTC 70
Fans - Motors No.
Standard Rows No.
coil Fittin s (ØAF) Ø
Auxiliary Rows No.
coil Fittin s (ØAC) Ø
Cond. drain fittin (ØC) Ø mm
Hi h (H) mm
Len ht (L) mm
Depht (P) mm
(A) mm
(B) mm
N. x Ø BAM mm
Net Wei ht k
Max.power motor input W
Max.current motor input A
1-1 2-1 2-1 2-1 2-1 1-1 2-2
333 33 44
1/2" 1/2" 3/4" 3/4" 1" 1"1/4 1"1/2
111 11 22
1/2" 1/2" 1/2" 1/2" 3/4" 1" 1"1/4
20 20 20 20 20 20 20
299 299 324 324 374 674 674
650 1.000 1.100 1.339 1.339 1.341 2.028
533 533 533 533 533 853 853
197 197 222 222 272 572 572
548 898 998 1.237 1.237 1.239 1.926
2xØ200 3xØ200 3xØ200 4xØ200 4xØ200 2xØ200 4xØ200
28 26 41 46 57 117 192
162 218 322 340 582 1.320 2.600
0,72 0,97 1,43 1,51 2,58 5,86 11,54
Fig. 5
Fig. 6
Fix the threaded rods of the correct len th to the screw anchors (fi . 5) and insert them
into the relative slots (fi . 6). After havin created a slope (max. 3 cm/m) in the direction
of the condensate outlet, lock the threaded rod with a nut and check nut. To prevent
Example
Proceed by insertin the manual air intake section (SSP) into the air filter section (SFA) by
means of the male-female couplin . After havin secured it with the self-tappin screws (4.2
x 9.5 alvanised), anchor it to the ceilin as illustrated for the base unit in fi ures 4-7. Put
another connectin flan e on the vibration isolation joint (GAM) and secure it usin cheese-
headed screws M8x16 and hexa on bolts. Insert the strai ht delivery plenum (PAM) in the
connectin flan e and fix it usin alvanised self-tappin screws 4.2 x 9.5. Connect the air
delivery union with round fittin s (BAM) with the procedure described above.
Electrical supply: 30 V/1/50 Hz
GAM
PAM FAM
UTC SFA
Fig. 7
4

INSTALLATION/USE/MAINTENANCE GUIDE
Fig. 8
Esempio 4
La sezione di riscaldamento con resistenza elettrica (SRE) viene di solito posizionata in
mandata prima del plenumdritto di mandata (PAM). Può essere utilizzata indifferentemente
con il bocchettone di mandata (BAM) o con il plenum a 90° di mandata (RAM). L'a ancio
è di tipo maschio-femmina con fissa io mediante viti autoforanti 4,2 x 9,5 zincate.
Fig. 09
Fig. 10
Esempio 3
A 90° plenum (RAM) may be used instead of the air delivery union for better
direction of airflow. Insert the manual air intake section (SSP) in the air filter
section (SFA) by means of the male-female couplin . After havin secured it
with the self-tappin screws (4.2 x 9.5 alvanised), anchor it to the ceilin as
illustrated for the base unit in fi ures 4-7. Put another connectin flan e on the
vibration isolation joint (GAM) and secure it usin cheese-headed screws M8x16
and hexa on bolts.Insert the strai ht delivery plenum (PAM) in the connectin
flan e and fix it usin alvanised self-tappin screws 4.2 x 9.5. Then connect
the 90° plenum (RAM) with the procedure described above.
Example 4 - The heatin section with electric heatin element (SRE) is usually placed
on the delivery side before the strai ht delivery plenum (PAM)
GAM
PAM FAM
UTC SFA SSP
BAM
GAM
PAM FAM
UTC SFA SSP
RAM
SRE
5

