Vermont Castings Group 36CFDVNV User manual
20305832 3/14 Rev. 1
Installation and Operating
Instructions
WARNING
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Un panneau vitré chaud peut
causer des brûlures.
Laissez refroidir le panneau
vitréavant d’y toucher.
Ne laisser jamais les enfants
toucher le panneau vitré.
AVERTISSEMENT
5832
36CFDV cover
36CFDV Series Gas Fireplace
220305832
High Elevations ...................................................... 6
Gas Pressures ....................................................... 6
Gas Specications, Orice Sizes ........................... 6
Fireplace & Framing Dimensions ........................... 7
Before You Start ..................................................... 7
Fireplace Framing ................................................. 7
Fireplace Location .................................................. 7
Finishing Material ................................................... 9
Optional Top Vent Application .............................. 10
Installation Precautions ........................................ 12
General Venting .................................................. 12
Termination Location ..................................... 13
Termination Clearances ................................. 14
Assembling Vent Pipes ........................................ 14
Rear Vent Installation Only .................................. 15
How to Use the Vent Graph ................................. 16
Vent Pipe Clearances .......................................... 17
Rear Vent Applications & Installation ................... 18
Top Vent Sidewall Applications & Installation ....... 19
Vertical Sidewall Applications & Installation ......... 21
Below Grade Installation ...................................... 23
Vertical Through-the-Roof
Applications & Installation .............................. 23
Check Gas Type................................................... 26
Gas Pipe Installation ............................................ 26
Electrical Wiring ................................................... 28
Remote Wall Mounted Switch .............................. 29
Remote Wall Switch ............................................. 29
Optional DC Remote Systems ............................. 29
Electronic Pilot Ignition Wiring ............................. 30
Optional Fan/Blower System BLOT ..................... 30
What To Do If You Smell Gas ............................... 31
Lighting Pilot for the First Time ............................ 31
Lighting Pilot ........................................................ 32
Lighting Burner ..................................................... 33
To Turn Off Gas .................................................... 33
What To Do If You Smell Gas ............................... 34
Lighting Electronic Ignition ................................... 34
To Turn Off Gas .................................................... 34
Electrical Wiring ................................................... 35
Junction Box Wiring ............................................. 36
Wall Switch Installation ........................................ 36
IPI System Wiring Diagram .................................. 37
What To Do If You Smell Gas ............................... 38
Operating Instructions .......................................... 39
To Turn Off Gas .................................................... 39
Glass Frame Removal ......................................... 40
Rockwool Placement ........................................... 41
Adjustable Bafe .................................................. 41
Log Placement ..................................................... 42
Lava Rock and Ember Placement ....................... 43
Burner, Pilot and Control Compartment ............... 44
Pilot Flame ........................................................... 44
Burner Flame ....................................................... 44
Vent System ......................................................... 45
Glass Door ........................................................... 45
Logs ..................................................................... 45
Rock Wool ........................................................... 45
Millivolt Standing Pilot Ignition ............................. 46
IPI System ............................................................ 47
All Control/Pilot Systems ...................................... 48
Firebox Components ............................................ 49
Logs ..................................................................... 50
Standing Pilot - Millivolt Control ........................... 51
IPI System ............................................................ 53
Venting Components ............................................ 54
36CFDV Series Gas Fireplace
20305832 3
2. This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases unless a certied
kit is used.
3. For propane/LP replace, do not place propane/LP
supply tank(s) inside any structure. Locate propane/
LP supply tank(s) outdoors. To prevent performance
problems, do not use propane/LP fuel tank of less than
100 lbs. capacity.
4. If you smell gas
• shut off gas supply.
• do not try to light any appliance.
• do not touch any electrical switch; do not use any
phone in your building .
• immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
5. Never install the replace
• in a recreational vehicle
• where curtains, furniture, clothing, or other am-
mable objects are less than 42" from the front, top,
or sides of the replace
• in high trafc areas
• in windy or drafty areas
6. This replace reaches high temperatures. Keep children
and adults away from hot surfaces to avoid burns or
clothing ignition. Fireplace will remain hot for a time after
shutdown. Allow surfaces to cool before touching.
11. Do not modify replace under any circumstances. Any
parts removed for servicing must be replaced prior to
operating replace.
12. Turn replace off and let cool before servicing, install-
ing, or repairing. Only a qualied service person should
install, service, or repair the replace. Have burner
system inspected annually by a qualified service
person.
This replace is a vented product. This replace must be
properly installed by a qualied service person. The glass
door must be properly seated and sealed. If this unit is not
properly installed by a qualied service person with glass
door properly seated and sealed, combustion leakage can
occur.
