VBSQR 190 Square Curb Roof Ventilator
A roof curb mounted extract fan
For residential and commercial ventilation
Ideal for bathrooms, laundries and drying rooms
•A slim-line extract fan with the lowest profile for this capacity
•Can be mounted parallel to the roof line for minimum profile
•Body dimensions 270 square x 125 overall exterior height
•Powder coated aluminium body and duct spigot
•316 Stainless steel outer cover or powder coat finish

Designed and manufactured in New Zealand by
www.ventpro.co.nz
A division of Unihatch NZ Ltd www.unihatch.co.nz Ph. 021 866 672
VBSQR 190 Square Curb Roof Ventilator
Dimensions & Mounting details
Specification:
•Ventpro VBSQR 190 Square Curb Ventilator with 150mm dia spigot
•Aluminium powder coated body with 316 Stainless steel face plate
•Backward curve centrifugal rotor with integral 240V 70W 3 speed motor
•Performance 130lts/sec fid –rated @ 50,000 hrs –IP55
•Suitable for square curb roof mounting.
Warning.
Appliance not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction concerning use of appliance by person responsible for their safety.
Children should be supervised to ensure they do not play withappliance
Ensure that fan is switched off from supply mains before removing guard
Precautions must be taken to avoid back-flow of gases into room from open flue of gas or other fuel-burning appliances. Ensure to allow
for disconnection of appliance from supply after installation
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard.
Means for disconnection must be incorporated in fixed wiring in accordance with wiring rules.
