Verathon ScanPoint Docking Station User manual

Calibration option
Calibration button
CALIBRATION QUICK REFERENCE
Sign in
®
ScanPoint®Docking Station
Top (Gender) button
Water line
0900-0621-06-60
1 Prepare Calibration Phantom
Place on flat, non-reflective surface;
fill with clean, room temperature water
to indicator mark; make sure water
contains minimal amount of bubbles
ScanPoint®Docking Station
Login name
Password
2 Place Instrument in ScanPoint
®
Docking Station
3 Log On to ScanPoint
®
First enter login name and
password, then click Sign in
button
5 Click the Calibration Button
6 Wait While ScanPoint
®
Prepares Instrument
7 When Prompted, Scan Calibration Phantom
Place Instrument in lid. Ensure that black tip of scanhead
is submerged in water. Then press the Top (Gender) button.
8 Wait While Instrument Calibrates
9 Return Instrument to ScanPoint
®
Docking Station
10 Select ”Print” Message to Print Certificate
of Calibration
CalibrationCalibration
Four arrows appear on the LCD screen when
analysis of the calibration data is complete.
ScanPoint®, Verathon®, and Verathon Medical®are either registered trademarks or trademarks of Verathon Inc. in the
United States and/or other countries. Copyright © 2006 by Verathon Inc. All rights reserved.
www.verathon.com https://my.scanpoint.com
For more information, call 800.331.2313 (in the U.S. and Canada) or contact your local Verathon Medical®representative.
4 Select “Calibration” on ScanPoint
®
Menu

4
CALIBRATION QUICK REFERENCE
5
To prepare calibration phantom , place on a flat, non-reflective surface and remove
lid. Pour clean, room temperature water into the container, filling to the indicator
mark. Make sure the water contains a minimal amount of bubbles. Then place the
spiral-shaped target in the container, using the notches to position target correctly.
Replace the lid on the calibration container.
1
2
Place the scanning unit in the ScanPoint®Docking Station connected to your computer.
Go to ScanPoint®by double-clicking the ScanPoint®icon on your Windows®desktop, or
by opening Internet Explorer and typing https://my.scanpoint.com in the browser's
address bar. Then, to log on, type your Login Name and Password on the Sign in
screen and click the Sign in button.
3
On the ScanPoint®menu, click Calibration. Verify that ScanPoint®has successfully
initialized the connection with your scanning unit by checking the status box, which
contains red and green lights and is located in the lower half of the Calibration screen.
The connection was successful if the green light is highlighted. If the red light is
highlighted, verify that you positioned the scanning unit correctly in the ScanPoint®
Docking Station.
Click the Calibration button on the Calibration Instrument screen.
6
Wait while ScanPoint®prepares the instrument, by installing the calibration program
on your device, and creates a calibration record in the database. When complete, the
message "Go make Phantom measurement and return device to ScanPoint®
Docking Station...waiting..." is highlighted.
7
Remove the scanning unit from the ScanPoint
®
Docking Station and place it in the cutout
in the top of the calibration container. Make sure the black tip of the scanhead is
submerged in the water. Then press and release the Top ("Gender") button (located
on top of the scanning unit, below the LCD screen).
8
Wait while the instrument scans the phantom and calibrates. Important: Do not
remove the instrument from the phantom until four arrows appear on the
LCD screen. The instrument beeps once when the scan is complete and then
proceeds to analyze the scan data to ensure that it meets the calibration parameters;
the instrument may automatically rescan the phantom, if necessary. When calibration
is complete, the instrument chirps and four arrows appear on the LCD screen.
9
10
Return the instrument to the ScanPoint®Docking Station and wait while it transmits
the calibration results to ScanPoint®. ScanPoint®then removes the calibration program
from your device and prepares the instrument to perform patient exams. Do not remove
the scanning unit from the ScanPoint®Docking Station until this process is complete.
When the calibration process is complete, the scanning unit beeps and ScanPoint®
displays the message, "Calibration Successful." If you wish to print a certificate of
calibration, click the message, "Click Here for Printable Certificate of Calibration."
CalibrationCalibration
0123
www.verathon.com https://my.scanpoint.com
For more information, call 800.331.2313 (in the U.S. and Canada) or contact your local Verathon Medical® representative.