INSTALLATION/USE/MAINTENANCE GUIDE
ISO 9001:2000 - Cert. n. 1368/1
Fig. 11
HYDRAULIC CONNECTION
MAIN HYDRAULIC CONNECTION
IN
OUT
IN
OUT
!
CAUTION! If the valve is installed, suitably insulate the valve body with insulating
material (fig. 1 ).
Connect the water inlet and outlet pipes, observin the indications iven on the side of
the unit. Correctly insulate the water supply pipes to prevent drippin durin the coolin
mode of operation. A shutoff valve should be inserted on the water supply pipe and a
balancin valve on the outlet pipe. The valve body and balancin valve should also be
properly insulated to prevent drippin . It is the installer's responsibility to insulate properly
and the manufacturer cannot be held liable for any insulation work.
N.B.: It is always advisable to install the valve.
In the heatin mode of operation
the valve reduces consumption because upon reachin the set temperature the
circulation of water is stopped to avoid wastin ener y (the fan coil would otherwise
continue to heat like a radiator, even with the motor at a standstill). In the cooling
mode of operation the valve stops the circulation of water when the set
temperature is reached, this stopping the internal exchanger from continuing
to condense water with possible undesirable dripping onto the floor. It also
reduces chiller operation with consequent energy saving.
!
CAUTION! Always use a wrench and counter-wrench for connection
of the coil to the pipes (fig. 11).
Fig. 1
Fig. 13
3 cm/m
The condensate drain pipe should slope downwards by at least 3 cm/m and
should not have ascendin or throttled sections in order to ensure a re ular flow
of water. It is advisable for a trap to be fitted. The condensate drain pipe should
be connected to a rainwater draina e system. Do not use sewa e systems to
avoid possible risin of odours in the event of evaporation of the water in the trap.
Upon completion of work, check that the condensate flows out properly by
pourin water into the tray. The condensate water draina e system should be
fabricated in a workmanlike manner and should be periodically checked.
The manufacturer cannot be held liable for any damage caused by dripping
in the absence of a valve or of periodic maintenance of the drainage system.
ELECTRICAL CONNECTIONS
!
RECOMMENDATIONS
Before carryin out electrical connections, ensure that the electricity supply to the
supply line has been cut off, checkin that the on-off switch is in the OFF position.
- Only qualified electricians should carry out the electrical connections.
- Check that the mains supply is sin le-phase 230 Vac/1/50 Hz (± 10%).
- Operatin the unit with volta es outside the above limits could cause malfunction
and renders the warranty null and void.
- The power supply line should be fitted with at least a switch isolator in conformity
with European standard EN60947-3.
- Make sure that the electrical system is suitable for providin not only the workin
current required by the unit, but also the necessary current for powerin household
and other electrical appliances already in use. Any electrical and mechanical
alterations or tamperin render the warranty null and void.
The cables should be sufficiently long so that they are not permanently
taut or create throttling or compression on metal parts.
The power cables should be sufficiently lon so that in the event of accidental
tu in the active wires are subjected to stress before the earth wire. Connect
the earth wire to the relative terminal marked with the symbol . Comply with
the safety re ulations in force in the country of installation.
CONNECTIONS TO THE TERMINAL BOARDS
The electrical connections should be made to the terminal boards on the side
of the appliance. Each terminal is identified by the label to be found on the terminal
boards.
!
CAUTION! FAILURE TO COMPLY WITH THE INDICATED CONNECTIONS
MAY CAUSE MOTOR BURNOUT!
CONDENSATE WATER DRAINAGE
Fig. 14
LEGENDA
PE Earth (yellow/ reen) IMinimum speed
MFan motor II Medium speed
NNeutral III Maximum speed
LPhase SDP/ Power card
Com Common (white)
Remote
control
230Vac/50Hz
Cross section area= 1,5 mm2
III
II
I
Com
Com
I
II
III
III
II
I
Com
C
PE
UTC
13 14 15 16
5 6 7 8 10 12
L
N
SDP/
WIRING DIAGRAM UTC MOD. 10 - 0 - 30 - 40
6