Early signs of carbon
monoxide poisoning are similar to the u with headaches,
dizziness and/or nausea. If you have these signs, the re-
place may not have been installed properly. Get fresh air
at once! Have the replace inspected and serviced by a
qualied service person. Some people are more affected
by carbon monoxide than others. These include pregnant
women, people with heart or lung disease or anemia,
those under the inuence of alcohol, and those at high
altitudes.
Propane/LP gas and natural gas are both odorless. An
odor-making agent is added to each of these gases. The
odor helps you detect a gas leak. However, the odor added
to these gases can fade. Gas may be present even though
no odor exists.
Make certain you read and understand all warnings. Keep
this manual for reference. It is your guide to safe and proper
operation of this replace.
1. The installation must conform with local codes or, in
the absence of local codes, with the National Fuel Gas
Code, ANSI Z223.1/NFPA 54, or the Natural Gas and
Propane Installation Code, CSA B149.1.
A manufactured home (USA only) or mobile home OEM
installation must conform with the Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part
3280, or, when such a standard is not applicable, the
Standard for Manufactured Home Installation, ANSI/
NCSBCS A225.A, or Standard for Gas Equipped Rec-
reational Vehicles and Mobile Housing, CSA Z240.4.
Please leave these instructions with the appliance.
Please retain these instructions for future reference
.
36CFDV Series Gas Fireplace
420305832
15. You must keep control compartments, burners, and
circulating air passages clean. More frequent clean-
ing may be needed due to excessive lint and dust.
Turn off the gas valve and pilot light before cleaning
replace.
16. Have venting system inspected annually by a quali-
ed service person. If needed, have venting system
cleaned or repaired. See Cleaning and Maintenance,
Page 48.
17. Keep the area around your replace clear of combus-
tible materials, gasoline, and other ammable vapor
and liquids. Do not run replace where these are used
or stored. Do not place items such as clothing or deco-
rations on or around replace.
18. Do not use this replace to cook food or burn paper or
other objects.
19. Never place anything on top of replace.
20. Do not use any solid fuels (wood, coal, paper, card-
board, etc.) in this replace. Use only the gas type
indicated on rating plate.
21. This appliance, when installed, must be electrically
grounded in accordance with local codes or in the
absence of local codes, with the National Electrical
Code, ANSI/NFPA 70, or the Canadian Electrical Code,
CSA C22.1.
22. Do not obstruct the ow of combustion and ventilation
air in any way. Provide adequate clearances around
air openings into the combustion chamber along with
adequate accessibility clearance for servicing and
proper operation.
23. When the appliance is installed directly on carpeting,
tile or other combustible material other than wood
ooring, you must set appliance on a metal or wood
panel or hearth pad extending the full width and depth
of the appliance.
24. Do not use replace if any part has been exposed to
or has been under water. Immediately call a qualied
service person to inspect the appliance and to replace
any part of the control system and any gas control
which has been under water.
25. Do not operate replace if any log is broken.
Direct Vent type appliances draw all combustion air from
outside of the dwelling through the vent pipe.
These appliances have been tested by CSA and found
to comply with the established standards in the USA and
Canada as follows:
TESTED TO:
ANSI Z21.88a-2012 / CSA 2.33a-2012 STANDARDS
It is normal for replaces fabricated of steel
to give off some expansion and/or contraction
noises during the start up or cool down cycle.
Similar noises are found with your furnace heat
exchanger or car engine.
It is not unusual for gas replace to give off some
odor the rst time it is burned. This is due to the
manufacturing process.
It is recommended that you burn your replace
for at least ten (10) hours the rst time you use it.
Place the fan switch in the “OFF” position during
this time.
26. Do not use a blower insert, heat exchanger insert, or
any other accessory not approved for use with this
replace.
27. Do not operate the replace with glass door removed,
cracked, or broken.
36CFDV Series Gas Fireplace
20305832 5
• This appliance has been certied for use with either
natural or propane gas. See appropriate data plates.
• This appliance is not for use with solid fuels.
• The appliance is approved for bedroom or bedsitting
room installations.
• The appliance must be installed in accordance with local
codes if any. If none exist use the current installation
code. ANSI Z223.1/NFPA 54 in the USA, CSA B149 in
Canada.
• This appliance is mobile home approved.
• The appliance must be properly connected to a venting
system.
• The appliance is not approved for closet installations.
• This appliance is approved to be vented using Vermont
Castings Group Twist-Lock Direct Vent Components.
FP3011
36CFDV controls
Off/Pilot/On Knob
Figure 1 -
36CFDV Fireplace Controls
Hi/Lo Knob
FP3011
The classication “noncombustible material” includes, but
is not limited to stone, brick and mortar. Noncombustibles
are safe to overlay the black-painted metal face (includ-
ing radiant plates) and do not pose a re hazard. Do not
allow any noncombustible nish material to extend past or
interfere with replace opening.
The classication “combustible material” includes, but is not
limited to plywood, drywall and particle board. Combustible
materials may contact the sides, bottom or back of rebox.
