12. From the left menu, select Network.
13. Disable DHCP.
14. In the Static IPAddress box, type a static IP address using the IP scheme for the camera
LAN (Usually 192.168.1.x).
15. From the left menu, select Video/Audio and then from the top menu select Image Settings.
16. Under Advanced Light Management Technology for Exposure Priority, select Frame Rate.
17. From the bottom, click SAVE CHANGES AND REBOOT.
18. Reconnect to the DVR using VVI or Vid-Center.
19. Open the Camera Setup dialog.
In Do
VVI a. From the Device tree, next to an EdgeVR, click and select Service.
b. Select the Setup tab.
c. Under the DVR Properties area, click Camera Setup.
Vid-
Center
From the Task Center pane, select Setup DVRs, then in the Task Actions
pane, double-click Camera Setup.
20. In the Label box, type a descriptive name for the connected camera.
21. From the Type list, choose ONCAM C-12 360-view or ONCAM C-12 360 view WDR single
stream.
22. In the Address: Port box, type the camera IP address.
23. Click OK to reboot the EdgeVR.
24. Reconnect to the EdgeVR and check the status logs to verify that the camera is connected.
25. Adjust the Recorded and Live video properties and configure motion detection sensitivity
for each camera added to the system.