INSTALLATION/USE/MAINTENANCE GUIDE
LEGENDA
PE Earth (yellow/ reen) IMinimum speed
MFan motor II Medium speed
NNeutral III Maximum speed
LPhase SDP Power card
Com Common (white) XA1 Connection box Fig. 16
Fig. 15
LEGENDA
PE Earth (yellow/ reen) IMinimum speed
MFan motor II Medium speed
NNeutral III Maximum speed
LPhase SDP Power chart
Com Common (white)
Remote control
230Vac/50Hz
Cross section area= 1,5 mm2
Motor power supply
230Vac/50Hz
Com
I
II
III
LN PE
14 15 16 17
1234
SDP (power chart)
25 26 27 28
Com
III
II
I
Remote control
230Vac/50Hz
Cross section area= 1,5 mm2
Com
I
II
III
Motor power supply
230Vac/50Hz
LN PE
14 15 16 17
1234
SDP (power chart)
25 26 27 28
blue
brown
rey
black
min med max Com
XA1
blue
brown
oran e
black
reeen
yellow
FAN COIL
UTC
WIRING DIAGRAM UTC MOD. 50
WIRING DIAGRAM UTC MOD. 60
FAN MOTOR CABLE COLOURS
mot. EM mot. EL
Min.speed red blue
Med.speed blue black
Max speed black brown
Common white white
7

INSTALLATION/USE/MAINTENANCE GUIDE
ISO 9001:2000 - Cert. n. 1368/1
TURNING THE COIL
!
CAUTION
The fan wheels may reach the speed of 1,000 rpm. Do not insert objects into the electric
fan and certainly not hands. The motor becomes hot durin operation; wait for it to cool
before touchin it. Durin the heatin mode of operation the exchan er and the connectin
pipes may become very hot (80°C). Wait for the exchan er to cool before touchin it or
protect hands with suitable loves. The heat exchan e water coils are suitable for workin
up to a maximum pressure of 8 bar.
To turn the coil, proceed as follows:
1. Disconnect the terminal board (6) from the side of the unit.
2. Remove the condensate collectin tray (2).
3. Remove the coil fixin screws (5).
4. Take out the coil (3), bein careful not to be cut by the fins and not to
dama e them.
5. Remove the knockouts (1) on the opposite side of the unit (usin a
screwdriver) to allow the coil connections to pass throu h.
6. Position the coil, turnin it without tippin it upside down, so that the fittin s
are in line with the holes left by the knockouts.
7. Fix the coil usin the previously removed screws (5).
8. Shift the terminal board (fixin it to the side opposite the water fittin s) and
the motor cables, fixin them with their clamps. Ensure that the cables pass
throu h the hole in the side of the unit, protectin them with the relative
rommet. If it proves easier to carry out this operation by separatin the
wires from the terminal board, mark the positions of the wires to avoid
makin mistakes when reconnectin .
9. Reconnect the wires to the relative terminal board (6), takin care that they
are correctly positioned.
10. Replace the condensate collectin tray (2).
Fig. 18
Fig. 17
LEGENDA
PE Earth (yellow/ reen) IMinimum speed
M1-M Fan motor II Medium speed
NNeutral III Maximum speed
LPhase SDP Power chart
Com Common (white) XA1-XA Connection box
KA1-KA -KA3 relè 20A/250V type finder 22,22 XA3 Terminal board
1 3
45 6
P=8
bar max
0°
60°
230Vac/50Hz
3X2,5 mm2
Motor power
supply
Remote
control
230Vac/50Hz
4X1,5 mm2
XA3
blue
black
rey
brown
KA1 KA2 KA3
blue
black
rey
brown
XA2
M2
M1
blue
red
oran e
brown
reen
yellow
UTC
blue
red
oran e
brown
reen
yellow
XA1
min med max Com min med max Com
Com
III
II
I
N
L
PE
WIRING DIAGRAM UTC MOD. 70
8