Do not overlay the black painted face with combustible
materials.
Input ratings are shown in BTU per hour and are certied
without deration for elevations up to 4,500 feet (1,370
m) above sea level.
For elevations above 4,500 feet (1,370 m) in USA,
installations must be in accordance with the current
ANSI Z223.1/NFPA 54 and/or local codes having juris-
diction.
In Canada, please consult provincial and/or local authori-
ties having jurisdiction for installations at elevations
above 4,500 feet (1,370 m).
36CFDVNV Nat. 21,000 15,000 #44
36CFDVPV LP 21,000 17,500 #54
36CFDVNI Nat. 21,000 15,000 #44
36CFDVPI LP 21,000 17,500 #54
Natural Propane (LP)
Inlet Minimum 5.5” w.c. 11.0” w.c.
Inlet Maximum 14.0” w.c. 14.0” w.c.
Manifold Pressure 3.5” w.c. 10.0” w.c.
Refer to cold climate pilot information on Page 43
for more information on standing pilot vs. intermittent pilot
options.
36CFDV Series Gas Fireplace
620305832
2256” (562 mm)
1556QE”
(405 mm)
256”
(651 mm)
3756M” (946 mm)
3456QE”
(884 mm)
3856O”
(978 mm)
19(6”
(505 mm)
15/16”
(24 mm)
3756M” (946 mm)
Minimum Rough Opening Width
Minimum Rough
Opening
Depth
Minimum Rough
Opening
Height
C
L
15(6QE”
(392 mm)
1/2” (13 mm)
or 5/8” (16 mm)
5832
36CFDV dims
2956QE” (738 mm)
2156QE”
(535 mm)
3856O”
(978 mm)
2756M"
(692 mm)
54(6QE” (1383 mm)
3856O” (798 mm)
3856O” (798 mm)
46QE” (110 mm)
256M” (57 mm)
76”
(187 mm)
32” (813 mm)
Figure 2 -
36CFDV Series Fireplace Dimensions
36CFDV Series Gas Fireplace
20305832 7
Read this homeowner manual thoroughly and follow all
instructions carefully. Inspect all contents for shipping
damage and immediately inform your dealer if any damage
is found. Do not install any unit with damaged, incomplete,
or substitute parts. Check your packing list to verify that
all listed parts have been received. You should have the
following:
• Fireplace (Firebox and Burner System)
• Log Set • Volcanic Rock
• Rock Wool
• Phillips Screwdriver • Framing Materials
• Hammer • Wall Finishing Materials
• Saw and/or saber saw • Level
• Electric Drill and Bits • Tee Joint
• Pliers • Measuring Tape
• Square • Pipe Wrench
• Caulking Material (Noncombustible)
• Fireplace Surround Material (Noncombustible)
• Piping Complying with Local Codes
• Pipe Sealant Approved for use with Propane/LPG
(Resistant to Sulfur Compounds)
Plan for the installation of your appliance. This includes
determining where the unit is to be installed, the vent con-
guration to be used, framing and nishing details, and
whether any optional accessories (i.e. blower, wall switch,
or remote control) are desired. Consult your local building
code agency to ensure compliance with local codes, includ-
ing permits and inspections.
The following factors should be taken into consideration:
• Clearance to side-wall, ceiling, woodwork, and windows.
Minimum clearances to combustibles
• This replace may be installed along a wall, across a
corner, or use an exterior chase. Refer to Figure 3 for
suggested locations.
• Location should be out of high trafc areas and away
from furniture and draperies due to heat from appli-
ance.
• Never obstruct the front opening of the replace.
• Do install in the vicinity where gasoline or other
ammable liquids may be stored.
• Vent pipe routing. See Venting section found in this
manual for allowable venting congurations.
• These units can be installed in a bedroom. See National
Fuel Gas Code ANSI Z233.1/NFPA 54 — (current
edition), the Uniform Mechanical Code — (current edi-
tion), and Local Building Codes for specic installation
requirements.
Figure 3 -
Locating Gas Fireplace
Y
EAB
C
D
F
YB
X
LU584-1
Locating unit
2/4/99 djt
** Island (C) and room divider (D) installation is possible as long
as the horizontal portion of vent system (X) does not exceed
20' (6 m).
* When you install your replace in (D) room divider or (E)
at on wall corner positions (Y), a minimum of 4" (102 mm)
clearance must be maintained from perpendicular wall and
front of replace.
A Flat on
Wall
B Cross
Corner
C Island**
D Room
Divider*
E Flat on
Wall
Corner*
F Chase
Installation
Y 4"
Minimum
Firebox framing can be built before or after the appliance
is set in place. Construct rebox framing following Figure
2 for specic installation requirements and for rebox
dimensions. The framing headers may rest on the top of
the rebox standoffs. Do not bring headers below top of
standoffs.
The rebox may be installed directly on a combustible oor
or raised on a platform of an appropriate height. When
the rebox is installed directly on carpeting, tile, or other
combustible material, other than wood ooring, the rebox
shall be installed on a metal or wood panel extending the
full width and depth of the enclosure.
36CFDV Series Gas Fireplace
820305832
72"
(1828 mm)
Minimum
6”
(152 mm)
Minimum
fP3012
wall clearances
Ceiling
Side Wall
Figure 4 -
Ceiling and Side Wall Clearances
FP3012
FP3000
mantel clearances
12” (305 mm)
8” (203 mm)
6” (152 mm)
256O”
(64 mm)
12”
(305 mm)
11”
(279 mm) 10”
(254 mm)
8” (203 mm)
Finish Wall
Header
Stud
Standoffs
Top of Heat
Exhaust Vent
FP3000
The combustible area above the facing must not
protrude more than 3/4" (19 mm) from the facing. If it
does, it is considered a mantel and must meet the mantel
requirements listed in this manual.
6"
5"
3" 45°
1"
256O”
156O”
356O”
456O”
FP3013
Mantel leg clear
Figure 5 -
Mantel Clearances
Side of Fireplace
Opening
Stud
Wall
FP3013
Combustible
Material Area
36CFDV Series Gas Fireplace
20305832 9
The fireplace must be secured to
the oor and/or to framing studs as
shown in Figure 6. Use two (2) wood
screws or masonry/ concrete screws
to secure replace to the oor. Use
four (4) screws to attach replace to
framing. The side nailing anges are
1/2" or 5/8" to accommodate different
wall thickness.
FP3014
secure fireplace
Figure 6 -
Securing Fireplace to Floor and
Framing Studs
Screw
Framing
Framing
Nailing
Flange
Screws
Screw
Nailing
Flange
Nailing
Flanges
Finished Wall Support
Tabs (Do Not Use for
Framing or Header)
Screw
Screw
FP3014
Any wiring (i.e. remote control, wall switch, and
optional fan) must be done prior to nal nishing to avoid
costly reconstruction.
Only noncombustible materials (i.e. brick, tile, slate, steel,
or other materials with a UL re rating of Zero) may be
used to cover the black surface of the appliance. A 300°F
minimum adhesive may be used to attach facing materials
to the black surface. If joints between the nished wall
and the replace surround are sealed, a 300°F minimum
sealant material (General Electric RTV103 or equivalent)
must be used.
36CFDV Series Gas Fireplace
10 20305832
The appliance is shipped as a rear vent unit. If the installa-
tion layout requires the unit to be a top vent conguration
the appliance can be converted by following the steps
below.
When removing and retting the plates be sure the associ-
ated gaskets are undamaged and retted as required.
1. Remove the rear plate by removing one (1) screw. Set
aside. Figure 7
2. Remove the plate with the 7" collar and gasket by re-
moving eight (8) screws. Set aside. Figure 8
FP3022
remove 7 collar
Remove
Screws
Remove
Screws
7" Collar
FP3022
Figure 8 -
Remove 7" Collar and Gasket
3. Remove the plate with the 4" collar and gasket by re-
moving four (4) screws. Set aside. Figure 9
4. Remove the top plate located on top of the unit by re-
moving one (1) screw. Set aside. Figure 9
FP3023
remove 4 collar
Remove
Screws
Remove
Screws
4" Collar
FP3023
Figure 9 -
Remove 4" Collar and Gasket
and Top Plate
Remove
Screw
Top Plate
5. Remove one (1) screw to remove the inner top plate
located on top directly beneath the plate just removed.
Break away the 7" circle using a screwdriver and rein-
stall. Figure 10
FP3024
remove circle
Remove Circle
FP3024
Figure 10 -
Remove Circle Section
from Inner Top Plate
FP3025
Inner top plate
Inner Top Plate
FP3025
FP3021
remove rear plate
Screw
Rear Plate
FP3021
Figure 7 -
Remove Rear Plate
Arch
Shield
36CFDV Series Gas Fireplace
20305832 11
6. Remove the large square plate and gasket by removing
the eight (8) screws. Set aside. Figure 11
FP3026
remove large plate
Remove
Screws
Large Square
Plate
FP3026
Figure 11 -
Remove Large Square
Plate and Gasket
7. Remove the small square plate and gasket by removing
four (4) screws. Set aside. Figure 12
FP3027
remove small square plate
Remove Screws
Small
Square
Plate
FP3027
Figure 12 -
Remove Small Square
Plate and Gasket
8. Install the plate and plates with collars removed in Steps
1-3 in reverse order onto the top of the unit. Install the
top plate and large and small plates in reverse order into
back of unit. Figure 13. The arch shield is not
needed for top vent applications and may be discarded.