INSTALLATION/USE/MAINTENANCE GUIDE
R
R
I
I
F
F
I
I
U
U
T
T
I
I
CLEANING AND MAINTENANCE
CAUTION! Before carrying out any cleaning or maintenance work, disconnect the
unit from the mains electricity supply!
ROUTINE MAINTENANCE
The user is duty bound to have all maintenance operations carried out by trained and
qualified personnel only. If the unit has to be dismantled, protect hands with work loves.
Monthly checks:
- Ensure that the fan impellers are clean. If they are dirty, clean them by suction so as not
to dama e them.
- Check the whole of the electrical part and in particular that the electrical connections are
ti ht.
Yearly checks:
- Check the whole of the electrical part and in particular that the electrical connections are
ti ht.
- Check the ti htness of all the bolts, nuts and whatever else may be loosened by the
constant vibrations of the unit.
- Check the motor for dust, dirt or other impurities. Periodically check that the motor works
without unusual vibrations or noise and that the fan inlet is not obstructed, which could
otherwise leadin to overheatin of the windin s.
- Check the fans for dirt or any forei n matter.
CLEANING THE AIR FILTER
The unit is fitted with an air filter on the fan inlet. Durin normal operation the filter holds
back impurities in the air.
The filter should be cleaned periodically to keep its filterin properties and the airflow to
the fan unchan ed.
It is advisable to clean the filter at least once a month, proceedin as follows.
1. Take out the filter.
2. Place the filter on a flat, dry surface and remove the accumulated dust with a vacuum
cleaner.
3. Wash the filter with water and deter ent (no solvents).
4. Leave the filter to dry in a ventilated place in the sun.
5. Replace the filter when it is perfectly dry.
Please clean the air filter every working season of the unit or more frequently
considering the unit activity.
Contact a firm specialised in differentiated waste disposal; it is the only way to be certain
of correct recyclin and thereby contribute to protection of the environment.
Fig. 19
1
43
N.B.: the filter may also be taken out from the side or from the top.
WHAT TO DO IF...
There is little outflowing air?
- Incorrect speed settin on the control panel (select the ri ht speed).
- Clo ed filter (clean the filter)
- Obstruction of the airflow on the intake or delivery line (remove obstruction).
The motor does not turn? Check that
- The power supply is switched on;
- The switches or thermostats are in the correct operatin position;
- There is no forei n matter jammin the rotation of the fan.
The unit does not heat/cool as before? Check that
- The filter and the coil are clean;
- No air has entered the water circuit by bleedin from the relative valve;
- The installation is correctly balanced;
- The boiler/chiller is in proper workin order.
DISMANTLING THE UNIT
This unit is made to last for many years. Qualified personnel are needed to dismantle it
in all safety. The first operation to be carried out before dismantlin the unit is to disconnect
it once and for all from the electricity supply.
This unit has been made usin recyclable materials (copper, aluminium, brass, plastic)
and assembled by screws and push-fits to make separation of the parts easy.
A
C
Q
U
A
+
D
E
T
E
R
S
I
V
O
9

INSTALLATION/USE/MAINTENANCE GUIDE
ISO 9001:2000 - Cert. n. 1368/1
10

INSTALLATION/USE/MAINTENANCE GUIDE
11

VENTILCLIMA S.p.A.
31020 SAN ZENONE DEGLI EZZELINI (TV) - Italy - Via Monte rappa, 67
Tel. [phone] r.a. - Telefax [phone]
http: www.ventilclima.com - e-mail: [email protected]
DUCTABLE AIR TREATMENT UNITS MI UTC 1105-0 VEN GB
All datas in this manual are no-bindin for Ventilclima company who takes the ri ht without advance notice
obbli ation, to provide to any modification for product improvenments.
Ventilclima takes part in EUROVENT CERTIFICATION pro ram. All products included in EUROVENT Directory
ISO9001:2000 - Cert. n. 1368/1