Figure 7
FP3028
completed top vent conversion
Figure 13 -
Completed Top Vent Conversion
FP3028
36CFDV Series Gas Fireplace
12 20305832
Consult local building codes before beginning the
installation. The installer must make sure to select the
proper vent system for installation. Before installing vent
kit, the installer must read this replace manual and vent
kit instructions.
Only a qualied installer/service person should install vent-
ing system. The installer must follow these safety rules:
• Wear gloves and safety glasses for protection.
• Use extreme caution when using ladders or when on
rooftops.
• Be aware of electrical wiring locations in walls and
ceilings.
The following actions will void the warranty on your vent-
ing system:
• Installation of any damaged venting component.
• Unauthorized modication of the venting system.
• Installation of any component part not manufactured
or approved by Vermont Castings Group.
• Installation other than permitted by these instruc-
tions.
Your replace is approved to be vented either through the
side wall, or vertical through the roof.
•
• Flexible UL1777 listed venting may be used in any vent-
ing application where rigid direct vent components can
be used. All restrictions, clearances and allowances that
pertain to the rigid piping apply to the exible venting.
Flex kits may not be modied. Flex kits may be added to
the end of a vent run made of rigid vent sections using
pipe manufacturer's approved ex to pipe adapters. This
may occur only if doing so does not violate any of the
venting length, height, routing, horizontal to vertical ratio
requirements or clearance considerations detailed in this
manual.
• Venting terminals shall not be recessed into a wall or sid-
ing.
• Select the amount of vertical rise desired. All horizontal
run of venting must have 1/4" rise for every 12" (305 mm)
of run towards the termination below 71/2 feet of vertical
rise. With 71/2 feet (2.3 m) or more vertical rise off top of
replace, the horizontal run may run level. NEVER run
vent piping downward.
• Horizontal venting which incorporates the twist lock pipe
must be installed on a level plane without an inclining or
declining slope.
• Horizontal venting which incorporates the use of ex
venting shall have an inclining slope from the unit of 1”
(25 mm) per 24” (610 mm).
There must not be any obstruction such as bushes, gar-
den sheds, fences, decks or utility buildings within 24”
(610 mm) from the front of the termination hood.
Do not locate termination hood where excessive snow or
ice build up may occur. Be sure to check vent termina-
tion area after snow falls, and clear to prevent accidental
blockage of venting system. When using snow blowers,
make sure snow is not directed towards vent termination
area.
It is imperative the vent termination be located observing
the minimum clearances as shown on following page.
36CFDV Series Gas Fireplace
20305832 13
V
X
X
X
D
E
B
B
B
C
B
M
B
A
J
K
F
L
VENT TERMINATION AIR SUPPLY INLET AREA WHERE TERMINAL IS NOT PERMITTED
H
I
Fixed
Closed
Operable
Operable Fixed
Closed
B
CFM145a
DV Termin Location
5/01/01 Rev. 12/05/01
sta
INSIDE
CORNER DETAIL
A
G
CFM145a
V
V
V
VV
V
V
V
A = Clearance above grade, veranda, porch, 12” (30 cm) 12” (30 cm)
deck, or balcony
B = Clearance to window or door that may be 6” (15 cm) for appliances 6” (15 cm) for appliances
opened < 10,000BTU/h (3kW), 12” (30 cm) < 10,000 BTU/h (3kW), 9”
for appliances > 10,000 Btuh (3kW) and (23 cm) for appliances > 10,000
< 100,000 BTU/h (30kW), 36” (91 cm) Btuh (3kW) and < 50,000 BTU/h
for appliances > 100,000 BTU/h (30kW) (15kW), 12” (30 cm) for
appliances > 50,000 BTU/h(15kW)
C = Clearance to permanently closed window 12” (305 mm) recommended to 12” (305 mm) recommended to
prevent window condensation prevent window condensation
D = Vertical clearance to ventilated soft located
above the terminal within a horizontal 18” (458 mm) 18” (458 mm)
distance of 2’ (610mm) from the center
line of the terminal
E = Clearance to unventilated soft 12” (305 mm) 12” (305 mm)
F = Clearance to outside corner see next page see next page
G = Clearance to inside corner (see next page) see next page see next page
H = Clearance to each inside of center line 3’ (91 cm) within a height of 15’ (5 m) 3’ (91 cm) within a height of 15’
extended above meter/regulator assembly above the meter/regulator assembly (5 m) above the meter/regulator
assy
I = Clearance to service regulator vent outlet 3’ (91 cm) 3’ (91 cm)
J = Clearance to nonmechanical air supply inlet 6” (15 cm) for appliances < 10,000 6” (15 cm) for appliances
to building or the combustion air inlet to any BTU/h (3kW), 12” (30 cm) for < 10,000 BTU/h (3kW), 9”
other appliances appliances > 10,000 BTU/h (3kW) and (23 cm) for appliances > 10,000
< 100,000 Btuh (30kW), 36” (91 cm) BTU/h (3kW) and < 50,000 BTU/h
for appliances > 100,000 BTU/h (30kW) (15kW), 12” (30 cm) for
appliances > 50,000 BTU/h(15kW)
K = Clearance to a mechanical air supply inlet 6’ (1.83 m) 3’ (91 cm) above if within 10'
(3 m) horizontally
L = Clearance above paved sidewalk or paved 7’ (2.13 m)† 7’ (2.13 m)†
driveway located on public property
M = Clearance under veranda, porch, deck or 12” (30 cm) 12” (30cm)
balcony
1 In accordance with the current CSA-B149 Installation Codes
2 In accordance with the current ANSI Z223.1/NFPA 54 National Fuel
Gas Codes
† A vent shall not terminate directly above a sidewalk or paved driveway
which is located between two single family dwellings and serves both
dwellings
only permitted if veranda, porch, deck or balcony is fully open on a
minimum 2 sides beneath the oor:
1. Local codes or regulations may require different
clearances.
2. The special venting system used on Direct Vent Fireplaces
are certied as part of the appliance, with clearances
tested and approved by the listing agency.
3. Vermont Castings Group assumes no responsibility for
the improper performance of the appliance when the venting
system does not meet these requirements.
Figure 14 -
Termination Locations
36CFDV Series Gas Fireplace
14 20305832
Outside Corner
Inside Corner
Termination Clearances
Termination clearances for buildings with combustible and noncombustible exteriors.
G =
Combustible
6" (152 mm)
Noncombustible
2" (51 mm)
F =
Combustible
6" (152 mm)
Noncombustible
2" (51 mm)
G
Balcony -
with no side wall
M =
Combustible &
Noncombustible
12" (305 mm)
M
Balcony -
with perpendicular side wall
M = 12" (305 mm)
P = 6” (152 mm)
M
F
Alcove Applications*
C
D
C
E
V
V
Combustible &
Noncombustible
E= Min. 2” (51 mm) for
non-vinyl sidewalls
Min. 12” (305 mm) for
vinyl sidewalls
O= 8’ (2.4 m) Min.
O
P
V
V
V
584-15
No.
of Caps DMin. CMax.
1 3’ (914 mm) 2 x DActual
2 6’ (1.8 m) 1 x DActual
3 9’ (2.7 m) 2/3 x DActual
4 12’ (3.7 m) 1/2 x DActual
DMin. = # of Termination caps x 3
CMax. = (2 / # termination caps) x DActual
Termination in an alcove space (spaces open only on one side
and with an overhang) is permitted with the dimensions specied for
vinyl or non-vinyl siding and softs. 1. There must be a 3’ (914 mm) mini-
The venting system must conform to local codes and/or
the current National Fuel Code ANSI Z223.1/NFPA 54.
Only venting components manufactured or approved by
Vermont Castings Group may be used in Direct Vent sys-
tems.
The venting system must be installed in accordance with
the current CSA-B149.1 installation code.
Secure ex vent pipe in place with a hose clamp (pro-
vided).
*Be sure the ex pipe overlaps at least 1” (25 mm) onto
the collars of the replace and termination. If the termina-
tion has an internal bead, be sure to overlap and secure
1” (25 mm) past the bead.
* Be sure the vent is actually crushed before proceeding.
Apply a tug to be sure the vent will not slip off the collars.
Repeat process with 7” ex vent pipe. The same proce-
dure must be performed on the vent side.
FP2290
flex vent
Hose Clamp
FP2290
Figure 16 -
Suecure Flex Vent Pipe with Hose Clamps.
Figure 15 -
Termination Clearances
mum between termination caps. 2. All mechanical air intakes within 10’
(1 m) of a termination cap must be a minimum of 3’ (914 mm) below the
termination cap. 3. All gravity air intakes within 3’ (914 mm) of a termina-
tion cap must be a minimum of 1’ (305 mm) below the termination cap.
36CFDV Series Gas Fireplace
20305832 15
FP3001a
rear vent
When using twist lock pipe it is not necessary to use seal-
ant on the joints.
To join twist lock pipes together, simply align the beads of
the male end with the grooves of the female end, twisting
the pipe until the ange on the female end contacts exter-
nal ange on the male end. It is recommended that you
secure the joints with three (3) sheet metal screws, how-
ever, this is not mandatory with twist lock pipe. Figure 17
To make it easier to assembly the joints, we suggest put-
ting a lubricant (Vaseline or similar) on the male end of the
twist lock pipe prior to assembly.
TWL100
Twist Lock Pipe
3/12/99 djt
Male End Female End
Screw Holes
TWL100
Figure 17 -
Twist-lock Pipe Joints
Remove the three (3) screws holding the arch shield to
the rear of the rebox. Set shield aside. Install the 4” (102
mm) inner vent pipe to the appliance inner collar and se-
cure with three (3) stainless steel sheet metal screws.
Figure 18. Install the 7” (178 mm) outer vent pipe to the
appliance outer collar. Secure pipe to the rear cover plate
using the tabs and three (3) sheet metal screws. Figure
19. Reinstall arch shield. If a 45° or 90° elbow is being
used, attach the elbow to the appliance in the same man-
ner then attach the venting to the elbow.
Sheet Metal
Screws
4" Inner
Pipe
FP3031
Figure 19 -
Install 7" Outer Vent Pipe
Arch Shield
FP3001a
Figure 18 -
Remove Arch Shield and Install 4" Inner Vent Pipe
FP3031
isntall rear pipe
Sheet Metal Screw
Tabs
7" Outer
Pipe
36CFDV Series Gas Fireplace
16 20305832
The Vent Graph should be read in conjunction with the
following vent installation instructions to determine the re-
lationship between the vertical and horizontal dimensions
of the vent system.
1. Determine the height of the center of the horizontal
vent pipe exiting through the outer wall. Using this di-
mension on the Sidewall Vent Graph, Figure 20, locate
the point intersecting with the slanted graph line.
2. From the point of this intersection, draw a vertical line
to the bottom of the graph.
3. Select the indicated dimension, and position the re-
place in accordance with same.
If the vertical dimension from the oor of the unit is 11’ (3.4
m) the horizontal run to the face of the outer wall must not
exceed 14’ (4.3 m).
If the vertical dimension from the oor of the unit is 7’ (2.1
m), the horizontal run to the face of the outer wall must not
exceed 8’ (2.4 m).
Page 24
40
38
36
34
32
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2
2 4 6 8 10 1214 16 1820
eg: A
FP2291
vent graph
X
Vertical Dimension from the Floor of Unit to the Center of
the Horizontal Vent Pipe
Horizontal Dimension From the Outside of Termination to
the Back of the Fireplace
Figure 20 -
Side Wall Venting Graph
X = 22" minimum for 33" Model
X = 25Z\v" minimum for 36" Models
(Floor to center of horizontal pipe)
36CFDV Series Gas Fireplace
20305832 17
3" 1"
1"
1"
FP3018
rear vent clear
Figure 21 -
Combustible Clearances for Vent Pipe
A Minimum of 3" (76 mm)
Clearance to the Top Is
Required Along Horizontal
Length until Flue Pipe
Penetrates Outside Wall.
A Minimum 1" (25
mm) Clearance
to Combustibles
Permitted All
Around Flue at
Outside Wall
until the ue penetrates
the outside wall.
until the ue penetrates the outside wall.
1"
3" 1"
1"
FP3017
rear vent clear
A Minimum of 3" (76 mm)
Clearance to the Top Is
Required Along Horizontal
Length until Flue Pipe
Penetrates Outside Wall.
A Minimum 1" (25 mm)
Clearance to Combustibles
Permitted All Around Flue at
Outside Wall
FP3018
FP3017
36CFDV Series Gas Fireplace
18 20305832
When installed as a rear vent unit this appliance may be
vented directly to a termination located on the rear wall
behind the appliance.
• Only Vermont Castings Group approved venting com-
ponents are approved to be used in these applications
(Refer to ‘Venting Components’ listed for different in-
stallation requirements).
• The maximum horizontal distance between the rear of
the appliance (or end of the transition elbow in a cor-
ner application) and the outside face of the rear wall is
20” (508 mm). Figure 22
• Only one 45° elbow is allowed in these installations.
• Minimum clearances between vent pipe and combus-
tible materials are as follows:
Top - 3” (76 mm)
- except at outside wall 1" (25 mm)
Sides - 1” (25 mm)
Bottom - 1” (25 mm)
FP3002
rear wall limit
20”
(508 mm)
Max.
20”
(508 mm)
Max.
Figure 22 -
Rear Vent Application, No Elbows
Locate and cut the vent opening in the wall.
For combustible walls rst frame in opening. Figure 26
When using ex vent, the opening will have to be
measured according to the 1” (25 mm) rise in 24” (610
mm) vertical run.
Cut a 9B\,”H x 9B\,” W (244 x 244
mm) hole through the exterior wall and frame as shown.
Figure 23
Hole opening should be 7Z\x”
(191 mm) diameter.
Secure restop to the inside frame, center in the 9B\," x
9B\," vent opening.
Measure the horizontal length requirement for the venting
including a 2” (51 mm) overlap, i.e. from the elbow to the
outside wall face plus 2” (51 mm). Figure 22
Install the 4” (102 mm) vent to the appliance collar and
secure with 3 sheet metal screws. Install the 7” (178 mm)
vent pipe to the appliance collar and secure with 3 sheet
metal screws. It is not necessary to seal this connection.
If a 45° elbow is being used attach the elbow to the appli-
ance in the same manner then attach the venting to the
elbow.
Guide the venting through the vent hole as you place the
appliance in its installed position. Guide the 4” (102 mm)
and 7” (178 mm) collar of the vent termination into the
outer ends of the venting. Do not force the termination. If
the vent pipes do not align with the termination, remove
and realign the venting at the appliance ue collars. Fig-
ure 24. Attach the termination to the wall as outlined in the
instruction sheet supplied with the termination.
VO584-100
Vent Opening
2/99 djt
9B\,”
(244 mm)
Min.
Fireplace Hearth Framing Detail
7Z\x”
(190 mm)
Fireplace Hearth
FP2293
Figure 23 -
Locate vent opening on wall
9B\,”
(244 mm) Min.
FP3002
36CFDV Series Gas Fireplace
20305832 19
FP2294
Side View Vent Termination
1/25/00 djt
Finish Wall
Vent
Termination
FP2294
Figure 24 -
Side View of Final Unit Location
Follow Steps 1 and 2 on Page 18.
Install the 4” (102 mm) ex vent pipe to the appliance col-
lars described in “General Information Assembling Vent
Pipes”, Page 14. If the installation requires a 45° angle,
grasp the vent pipe close to the appliance collar and bend
to 45°. DO NOT exceed 45°. Figure 25
Install the 7” vent pipe in the same manner as Step 2.
There must be a 1/2” (13 mm) rise in a 12” (305
mm) length of ex vent.
Assemble the ex vent to the collars on the termination as
you did on the appliance.
FP1473
corner flex install
4/04 djt
Termination
Flex Section
Appliance Collars
FP1473
Figure 25 -
Grasp the vent pipe close to the collar and
bend to 45° angle. do not exceed 45°.
FP1472
rise in length
4/04 djt
Rise
FP1472
Figure 26 -
There must be a 1/2" rise per foot length
The Vent Graph, showing the relationship between verti-
cal and horizontal side wall venting, will help to determine
the various dimensions allowable.
When vent termination exits through foundations less
than 20” (508 mm) below siding outcrop, the vent pipe
must ush up with the siding.
It is best to locate the replace in such a way that mini-
mizes the number of offsets and horizontal vent length.
The horizontal vent run refers to the total length of vent
pipe from the ue collar of the replace (or the top of the
Transition Elbow) to the face of the outer wall.
Horizontal plane means no vertical rise exists on this por-
tion of the vent assembly.
• The maximum number of 90° elbows per side wall in-
stallation is three (3). Figure 27
• If a 90° elbow is tted directly on top of the replace
ange the maximum horizontal vent run before the ter-
mination or a vertical rise is 36” (914 mm). Figure 28
• If a 90° elbow is used in the horizontal vent run (level
height maintained) the horizontal vent length is re-
duced by 36” (914 mm). Figures 29 & 30. This does
not apply if the 90° elbows are used to increase or
redirect a vertical rise. Figure 27
36CFDV Series Gas Fireplace
20 20305832
According to the vent graph (Page 16) the
maximum horizontal vent length in a system with a 7Z\x’
(2.3 m) rise is 20’ (6 m) and if a 90° elbow is required in
the horizontal vent it must be reduced to 17’ (5.2 m).
In Figures 23 & 24, dimension A plus B must not be great-
er than 17’ (5.2 m)
• The maximum number of 45° elbows permitted per in-
stallation is six (6). These elbows can be installed in
either the vertical or horizontal run.
• For each 45° elbow installed in the horizontal run, the
length of the horizontal run MUST be reduced by 18”
(457 mm). This does not apply if the 45° elbows are
installed on the vertical part of the vent system.
• The maximum number of elbow degrees in a system is
270°. Figure 31
Example: Elbow 1 = 90°
Elbow 2 = 45°
Elbow 3 = 45°
Elbow 4 = 90°
Total angular variation = 270°
3 x 90°
Elbows
3 x 90°
Elbows
FP1176
Figure 27 -
Maximum three (3) 90° elbows per installation
Max 20"
Max 20"
36"
(914mm)
Max.
36"
(914mm)
Max.
FP1177
Figure 28 -
Maximum horizontal run with no rise
7'6"
(2.3m)
AB
A + B = 17' (Max.)
(5.2m)
FP1178 Figure 29 -
Horizontal Run Reduction
V584-201
Horizontal Run
2/99 djt
10’
(3 m)
7’
(2.1 m)
7’6"
(2.3 m)
V584-201
Figure 30 -
Maximum Vent Run with Elbows
1
2
3
4
1
2
3
4
FP1180
Figure 31 -
Maximum Elbow Usage
